3814-6. Driving tips
4
Driving
road, please observe the follow-
ing precautions to ensure your
driving enjoyment and to help
prevent the closure of areas to
off-road vehicles:
Drive your vehicle only in
areas where off-road vehicles
are permitted to travel.
 Respect private property. Get
owner’s permission before
entering private property.
 Do not enter areas that are
closed. Honor gates, barriers
and signs that restrict travel.
 Stay on established roads.
When conditions are wet,
driving techniques should be
changed or travel delayed to
prevent damage to roads.
■Additional information for off-
road driving
For owners in U.S. mainland,
Hawaii and Puerto Rico:
To obtain additional information per-
taining to driving your vehicle off-
road, consult the following organiza-
tions: • State and Local Parks and Recre-
ation Departments
• State Motor V ehicle Bureau
• Recreational Vehicle Clubs
• U.S. Forest Service and Bureau of Land Management
WA R N I N G
■Off-road driving precautions
Always observe t he following pre-
cautions to minim ize the risk of
death, serious injury or damage to
your vehicle:
●Drive carefully when off the
road. Do not take unnecessary
risks by driving in dangerous
places.
●Do not grip the steering wheel
spokes when driving off-road. A
bad bump could jerk the wheel
and injure your hands. Keep
both hands and especially your
thumbs on the ou tside of the
rim.
●Always check your brakes for
effectiveness immediately after
driving in sand, mud, water or
snow.
●After driving through tall grass,
mud, rock, sand, rivers, etc.,
check that there is no grass,
bush, paper, rags, stone, sand,
etc. adhering or trapped on the
underbody. Clear off any such
matter from the underbody. If
the vehicle is used with these
materials trapped or adhering to
the underbody, a breakdown or
fire could occur.

3824-6. Driving tips
WA R N I N G
●When driving off-road or in rug-
ged terrain, do not drive at
excessive speeds, jump, make
sharp turns, strike objects, etc.
This may cause loss of control
or vehicle rollover causing
death or serious injury. You are
also risking expensive damage
to your vehicle’s suspension
and chassis.
NOTICE
■To prevent the water damage
Take all necessary safety mea-
sures to ensure that water dam-
age to the hybrid battery (traction
battery), hybrid s ystem or other
components does not occur.
●Water entering the engine com-
partment may cause severe
damage to the hybrid system.
Water entering the interior may
cause the hybrid battery (trac-
tion battery) stowed under the
rear seats to short circuit.
●Water entering the hybrid trans-
mission will cause deterioration
in transmission quality. The mal-
function indicator may come on,
and the vehicle may not be driv-
able.
●Water can wash the grease
from wheel bearings, causing
rusting and premature failure,
and may also enter the hybrid
transaxle case, reducing the
gear oil’s lubricating qualities.
■When you drive through
water
If driving through water, such as
when crossing shallow streams,
first check the depth of the water
and the bottom of the riverbed for
firmness. Drive slowly and avoid
deep water.
■Inspection after off-road driv-
ing
●Sand and mud that has accu-
mulated around brake discs
may affect braking efficiency
and may damage brake system
components.
●Always perform a maintenance
inspection after each day of off-
road driving that has taken you
through rough terrain, sand,
mud, or water. For scheduled
maintenance information, refer
to the “Scheduled Maintenance
Guide” or “Owner’s Manual
Supplement”.

383
5
5
Audio
Audio
5-1. Basic functionButtons overview......... 385
Menu screen ............... 387
Status icon .................. 388
“Setup” screen ............ 390
5-2. Basic information before operation
Initial screen ................ 391
Touch screen............... 392
Home screen............... 394
Entering letters and num- bers/list screen operation.................................. 395
Screen adjustment ...... 398
Linking multi-information display and the system.................................. 399
5-3. Connectivity settings Registering/Connecting a Bluetooth
® device ..... 400
Setting Bluetooth
® details
.................................. 404
Wi-Fi
® Hotspot ............ 412
5-4. Apple CarPlay/Android Auto
Apple CarPlay
®/Android
Auto ........................... 417
5-5. Other settings General settings .......... 424
Voice settings .............. 428
Vehicle settings ........... 4295-6. Using the audio/visual
system
Quick reference ........... 430
Some basics................ 431
5-7. Radio operation AM/FM/SiriusXM (SXM) radio .......................... 435
5-8. Media operation USB memory ............... 442
iPod/iPhone (Apple Car- Play) .......................... 444
Android Auto................ 447
Bluetooth
® audio ......... 448
5-9. Audio/visual remote con- trols
Steering switches ........ 452
5-10.Audio settings Setup ........................... 454
5-11.Tips for operating the audio/visual system
Operating information.. 456
5-12.Voice command system operation
Voice command system .................................. 468
Command list .............. 471
5-13.Phone operation (Hands- free system for cellular
phones)
Quick reference ........... 475
Some basics................ 476

384
Placing a call using the Bluetooth
® hands-free sys-
tem ............................ 480
Receiving a ca ll using the
Bluetooth
® hands-free sys-
tem ............................ 483
Talking on the Bluetooth
®
hands-free system..... 484
Bluetooth
® phone message
function...................... 486
5-14.Phone settings Setup........................... 491
5-15.What to do if... (Blue- tooth
®)
Troubleshooting .......... 501
5-16.Connected Services over- view
Connected Services .... 505
Type A: Function achieved by using a smartphone or
DCM .......................... 506
Type B: Function achieved by using DCM and the sys-
tem ............................ 508
Type C: Function achieved by using DCM............ 509
Type D: Function achieved by using DCM and a
smartphone ............... 512
5-17.Connected Services oper- ation
Toyota Apps ................ 5145-18.Setup
Toyota Apps settings ... 518

3855-1. Basic function
5
Audio
5-1.Basic function
*: Vehicles with Audio onlyFor details about Audio Plus or P remium Audio, refer to “Navigation and
Multimedia System Owner’s Manual”.
By touching the screen with y our finger, you can control the
selected functions. ( P.392, 393)
Press to seek up or down for a radio station or to access a
desired track/file. ( P.435, 442, 444, 448)
Press to access the Bluetooth
® hands-free system. ( P.475)
• When an Apple CarPlay connecti on is established, press to display the
Phone application screen.
*1
Press to display the Toyota Apps screen.*1, 2 (  P.514)
Turn to change the radio station or skip to the next or previou s
track/file. ( P.435, 442, 444, 448)
Press to turn the audio/visual system on and off, and turn it t o
adjust the volume. Press and hold to restart the system. ( P.391,
431)
Buttons over view*
Operations of each part
A
B
C
D
E
F

3865-1. Basic function
When an Apple CarPlay/Android Auto connection is established,
press to display the Maps application screen.
*1
Press to display the audio/visual system screen. (430, 431)
Press to display the “Menu” screen. ( P.387)
Press to display the home screen. ( P.394)
*1: This function is not made available in some countries or areas.
*2: When an Apple CarPlay/Android Auto connection is established, this
function will be unavailable.
●The screen shots in this document
and the actual screens of the sys-
tem differ depending on whether
the functions and/or a contract
existed.
G
H
I
J
WA R N I N G
●For safety, the driver should not
operate the system while
he/she is driving. Insufficient
attention to the r oad and traffic
may cause an accident.

3875-1. Basic function
5
Audio
Press the “MENU” button to display the “Menu” screen.
Displays the clock. Select to display the clock settings screen.
( P.425)
Select to display the audio control screen. ( P.430)
Select to display the hands-free operation screen. ( P.475)
• When an Apple CarPlay connection is established, select to display the
Phone application screen.
*1
Select to display the Toyota Apps screen.*1, 2 (  P.514)
When an Apple CarPlay/Android Auto connection is established
and this button displays “Apple CarPlay”/“Android Auto”, select to
display the home screen of Apple CarPlay/Android Auto.
*1
( P.417)
Select to display the energy monitor/consumption screen.
( P.113)
Select to display the “Setup” screen. ( P.390)
Select to adjust the contrast, brightness, etc. of the display.
( P.398)
*1: This function is not made available in some countries or areas .
*2: When an Apple CarPlay/Android Auto connection is established, this
function will be unavailable.
Menu screen
Menu screen operation
A
B
C
D
E
F
G
H

3885-1. Basic function
Indicate during data commu-
nication performed via Data
Communication Module
(DCM)
*1
The reception level of Data
Communication Module
(DCM) display
*1 ( P.388)
The reception level of the
connected phone display
( P.388)
Remaining battery charge
display ( P.389)
Bluetooth
® phone connection
condition display ( P.389)
Wi-Fi
® connection condition
display
*1, 2 (  P.412)
*1: Vehicles equipped with DCM
*2: This function is not made avail-
able in some countries or areas.
●The number of status icons that
can be displayed differs depend-
ing on the displayed screen.
The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,
/ is displayed.
“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth
® phone you have.
While connected with cellular
phone
Status icon
Status icons are displayed
at the top of the screen.
Status icon explanation
A
B
C
D
E
F
5HFHSWLRQOHYHOGLVSOD\
Reception LevelIndicators
Poor
Excellent

3895-1. Basic function
5
Audio
While using Data Communi-
cation Module (DCM)
While using Wi-Fi® Hotspot
●When Wi-Fi® Hotspot is off, no
item is displayed.
The amount displayed does not
always correspond with the
amount displayed on the Blue-
tooth
® device.
The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth
® device connected.
This system does not have a
charging function. An antenna for the Bluetooth
®
connection is built into the
instrument panel.
The condition of the Bluetooth
®
connection may deteriorate and
the system may not function
when a Bluetooth
® phone is
used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.
Leave the Bluetooth
® phone in a
place where the condition of the
Bluetooth
® connection is good.
Reception LevelIndicators
Poor
Excellent
Reception LevelIndicators
No connection
Connected
Remaining battery charge
display
Remaining chargeIndicators
Empty
Full
Bluetooth® connection
condition display
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the Blue-
tooth
® connection is
good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.

3905-1. Basic function
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.Select to change the selected
language, operation sound
settings, etc. ( P.424)
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P.404)
Select to set audio settings.
( P.454)
Select to set the phone
sound, contacts, message
settings, etc. ( P.491)
Select to set the voice set-
tings. ( P.428) Select to set vehicle informa-
tion. (
P.429)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P.413)
Select to set Toyota Apps
settings.
*2 (  P.518)
*1: Vehicles equipped with DCM
*2: This function is not made avail-
able in some countries or areas.
“Setup” screen
“Setup” screen
A
B
C
D
E
F
G
H
