513-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
• Tilt in two directions to switch
between displays, for exam-
ple. Press the button.
The main menu is displayed.
All Toyota Supra Command
functions can be called up via
the main menu.
1 Press the button twice.
All menu items of the main menu
are displayed.
2Select a menu item.
3To move the menu item to the
desired position, tilt the Con-
troller to the right or left.
Highlighted menu items can be
selected. Buttons on the Controller
ButtonFunction
Press once: call up main
menu.
Press twice: display all
menu items of the main
menu.
Open the Media/Radio
menu.
Open the Communication
menu.
Press once: open the
previous display.
Press and hold: open the
menus used last.
Open the Options menu.
Operating with the Con-
troller
Opening the main menu
Adapting the main menu
Selecting menu items

523-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
1Turn the Controller until the
desired menu item is high-
lighted.
2Press the Controller.
The display of menus
“Media/Radio”, “Communica-
tion” and “Connected Serv.” can
be adjusted, for instance to
remove the entries of functions
that are not used from the
menu.
Via Toyota Supra Command:
1Select the menu.
2“Personalize menu”
3Select desired menu con-
tents to be displayed.
After a menu item is selected,
for instance "System settings", a
new display appears.
• Move the Controller to the left.
The current display closes and the
previous display is shown.
• Press the button.
The previous display re-opens.
• Move the Controller to the
right.
The new display opens.
An arrow indicates that addi-
tional displays can be opened.
Press and hold this button.
The recently used menus are
displayed.
Press the button.
The "Options" menu is dis-
played.
The menu consists of various
areas:
• Screen settings, for instance
"Split screen".
• Control options for the
selected main menu, for
instance for "Media/Radio".
• If applicable, further operating
options for the selected menu,
for instance "Save station".
Settings, such as brightness,
can be entered.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings" Adjusting menu contents
Changing between dis-
plays
Opening recently used
menus
Opening the Options
menu
Changing settings

533-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
3"Displays"
4"Control display"
5"Brightness at night"
6Turn the Controller until the
desired setting is displayed.
7Press the Controller.
1Turn the Controller: select let-
ter or number.
2: confirm entry.
For alphabetical lists with more
than 30 entries, the letters for
which there is an entry are dis-
played at the left edge.
1Turn the Controller to the left
or right quickly.
All letters for which there are
entries are displayed on the left
edge.
2Select the first letter of the
desired entry.
The first entry of the selected letter
is displayed.
The Control Display is equipped
with a touchscreen.
Touch screen with your fingers.
Do not use any objects.
Tap on the symbol.
The main menu is displayed.
All Toyota Supra Command
functions can be called up via
the main menu.
1 Tap on symbol.
All menu items of the main menu
are displayed.
2Drag the menu item to the
desired position on the right
or left. Entering letters and num-
bers
Input
Deleting
SymbolFunction
Press the Controller:
delete letter or number.
Hold the Controller down:
delete all letters or num-
bers.
Using alphabetical lists
Operating via touch-
screen
General information
Opening the main menu
Adapting the main menu

543-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
Tap desired menu item.
You can display dynamic con-
tents within the menu items. The
contents of the menu items
update automatically, e.g., the
active destination guidance in
the navigation. To access the
dynamic content directly, tap on
the lower section of the menu
item.
Via Toyota Supra Command:
1"My Vehicle"
2"Contents of main menu"
After a menu item is selected, a
new display opens.
An arrow indicates that addi-
tional displays can be opened.
• Swipe to the left.
• Tap arrow.
New display is opened.Settings such as brightness can
be changed via the touch-
screen.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Displays"
4"Control display"
5"Brightness at night"
6To perform the desired set-
ting:
• Slide in the selected field to
the right or left, until the
desired setting is displayed.
• , Tap on symbol.
1 Touch the symbol on the
touchscreen.
A keyboard is displayed in the Con-
trol Display.
2Enter letters and numbers. Selecting menu items
Dynamic contents
Changing between dis-
plays
Changing settings
Entering letters and num-
bers
Input

553-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
The navigation map can be
moved with the touchscreen.
Some Toyota Supra Command
functions can be operated using
the touchpad on the Controller.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Touchpad"
4Select the desired setting:
• "Speller": enter letters and
numbers.
• "Map": using the map.
• "Search fields": write letters
without selecting the list field.• "Audio feedback": pro-
nounces entered letters and
numbers.
Entering letters requires some
practice at the beginning. When
entering, pay attention to the fol-
lowing:
• The system distinguishes
between upper and
lower-case letters and num-
bers. To make entries, it may
be necessary to change
between upper and
lower-case letters, numbers
and characters, refer to page
53.
• Enter characters as they are
displayed on the Control Dis-
play.
• Always enter associated char-
acters, such as accents or
periods so that the letter can
be clearly recognized. The set
language determines what
input is possible. Where nec-
essary, enter special charac-
ters via the Controller. Deleting
SymbolFunction
Tapping the symbol:
deletes the letter or num-
ber.
Tapping and holding the
symbol all letters: deletes
all letters or numbers.
Operating navigation map
FunctionOperation
Enlarge/shrink
map.Drag in or out
with the fingers.
Touchpad
General information
Selecting functions
Entering letters and num-
bers

563-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
The map in the navigation sys-
tem can be moved via the
touchpad.The Toyota Supra Command
functions can be stored on the
programmable memory buttons
and called up directly, for
instance radio stations, naviga-
tion destinations and phone
numbers.
Settings are stored for the driver
profile currently used.
1Select function via Toyota
Supra Command.
2 Press and hold the
desired button until a signal
sounds.
Press the button.
The function will work immedi-
ately. This means, for instance
that the number is dialed when a
phone number is selected.
Touch buttons with finger. Do
not wear gloves or use objects.
The button assignment is dis-
played at the top edge of Entering special charac-
ters
EntryOperation
Delete a charac-
ter.Swipe to the left
on the touchpad.
Enter a blank
space.
Swipe to the
right in the cen-
ter of the touch-
pad.
Enter a hyphen.
Swipe to the
right in the upper
area of the
touchpad.
Enter an under-
score.
Swipe to the
right in the lower
area of the
touchpad.
Using the map
FunctionOperation
Move map.
Swipe in the
appropriate
direction.
Enlarge/shrink
map.Drag in or out on
the touchpad
with fingers.
Display menu.Tap once.
Programmable memory
buttons
General information
Storing a function
Running a function
Displaying the key assign-
ment

573-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
screen.
1Press and hold buttons 1 and
8 simultaneously for approx.
5 seconds.
2"OK"
Most functions displayed on the
Control Display can be operated
by voice commands via the
voice activation system. The
system supports you with
announcements during input.
• Functions that can only be
used when the vehicle is sta-
tionary can only be operated
via the voice activation sys-
tem to a limited extent.
• The system uses a special
microphone on the driver's
side.
• ›...‹ in the Owner's Manual
denotes verbal instructions to
use with the voice activation
system.
• A language must be set via
Toyota Supra Command that is supported by the voice acti-
vation system. To set the lan-
guage, refer to page 60
• Always say commands in the
language of the voice activa-
tion system.
1 Press the button on the
steering wheel.
2Wait for the signal.
3Say the command.
No other commands may be
available. In this case, operate
the function via Toyota Supra
Command.
Most menu items on the Control
Display can be voiced as com-
mands. Deleting the button
assignments
Operation via voice
Concept
General information
Functional requirements
Using the voice activation
system
Activating the voice activa-
tion system
This symbol indicates that
the voice activation sys-
tem is active.
Terminating the voice activa-
tion system
Press the button on the
steering wheel or ›Can-
cel‹.
Possible commands
General information

583-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
Commands from other menus
can also be spoken.
You may select list entries such
as phone list entries via voice
activation. Read these list
entries out loud exactly as they
are shown in the respective list.
The following is displayed in the
top area of the Control Display:
• Some possible commands for
the current menu.
• Some possible commands
from other menus.
• Status of the voice recogni-
tion.
• Encrypted connection is
not available.
• To have the available spoken
instructions read out loud:
›Voice commands‹.
• To have information on the
operating principle of the
voice activation system read
out loud: ›General information
on voice control‹.
• To have help for the current
menu read out loud: ›Help‹.
Do not use the voice activation system to initiate an Emergency
Request. In stressful situations,
the voice and vocal pitch can
change. This can unnecessarily
delay the establishment of a
phone connection.
Instead, use the SOS button,
refer to page 316, close to the
interior mirror.
You can set the system to use
standard dialog or a short ver-
sion.
The short version of the voice
dialog plays back short mes-
sages in abbreviated form.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Language"
4"Speech mode:"
5Select the desired setting.
It is possible to answer during
inquiries of the voice activation
system. The function can be
deactivated if inquiries are often
undesirably interrupted, for
instance due to background
noise or talking.
Via Toyota Supra Command: Displaying possible com-
mands
Help on the voice activation
system
Information for Emergency
Requests
Adjusting
Setting the voice dialog
Speaking during voice out-
put

593-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
1"My Vehicle"
2"System settings"
3"Language"
4"Speaking during voice out-
put"
Online speech processing pro-
vides a dictation function, a nat-
ural method of entering
destinations and improves the
quality of voice recognition. To
use the functions, data is trans-
mitted to a service provider via
an encrypted connection and
stored locally there.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Language"
4"Server speech recognition"
Turn the volume button during
the spoken instructions until the
desired volume is set.
• The volume remains constant
even if the volume of other
audio sources is changed.
• The volume is stored for the
driver profile currently used.
• Certain noises can be
detected and may lead to problems. Keep the doors and
windows closed.
• Noises from the front passen-
ger or the rear seat bench can
impair the system. Avoid mak-
ing other noise in the vehicle
while speaking.
• Major language dialects can
cause problems with the voice
recognition feature. Speak
loud and clear.
A smartphone connected to the
vehicle can be used via voice
activation.
Activate voice command
response on the smartphone for
this purpose.
1Press and hold the but-
ton on the steering wheel for
approx. 3 seconds.
Voice command response is acti-
vated on the smartphone.
2Release the button.
If activation is successful, a confir-
mation appears on the Control Dis-
play.
If it was not possible to activate
voice command response, the
list of Bluetooth devices appears
on the Control Display. Online speech processing
Adjusting the volume
System limits
Using a smartphone via
voice activation

603-1. CONTROLS
Supra Owner's Manual_U (from Nov. '20 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures that are not necessarily
available in your vehicle, e. g.,
due to the selected options or
country versions. This also
applies to safety-related func-
tions and systems. When using
these functions and systems,
the applicable laws and regula-
tions must be observed.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3If necessary, "Language"
4"Language:"
5Select the desired setting.
The setting is stored for the
driver profile currently used.
For voice dialog for the voice
activation system, refer to page
58.Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Date and time"
4"Time zone:"
5Select the desired setting.
The setting is stored for the
driver profile currently used.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Date and time"
4"Time"
5Turn the Controller until the
desired hours are displayed.
6Press the Controller.
7Turn the Controller until the
desired minutes are dis-
played.
8Press the Controller.
Via Toyota Supra Command:
1"My Vehicle"
2"System settings"
3"Date and time"
4"Time format:"
General settings
Vehicle features and
options
Language
Setting the language
Setting the voice dialog
Time
Setting the time zone
Setting the time
Setting the time format
