TOYOTA SEQUOIA 2019 Owners Manual (in English)

1213-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
WARNING
■When adjusting the seat position
● Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.
■ Seat adjustment
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may un expect-
edly move and cause the driver to lose control of the vehicle.
● After adjusting the seat, make sure that the seat is locked in position.
(manual type only)

1223-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY
Rear seats
■Second seats
Separated type
Seat position adjustment
lever
Seatback angle adjustment
lever
Adjustment procedures

1233-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY
Bench type
Seat position adjustment
lever
*
Seatback angle adjustment
lever
*: The second center seat can bemoved forward further than side
seats.

1243-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY■
Third seats
Manual type
Seatback angle adjustment
lever
Power type
Seatback angle adjustment
switch
Seatback folding/returning
switch

1253-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY■
Before folding dow
n the second seats
Adjust the head restraints to
the downmost position.
Stow the rear seat belt buck-
les.
Folding down the second seats
1
2

1263-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY■
Folding down the second seats
Pull the lever to unlock the seatback and then fold the seatbac
k
down.
■After folding down the second seat (if equipped)
Fold out the board from the
seatback.
Separated typeBench type

1273-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY■
Getting in the vehicle
Pull up the lever and fold down
the seatback. The seat will slide
forward.
Move the seat to the front-most
position.
■Getting out of the vehicle
Depress the release pedal and
fold down the seatback. The
seat will slide forward.
Move the seat to the front-most
position.
Make sure that no passenger is
seated on the second seat
before depressing the release
pedal.
■
After passengers have entered/exited the vehicle
Lift up the seatback and slide t he seat backward until it locks.
Moving a second seat for a ccess to the third seats

1283-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY■
Before folding down the third seats
Stow the third center seat belt. (
P. 3 0 )
Adjust the center head
restraint to the downmost
position.
Stow the third seat belt buck-
les.
Folding down the third seats
1
2
3

1293-3. Adjusting the seats
3
Operation of each component
SEQUOIA_OM_USA_OM0C013U_19MY■
Folding down the third
seats (manual type)
Pull the head restraint lock
release lever to fold the head
restraint.
Pull the lever to unlock the seatback and then fold the seatbac k
down.
1
2
From rear door sideFrom back door side

1303-3. Adjusting the seats
SEQUOIA_OM_USA_OM0C013U_19MY■
Folding down the third
seat (power type)
Press and hold the seatback folding switch until the seatback f olds
down fully and the buzzer sounds.
The outside head restraints are folded automatically.
■ The power third seat can be folded down/returned when
Turn the engine switch to the “LOCK” position or the shift leve r is in P, with the
rear door opened (from rear door side) or back door opened (fro m back door
side).
From rear door sideFrom back door side
