6498-2. Steps to take in an emergency
8
When trouble arises
installed on the compact spare
tire.
6Stow the flat tire, tire jack and
all tools.
■The compact spare tire
●The compact spare tire is identi-
fied by the label “TEMPORARY
USE ONLY” on the tire sidewall.
Use the compact spare tire tempo-
rarily, and only in an emergency.
●Make sure to check the tire infla-
tion pressure of the compact
spare tire. ( P.671)
■When using the compact spare
tire
As the compact sp are tire is not
equipped with a tire pressure warn-
ing valve and transmitter, low infla-
tion pressur e of the spar e tire will
not be indicated by the tire pressure
warning system. Also, if you replace
the compact spare tire after the tire
pressure warning light comes on,
the light remains on.
■When the compact spare tire is
attached
The vehicle height may become
lower when driving with the compact
spare tire compared to when driving
with standard tires.
■If you have a flat front tire on a
road covered with snow or ice
Install the compact spare tire on one
of the rear wheels of the vehicle.
Perform the following steps and fit
tire chains to the front tires:
1 Replace a rear tire with the com-
pact spare tire.
2 Replace the flat front tire with the
tire removed from the rear of the
vehicle.
3 Fit tire chains to the front tires.
■When stowing the jack
Before storing the jack, adjust the
height of the jack to match the
shape of the jack holder. The storage direction of the jack dif-
fers depending on the type, so make
sure to store the ja
ck in the correct
direction.
Except for models made in Japan
*:
For models made in Japan
*:
*: The country of production is writ- ten on the Certification Regulation
label. ( P.665)
WA R N I N G
■When using the compact
spare tire
●Remember that the compact
spare tire provided is specifi-
cally designed for use with your
vehicle. Do not use your com-
pact spare tire on another vehi-
cle.
●Do not use more than one com-
pact spare tire simultaneously.
●Replace the comp act spare tire
with a standard tire as soon as
possible.
●Avoid sudden acceleration,
abrupt steering, sudden brak-
ing and shifting operations that
cause sudden engine braking.

6528-2. Steps to take in an emergency
The battery terminal connec-
tions may be loose or cor-
roded.
The engine starting system may
be malfunctioning due to an
electrical problem such as elec-
tronic key battery depletion or a
blown fuse. However, an interim
measure is available to start the
engine. ( P.652)
One of the following may be the
cause of the problem:
 The battery may be dis-
charged. ( P.655)
 One or both of the battery ter-
minals may be disconnected.
 There may be a malfunction
in the steering lock system
(vehicles with smart key sys-
tem).
Contact your Toyota dealer if the
problem cannot be repaired, or if
repair procedures are unknown. When the engine does not start,
the following steps can be used
as an interim measure to start
the engine if the engine switch is
functioning normally:
1
Pull the parking brake switch
to check that the parking
brake is set. ( P.203)
Parking brake indicator will come
on.
2 Shift the shift lever to P.
3 Turn the engine switch to
ACC.
4 Press and hold the engine
switch for about 15 seconds
while depressing the brake
pedal firmly.
Even if the engine can be
started using the above steps,
the system may be malfunction-
ing. Have the vehicle inspected
by your Toyota dealer.
The starter motor does
not turn over (vehicles
with smart key system)
The starter motor does
not turn over, the interior
lights and headlights do
not turn on, or the horn
does not sound
Emergency start function
(vehicles with smart key
system)

716What to do if... (Troubleshooting)
may also sound. (P.628, 639)
 Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the
alarm sounds. ( P.73)
To stop the alarm, turn the engine
switch to ON or start the engine.
 Is the message displayed on
the multi-information display?
Check the message on the
multi-information display.
( P.639)
 When a warning light turns on
or a warning message is dis-
played, refer to P.628, 639.
 Stop the vehicle in a safe
place and replace the flat tire
with the spare tire. ( P.642)
Try the procedure for when
the vehicle becomes stuck in
mud, dirt, or snow. ( P.661)
An alarm is activated and
the horn sounds (if
equipped)
A warning buzzer sounds
when leaving the vehicle
A warning light turns on
or a warning message is
displayed
When a problem has
occurred
If you have a flat tire
The vehicle becomes
stuck

Alphabetical Index719
control ............................ 84, 88
BSM (Blind Spot Monitor) ...... 260 Blind Spot Monitor function .. 264
Rear Cross Traffic Alert function........................................... 267
C
Care Aluminum wheels ................. 558
Exterior ................................. 558
Interior .................................. 561
Seat belts ............................. 561
Cargo capacity ............... 175, 178
Cargo hooks ........................... 532
Chains ..................................... 369
Child-protectors .. ................... 112
Child restraint s ystem ............. 50
Fixed with a LATCH system ... 59
Fixed with a seat belt ............. 54
Front passenger occupant clas- sification system ................... 43
Points to remember ................ 50
Riding with children ................ 49
Types of child restraint system installation met hod ............... 52
Using an anchor bracket ........ 61
Child safety ............................... 49 Airbag precautions ................. 38
Back door precautions ......... 114
Battery precautions ...... 580, 658
Child restraint system............. 52
Heated steering wheel and seat
heater precautions ............. 522
How your child should wear the seat belt................................ 30
Moon roof precau tions ......... 160
Panoramic moon roof precau- tions.................................... 164
Power window lock switch.... 158
Power window precautions .. 157
Rear door child-protectors.... 112
Removed key battery precau- tions ....................................606
Seat belt extender precautions .............................................30
Seat belt precautions..............29
Seat heater precautions .......522
Cleaning ..........................558, 561 Aluminum wheels .................558
Exterior .................................558
Interior ..................................561
Radar sensor ........................224
Seat belts .............................561
Clock ....................................84, 88
Coat hooks ..............................548
Condenser ............. ..................577
Connected Service s ...............495
Console box ............................529
Consumption screen ................99
Coolant Checking ..............................576
Preparing and checking before winter ..................................367
Warning light.........................629
Cooling system .......................576 Engine overheating ..............659
Cruise control (Dynamic radar cruise control with full-speed
range).....................................250
Cup holders.............................529
Current fuel consumption........99
Current fuel economy ..............91
Curtain shield airbags ..............33
Customizable featu res ...........688
D
Daytime running light system209
Replacing light bulbs ............609
DCM .................496, 498, 499, 502
Deck board ..............................532
Defogger Outside rear view mirrors ........................ 511, 517
Rear window................. 511, 517

Alphabetical Index721
If a warning light turns on ..... 628
If a warning message is dis-played................................. 639
If the electronic key does not operate properly ................. 653
If the engin e will not start ..... 651
If the vehicle battery is dis- charged .............................. 655
If the vehicle is trapped in rising water .................................. 619
If you have a flat tire ............. 642
If you lose your keys ............ 653
If you think something is wrong ........................................... 626
If your vehicle becomes stuck ........................................... 661
If your vehicle has to be stopped in an emergency................. 618
If your vehicle needs to be towed ........................................... 621
If your vehicle overheats ...... 659
Emergency flashers ............... 618
Engine ACC.............................. 193, 197
Compartment ....................... 574
Engine switch ............... 193, 194
Fuel pump shut off system ... 627
Hood..................................... 571
How to start the engine 193, 194
Identification number ............ 665
If the engin e will not start ..... 651
If your vehicle has to be stopped in an emergency................. 618
Ignition switch (Engine switch) ................................... 193, 194
Overheating.......................... 659
Tachometer ...................... 82, 85
Engine coolant Capacity ............................... 668
Checking .............................. 576
Preparing and c hecking before
winter.................................. 367 Warning light.........................629
Engine coolant temperature gauge .................................82, 85
Engine immobilizer system .....70
Engine oil Capacity ...............................666
Checking ..............................574
Preparing and checking before winter ..................................367
Warning light.........................629
Engine switch .................193, 194 Auto power off fun ction .........198
Changing the engine switch modes.................................197
Changing the engine switch positions .............................193
If your vehicle has to be stopped in an emergency .................618
Enhanced Vehicle Stability Con- trol (Enhanced VSC ) .............360
Enhanced VSC (Enhanced Vehi- cle Stability Control).............360
Entering letters and numbers/list screen operation...................385Entering letters and numbers385
List screen ............................386
EPS (Electric Po wer Steering)
Function................................360
Warning light.........................630
Establishing an Android Auto connection .......... ..................408
Establishing an Apple CarPlay connection .......... ..................407
Event data recorder (EDR) .......10
F
Flat tire.....................................642 Tire pressure w arning system
...........................................584
Floor mats .................................26
Fluid Automatic transm ission ........669

Alphabetical Index725
Mud & Sand mode .................. 353
Multi-information displayAudio system-linked display ... 93
Changing the display.............. 90
Display contents ..................... 89
Driving informatio n display ..... 91
Driving support system informa- tion display ........................... 93
Dynamic radar cruise control with full-speed range .......... 250
Eco Driving Indicator .............. 92
Intuitive parking assist-sensor ........................................... 270
Language ....................... 96, 689
LTA (Lane-Tracing Assist) .... 242
Menu icons ............................. 90
Meter control switches ........... 90
Navigation system-linked display ............................................. 93
PCS (Pre-Collision System) . 229
Pop-up display ....................... 96
Settings .......................... 94, 689
Suggestion function................ 98
Tire pressure ........................ 584
Units ............................... 96, 689
Vehicle information display..... 93
Warning message display ...... 98
Warning messages............... 639
Multi-terrain Select ................. 353
N
Navigation system-linked display ................................................. 93
Noise from under vehicle .......... 8
Normal mode .................. 351, 354
O
Odometer ............................ 82, 85
Odometer and trip meter display “ODO TRIP” switch .......... 84, 88
“ODO TRIP”switch ............. 84, 88 Oil
Engine oil..............................666
Rear differential oil................669
Transfer oil............................669
Opener Back door ..................... 116, 118
Fuel filler door.......................221
Hood .....................................571
Outer foot lights Replacing light bulbs ............609
Wattage ................................670
Outside rear view mirrors ......154 Adjusting and folding ............154
BSM (Blind Spot M onitor) .....261
Outside rear view mirror defog- gers ............................ 511, 517
Outside temperature display ...............................83, 87
Overheating.............................659
P
Panic mode .............................105
Panoramic moon roof Jam protection function ........163
Operation..............................162
Warning message.................164
Panoramic view monitor ........313 Camera switch......................315
Checking around the vehicle 318
Checking the front and around the vehicle ..........................319
Checking the rear and around the vehicle ..........................324
Checking the sides of the vehicle ...........................................321
Customizing the panoramic view monitor ...............................332
Display..................................315
Driving precautions ...............313
How to switch the display .....316
Magnifying function ..............332
Panoramic view monitor precau-

730Alphabetical Index
switch ................................. 250
VSC OFF switch................... 361
Window lock switch .............. 158
Windshield defogger switch ......................... 511, 517
Windshield wipers and washer switch ................................. 215
T
Tachometer ......................... 82, 85
Tail lights Light switch .......................... 209
Replacing light bulbs ............ 609
Talking on the Bluetooth
® hands-
free system ........................... 474 Call screen operation ........... 474
Incoming call waiting ............ 476
Sending tones ...................... 475
Transmit volume setting ....... 475
Theft deterrent system Alarm ...................................... 73
Engine immobilizer system .... 70
Tire inflati on pressure
Maintenance data................. 670
Tire inflation pressure display function............................... 584
Warning light ........................ 634
Tire information ...................... 678 Glossary ............................... 682
Size ...................................... 680
Tire identification number ..... 679
Tire section names ............... 680
Tire pressure warning system Function ............................... 584
Initializing ............................. 590
Installing tire pressure warning valves and transmitters ...... 589
Registering ID codes ............ 593
Warning light ........................ 634
Tires ......................................... 581 Chains .................................. 369 Checking ..............................581
Glossary ...............................682
If you have a flat tire .............642
Inflation pressure
..................595
Information ......... ..................678
Replacing .............................642
Rotating tires ........................583
Size ......................................670
Snow tires.............................367
Spare tire ..............................642
Tire identification number .....679
Tire inflation pressure display function ...............................584
Tire pressure w arning system
...........................................584
Uniform Tire Quality Grading 681
Warning light.........................634
Tools ........................................643
Top tether strap ........................61
Total load capacity .........175, 178
Touch screen ..........................382 Touch screen gestures .........382
Touch screen operation ........383
To w i n g Dinghy towing .......................191
Emergency towing ................623
Towing eyelet................624, 643
Trailer sway control ..............360
Trailer towing ...... ..................179
Toyota Apps ............................504 Entering keyword ..................506
Toyota Apps button (Setup screen) ...................................380
Toyota Apps settings .............508
Toyota parking assist monitor ...............................................300Distance guide line display mode ...........................................305
Driving precautions ...............300
Estimated course line display mode ..................................303
Parking assist guide line display

732Alphabetical Index
PKSB OFF indicator ............. 632
Pre-collision warning ............ 229
RCTA (Rear Cross Traffic Alert) ........................................... 261
RCTA OFF indicator ............. 632
Seat belt reminder ................ 635
Vehicle sway warning ........... 241
Warning lights ABS ...................................... 630
Brake hold operated indicator........................................... 633
Brake Override System ........ 633
Brake system ....................... 628
Charging system .................. 628
Drive-Start Control ............... 633
Electric power steering ......... 630
Engine .................................. 629
High coolant temperature ..... 629
Intuitive parking assist OFF indi- cator ................................... 631
Low engine oil pressure ....... 629
Low fuel level ....................... 634
LTA indicator ......................... 631
Malfunction indicator lamp ... 629
Parking brake indicator ........ 634
PCS warning light................. 630
PKSB (Parking Support Brake) ........................................... 633
PKSB OFF indicato r ............. 632
RCTA OFF indicator ............. 632
Seat belt reminder light 635, 635
Slip indicator......................... 632
SRS ...................................... 629
Stop & Start cancel indicator 631
Tire pressure ........................ 634
Warning messages................. 639
Washer Checking .............................. 580
Low washer fluid warning mes-sage ........................... 580, 639
Preparing and c hecking before
winter.................................. 367 Switch ...........................215, 218
Washing and waxing ..............558
Weight Cargo capacity .............175, 178
Load limits ............................178
Weight ..................................664
Wheels .....................................597 Replacing wheels .................597
Size ......................................670
Wi-Fi
®.......................................402
Connecting a device to the in- vehicle access point ...........402
Operating hints .....................405
Wi-Fi
® button (Setup screen) 380
Wi-Fi
® Hotspot ........................402
Window glasses Power windows ....................156
Window lock switch ...............158
Windows Power windows ....................156
Rear window defogger . 511, 517
Washer .........................215, 218
Windshield defogger ...... 511, 517
Windshield wipers Intermittent windshield wipers...........................................215
Position.........................215, 218
Rain-sensing windshield wipers ...........................................215
Replacing the wiper insert ....601
Winter driving tips ..................367
Wiper insert .............................601
Wireless charger.....................540
Wireless remote control.........104 Battery-saving function .........129
Locking/Unlocking ................104
Panic mode ..........................105
Replacing the battery ...........604
