TOYOTA SEQUOIA 2009 2.G Quick Reference Guide

29
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Telephone controls (Bluetooth®)
(if equipped)
Bluetooth®technology allows dialing or receipt of calls without taking
hands from the steering wheel or using a cable to connect the compatible\
telephone and the system.
Refer to “Hands-free phone system (for cellular phones),” Section\
3-4 in
the Owner’s Manual for more details.
MicrophoneAudio unit
Steering wheel telephone switches
Vo l u m e
Voice command
buttonEnd call
Start call
End call
Start call
Vo l u m eVoice command
button
Ty p e BTy p e A
412xxxM2.qxd 7/16/08 4:14 PM Page 29

30
FEATURES/OPERATIONS
Power outlets-115V AC
ON/OFF switch
Engine switch must be in the “ON” position to be used.
Power outlets-12V DC (if equipped)
Luggage compartment
Instrument panelInside of the
center console box
Back of the center console box
Engine switch must be in the “ACC” or “ON” position to be us\
ed.
412xxxM2.qxd 7/16/08 4:14 PM Page 30

31
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Cup holders
Front
Rear
Front consoleBack of the front console
Rear side trimRear console box (if equipped)
Accessory meter
Outside temperature/Cruise information display (if equipped)
Clock
Hour set
Minute set
Change information (if equipped)
“SELECT RESET” button (if equipped)
“SETUP US/M” button to customize unit (if equipped)
Refer to your Owner’s Manual for complete details on this system before
attempting to use it.
412xxxM2.qxd 7/16/08 4:14 PM Page 31

32
SAFETY AND
EMERGENCY FEATURES
If belt is fully extended, then retracted even slightly, it cannot be
re-extended beyond that point, unless fully retracted again. This featur\
e
is used to help hold child restraint systems securely.
To find more information about seat belts, and how to install a child
restraint system, refer to the Owner's Manual.
Keep as low on
hips as possible
Take up slack
Too high
Seat belts
System reset initialization
1. Push and hold “ SET” button
until the indicator blinks
three times.
2. Wait a few minutes to allow initialization to complete.
Tire Pressure Monitoring (warning)
System
After adjusting tire pressures, or after tires have been rotated or
replaced, turn the ignition switch to “ON” and press and hold the \
“ SET” button until indicator blinks three times. Let the vehicle sit f\
or a
few minutes to allow initialization to complete.
Refer to the load label on the door jamb or the Owner’s Manualfor tire
inflation specifications.
If the tire pressure indicator flashes for more than 60 seconds and then\
remains on, take the vehicle to your local Toyota dealer.
Note : The warning light may come on due to temperature changes or
changes in tire pressure from natural air leakage. If the system has not\
been initialized recently, setting the tire pressures to factory
specifications should turn off the light.
412xxxM2.qxd 7/16/08 4:14 PM Page 32

33
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Push up
Seat belts-Shoulder belt anchor
Squeeze lock release to lower
Spare tire & tools
Spare tire, jack and tool location
Removing the spare tire
(1) Remove the cover.
(2) Assemble the jack handle.
(3) Insert the jack handle extension into the lowering screw. Lower the spare tire completely to the ground.
Refer to the Owner’s Manual for tire changing and jack positioning
procedures.
Moving the lever to “LOCK” will allow the door to be opened only f\
rom
the outside.
Rear door
Doors-Child safety locks
(1)(2)(3)
Spare tireJack and tool
412xxxM1.qxd 7/16/08 4:15 PM Page 3

MN 00505-QRG09-SEQ
Printed in the USA 7/08
412xxxM1.qxd 7/16/08 4:16 PM Page 4
