TOYOTA SUPRA 2021 (in English) Owner's Guide

312-1. QUICK REFERENCE
2
QUICK REFERENCE
Supra Owner's Manual_U (from Mar. '21 Prod.)
The friction during hard braking
may produce brake dust and
make the rims dirty. Brake dust
can be removed by cleaning the
rims. Toyota recommends using
vehicle care and cleaning prod-
ucts from Toyota.
Depending on the previous dis-
plays, the status display
appears when the engine is run-
ning or after the vehicle has
been driven for at least 30 min-
utes.
Via Toyota Supra Command:
1"My Vehicle"
2"Vehicle status"
3"Engine oil level"
Different messages appear on
the Control Display depending
on the engine oil level. Pay
attention to these messages.
Safely park the vehicle and switch off drive-ready state
before adding engine oil.
Only add engine oil when the
message is displayed in the
instrument cluster.
Observe the quantity to be
added in the message.
Take care not to add too much
engine oil.
Observe recommended engine
oil types, refer to page 295.
The button is located in the cen-
ter console. Cleaning the wheels
Electronic oil measure-
ment
Functional requirements
Displaying the engine oil
level
Adding engine oil
General information
Adding
Providing assistance
Hazard warning flashers

322-1. QUICK REFERENCE
Supra Owner's Manual_U (from Mar. '21 Prod.)
Via Toyota Supra Command:
1"Toyota Supra Connect"
2"Toyota Supra Assistance"
3"Roadside assistance"
A voice connection is established.
The Concierge offers informa-
tion on events, gas stations or
hotels, and provides phone
numbers and addresses. Many
hotels can be booked directly by
the Concierge.
Via Toyota Supra Command:
1"Toyota Supra Connect"
2"Toyota Supra Assistance"
3"Concierge"
A voice connection to the Con-
cierge is established.
Remote maintenance are ser-
vices that help to maintain vehi-
cle mobility.
Remote maintenance can com-
prise the following services:
• Roadside assistance.
• Battery guard.When leaving the vehicle, turn
the engine switch off, apply the
parking brake and lock the
doors.
When parking, stop the vehicle
in a safe and appropriate park-
ing area, operate the “P” (park-
ing) switch on the selector lever
and turn the engine switch off. Roadside assistance
Toyota Supra Connect
Concierge
Remote maintenance
After driving
When parking
WA R N I N G
When taking a nap in the vehicle,
make sure to turn the engine
switch off.

332-1. QUICK REFERENCE
2
QUICK REFERENCE
Supra Owner's Manual_U (from Mar. '21 Prod.)
WA R N I N G
When taking a nap in the vehicle
is unavoidable, park the vehicle in
a safe place, turn the engine
switch off, and if possible, sleep in
the passenger seat. If the engine
is left running, the accelerator
pedal may be depressed or selec-
tor lever may be operated unin-
tentionally, possibly leading to an
accident. Also, if the engine is run
at a high speed for a long time,
the exhaust system and engine
may become extremely hot, pos-
sibly causing to a fire.
WA R N I N G
Be careful when parking, as to not
park the vehicle near flammable
materials.
Do not park the vehicle near flam-
mable materials, such as dry
grass, leaves, paper, oil, etc. If
these kinds of material touch a
part of the exhaust system, it may
cause a fire.

342-1. QUICK REFERENCE
Supra Owner's Manual_U (from Mar. '21 Prod.)

35
3
3
CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
CONTROLS
.3-1. CONTROLS
Cockpit ...........................36
Sensors of the vehicle....40
Operating state of the vehi-
cle.................................43
Toyota Supra Command
.....................................46
General settings .............60
Personal settings ...........63
Connections ...................68
Opening and closing ......77
Seats, mirrors, and steering
wheel ............................96
Transporting children safely
..................................109
Driving .........................115
Displays ......................133
Lights ..........................153
Safety ..........................159
Driving stability control sys-
tems ..........................193
Driver assistance systems
..................................198
Driving comfort ............223
Climate control ............224
Interior equipment .......233
Storage compartments
..................................243
Cargo area ..................245

363-1. CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
3-1.CONTROLS
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
1Central locking system
Unlock P.84
Lock P.84
2 Power windows P.94
3Exterior mirror operation
P.1054Lights
Lights off P.153
Daytime running lights P.156
Parking lights P.154
Automatic headlight
control P.153
Cockpit
Vehicle features and options
In the vicinity of the steering wheel

373-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
Automatic high-beam P.156
Low beams P.155
Instrument lighting
P.158
Right roadside parking
light P.155
Left roadside parking
light P.155
5Steering column stalk, left
Turn signal P.121
High beams, headlight
flasher P.122
Automatic high-beam
P.156
Onboard Computer
P.133
6Shift paddle P.129
7Steering wheel buttons, left
Cruise control on/off
P.198
Dynamic radar cruise
control on/off P.202
Cruise control: store
speed
Speed Limit Assist: take over
suggested speed P.210
Continuing cruise con-
trol/Pausing cruise control P. 1 9 8
Dynamic radar cruise
control: increase distance
P. 1 9 8
Dynamic radar cruise
control: reduce distance
P. 1 9 8
Cruise control rocker switch
P. 1 9 8
8Instrument cluster P.133
9Steering wheel buttons, right
Selection lists P.145
Volume, see Owner's
Manual for Navigation, Enter-
tainment and Communication
Voice activation system
P. 5 7
Telephone, see
Owner's Manual for Naviga-
tion, Entertainment and Com-
munication
Thumbwheel for selection
lists P.145
10Shift paddle P.129
11Steering column stalk, right
Wiper P.122
Rain sensor P.123
Clean the windshield
P. 1 2 4
12Adjust the steering wheel
P. 1 0 7

383-1. CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
13 Horn, entire surface
14 Unlock hood P.29015 Unlocking the trunk lid
P. 8 0
1Control Display P.48
2 Hazard warning sys-
tem P.313
3Ventilation P.230
4Glove compartment P.243
5Radio/multimedia, see
Owner's Manual for Naviga-
tion, Entertainment, and
Communication
6Automatic air conditioning
P.224
7Controller with buttons P.48
8 Sport mode button P. 1 3 2
SPORT driving mode
Toyota Supra Safety
P. 1 7 2
Auto Start/Stop func-
tion P.116
Parking Sensors P.40
Rearview cameraP.217
RCTA (Rear cross trafficalert)
functionP.220
VSC Vehicle Stability
Control System P.194
In the vicinity of the center console
1
4
23
5
6
7
89
10
11

393-1. CONTROLS
3
CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
9 Parking brake P.119
10Automatic transmission
selector lever P.12611 Switch drive-ready
state on/off P.115
1 Indicator light,
front-seat passenger airbag
P.171
2 Reading lights P.159
3 Interior lights P.158
4 Emergency call, SOS
P.314
In the vicinity of the roofliner

403-1. CONTROLS
Supra Owner's Manual_U (from Mar. '21 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e.g., due to the selected
options or country versions. This
also applies to safety-related
functions and systems. When
using these functions and sys-
tems, the applicable laws and
regulations must be observed.
Depending on the equipment,
the following cameras and sen-
sors are installed in the vehicle:
• Cameras behind the wind-
shield.
• Rearview camera.
• Front radar sensor.
• Radar sensors, side, rear.
• Ultrasound sensors in the
bumpers.
Keep the vehicle cameras and
sensors, as well as surrounding
areas, clean and unobstructed.The cameras are located in the
area of the interior mirror.
The camera is located in the
handle of the trunk lid.
The cameras may not be fully
functional and may provide
incorrect information in the fol-
lowing situations:
• In heavy fog, wet conditions,
or snow fall.
• On steep hills, in steep
Sensors of the vehicle
Vehicle equipment
Overview
Cameras
Cameras behind the wind-
shield
Rearview camera
System limits of the cam-
eras
