Page 131 of 560

1313-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■When folding the rear seatbacks down
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shi ft the shift
lever to P.
● Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
● Do not allow children to enter the luggage compartment.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
● Do not depress the second seat release pedal from the third seat while the
second seat is occupied.
■ After returning the rear seatback to the upright position
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.
● Check that the seat belts are not twisted or caught in the seatback.
Page 132 of 560

1323-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
NOTICE
■Stowing the seat belts
The seat belts and the buckles must be stowed.
■ Second seatback board weight capacity (if equipped)
Do not place any object heavier than 220 lb. (100 kg) on the se cond seat-
back board.
■ Before sliding the second center seat to the most forward posit ion
(vehicles with bench type second seat)
Ensure that the cup holder on the front console box is closed.
Page 133 of 560

1333-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
Driving position memor y
The steering wheel will automatically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have
been performed, the steering
wheel will automatically
adjusted to a position that
allows driver to enter and exit
the vehicle easily. • The shift lever has been shifted to P.
• The engine switch has been turned to the “ON” position.
• The driver’s seat belt has been unfastened.
When any of the following has be en performed, the steering wheel
will automatically return to their original positions. • The engine switch has been turned to the “ACC” or “ON” posi- tion.
• The driver’s seat belt has been fastened.
: If equipped
This feature automatically adjusts the front seats, steering wh eel
and outside rear view mirrors to make entering and exiting the
vehicle easier or to suit your preferences.
Power easy access system
Page 134 of 560

1343-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Your preferred driving position (the position of the driver’s seat, steer-
ing wheel and outside rear view mirrors) can be recorded and re called
by pressing a button.
Two different driving positions can be recorded into memory.
■Recording procedure
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Adjust the driver’s seat, steerin g wheel, and outside rear view
mirrors to the desired positions.
While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button “1” or
“2” until the buzzer sounds.
If the selected button has
already been preset, the previ-
ously recorded position will be
overwritten.
■
Recall procedure
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.
Driving position memory
1
2
3
4
1
2
3
Page 135 of 560

1353-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
■To stop the position recall operation part-way through
Perform any of the following:
●Press the “SET” button.
● Press button “1” or “2”.
● Operate any of the seat adjustment switches (only cancels seat position
recall).
● Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).
■ Seat positions that can be memorized ( P. 120)
The adjusted positions other than the position adjusted by lumb ar support
switch can be recorded.
■ Operating the driving position m emory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.
■ In order to correctly use the dr iving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be sl ightly different
when it is recalled.
Page 136 of 560

1363-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Each key can be registered to recall your preferred driving position.
■Registering procedure
Record your driving position to button “1” or “2” before perfor ming
the following:
Carry only the key you want to register, and then close the dri ver’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
recorded properly.
Check that the shift lever is in P.
Turn the engine switch to “ON” position.
Recall the driving position that you want to record.
While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.
If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.
■
Recall procedure
Make sure that the doors are locked before recalling the drivin g
position. Carry the key that has been registered to the driving
position, and then unlock and open the driver’s door using the
wireless remote control.
The driving position will move to the recorded position (not in cluding the
steering wheel).
If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.
Turn the engine switch to the “ACC” or “ON” position, or fasten a
seat belt.
The seat and steering wheel will move to the recorded position.
Memory recall function
1
2
3
4
1
2
Page 137 of 560

1373-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY■
Cancelation procedure
Carry only the key you want to cancel and then close the driver
’s
door.
If 2 or more keys are in the vehicle, the driving position cann ot be
canceled properly.
Turn the engine switch to the “ON” position.
While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.
If the button could not be canceled, the buzzer sounds continuo usly for
approximately 3 seconds.
■ Recalling the driving position using the memory recall function
Different driving positions can be registered for each key. Therefore, the driv-
ing position that is recalled may be different depending on the key being car-
ried.
■ Customization
The unlock door settings of the memory recall function can be customized.
(Customizable features: P. 516)
WARNING
■ Seat adjustment caution
Take care during seat adjustment so that the seat does not stri ke the rear
passenger or squeeze your body against the steering wheel.
1
2
Page 138 of 560

1383-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Head restraints
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Center seat
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Outer seats
To u s e
Lift up the head restraint until it
locks.
To f o l d
Pull the head restraint lock release
lever to fold the head restraint.
Head restraints are provided for all seats.
Front and second seats
Lock release button
Third seats
Lock release button
Page 139 of 560

1393-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
■Removing the head restraints
■ Installing the head restraints
■ Adjusting the height of the head restraints (front and second o uter
seats)
■ Adjusting the second and thir d center seat head restraint
Always raise the head restraint one level from the stowed position when
using. Pull the head restraint up while pressing
the lock release button.
The head restraint of second center seat
(if equipped) and third outer seats cannot
be removed.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
● Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
Lock release button
Lock releasebutton
Page 140 of 560

1403-4. Adjusting the steering wheel and mirrors
SEQUOIA_OM_USA_OM0C013U_19MY
Steering wheel
Manual adjustment type
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
Power adjustment type
Operating the switch moves the steering wheel in the following direc-
tions:
Up
Down
Toward the driver
Away from the driver
The steering wheel ca n be adjusted to a comfortable position.
Adjustment procedure
1
2
