Interior light
To turn on the interior light, slide the
switch.
The interior light switch has the following
positions:
ªONºÐKeeps the light on all the time.
ªOFFºÐTurns the light off.
ªDOORºÐTurns the light on when either
door is opened. The light goes off when
both doors are closed.ILLUMINATED ENTRY SYSTEM
With the switch in the ªDOORº position,
the light comes on when either door is
opened. After both doors are closed, the
light remains on for about 15 seconds and
then goes out.
However, in the following cases, the light
goes out immediately:

Both doors are closed when the igni-
tion key is in ªACCº or ªONº

Both doors are closed and locked
When either door is unlocked with the
wireless remote control transmitter, the
light comes on for 15 seconds, even if the
door is not opened.
Ignition switch light
For easy access to the ignition switch,
the ignition switch light comes on when
either doors are opened.
The light remains on for a certain time
after both doors are closed.
When either door is unlocked with the
wireless remote control transmitter, the
light comes on for 15 seconds, even if the
door is not opened.
When both doors are locked or the igni-
tion switch is turned to ªACCº, ªONº after
both doors are closed, the light fades out.

'01 SOLARA_U (L/O 0009)
882001 MY SOLARA (OM33527U)
Personal lights
Coupe
Convertible
CoupeÐ
To turn on the personal light, push the
switch. To turn it off, push the switch
once again.
ConvertibleÐ
The personal lights operate separately
with each outer switch.
To turn on the light, push the switch on
your side. To turn the light off, push the
switch once again.
The center switch has the following posi-
tions:
ªDOORºÐTurn both lights on when either
door is opened.
ªOFFºÐThe lights are off unless you oper-
ate either outside switch.
ILLUMINATED ENTRY SYSTEM
(convertible)
With the switch in the ªDOORº position,
the light comes on when either door is
opened. After both doors are closed, the
light remains on for about 15 seconds and
then goes out.
However, in the following cases, the light
goes out immediately:

Both doors are closed when the igni-
tion key is in ªACCº or ªONº

Both doors are closed and lockedWhen either door is unlocked with the
wireless remote control transmitter, the
light comes on for 15 seconds, even if the
door is not opened.

'01 SOLARA_U (L/O 0009)
892001 MY SOLARA (OM33527U)
To turn on the windshield wipers, move
the lever to the desired setting.
The key must be in the ªONº position.Lever position
Speed setting
Position 1Intermittent
Position 2Slow
Position 3Fast
With interval adjuster: The ªINT TIMEº
band lets you adjust the wiping time inter-
val when the wiper lever is in the intermit-
tent position (position 1). Twist the band
upward to increase the time between
sweeps, and downward to decrease it. To squirt washer fluid, pull the lever
toward you.
If the windshield wipers are off, they will
operate a couple of times after the washer
squirts.
For instructions on adding washer fluid,
see ªAdding washer fluidº in Section 7±3.
In freezing weather, warm the windshield
with the defroster before using the washer.
This will help prevent the washer fluid
from freezing on your windshield, which
can block your vision.
NOTICE
Do not operate the wipers if the wind-
shield is dry. It may scratch theglass.
Ty p e A
Ty p e B
Windshield wipers and
washer Rear window and outside
rear view mirror defoggers

'01 SOLARA_U (L/O 0009)
902001 MY SOLARA (OM33527U)
To defog or defrost the rear window,
push the switch.
The key must be in the ªONº position.
The thin heater wires on the inside of the
rear window will quickly clear the sur-
faces. An indicator light will illuminate to
indicate the defogger is operating.
On some models, heater panels in the
outside rear view mirrors will also quickly
clear the surfaces.
Push the switch once again to turn the
defogger off.
The system will automatically shut off af-
ter the defogger has operated about 15
minutes.
CAUTION
Since the mirror surfaces can get hot
keep your hands off them when the
defogger switch is on.
Make sure you turn the defoggers off
when the surfaces are clear. Leaving the
defoggers on for a long time could cause
the battery to discharge, especially during
stop±and±go driving. The defoggers are
not designed for drying rain water or for
melting snow.If the outside rear view mirrors are heavi-
ly coated with ice, use a spray de±icer
before operating the switch.
NOTICE
When cleaning the inside of the
rear window, be careful not toscratch or damage the heater wiresor connectors.
Convertible: When the convertibletop is completely lowered, keep therear window defogger turned off to
avoid damage to the convertibletop.

'01 SOLARA_U (L/O 0009)
912001 MY SOLARA (OM33527U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Gauges, Meters and Service reminder indicators
Fuel gauge92
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Engine coolant temperature gauge 92
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Odometer and two trip meters 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 94
. . . . . . . . . . . . . . .
SECTION 1± 5

'01 SOLARA_U (L/O 0009)
922001 MY SOLARA (OM33527U)
Fuel gauge
Low fuel level
warning light
The gauge works when the ignition
switch is on and indicates the approxi-
mate quantity of fuel remaining in the
tank.
Nearly fullÐNeedle at ªFº
Nearly emptyÐNeedle at ªEº
It is a good idea to keep the tank over
1/4 full.
This fuel gauge has a non±return type
needle which remains at the last indicated
position when the ignition switch is turned
off.
If the fuel level approaches ªEº or the low
fuel level warning light comes on, fill the
fuel tank as soon as possible.On inclines or curves, due to the move-
ment of fuel in the tank, the fuel gauge
needle may fluctuate or the low fuel level
warning light may come on earlier than
usual.
If the fuel tank is completely empty, the
malfunction indicator lamp comes on. Fill
the fuel tank immediately.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.The gauge indicates the engine coolant
temperature when the ignition switch is
on. The engine operating temperature
will vary with changes in weather and
engine load.
If the needle moves into the red zone,
your engine is too hot. If your vehicle
overheats, stop your vehicle and allow the
engine to cool.
Your vehicle may overheat during severe
operating conditions, such as:

Driving up a long hill on a hot day.

Reducing speed or stopping after high
speed driving.
Engine coolant temperature
gauge

'01 SOLARA_U (L/O 0009)
932001 MY SOLARA (OM33527U)

Idling for a long period with the air
conditioning on in stop±and±go traffic.

Towing a trailer.
NOTICE
Do not remove the thermostat inthe engine cooling system as thismay cause the engine to overheat.The thermostat is designed to con-
trol the flow of coolant to keep thetemperature of the engine withinthe specified operating range.
Do not continue driving with anoverheated engine. See ªIf your ve-hicle overheatsº in Section 4.
Tachometer
The tachometer indicates engine speed
in thousands of rpm
( revolutions per
minute). Use it while driving to select
correct shift points and to prevent en-
gine lugging and over±revving.
Driving with the engine running too fast
causes excessive engine wear and poor
fuel economy. Remember, in most cases
the slower the engine speed, the greater
the fuel economy.
NOTICE
Do not let the indicator needle get into the red zone. This may causesevere engine damage.
Odometer and two trip meters
This meter displays the odometer and
two trip meters.
1. OdometerÐShows the total distance the vehicle has been driven.
2. Two trip metersÐShow two different distances independently driven since
the last time each trip meter was set
to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected.

'01 SOLARA_U (L/O 0009)
942001 MY SOLARA (OM33527U)
3. Trip meter reset knobÐResets the twotrip meters to zero, and also change
the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push.
To reset the trip meter A to zero, dis-
play the meter A reading, then push
and hold the knob until the meter is
set to zero. The same process can be
applied for resetting the trip meter B.
(c) Fasten front passenger 's seat
belt.
(a) If parking brake is
off, stop
immediately and
contact Toyota
dealer.
(b) Fasten driver 's seat belt.
If the indicator or
buzzer comes on...
(d) Stop and check.
(e) Take vehicle to Toyota dealer.
or
(indicator and buzzer)Do this. (g) Stop and check.
(h)Take vehicle to
Toyota dealer.
(i) Close all doors.
(j) Replace bulb.
or
(f)
Fill up tank.
Low fuel level
warning light
If the indicator or
buzzer comes on...
Do this.
Service reminder indicators
an d warn in g bu zzers

'01 SOLARA_U (L/O 0009)
952001 MY SOLARA (OM33527U)
(l)Add washer fluid.
(m) Take vehicle to
Toyota dealer.
(n) Remove key.
Key reminder
buzzer
(k) Take vehicle to
Toyota dealer
immediately.
If the indicator or
buzzer comes on... Do this.
(a) Brake System Warning Light
This light comes on in the following cases
when the ignition key is in the ªONº posi-
tion.

When the parking brake is applied...

When the brake fluid level is low...
CAUTION
It is dangerous to continue driving
normally when the brake fluid level is
low.
Have your vehicle checked at your
Toyota dealer in the following case:

The light does not come on even if the
parking brake is applied when the igni-
tion key is in the ªONº position.
CAUTION
If the light does not turn off even
after the parking brake is released
while the engine is running, immedi-
ately stop your vehicle at a safe
place and contact your Toyota dealer.
In this case, the brakes may not work
properly and your stopping distance
will become longer. Depress the brake
pedal firmly and bring the vehicle to
an immediate stop.
(b) Driver's Seat Belt Reminder Light
and Buzzer
This light and buzzer remind you to
buckle up the driver's seat belt.
Once the ignition key is turned to ªONº or
ªSTARTº, the reminder light and buzzer
come on if the driver's seat belt is not
fastened. Unless the driver fastens the
belt, the light stays on and the buzzer
stops after about 4 to 8 seconds.

'01 SOLARA_U (L/O 0009)
962001 MY SOLARA (OM33527U)
(c) Front Passenger 's Seat Belt Re-minder Light
This light reminds you to buckle up the
front passenger 's seat belt.
Once the ignition key is turned to ªONº or
ªSTARTº, the reminder light comes on if
a passenger sits in the front passenger
seat and does not fasten the seat belt.
Unless the front passenger fastens the
belt, the light stays on. This light reminds
you to buckle up, the front passenger 's
seat belt.
If luggage load is placed on the front
passenger seat, depending on its weight
and how it is placed on the seat, built±in
sensors in the seat cushion may detect
the pressure, causing the reminder light to
come on.
(d) Discharge Warning Light
This light warns that the battery is being
discharged.
If it comes on while you are driving, there
is a problem somewhere in the charging
system.
The engine ignition will continue to oper-
ate, however, until the battery is dis-
charged. Turn off the air conditioning,
blower, radio, etc., and drive directly to
the nearest Toyota dealer or repair shop.NOTICE
Do not continue driving if the engine drive belt is broken or loose.
(e) Malfunction Indicator Lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty. (See ªFuel gaugeº in this section for
instructions.)
b. The fuel tank cap is not tightened se- curely. (See ªFuel tank capº in Section
1±2 for instructions.)
c. There is a problem somewhere in your engine or automatic transmission elec-
trical system.
If it comes on while you are driving in
case c, have your vehicle checked/re-
paired by your Toyota dealer as soon as
possible.
(f) Low Fuel Level Warning Light
This light comes on when the fuel level
in the tank becomes nearly empty. Fill up
the tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the low fuel level
warning light may come on earlier than
usual. (g) Low Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are
driving, pull off the road to a safe place
and stop the engine immediately. Call a
Toyota dealer or qualified repair shop for
assistance.
The light may occasionally flicker when
the engine is idling or it may come on
briefly after a hard stop. There is no
cause for concern if it then goes out when
the engine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to
indicate low oil level, and the oil level
must be checked using the level dipstick.
NOTICE
Do not drive the vehicle with the
warning light onÐeven for one block.It may ruin the engine.
