TOYOTA SEQUOIA 2001  Service Repair Manual RS0N2±16
H23896
Curtain Shield
Airbag Assembly
N´m (kgf´cm, ft´lbf): Specified torque
9.8 (100, 7)
9.8 (100, 7)
9.8 (100, 7)
RS±70
± SUPPLEMENTAL RESTRAINT SYSTEMCURTAIN SHIELD AIRBAG ASSEMBLY
