TOYOTA SEQUOIA 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: SEQUOIA, Model: TOYOTA SEQUOIA 2001Pages: 4323, PDF Size: 48.49 MB
Page 3341 of 4323
RS11B±01
AB0152
SST RS±50
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3333 Author: Date:
2005 SEQUOIA (RM1146U)
DISPOSAL
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
When scrapping a vehicle equipped with the SRS or dis-
posing of the front seat airbag assembly LH, be sure to
deploy the airbag first in accordance with the procedure
described below. If any abnormality occurs with the airbag
deployment, contact the SERVICE DEPT. of TOYOTA
MOTOR SALES, U.S.A., INC.
CAUTION:
Never dispose of a front seat airbag assembly that
has an undeployed airbag.
The airbag produces an exploding sound when it is
deployed, so perform the operation outdoors and
where it will not create a nuisance to nearby resi-
dents.
When deploying the airbag, always use the specified
SST (SRS Airbag Deployment Tool). Perform the op-
eration in a place away from electrical noise.
When deploying the airbag, perform the operation at
least 10 m (33 ft) away from the front seat airbag as-
sembly.
The front seat airbag assembly becomes extremely
hot when the airbag is deployed, so do not touch it for
at least 30 minutes after deployment.
Use gloves and safety glasses when handling a front
seat airbag assembly with a deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front seat airbag assem-
bly with a deployed airbag.
HINT:
Prepare a battery as the power source to deploy the airbag.
Page 3342 of 4323
AB0158
Battery
SST
H17490
H17494SST SST
R13455
10 m (33 ft) or more
SSTBattery
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±51
3334 Author: Date:
2005 SEQUOIA (RM1146U)
1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE-
HICLE
(a) Check the function of the SST (see step 1±(a) on page
RS±23).
SST 09082±00700
(b) Precaution (see page RS±1 and RS±3).
(c) Disconnect the cable from the negative battery terminal.
Wait for 90 seconds after disconnecting the cable to prevent the
airbag working.
(d) Remove the 4 bolts from the front seat assembly
(see page BO±111 (power adjuster type) and BO±125
(manual adjuster type)).
HINT:
Keep the front seat assembly LH in the cabin.
(e) Disconnect the connector (yellow colored one) from the
front seat airbag assembly LH.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(f) Install the SST.
(1) Connect the connectors of the SST to the airbag
connector.
SST 09082±00700, 09082±00750
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Move the SST at least 10 m (33 ft) away from the ve-
hicle side window.
(3) Maintaining enough clearance for the SST wire har-
ness in the front side window, close all doors and
windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(4) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip to the battery neg-
ative (±) terminal.
Page 3343 of 4323
H17495
AB0152
SST RS±52
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3335 Author: Date:
2005 SEQUOIA (RM1146U)
(g) Deploy the airbag.
(1) Check that no one is inside the vehicle or within a
10 m (33 ft) radius of the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
CAUTION:
When deploying the airbag, make sure that no one is
near the vehicle.
The front seat airbag assembly becomes extremely
hot when the airbag is deployed, so do not touch it for
at least 30 minutes after deployment.
Use gloves and safety glasses when handling a front
seat airbag assembly with a deployed airbag.
Do not apply water, etc. to a front seat airbag assem-
bly with a deployed airbag.
Always wash your hands with water after completing
the operation.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
2. DEPLOYMENT WHEN DISPOSING OF SIDE AIRBAG
ASSEMBLY
NOTICE:
When disposing of the side airbag assembly, never
use the customer's vehicle to deploy the airbag.
Be sure to follow the procedure given below when de-
ploying the airbag.
HINT:
Prepare a battery as the power source to deploy the airbag.
(a) Check the function of the SST (see step 1±(a)).
(b) Remove the front seat airbag assembly
(see page BO±111 (power adjuster type) and BO±125
(manual adjuster type)).
(c) Remove the seatback assembly (see page RS±46).
Page 3344 of 4323
H23934
AB0163
Wire Harness
Diameter
Stripped Wire Harness Section
H17493
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±53
3336 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Remove the 2 nuts and side airbag assembly from the
seatback assembly.
CAUTION:
When removing the front seat airbag assembly, work
must be started 90 seconds after the ignition switch
is turned to the ºLOCKº position and the negative (±)
terminal cable is disconnected from the battery.
When storing the front passenger airbag assembly,
keep the airbag deployment side facing upward.
(e) Using a service±purpose wire harness for the vehicle, tie
down the front passenger airbag assembly to the tire.
Wire harness: Stripped wire harness section
1.25 mm
2
or more (0.0019 in2. or more)
HINT:
To calculate the area of the stripped wire harness section:
Area = 3.14 x (Diameter)
2 divided by 4
CAUTION:
If the wire harness is too thin or an alternative object is
used to tie down the front passenger airbag assembly, it
may be snapped by the shock when the airbag is deployed.
Always use a wire harness for vehicle use with an area of
at least 1.25 mm
2
(0.0019 in.2).
(1) Install the 2 nuts to the side airbag assembly.
Page 3345 of 4323
H17497
H24673
Width
Inner
Diameter
H24674
SST
H24675
Tires
(2 or more)
Tires
(2 or more)
RS±54
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3337 Author: Date:
2005 SEQUOIA (RM1146U)
(2) Wind the wire harness around the stud bolts of the
side airbag assembly as shown in the illustration.
(3) Position the side airbag assembly inside the tire
with the airbag deployment direction facing inside.
Tire size: Must exceed the following dimensions:
Width: 185 mm (7.28 in.)
Inner diameter: 360 mm (14.17 in.)
CAUTION:
Make sure that the wire harness is tight. If there is
slack in wire harness, the side airbag assembly may
become loose due to the shock when the airbag is
deployed.
Always tie down the side airbag assembly with the
airbag deployment side facing inside the tire.
NOTICE:
The tire will be marked by the airbag deployment, so use an
extra tire.
(f) Install the SST.
(1) Connect the SST connector to the side airbag as-
sembly connector.
SST 09082±00750
(g) Place the tires.
(1) Place at least 2 tires under the tire which the front
seat airbag assembly is tied to.
(2) Place at least 2 tires over the tire which the front
seat airbag assembly is tied to. The top tire should
have the disc wheel installed.
NOTICE:
Do not place the SST connector under the tire because it
could be damaged.
Page 3346 of 4323
H23917
H1749610 m (33 ft) or more SSTBattery
Side Airbag
Assembly
H00544
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±55
3338 Author: Date:
2005 SEQUOIA (RM1146U)
(3) Tie the tires together with 2 wire harness.
CAUTION:
Make sure that the wire harness is tight. Looseness in the
wire harness results in the tires coming free due to the
shock when the airbag is deployed.
(h) Install the SST.
Connect the connectors of the 2 SST to the side airbag
assembly connector.
SST 09082±00700
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock. Also, se-
cure some slack for the SST wire harness inside the tire.
(i) Deploy the airbag.
(1) Connect the red clip of the SST to the battery posi-
tive (+) terminal and the black clip of the SST to the
battery negative (±) terminal.
(2) Check that no one is within a 10 m (33 ft) radius of
the tire which the front seat airbag assembly LH is
tied to.
(3) Press the SST activation switch and deploy the air-
bag.
CAUTION:
When deploying the airbag, make sure that no one is near
the tire.
HINT:
The airbag deploys as the LED of the SST activation switch
comes on.
Page 3347 of 4323
RS0LD±06
RS±56
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3339 Author: Date:
2005 SEQUOIA (RM1146U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the seat frame assembly or seatback cover with a new one.
CaseReplacing part
The side airbag has been deployed.Seat assembly
The side airbag assembly has been found to be faulty in troubleshooting.Seat frame assembly
The side airbag assembly has been found to have cuts while checking items
(see page RS±49).Seat frame assembly
The seatback cover has been found to have cuts and frayed seams while
checking items
(see page RS±49).
Seatback cover
The side airbag assembly has been found to be faulty while checking items
(See page RS±49).Seat frame assembly
The seatback cover has been found to be faulty while checking items
(see page RS±49).Seatback cover
The seatback assembly has been dropped.Seat frame assembly
CAUTION:
For removal and installation of the seat frame assembly, see page RS±46 and RS±57. Be sure to fol-
low the correct procedure.
Page 3348 of 4323
RS11C±01
H24319
H24318Hog Ring
H24321Hog Ring
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±57
3340 Author: Date:
2005 SEQUOIA (RM1146U)
INSTALLATION
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
NOTICE:
If the side airbag assembly has been dropped, or
there are cracks, dents or other defects in the case or
connector, replace the side airbag assembly with a
new one.
When installing the side airbag assembly, take care
it is not pinched between other parts.
Never use airbag parts from another vehicle. When
replacing parts, replace them with new ones.
1. INSTALL SEATBACK COVER
(a) Install the seatback cover to the seatback pad.
(b) Install the 2 headrest supports.
(c) Turn up the seatback cover and install the hog rings.
2. INSTALL SEATBACK COVER AND PAD
(a) Install the seatback cover and pad to the seat frame as-
sembly.
(b) Install the 2 headrest supports to the seat frame assem-
bly.
(c) Install the hog rings to the seat frame assembly.
(d) Install the hog rings to the seat frame assembly.
Page 3349 of 4323
H24861
H24317
H24316
H24315
RS±58
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
3341 Author: Date:
2005 SEQUOIA (RM1146U)
(e) w/ Side airbag:
Connect the seatback cover bracket to the seat frame as-
sembly with the nut.
Torque: 5.5 N´m (56 kgf´cm, 49 in.´lbf)
(f) Close the fastener.
(g) Install the hog rings to the seat frame assembly.
3. INSTALL ARMREST ASSEMBLY
(a) Install the spacer to the armrest assembly.
(b) Install the armrest assembly, armrest lock plate and arm-
rest spacer with the bolt.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
HINT:
Install the armrest lock plate as shown in the illustration.
(c) Install the armrest cap.
4. INSTALL POWER SWITCH
Install the power switch with the 3 screws.
5. INSTALL LUMBAR SWITCH
Install the lumbar switch with the 2 screws to the seat cushion
outer shield.
6. INSTALL FRONT SEAT INNER BELT
(a) Install the front seat inner belt with the nut.
Torque: 42 N´m (428 kgf´cm, 31 ft´lbf)
(b) Connect the connectors and wire harness clamps.
7. INSTALL SEAT CUSHION LOWER SHIELD, SEAT
CUSHION OUTER SHIELD AND SEAT CUSHION IN-
NER SHIELD
(a) Assemble the seat cushion lower shield and seat cushion
outer shield with the screw.
(b) Perform the same procedure on the other side.
(c) Connect the lumbar switch connector to the lumbar
switch, and install the seat cushion lower shield, outer
shield and inner shield.
Page 3350 of 4323
H24314
H24313
H24312
± SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS±59
3342 Author: Date:
2005 SEQUOIA (RM1146U)
(d) Install the 2 screws to the seat cushion lower shield.
(e) Install the 2 screws to the seat cushion inner shield.
(f) Install the 2 screws to the seat cushion outer shield.
(g) Install the screw to the seat cushion outer shield.
8. INSTALL SLIDE KNOB AND RECLINING KNOB
9. INSTALL HEADREST
10. INSTALL FRONT SEAT
Mount the front seat to the vehicle.
NOTICE:
Be careful not to damage the body.
(a) w/ Side airbag:
Connect the connectors.
(b) Connect the connectors.
(c) Slide the front seat to the rearmost position.
(d) Tighten the bolts on the front side temporarily, starting
from the bolt on the inner side.
(e) Tighten them completely.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
(f) Slide the front seat to the foremost position.
(g) Tighten the bolts on the rear side temporarily, starting
from the bolt on the inner side.
(h) Tighten them completely.
Torque: 37 N´m (377 kgf´cm, 27 ft´lbf)
11. INSTALL SEAT TRACK COVERS
12. CONNECT CABLE TO NEGATIVE BATTERY TERMI-
NAL
13. PERFORM INITIALIZATION (SEE PAGE BE±77)
Some system need initialization when disconnecting the cable
from the negative battery terminal.
14. INSPECT SRS WARNING LIGHT (SEE PAGE DI±1137)
