RS0BC±08
RS±30
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
3313 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the steering wheel pad, steering wheel or spiral cable with a new one.
CaseReplacing part
The airbag has been deployed.Steering wheel pad
The steering wheel pad has been found to be faulty in troubleshooting.Steering wheel pad
The spiral cable has been found to be faulty in troubleshooting.Spiral cable
The steering wheel pad has been found to be faulty while checking items.
(see page RS±22)Steering wheel pad
The steering wheel has been found to be faulty while checking items.
(see page RS±22)Steering wheel
The spiral cable has been found to be faulty while checking items.
(see page RS±22)Spiral cable
The steering wheel pad has been dropped.Steering wheel pad
CAUTION:
For removal and installation of the steering wheel pad, see page SR±14 and SR±23. Be sure to follow
the correct procedure.

RS0BD±11
± SUPPLEMENTAL RESTRAINT SYSTEMSTEERING WHEEL PAD AND SPIRAL CABLE
RS±31
3314 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
CAUTION:

If the steering wheel pad has been dropped, or there are cracks, dents or other defects in the
case or connector, replace the steering wheel pad with a new one.

When installing the steering wheel pad, take care it is not pinched between other parts.

Never use airbag parts from another vehicle. When replacing parts, replace them with new
ones.
1. INSTALL SPIRAL CABLE (SEE PAGE SR±23)
2. INSTALL STEERING COLUMN COVER LOWER (SEE PAGE SR±23)
3. INSTALL STEERING WHEEL (SEE PAGE SR±23)
4. INSTALL STEERING WHEEL PAD (SEE PAGE SR±23)
5. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
6. PERFORM INITIALIZATION (SEE PAGE SR±23)
Some system need initialization when disconnecting the cable from the negative battery terminal.
7. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)

RS0BE±11
H23930
Front Passenger
Airbag Assembly
N´m (kgf´cm, ft´lbf) : Specified torque
20 (204, 15)
Lower Finish Panel
Cowl Side Trim Board
Lower No. 2
Finish Panel
Front Door
Scuff Plate
Glove Compartment Door
Front Door Scuff PlateCowl Side Trim Board
Front Console Box
Lower Instrument Cover
Upper Console Panel
Rear Console Box Side Panel
Side Panel
5.0 (51, 44 in.´lbf)
Shifting Hole Cover
Rear Console Box
Disc Player Cover
Disc Player w/ Rear seat audio or Rear seat entertainment: RS±32
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
3315 Author: Date:
2005 SEQUOIA (RM1146U)
FRONT PASSENGER AIRBAG ASSEMBLY
COMPONENTS

RS0T6±03
H23215
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS±33
3316 Author: Date:
2005 SEQUOIA (RM1146U)
REMOVAL
NOTICE:

If the wiring connector of the SRS is disconnected
and the ignition switch is in the ON or ACC position,
DTCs will be recorded.

Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.
1. PRECAUTION (SEE PAGE RS±1 and RS±3)
2. DISCONNECT CABLE FROM NEGATIVE BATTERY
TERMINAL
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
3. REMOVE FRONT DOOR SCUFF PLATES
(SEE PAGE BO±89)
4. REMOVE COWL SIDE TRIM BOARDS
(SEE PAGE BO±89)
5. REMOVE SIDE PANELS (SEE PAGE BO±89)
6. REMOVE LOWER FINISH PANEL
(SEE PAGE BO±89)
7. REMOVE GLOVE COMPARTMENT DOOR
(SEE PAGE BO±89)
8. REMOVE LOWER NO. 2 FINISH PANEL
(SEE PAGE BO±89)
9. REMOVE SHIFTING HOLE COVER
(SEE PAGE BO±89)
10. REMOVE UPPER CONSOLE PANEL
(SEE PAGE BO±89)
11. REMOVE REAR CONSOLE BOX
(SEE PAGE BO±89)
12. REMOVE FRONT CONSOLE BOX
(SEE PAGE BO±89)
13. REMOVE LOWER INSTRUMENT COVER
(SEE PAGE BO±89)
14. REMOVE FRONT PASSENGER AIRBAG ASSEMBLY
(a) Using a clip remover, disengage the connector clamp.
(b) Disconnect the airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(c) Remove the bolt holding the front passenger airbag as-
sembly and instrument panel.
(d) Remove the 2 bolts holding the front passenger airbag
assembly and instrument panel reinforcement.

H23212
RS±34
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
3317 Author: Date:
2005 SEQUOIA (RM1146U)
(e) Remove the front passenger airbag assembly.
CAUTION:

Do not store the front passenger airbag assembly
with the airbag deployment side facing downward.

Never disassemble the front passenger airbag as-
sembly.

RS119±01
H16182
H23213
H23214
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS±35
3318 Author: Date:
2005 SEQUOIA (RM1146U)
INSPECTION
1. VEHICLE NOT INVOLVED IN COLLISION
(a) Perform a diagnostic system check (see page DI±1147).
(b) With the front passenger airbag assembly installed on the
vehicle, perform a visual check. If there are any defects
as mentioned below, replace the front passenger airbag
assembly with a new one:
Cuts, minute cracks or marked discoloration on the instru-
ment panel around the front passenger airbag assembly.
2. VEHICLE INVOLVED IN A COLLISION AND AIRBAG IS
NOT DEPLOYED
(a) Perform a diagnostic system check (see page DI±1147).
(b) With the front passenger airbag assembly removed from
the vehicle, perform a visual check. If there are any de-
fects as mentioned below, replace the front passenger
airbag assembly, instrument panel or instrument panel re-
inforcement with a new one:

Cuts, minute cracks or marked discoloration on the
front passenger airbag assembly.

Cracks or other damage to the connectors.

Deformation or cracks on the instrument panel or
instrument panel reinforcement.
CAUTION:
For removal and installation procedures of the front pas-
senger airbag assembly, see page RS±33 and RS±43. Be
sure to follow the correct procedure.

RS11A±01
AB0152
SST RS±36
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
3319 Author: Date:
2005 SEQUOIA (RM1146U)
DISPOSAL
HINT:
When scrapping a vehicle equipped with the SRS or disposing
of the front passenger airbag assembly, be sure to deploy the
airbag first in accordance with the procedure described below.
If any abnormality occurs with the airbag deployment, contact
the SERVICE DEPT. of the TOYOTA MOTOR SALES, U.S.A.,
INC.
CAUTION:

Never dispose of a front passenger airbag assembly
that has an undeployed airbag.

The airbag produces an exploding sound when it is
deployed, so perform the operation outdoors and
where it will not create a nuisance to nearby resi-
dents.

When deploying the airbag, always use the specified
SST (SRS Airbag Deployment Tool). Perform the op-
eration in a place away from electrical noise.

When deploying the airbag, perform the operation at
least 10 m (33 ft) away from the front passenger air-
bag assembly.

The front passenger airbag assembly becomes ex-
tremely hot when the airbag is deployed, so do not
touch it for at least 30 minutes after deployment.

Use gloves and safety glasses when handling a front
passenger airbag assembly with a deployed airbag

Do not apply water, etc. to a front passenger airbag
assembly with a deployed airbag.

Always wash your hands with water after completing
the operation.
HINT:
Prepare a battery as the power source to deploy the airbag.

AB0158
SSTBattery
H23215
H23216SST
R13455
10 m (33 ft) or more
SSTBattery
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS±37
3320 Author: Date:
2005 SEQUOIA (RM1146U)
1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE-
HICLE
(a) Check the function of the SST (see step 1±(a) on page
RS±23).
(b) Precaution (see page RS±1 and RS±3).
(c) Disconnect the cable from the negative battery terminal.
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
(d) Remove the glove compartment door (see page
BO±89).
(e) Remove the lower No. 2 finish panel (see page
BO±89).
(f) Disconnect the airbag connector (yellow colored one)
from the front passenger airbag assembly.
(1) Using a clip remover, disengage the connector
clamp.
(2) Disconnect the airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(g) Install the SST.
(1) Connect the SST connector to the front passenger
airbag assembly.
SST 09082±00700, 09082±00780
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Move the SST at least 10 m (33 ft) away from the ve-
hicle side window.
(3) Maintaining enough clearance for the SST wire har-
ness in the front side window, close all doors and
windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(4) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip of the SST to the
negative (±) terminal.

AB0152
SST
H23213
RS±38
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
3321 Author: Date:
2005 SEQUOIA (RM1146U)
(h) Deploy the airbag.
(1) Check that no one is inside the vehicle or within a
10 m (33 ft) radius of the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
CAUTION:

When deploying the airbag, make sure that no one is
near the vehicle.

The front passenger airbag assembly becomes ex-
tremely hot when the airbag is deployed, so do not
touch it for at least 30 minutes after deployment.

Use gloves and safety glasses when handling a front
passenger airbag assembly with a deployed airbag.

Do not apply water, etc. to a front passenger airbag
assembly with a deployed airbag.

Always wash your hands with water after completing
the operation.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
2. DEPLOYMENT WHEN DISPOSING OF FRONT PAS-
SENGER AIRBAG ASSEMBLY ONLY
NOTICE:

When disposing of the front passenger airbag assem-
bly, never use the customer's vehicle to deploy the
airbag.

Be sure to follow the procedure detailed below when
deploying the airbag.
HINT:
Prepare a battery as the power source to deploy the airbag.
(a) Check the function of the SST (see step 1±(a)).
(b) Remove the front passenger airbag assembly (see page
RS±33).
CAUTION:

When removing the front passenger airbag assembly,
work must be started 90 seconds after the ignition
switch is turned to the ºLOCKº position and the nega-
tive (±) terminal cable is disconnected from the bat-
tery.

When storing the front passenger airbag assembly,
keep the airbag deployment side facing upward.

AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H23218
Inner
Diameter Width
± SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS±39
3322 Author: Date:
2005 SEQUOIA (RM1146U)
(c) Using a service±purpose wire harness for the vehicle, tie
down the front passenger airbag assembly to the tire.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in.2 or more)
CAUTION:
If the wire harness is too thin or an alternative object is
used to tie down the front passenger airbag assy, it may be
snapped by the shock when the airbag is deployed. Always
use a wire harness for vehicle use with an area of at least
1.25 mm
2
(0.0019 in.2).
HINT:
To calculate the area of the stripped wire harness section:
Area = 3.14 X (Diameter)
2 divided by 4
(1) Position the front passenger airbag assembly in-
side the tire with the airbag deployment side facing
inside.
Tire size: Must exceed the following dimensions:
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:

Make sure that the wire harness is tight. If there is
slack in wire harness, the front passenger airbag as-
sembly may become loose due to the shock when the
airbag is deployed.

Always tie down the front passenger airbag assembly
with the airbag deployment side facing inside.
NOTICE:
The tire will be marked by the airbag deployment, so use an
extra tire.
