TOYOTA SIENNA 2013 XL30 / 3.G Owners Manual

601
3-7. Using the
storage features
3
Interior features
SIENNA_OM_OM45472U_(U)Ty p e G
Removing the second center
seat. (P. 106)
Type H (if equipped)
Type I (if equipped)
ITN37N026
ITN37N027
Auxiliary boxes

602 3-7. Using the storage features
SIENNA_OM_OM45472U_(U)Type J (if equipped)
Type K (if equipped)
Auxiliary boxes

603
3-7. Using the
storage features
3
Interior features
SIENNA_OM_OM45472U_(U)
■Coin holder (type A)
CAUTION
■Caution while driving (type A and F)
Keep the auxiliary boxes closed.
Injuries may result in the event of an accident or sudden braking.
Nickels, quarters and dimes can be
stored separately.
Auxiliary boxes

604
SIENNA_OM_OM45472U_(U)
3-8. Other interior features
Sun visors
To set the visor in the for-
ward position, flip it down.
To set the visor in the side
position, flip down, unhook,
and swing it to the side.
To use the side extender,
place the visor in the side
position, then slide it back-
ward.

605
3-8. Other interior features
3
Interior features
SIENNA_OM_OM45472U_(U)
Vanity mirrors
NOTICE
■To prevent battery discharge
Do not leave the vanity lights on for extended periods while the engine is off.
Flip down.
Open the cover.
The light turns on when the
cover is opened.

606
3-8. Other interior features
SIENNA_OM_OM45472U_(U)
Clock
: If equipped
■The clock is displayed when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON
mode.
■ When disconnecting and reco nnecting battery terminals
The time display will automatically be set to 1:00.
Vehicles with multi-information display
 P. 254
Vehicles without multi-information display Adjusts the hours.
Adjusts the minutes.

607
3-8. Other interior features
3
Interior features
SIENNA_OM_OM45472U_(U)
Conversation mirror
: If equipped
The conversation mirror can provide the driver and the front passen-
ger with a view of the rear seat area without the need to turn around.
Push the lid and allow the lid
to open.
Push the lid. To first locked
position.STEP1
STEP2

608
3-8. Other interior features
SIENNA_OM_OM45472U_(U)
Power outlets
The power outlet can be used for the following components:
12 V: Accessories that run on less than 10 A
120 V AC: Accessories that use less than 100 W
■ 12 V
Center panel type A
Center panel type B

609
3-8. Other interior features
3
Interior features
SIENNA_OM_OM45472U_(U)
Luggage compartment
■
120 V AC (if equipped)
Power outlet socket console box type A
Power outlet socket console box type B

610 3-8. Other interior features
SIENNA_OM_OM45472U_(U)
■The power outlet can be used when
Vehicles without a smart key system
12 V: The engine switch is in the “ACC” or “ON” position.
120 V AC: The engine switch is in the “ON” position.
Vehicles with a smart key system
12 V: The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
120 V AC: The “ENGINE START STOP” switch is in IGNITION ON mode.
Power outlet socket luggage compartment
