TOYOTA SIENNA HYBRID 2021 Accessories, Audio & Navigation (in English)

3019-2. Connected services operation
9
Connected services
1Select “Update” on the appli-
cation screen. ( P.300)
2 Check that downloading
starts.
“Download in Background”: Select
to operate other functions while
downloading.
“Cancel”: Select to cancel updating.
3Check that downloading is
complete.
“Later”: Select to install later. When
this screen button is selected, the
screen will re turn to the last dis-
played screen. To install the update
data: ( P.301)
“See Detail”: Select to display
detailed information on the update
data.
“Install”: Select to install the update
data. Follow the steps “Installing
the update data” from step 2.
(  P.301)
■Installing the update data
After the downloading is com-
plete, “Update” will be changed
to “Install”.
1 Select “Install” on the appli-
cation screen. ( P.300)
2 Select “Continue”.
“Later”: Select to postpone the
installation of the update data and
go back to the previous screen.
3Check that installing is
started.
“Install in Background”: Select to
operate other functions while
installing.
4Select “OK” after the install-
ing is complete.
●The Toyota apps cannot be oper-
ated while installing.
When problems occur with start-
ing the application player, a
message will appear on the
screen. Referring to the follow-
ing items, identify the problem
and take the suggested correc-
tive action.
“When it is safe and legal to
do so, please ensure your
Toyota mobile application is
running and logged in on your
phone.”
The Toyota mobile application can-
not be connected to Bluetooth
®
SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
https://www.toyotapr.com/
serviciosconectados
in Puerto Rico, to confirm if the
phone is Bluetooth® SPP compati-
ble or not, and then activate the
Toyota mobile application.
“Installation failed, please try
again”
Installation can be attempted again
by changing to the application
screen and pressing the “Install”
switch.
“Application download error.
Please try again later.”
Downloading can be attempted
again by checking the communica-
If a message appears on
the screen

3029-2. Connected services operation
tion status, changing to the applica-
tion screen and pressing the
“Download” switch again.
 “Download error, some
Toyota mobile application
functions may not work as
expected. Please reinitiate
the download process.”
The Toyota mobile application can-
not be connected to Bluetooth
®
SPP.
Refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
https://www.toyotapr.com/
serviciosconectados
in Puerto Rico, to confirm if the
phone is Bluetooth® SPP compati-
ble or not, and then activate the
Toyota mobile application.
Please ensure your Toyota mobile
application is running and logged in
on your phone while vehicle is not
moving.
 “To use the services, Toyota
mobile application needs to
be running on your phone.
For more information, please
visit toyota.com or call 1-800-
331-4331 in the United
States, 1-888-869-6828 in
Canada, and 1-877-855-8377
in Puerto Rico.”
The Toyota mobile application can-
not be connected to Bluetooth
®
SPP.
Refer to https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/connected
in Canada, and
https://www.toyotapr.com/
serviciosconectados
in Puerto Rico, to confirm if the
phone is Bluetooth® SPP compati-
ble or not, and then activate the
Toyota mobile application.
“Communication unsuccess-
ful. Please try again.”
Communication was disconnected.
After a few moments, retry the
operation.
A keyword can be entered to an
application by the software key-
board or voice recognition func-
tion. For details about the
functions and services provided
by each application, refer to
https://www.toyota.com/
connected-services
in the United States,
https://www.toyota.ca/
connected
in Canada, and
https://www.toyotapr.com/
serviciosconectados
in Puerto Rico.
The keyboard layout can be
changed. ( P.60)
Entering keyword opera-
tion

3039-2. Connected services operation
9
Connected services
1Display the application
screen. ( P.300)
2 Select the desired application
screen button.
3 Select the character entering
space.
4 Enter a search term, and
then select “OK”.
5 Entering characters will be
reflected on the character
entering space.
 For details on operating the
keyboard:  P.30
1 Display the application
screen. ( P.300)
2 Select the desired application
screen button.
3 Press the talk switch.
( P.198)
4 Say the desired keyword.
 Completion of the keyword
will be detected automatically.
5 Search results will be dis-
played on the screen.
*: Premium Audio only
●The hands-free system cannot be
used while Destination Assist is
being used.
■From the map screen
1 Press the “MAP” button.
2 Select .
Entering a keyword using
the software keyboard
Entering a keyword using
the voice recognition func-
tion
Destination Assist*
Destination Assist provides
you with live assistance for
finding destinations via the
Toyota response center.
You can request either a
specific business, address,
or ask for help locating your
desired destination by cate-
gory, such as restaurants,
gas stations, shopping cen-
ters or other Points of Inter-
est (POI).
After you tell the agent your
choice of destination, its
coordinates are sent wire-
lessly to your vehicle’s navi-
gation system.
Make a call with Destina-
tion Assist

3049-2. Connected services operation
3Follow the steps in “From the
menu screen” from step 3.
( P.304)
■From the menu screen
1 Press the “MENU” button.
2 Select “Destination”.
3 Select “Dest Assist”.
4 When an agent comes on the
line, tell the agent the
address, business name, or
the type of POI or service.
 To adjust the call volume,
select “-” or “+”, or use the vol-
ume switch on the steering
wheel during the call.
 To hang up the phone, select
“End” or press the switch
on the steering wheel.
5 After the agent helps you
determine your location of
choice, select the screen but-
ton of the desired action.
“Save”: Select to register as a
memory point.
“Go”: Select to set as a destination.
: Select to call the registered
number.

3059-3. Setup
9
Connected services
9-3.Setup
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Apps”.
4 Select the desired items to
be set.
Select to set the pop up
reminder for smartphone
data usage. ( P.305)
Select to detect if an iPhone
app is automatically turned on/off.
Select to turn on/off the
enhanced USB connection
mode
• When an iPhone is connected
while this setting is set to “On”,
communication with devices con-
nected to other USB ports may
not be possible. Also, depending
on the device, charging may not
be possible.
Select to reset all setup items
to default setting.
The data usage notification pop-
up, which indicates that the sys-
tem will use an internet connec-
tion, can be enabled/disabled.
1 Display the Toyota apps set-
tings screen. ( P.305)
2 Select “Data Usage Mes-
sage”.
3 Change the setting as
desired.
Toyota apps settings
Toyota apps settings can be
changed.
Displaying the Toyota
apps settings screen
Toyota apps settings
screen
A
B
'DWDXVDJHQRWLILFDWLRQ
SRSXSVHWWLQJV
C
D

3069-3. Setup

307
Index
Alphabetical Index ......308

308Alphabetical Index
Alphabetical Index
A
AM/FM/SiriusXM® Satellite Radio
............................................... 126 Available HD Radio™ technol- ogy ..................................... 130
Caching a radio program...... 127
Displaying the radio ID ......... 132
How to Subscribe to SiriusXM Services ............................. 131
Overview .............................. 126
Presetting a station .............. 127
Radio broadcast data system ........................................... 129
Radio options ....................... 128
Refer to the table below to iden- tify the problem and take the
suggested corrective action 133
Selecting a station from the list ........................................... 128
Smart favorites ..................... 132
Troubleshooting guide.......... 130
Using HD Radio™ Technology ........................................... 129
Android Auto .......................... 139 Overview .............................. 139
“Android Auto” button (“Menu” screen) .............................. 14, 54
Apple CarPlay
®/Android Auto™
................................................. 53 Establishing an Android Auto connection ............................ 54
Establishing an Apple CarPlay connection ............................ 53
Troubleshooting ..................... 56
“Apple CarPlay” button (“Menu” screen) .............................. 14, 53
“Apps” button (“Menu” screen) ......................................... 14, 300
“APPS” button ..... .............12, 300
Audio/visual remote controls 144
“Audio” button (“Menu” screen) .........................................14, 120
“Audio” button (“Setup” screen) .........................................18, 145
“AUDIO” button ........12, 120, 121
Audio settings.........................145 Audio settings screen ...........145
Displaying the audio settings screen.................................145
B
Basic function ...........................12
Basic information before opera-tion ...........................................26
Basic operation.................72, 120
Bluetooth
® audio ....................140
Overview ..............................140
Registering/Connecting a
Bluetooth
® device ...............142
Bluetooth
® phone message func-
tion .........................................270 Calling the message sender .273
Checking received messages ...........................................271
Displaying the message screen ...........................................270
Receiving a mess age ...........270
Replying to a message (dictation reply) ..................................272
Replying to a message (quick reply) ..................................272
“Bluetooth” button (“Setup” screen) ...............................18, 40
Buttons overview......................12 Operations of each part ..........12
C
Checking around the vehicle.227Screen display ......................227
Checking the front and around the vehicle .............................228

Alphabetical Index309
Screen display...................... 228
Checking the rear and around the vehicle............................. 234Guide lines displayed on the screen ................................ 237
Parking ................................. 239
Screen display...................... 234
Checking the sides of the vehicle ............................................... 231Screen display...................... 231
“Climate” button (“Menu” screen) .................................... 14
Clock settings ..................... 14, 61
Command list ......................... 186 Command list overview ........ 186
Connected services ............... 290 Functional overview ............. 290
Connected services operation ............................................... 300
Connected services overview290
Connectivity settings ............... 36
Customizing the panoramic view monitor .................................. 243Changing the body color dis- played in the panoramic view
monitor ............................... 243
D
“Data Services” button (“Setup”
screen) ............................ 18, 196
Data services settings ........... 196 Setting download methods ... 196
Destination Assist .................. 303 Make a call with Destination Assist.................................. 303
“Destination” button (“Menu” screen) .............................. 14, 84
Destination search ................... 84
Destination search operation .. 84 Destination screen ................. 84
One-touch setting home/favorite as a destination .................... 90 Searching by address.............87
Searching by contact ..............87
Searching by Destination Assist
.............................................86
Searching by emergency........86
Searching by favorites list ......85
Searching by keyword ............85
Searching by point of interest .88
Searching by recent destinations .............................................86
Selecting search area .............84
Setting home as destination ...85
Detailed navigatio n settings ..106
Detailed navigation settings screen.................................106
Displaying the detailed naviga- tion settings screen ............106
“Display” button (“Menu” screen) ...............................14, 33
Distance guide line display mode ...............................................213Screen description................213
E
“ECO” button (“Information” screen) .....................................19
Editing route .............................99 Displaying the edit route screen.............................................99
Entering letters and numbers/list screen operation.....................30Entering letters and numbers .30
List screen ..............................31
Estimated course line display mode ......................................210Screen description................210
External devices ... ..................164
HDMI settings .......................164
G
“General” button (“Setup”

310Alphabetical Index
screen) .............................. 18, 60
General settings ....................... 60 Displaying the general settings screen .................................. 60
General settings screen ......... 60
GPS (Global Positioning System) ............................................... 115Limitations of the navigation sys- tem ..................................... 115
Guiding the route ..................... 21 Deleting destinations .............. 21
Setting the destination............ 21
H
“HOME” button ................... 12, 29
Home screen ............................. 29Home screen operation .......... 29
I
“Info” button (“Menu” screen) ............... 14, 19
Information display ................ 194
“Information” screen ............... 19
Initial screen ............................. 26 Caution screen ....................... 26
Maintenance information ........ 26
Restarting the system ............ 26
iPod/iPhone (Apple CarPlay) . 136 Overview .............................. 136
L
Linking multi-information display and the system ....................... 35
M
Magnifying function ............... 242 Magnifying the display.......... 242
“MAP” button...................... 12, 72
Map database version and cov- ered area ............................... 117 Map information....................117
Temporary updates of the map
...........................................117
Map screen information ...........76 Displaying information about the icon where the cursor is set..80
Displaying the map options screen...................................76
Standard map icons ...............81
Map screen operation ..............74 Current position display ..........74
Map scale ...............................74
Map scroll operation ...............75
Orientation of the map ............75
Media operation ......................134
“MENU” button ...................12, 14
“Menu” screen ..........................14 “Menu” screen operation ........14
Mobile Assistant .....................191 Connectable devices and avail-able functions .....................191
Mobile Assistant operation ...191
N
Natural language understanding ...............................................185
Navigation .................................72 Map screen overview .............72
“Navigation” button (“Setup” screen) .............................18, 102
Navigation operation ................20
Navigation settings ................102 Displaying navigation settings screen.................................102
Navigation settings screen ...102
Setting up areas to avoid......104
Setting up favorites list .........103
Setting up home ...................102
O
Operating information ....148, 173
