TOYOTA SEQUOIA 2001 Service Repair Manual

AT138±01
D10672
N´m (kgf´cm, ft´lbf) : Specified torqueOil Cooler PipeOil Cooler Bracket
Clip
ClipOil Cooler
11 (110, 8)
5.0 (50, 48 in.´lbf)
Clip
Grommet
Grommet
Condenser Mounting
Insulator
11 (110, 8)
Hose
Grommet
Condenser Mounting
Insulator
± AUTOMATIC TRANSMISSION (A750E, A750F)AIR COOLED OIL COOLER
AT±15
2923 Author: Date:
2005 SEQUOIA (RM1146U)
AIR COOLED OIL COOLER
COMPONENTS

AT139±01
D10673
D10674
D10675
D05209
AT±16
± AUTOMATIC TRANSMISSION (A750E, A750F)AIR COOLED OIL COOLER
2924 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE PIPE
Loosen the 2 clips and disconnect the 2 hoses.
2. REMOVE OIL COOLER
(a) Remove the 3 bolts and oil cooler.
Torque: 11 N´m (110 kgf´cm, 8 ft´lbf)
(b) Remove the bolt, transmission oil cooler bracket and
grommet.
Torque: 4.9 N´m (50 kgf´cm, 43 in.´lbf)
(c) Remove the 2 grommets and condenser mounting insula-
tors.
3. REMOVE OIL COOLER TUBE
(a) Loosen the 2 clips and disconnect the 2 hoses.
(b) Remove the bolt and oil cooler tube with the 2 hoses.
Torque: 5.0 N´m (50 kgf´cm, 48 in.´lbf)
(c) Loosen the 2 clips and disconnect the 2 hoses.

AT13A±01
± AUTOMATIC TRANSMISSION (A750E, A750F)AIR COOLED OIL COOLER
AT±17
2925 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
Installation is in the reverse order of removal (See page AT±16).
HINT:
After installation, check fluid level (See page DI±524).

AT13B±01
F17895
Steering Wheel Pad
Steering
Wheel
Column Lower
CoverCombination
SwitchSteering Column Assembly
Transmission Control
Cable Assembly
Lower LH Finish PanelColumn Hole
Cover No. 2
No. 2 Universal
Joint Assembly
No. 2 Heater to Register Dust Torx® Screw
35 (360, 26)
35 (360, 26)
8.0 (82, 71 in.´lbf)
26 (260, 19)
26 (260, 19)
8.8 (90, 78 in.´lbf)
50 (510, 37)
8.8 (90, 78 in.´lbf)
Front Door Scuff PlateCowl Side Trim
Hood Lock
Release Lever
8.0 (82, 71 in.´lbf)
Side Panel
No. 2 lntermediate
Shaft AssemblyBrake Pedal
Return Spring
Column Upper Cover
N´m (kgf´cm, ft´lbf): Specified torque
Steering Wheel Lower
No. 3 Cover
Steering Wheel Lower
No. 2 Cover
35 (360, 26)
Siding Yoke
Torx® Screw AT±18
± AUTOMATIC TRANSMISSION (A750E, A750F)COLUMN SHIFT ASSEMBLY
2926 Author: Date:
2005 SEQUOIA (RM1146U)
COLUMN SHIFT ASSEMBLY
COMPONENTS

D14235
: Specified torqueN´m (kgf´cm, ft´lbf)Shift Lever Housing
Spring Shift Lever
Steering Column Assembly
10.5 (110, 8)
2.2 (23, 19 in.´lbf)
2.9 (29, 25 in.´lbf)
12 (120, 9)
Parking Lock Cable Housing
18 (180, 13)




Parking Lock Cable No. 2
Parking Lock Cable No. 1
MP grease
Non±reusable part

± AUTOMATIC TRANSMISSION (A750E, A750F)COLUMN SHIFT ASSEMBLY
AT±19
2927 Author: Date:
2005 SEQUOIA (RM1146U)

AT13C±01
D05180
AT±20
± AUTOMATIC TRANSMISSION (A750E, A750F)COLUMN SHIFT ASSEMBLY
2928 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
1. REMOVE STEERING COLUMN ASSEMBLY
(See page SR±14)
2. REMOVE PARKING LOCK CABLE ASSEMBLY
(a) Remove the screw and parking lock cable No. 2.
(b) Using a torx® socket wrench, remove the 2 screws and
parking lock cable No. 1.
(c) Remove the spring.
(d) Remove the 2 bolts and parking lock cable housing.
3. REMOVE SHIFT LEVER
(a) Disconnect the connector.
(b) Using a torx® socket wrench, remove the torx® screw and
shift lever.
4. REMOVE SHIFT LEVER HOUSING
Using a torx® socket wrench, remove the 3 torx® screws and
shift lever housing.

AT13D±01
D10678
D10679
± AUTOMATIC TRANSMISSION (A750E, A750F)COLUMN SHIFT ASSEMBLY
AT±21
2929 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
1. INSTALL SHIFT LEVER HOUSING
Using a torx® socket wrench, install the shift lever housing with
3 new screws.
Torque: 12 N´m (120 kgf´cm, 9 ft´lbf)
2. INSTALL SHIFT LEVER
(a) Using a torx® socket wrench, install the shift lever with a
new screw.
Torque: 18 N´m (180 kgf´cm, 13 ft´lbf)
(b) Connect the connector.
3. INSTALL PARKING LOCK CABLE NO. 1 AND NO. 2
(a) Apply MP grease on the lock pin and internal surface of
shift lever housing.
(b) Install the spring and parking lock cable No. 1 into the shift
lever housing.
NOTICE:
Be careful not to bend or twist the cable abnormally.
(c) Using a torx® socket wrench, install 2 new screws.
Torque: 2.9 N´m (29 kgf´cm, 25 in.´lbf)
(d) Wire the cable No. 1 and No. 2, as shown in the illustra-
tion.
(e) Temporarily install the cable housing to steering column
assembly with 2 new bolts.
NOTICE:
Be careful not to bend or twist the cable abnormally.
(f) After installation, confirm the following items.
(1) When the shift lever is in P position and the pedal
button is pushed in by 7 mm (0.28 in.), shift lever
should be locked by lock pin.
(2) When the pedal button is released, the shift lever
should be able to be shifted from P position to other
positions.
(3) When the shift lever is in the N or D position and the
pedal button is pushed in by 7 mm (0.28 in.), the
shift lever should be able to be shifted.

D02002
AT±22
± AUTOMATIC TRANSMISSION (A750E, A750F)COLUMN SHIFT ASSEMBLY
2930 Author: Date:
2005 SEQUOIA (RM1146U)
(g) Install the parking lock cable No. 2 to column upper brack-
et with the clip.
(h) Install the cable end to the sliding block of the column up-
per bracket with the screw.
Torque: 2.2 N´m (23 kgf´cm, 19 in.´lbf)
(i) After installation, check the following items.
(1) When the pedal button is pushed, shift lever should
be locked.
(2) When the pedal button is released, shift lever
should be unlocked.
4. INSTALL STEERING COLUMN ASSEMBLY
(See page SR±23)
5. ADJUST CABLE HOUSING
(a) Shift the shift lever to the P position.
(b) Turn the ignition key to the LOCK position.
(c) Loosen the 2 bolts and adjust the cable housing.
HINT:

Pedal button should touch the pedal plate cushion.

Brake pedal should not be moved by the pedal button.

Cable housing should not be toughed the brake pedal
and the brake pedal plate cushion.
(d) Torque the 2 bolts.
Torque: 10.5 N´m (110 kgf´cm, 8 ft´lbf)
6. CONFIRM SHIFT LOCK SYSTEM OPERATION
(a) Only when the brake pedal is engaged and the ignition
key is not in the LOCK position, the shift lever can be
shifted from the P position to other positions.
When the shift lever is in the P position and the brake ped-
al is released, the shift lever cannot be shifted from P posi-
tion to other positions.
(b) When the shift lever is not in the P position, the ignition
key cannot be turned to the LOCK position.
Only when the shift lever is in the P position, the ignition
key can be removed.
(c) Cable No. 1 and No. 2 should not be deformed by other
parts located around the steering column.

AT13E±01
D13873
A750E
Clamp
Oil Cooler Pipe34 (346, 25)
Torque
Converter
Clutchx6
Transmission
48 (490, 35)
71 (724, 52)
Front Exhaust Pipe RH
N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
37 (377, 27)
Stabilizer BarBushing
Stabilizer Bar Bracket
No. 1 Engine Under Cover
40 (410, 30)
88 (897, 65)
18 (185, 13)
CrossmemberEngine Rear
Mounting Insulator
Shift Control Cable
37 (377, 27)
Gasket

Front Exhaust
Pipe LH
Rear End Plate
18 (185, 13)
Gasket


62 (630, 46)



62 (630, 46)



Gasket
Propeller Shaft
19.5 (199, 14)
14.5 (148, 11)
65 (660, 48)
72 (734, 53)
33 (336, 24)
33 (336, 24)



Gasket
48 (490, 35)
Front Suspension
Member Bracket Front Suspension
Member Bracket
12 (122, 9)
48 (490, 35)
± AUTOMATIC TRANSMISSION (A750E, A750F)AUTOMATIC TRANSMISSION UNIT
AT±23
2931 Author: Date:
2005 SEQUOIA (RM1146U)
AUTOMATIC TRANSMISSION UNIT
COMPONENTS

D13874
A750F
N´m (kgf´cm, ft´lbf) : Specified torque

Non±reusable part
37 (377, 27)
Stabilizer Bar
Bushing
Stabilizer Bar Bracket
No. 1 Engine Under Cover
18 (185, 13)
Rear End Plate
Torque Converter Clutch
x6
48 (490, 35)
Oil Cooler Pipe
34 (346, 25)
Gasket

Front Exhaust Pipe RH
Gasket


Gasket
37 (377, 27)
Crossmember
Engine Rear
Mounting
Insulator
19.5 (199, 14)
14.5 (148, 11)
Transmission and
Transfer
88 (897, 65)
Rear Propeller Shaft88 (897, 65)
Front Propeller Shaft
Heat Insulator
Front Exhaust Pipe LH
Clamp
71 (724, 52)

Gasket
48 (490, 35)
16 (164, 12)
65 (660, 48)
88 (897, 65)
88 (897, 65)
72 (734, 53)
Front Suspension
Member Bracket
33 (336, 24)
Front Suspension
Member Bracket
33 (336, 24)




62 (630, 46)

62 (630, 46)

12 (122, 9)
48 (490, 35)
AT±24
± AUTOMATIC TRANSMISSION (A750E, A750F)AUTOMATIC TRANSMISSION UNIT
2932 Author: Date:
2005 SEQUOIA (RM1146U)
