TOYOTA SOLARA 2001 Owners Manual (in English)

'01 SOLARA_U (L/O 0009)
972001 MY SOLARA (OM33527U)
(h) ªABSº Warning Light
The light comes on when the ignition key
is turned to the ªONº position. If the anti±
lock brake system works properly, the
light turns off after a few seconds. There-
after, if the system malfunctions, the light
comes on again.
When the ªABSº warning light is on (and
the brake system warning light is off), the
anti±lock brake system and the traction
control system do not operate, but the
brake system still operates conventionally.
When the ªABSº warning light is on (and
the brake system warning light is off), the
anti±lock brake system does not operate
so that the wheels could lock up during
a sudden braking or braking on slippery
road surfaces.
If either of the following conditions
occurs, this indicates a malfunction
somewhere in the parts monitored by
the warning light system. Contact your
Toyota dealer as soon as possible to
service the vehicle.

The light does not come on when the
ignition key is turned to the ªONº posi-
tion, or remains on.

The light comes on while you are driv-
ing.A warning light turning on briefly during
operation does not indicate a problem.
(i) Open Door Warning Light
This light remains on until both doors are
completely closed.
(j) Rear Light Failure Warning Light
If this light comes on when the headlight
switch is turned on (at the first or second
clickstop), it indicates that one or more of
the tail lights are burned out.
If it comes on when the brake pedal is
depressed, one or more stop lights are
burned out.
Have defective bulbs replaced as soon as
possible.
(k) SRS Warning Light
This light will come on when the igni-
tion key is turned to the ªACCº or
ªONº position. After about 6 seconds,
the light will go off. This means the
systems of the airbag and front seat
belt pretensioner are operating properly.
This warning light system monitors the
airbag sensor assembly, front airbag sen-
sors, side airbag sensors, front seat belt
pretensioner assemblies, inflators, warning
light, interconnecting wiring and power
sources. If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.

The light does not come on when the
ignition key is turned to the ªACCº or
ªONº position or remains on.

The light comes on or flashes while
driving.
(l) Low Windshield Washer Fluid Level Warning Light
The light warns that the windshield washer
fluid level is too low. Add washer fluid at
your earliest opportunity. (For instructions,
see ªAdding washer fluidº in Section 7±3.)
(m) ªTRAC OFFº Indicator/Warning Light
This light comes on when the ignition key
is turned to ªONº, and will go off after a
few seconds. This means that the system
is operating properly.
If one of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.

The light remains on more than a few
seconds after the ignition switch is
turned on.

'01 SOLARA_U (L/O 0009)
982001 MY SOLARA (OM33527U)

The light comes on while driving even
if the ªTRAC OFFº switch is not
pushed.

The light flashes.
(n) Key Reminder Buzzer
This buzzer reminds you to remove the
key when you open the driver 's door with
the ignition key in the ªACCº or ªLOCKº
position. CHECKING SERVICE REMINDER
INDICATORS (except the low fuel level
warning light and low windshield
washer fluid level warning light)
1. Apply the parking brake.
2. Open one of the doors. The open door warning light should
come on.
3. Close the door. The open door warning light should go
off.
4. Turn the ignition key to ªACCº. The SRS warning light should come on.
It goes off after about 6 seconds.
5. Turn the ignition key to ªONº, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light and
SRS warning light should come on. The
ªABSº, ªTRAC OFFº and slip indicator
lights go off after a few seconds.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, have it checked by your Toyota
dealer as soon as possible.

'01 SOLARA_U (L/O 0009)
992001 MY SOLARA (OM33527U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Ignition switch,Transmission and Parking brake
Ignition switch with steering lock100
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission 101
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Manual transmission 105
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Parking brake 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Cruise control 107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
SECTION 1± 6

'01 SOLARA_U (L/O 0009)
1002001 MY SOLARA (OM33527U)
ªSTARTºÐStarter motor on. The key
will return to the ªONº position when
released.
For starting tips, see Section 3.
ªONºÐEngine on and all accessories
on.
This is the normal driving position.
ªACCºÐAccessories such as the radio
operate, but the engine is off.
If you leave the key in the ªACCº or
ªLOCKº position and open the driver's
door, a buzzer will remind you to remove
the key.ªLOCKºÐEngine is off and the steering
wheel is locked. The key can be re-
moved only at this position.
You must push in the key to turn the key
from ªACCº to the ªLOCKº position. On
vehicles with an automatic transmission,
the selector lever must be put in the ªPº
position before pushing the key.
Vehicles with engine immobiliser systemÐ
Once you remove the key, the engine im-
mobiliser system is automatically set. (See
ªEngine immobiliser systemº in Section
1±2.)
When starting the engine, the key may
seem stuck at the ªLOCKº position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.
CAUTION
For manual transmission:
Never remove the key when the ve-
hicle is moving, as this will lock the
steering wheel and result in loss of
steering control.
NOTICE
Do not leave the key in the ªONº
position if the engine is not running.The battery will discharge and theignition could be damaged.
Ignition switch with steering
lock

'01 SOLARA_U (L/O 0009)
1012001 MY SOLARA (OM33527U)
Automatic transmission
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of ªPº position when the
brake pedal is depressed (with the ignition
switch in ªONº position and the lock re-
lease button depressed).
(a) Selector lever
The shift position is also displayed on the
instrument cluster.
P:Parking, engine starting and
key removal
R: Reverse
N: Neutral
D: Normal driving (with overdrive on)
2: Stronger engine braking
L: Maximum engine braking
Lock release button
To prevent misshifting
With the brake pedal depressed,
shift while holding the lock release
button in. (The ignition switch must
be in ªONº position.) Shift while holding the
lock release button in.
Shift normally. Selector lever
Overdrive
switch

'01 SOLARA_U (L/O 0009)
1022001 MY SOLARA (OM33527U)
(b) Overdrive switch
You can select either third gear (with
overdrive off) or fourth gear (with over-
drive on) by pushing this switch.
To turn the overdrive off, push the switch.
The ªO/D OFFº indicator light should come
on. To turn the overdrive on again, push
the switch again. The ªO/D OFFº indicator
light should go off.
Always drive your vehicle with the over-
drive on for better fuel economy and
quieter driving.
If the engine is turned off when the over-
drive is off and restarted, the overdrive
will be on automatically.Vehicles with cruise controlÐWhen the
cruise control is being used, even if you
downshift the transmission by pushing and
releasing the overdrive switch, engine
braking will not be enabled because the
cruise control is not cancelled.
For ways to decrease the vehicle speed,
see ªCruise controlº in this section.
(c) Normal driving
1. Start the engine as instructed in ªHow to start the engineº in Section 3. The
transmission must be in ªPº or ªNº.
2. With your foot holding down the brake pedal, shift the selector lever to ªDº.
When the lever is in the ªDº position, the
automatic transmission system will select
the most suitable gear for running condi-
tions such as normal cruising, hill climb-
ing, hard towing, etc.
Always turn the overdrive on for better
fuel economy and quieter driving. If the
engine coolant temperature is low, the
transmission will not shift into overdrive
gear even with the overdrive on.
CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake pedal. Depress the accelerator pedal
slowly for smooth starting.
(d) Using engine braking
To use engine braking, you can downshift
the transmission as follows:

Push the overdrive switch. The ªO/D
OFFº indicator light will come on and
the transmission will downshift to third
gear.

Shift into the ª2º position. The trans-
mission will downshift to second gear
when the vehicle speed drops down to
or lower than the following speed, and
stronger engine braking will be en-
abled.
5S±FE engine 112 km/h (69 mph) . . . . .
1MZ±FE engine 122 km/h (75 mph) . . . .

Shift into the ªLº position. The trans-
mission will downshift to first gear
when the vehicle speed drops down to
or lower than the following speed, and
maximum engine braking will be en-
abled.
5S±FE engine 50 km/h (31 mph). . . . . .
1MZ±FE engine 54 km/h (33 mph) . . . . .

'01 SOLARA_U (L/O 0009)
1032001 MY SOLARA (OM33527U)
Vehicles with cruise controlÐWhen the
cruise control is being used, even if you
downshift the transmission by pushing and
releasing off the overdrive switch, engine
braking is not enabled because the cruise
control is not cancelled.
For ways to decrease the vehicle speed,
see ªCruise controlº in this section.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
(e) Using ª2º and ªLº positions
The ª2º and ªLº positions are used for
strong engine braking as described pre-
viously.
With the selector lever in ª2º or ªLº, you
can start the vehicle in motion as with the
lever in ªDº.
With the selector lever in ª2º, the vehicle
will start in first gear and automatically
shift to second gear.
With the selector lever in ªLº, the trans-
mission is engaged in first gear.
NOTICE
Be careful not to over±rev the en-gine. Watch the tachometer to keepengine rpm from going into the redzone. The approximate maximum al-
lowable speed for each position isgiven below for your reference:
ª2º 125 km/h (77 mph)
. . . . . . . . . . . .
ªLº 69 km/h (42 mph). . . . . . . . . . . . .

Do not continue hill climbing or hard towing for a long time in theª2º or ªLº position. This may causesevere automatic transmission dam-
age from overheating. To preventsuch damage, ªDº position shouldbe used in hill climbing or hard
towing.
(f) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the selector lever to the
ªRº position.
NOTICE
Never shift into reverse while the ve-
hicle is moving.
(g) Parking
1. Bring the vehicle to a complete stop.
2. Pull the parking brake lever up fully to securely apply the parking brake.
3. With the brake pedal pressed down, shift the selector lever to the ªPº posi-
tion.
CAUTION
Never attempt to move the selector
lever into ªPº position under any cir-
cumstances while the vehicle is mov-
ing. Serious mechanical damage and
loss of vehicle control may result.
(h) Good driving practice

If the transmission repeatedly shifts up
and down between third gear and over-
drive when climbing a gentle slope, the
overdrive should be turned off. Be sure
to turn the switch on immediately after-
ward.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use overdrive.

'01 SOLARA_U (L/O 0009)
1042001 MY SOLARA (OM33527U)
CAUTION
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.
NOTICE
Do not hold the vehicle on an up-grade with the accelerator pedal. Itcan cause the transmission to over-heat. Always use the brake pedal or
parking brake.
(i) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in
snow, mud, sand, etc., then you may
attempt to rock your vehicle free by
moving it forward and backward. Do
not attempt this procedure if people
or objects are anywhere near the ve-
hicle. During the rocking operation
the vehicle may suddenly move for-
ward or backward as it becomes un-
stuck, causing injury or damage to
nearby people or objects.
NOTICE
If you rock your vehicle, observe thefollowing precautions to prevent dam-age to the transmission and otherparts.
Do not depress the accelerator ped-al while shifting the selector leveror before the transmission is com-
pletely shifted to forward or reversegear.
Do not race the engine and avoidspinning the wheels.
If your vehicle remains stuck after
rocking the vehicle several times,consider other ways such as tow-ing.
(j) If you cannot shift the selector le-
ver out of ªPº position
If you cannot shift the selector lever from
ªPº position even though the brake pedal
is depressed, use the shift lock override
button. For instructions, see ªIf you cannot
shift automatic transmission selector leverº
in Section 4.

'01 SOLARA_U (L/O 0009)
1052001 MY SOLARA (OM33527U)
Manual transmission
The shift pattern is conventional as
shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake.Recommended shifting speeds
The transmission is fully synchronized and
upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the following
speeds:
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
Upshifting too soon or downshifting too
late will cause lugging, and possibly ping-
ing. Regularly revving the engine to maxi-
mum speed in each gear will cause ex-
cessive engine wear and high fuel
consumption. Maximum allowable speeds
To get on a highway or to pass slower
traffic, maximum acceleration may be nec-
essary. Make sure you observe the follow-
ing maximum allowable speeds in each
gear:
gear km/h (mph)
1 52 (32)
2 93 (57)
3 147 (91)
NOTICE
Do not downshift if you are going
faster than the maximum allowablespeed for the next lower gear.

'01 SOLARA_U (L/O 0009)
1062001 MY SOLARA (OM33527U)
Good driving practice

If it is difficult to shift into reverse, put
the transmission in neutral, release the
clutch pedal momentarily, and then try
again.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use the fifth gear.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
NOTICE
Make sure the vehicle is completelystopped before shifting into reverse.
Parking brake
Ty p e A
Ty p e B
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
To set: Pull up the lever. For better hold-
ing power, first depress the brake pedal
and hold it while setting the parking
brake.
To release: Pull up the lever slightly (1),
press the lock release button (2), and low-
er (3).
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.
