TOYOTA SUPRA 2020 Accessories, Audio & Navigation (in English)
Manufacturer: TOYOTA, Model Year: 2020, Model line: SUPRA, Model: TOYOTA SUPRA 2020Pages: 92, PDF Size: 1.94 MB
Page 41 of 92
412-1. ENTERTAINMENT
Supra_Navi_(U)
2
ENTERTAINMENT
1 "Media/Radio"
2 "FM " or "AM "
3 Move the Controller to the
left.
4 "Save station"
The storage list is displayed.
5Select the desired memory
location.
1 "Media/Radio"
2 "FM " or "AM "
3 Highlight the desired station.
4 Press the Controller and hold
until the storage list is dis-
played.
5 Select the desired memory
location.
The stations can also be stored
on the programmable memory
buttons, see the Owner's Man-
ual for the vehicle.
Station selection via the fre-
quency. 1
"Media/Radio"
2 "FM " or " AM"
3 Move the Controller to the
left.
4 "Manual search"
5 To select the frequency: turn
the Controller.
6 To store the frequency: press
the Controller.
When storing a station with RDS
signal, the RDS information
transferred during storing is
accepted as the station name.
The station name can be
changed.
1 "Media/Radio"
2 "FM "
3 Select the desired station.
4 Press the button.
5 "Rename to: "
If necessary, wait until the name of
the desired station appears.
6Press the Controller to store
this name.
If a radio station broadcasts
radio text or radio text plus, this
information can be displayed,
for instance the track or per-
SymbolMeaning
Station is not stored.
Station is already stored.
Storing the station being
played
Storing a station that is not
being played
Selecting a station manu-
ally
Renaming a station
Additional station informa-
tion
Concept
Page 42 of 92
422-1. ENTERTAINMENT
Supra_Navi_(U)
former of the music.
Availability, content and
sequence are set by the radio
station.
1"Media/Radio"
2 "FM "
3 Select the desired station.
4 Press the button.
5 "Station info"
Many radio stations broadcast
both analog and digital signals.
When setting a station with a
digital signal, it may take a few
seconds before the station plays
in digital quality.
Information about HD Radio sta-
tions whose station name ends
with ...HD or with ...HD1:
In areas in which the station is
not continuously received in dig-
ital mode, the playback switches
between analog and digital
reception. In this case, switch off
digital radio reception.
Information about HD Radio multicast stations whose station
name ends with ...HD2, ...HD3,
...:
In areas in which the station is
not continuously received in dig-
ital mode, there may be interrup-
tions of the audible signal lasting
several seconds. The duration
of the interruption depends on
the reception.
1
"Media/Radio"
2 "FM " or " AM"
Depending on the vehicle equip-
ment and country version, it may
not be possible to receive AM sta-
tions.
3 Press the button.
4 "HD Radio reception "
This symbol is displayed in
the status line when the audio
signal is digital.
Some stations broadcast addi-
tional information on the current
track, such as the name of the
artist.
1 "Media/Radio"
2 "FM " or " AM"
Depending on the vehicle equip-
ment and country version, it may
not be possible to receive AM sta-
tions.
Displaying additional station
information
HD Radio™ reception
Concept
General information
Activating/deactivating digi-
tal radio reception
Displaying additional infor-
mation
Page 43 of 92
432-1. ENTERTAINMENT
Supra_Navi_(U)
2
ENTERTAINMENT
3 Select a station.
4 Press the button.
5 "Station info"
HD Radio Technology manufac-
tured under license from iBiquity
Digital Corporation. U. S. and
Foreign Patents. HD Radio™
and the HD, HD Radio, and
"Arc " logos are proprietary
trademarks of iBi quity Digital
Corp.
Before a channel can be played,
you must subscribe to it via tele-
phone. Several channels can be
combined into specified pack-
ages.
In order to enable or unsub-
scribe from channels, you must
have reception. It is usually at its best when you have an unob-
structed view of the sky.
The channel name is displayed
in the status line.
1
"Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Show subscription info "
The phone number and identifica-
tion number of the radio are dis-
played.
5Call the phone number to
have the channel enabled.
You can unsubscribe from the
channels again via this phone
number.
1 "Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Show subscription info "
The phone number and identifica-
tion number of the radio are dis-
played.
5Call the phone number to
cancel your subscription to
the channel.
You can only listen to enabled
channels.
License conditions
Satellite radio
General information
Managing a subscription
General information
Enabling channels
Unsubscribing from chan-
nels
Selecting channels
Page 44 of 92
442-1. ENTERTAINMENT
Supra_Navi_(U)
1"Media/Radio"
2 "Satellite radio "
The last station listened to will be
played and the station list dis-
played.
3 Select the desired channel
from the channel list.
To display information about the
selected channel:
1 Highlight a channel.
2 Press the button.
3 "Channel information "
The display of the playback list
can be adjusted.
1 "Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Change view "
5 Select the desired display:
"Channel "
The name of the channel will be
displayed.
"Artist "
The name of the ar tist playing will
be displayed.
"Titles "
The name of the track playing will
be displayed.
The next and/or previous chan-
nel from the channel list is
played.
1"Media/Radio"
2 "Satellite radio "
A symbol on the highlighted
channel indicates whether the
channel has already been
stored.
To store the channel played:
1 Move the Controller to the
left.
2 "Save station "
The storage list is displayed.
3Select the desired memory
location.
Or:
1 Highlight the played channel.
2 Press the Controller.
The storage list is displayed.
3Select the desired memory
location.
To store a channel other than
the one played:
Adjusting display of the
channel list
Changing the channel
Press the button on the
radio.
Storing a channel
Sym-
bolMeaning
Channel is not stored.
Channel is already stored.
Page 45 of 92
452-1. ENTERTAINMENT
Supra_Navi_(U)
2
ENTERTAINMENT
1 Highlight the played channel.
2 Press the Controller and hold
until the storage list is dis-
played.
3 Select the desired memory
location.
Or:
1 Highlight the played channel.
2 Press the button.
3 "Save in presets "
The storage list is displayed.
4Select the desired memory
location.
The stations can also be stored
on the programmable memory
buttons.
1 "Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Category "
5 Select the desired category.
The subscribed channels from this
category are displayed.
6Select the desired channel.
The channel you are currently
listening to is stored in a buffer
for up to an hour. Prerequisite: the signal must be
available.
The stored audio track can be
played with a delay following the
live broadcast. When the mem-
ory is full, the older tracks are
overwritten. The memory is
cleared when a new channel is
selected or when the vehicle is
switched off.
1
"Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Time shift "
Within the stored recording, it is
possible to jump to any point in
time.
You can jump to the next or the
previous track.
The recording is spooled for-
ward or back.
Selecting a category
Timeshift
General information
Opening the timeshift func-
tion
Time shift forward/reverse
Press the button on the
radio or turn the Control-
ler.
Press and hold the but-
ton on the radio.
Page 46 of 92
462-1. ENTERTAINMENT
Supra_Navi_(U)
With automatic timeshift, audio
playback is paused for the fol-
lowing events.
Incoming and outgoing tele-
phone calls.
Activation of the voice activa-
tion system.
Muting.
After that, audio playback is
continued from the time of the
interruption.
1 Move the Controller to the
left.
2 To activate: "Automatic
time shift "
Deactivate: "Automatic time
shift".
A maximum of 6 channels can
be stored as Smart Favorites.
If a stored channel is selected, the current track will be played
from the beginning.
1
Press the button.
2 "Add to Smart Favorites "
1 Press the button.
2 "Remove from Smart
Favorites "
1 "Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Category "
5 Select a Smart Favorite.
The subscribed channels from this
category are displayed.
6Select the desired channel.
A performer, a track, a league or
a team can be stored as a favor-
ite. If the stored favorite is
played on a channel, a message
appears on the Control Display.
Timeshift menu
Sym-
bolFunction
Go to the liv e broadcast.
Automatic timeshift deacti-
vated/activated.
/Playback/pause.
Automatic timeshift
Smart Favorites
General information
Adding the current channel
to Smart Favorites
Removing the current chan-
nel from Smart Favorites
Selecting Smart Favorite
Favorites
General information
Page 47 of 92
472-1. ENTERTAINMENT
Supra_Navi_(U)
2
ENTERTAINMENT
Up to 30 Favorites can be
stored.
It is only possible to store Favor-
ites that are currently being
broadcast. The channel informa-
tion must be available.
1 "Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Add to favorites"
5 Highlight the performer or
track, and press the Control-
ler.
A symbol indicates whether the
artist and track were already
stored.
1 "Media/Radio"
2 "Satellite radio "
3 Move the Controller to the
left.
4 "Add to favorites"
5 "Add sports information" 6
Select the type of sport
desired.
7 Select the desired team.
A notification can be displayed
when a selected favorite is
being played.
1 "Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Manage favorites "
The stored Favorites are displayed.
5"Activate alert "
Set a check mark to activate notifi-
cation for the sele cted Favorites.
Remove the check mark to deacti-
vate notification for the selected
Favorites.
6 Select the desired Favorites.
If an activated favorite is played
back, the following message is
displayed for approx. 20 sec-
onds:
"Favorite on air! ".
To change to the played Favor-
ites:
Tap on the message on the
Control Display.
Or:
1 Move the Controller to the
left.
Storing the artist or trackSym-
bolMeaning
Artist/track is not stored.
Artist/track was already
stored.
Storing the league or team
Activating/deactivating a
notification
Opening the Favorites
Page 48 of 92
482-1. ENTERTAINMENT
Supra_Navi_(U)
2 "Favorite alert"
Select the symbo l while the mes-
sage is shown.
The displayed favorite is played.
When the message disappears,
the list of channels that is cur-
rently playing one of the stored
Favorites can be displayed.
1 Move the Controller to the
left.
2 "Category "
3 Select the Favorites list.
The channels that are currently
playing a favorite are displayed.
4Select the channel that you
would like to change to.
1 "Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Manage favorites"
The stored Favorites are displayed.
5Highlight the desired favor-
ites.
6 Press the button.
7 "Delete entry "
Traffic and weather information
for a selected region is broad- cast every few minutes.
1
"Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Configure jump "
5 Select the desired region.
You must have reception in
order to activate or deactivate.
1 "Media/Radio"
2 "Satellite radio "
3 Press the button.
4 "Configure jump "
5 "Jump to:"
Place a check mark to activate
Traffic Jump.
Information for the selected region
is broadcast as soon as it is avail-
able.
Remove the check mark to deacti-
vate Traffic Jump.
In the channel magazine, the
current and subsequent pro-
gram for each channel booked
is displayed.
1"Media/Radio"
2 "Satellite radio "
Deleting Favorites
Traffic Jump
General information
Selecting a region
Activating/deactivating Traf-
fic Jump
Channel magazine
Page 49 of 92
492-1. ENTERTAINMENT
Supra_Navi_(U)
2
ENTERTAINMENT
3 Move the Controller to the
left.
4 "SiriusXM program
guide"
About twice a year, Sirius per-
forms an update of the channel
names and positions. The
update takes place automati-
cally and may take several min-
utes.
Reception may not be avail-
able in some situations, such
as under certain environmen-
tal or topographical condi-
tions. The satellite radio has
no influence on this.
Graphical contents can be
received under certain cir-
cumstances.
The signal may not be avail-
able in tunnels or under-
ground garages next to tall
buildings or near trees, moun-
tains or other powerful
sources of radio interference.
Up to 40 stations can be stored. 1
"Media/Radio"
2 "Presets "
3 Select the desired station.
1 "Media/Radio"
2 "Presets "
3 Highlight the station you want
to delete.
4 Press the button.
5 "Delete entry "
Automatic update
System limits
Stored stations
General information
Selecting a station
Deleting a station
Page 50 of 92
502-1. ENTERTAINMENT
Supra_Navi_(U)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures that are not necessarily
available in your vehicle, e. g.,
due to the selected options or
country versions. This also
applies to safety-related func-
tions and systems. When using
these functions and systems,
the applicable laws and regula-
tions must be observed.
Music tracks, audio books, and
podcasts can be played back.
Sound is played back through
the vehicle loudspeakers.
Settings are stored for the driver
profile currently used.
Depending on the vehicle equip-
ment, the following audio
sources can be used: Tracks from USB storage
devices can be stored on the
music hard disk in the vehicle
and played from there.
USB storage device with com-
pressed audio files: all play-
able audio files from the USB
storage device are stored in a
directory that receives the
name of the USB storage
device. Tracks and directories
can be subsequently
renamed and deleted. Man-
aging the music hard disk,
refer to page 51.
Tracks with Digital Rights Man-
agement DRM copy protection
can be stored but cannot be
played back.
Regularly back up your music
hard disk, refer to page 53, oth-
erwise the stored music might
be lost if there is a fault on the
hard disk.
1 Connect the USB storage
device, refer to page 55, to
the USB interface.
2 "Media/Radio"
3 "USB "
Or: Select the name of the USB
Audio
Vehicle features and
options
General information
Sym-
bolMeaning
Music hard disk.
USB storage device.
Music interface for smart-
phones.
Bluetooth audio.
Music hard disk
General information
Storing from a USB stor-
age device
