Alignment
Marks SR−88
− STEERINGSTEERING LINKAGE
1996 TOYOTA T100 (RM449U)
5. INSTALL PITMAN ARM
(a) Align the alignment marks on the pitman arm and the
cross shaft.
(b) Install the spring washer and pitman arm set nut.
Torque: 177 N·m (1,800 kgf·cm, 130 ft·lbf)
(c) Connect the pitman arm to the relay rod.
(d) Install the nut and a new cotter pin.
Torque: 90 N·m (920 kgf·cm, 67 ft·lbf)
6. INSTALL ENGINE UNDER COVER
Tighten the 4 bolts.
7. CHECK FRONT WHEEL ALIGNMENT
(See page SA−10)

Downloaded from www.Manualslib.com manuals search engine BE01F−10
BE−2
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U)
PROBLEM SYMPTOMS TABLE
The table below will be useful for you in troubleshooting these electrical problems. The most likely causes
of the malfunction are shown in the order of their probability. Inspect each part in the order shown, and re-
place the part when it is found to be faulty.
USA:
HEADLIGHT AND TAILLIGHT SYSTEM
SymptomSuspect AreaSee page
Headlight does not light up
(Taillight is normal)
1. HEAD Fuse (Relay Block)
2. Light Control Switch
3. Headlight Dimmer Switch
4. Headlight BulbBE−14
BE−17
BE−17
BE−17
Headlight does not light up
(Taillight does not light up)
1. Light Control Switch
2. Headlight Dimmer Switch
3. Wire Harness
4. Headlight BulbBE−17
BE−17
−
−
Only one light comes on
1. HEAD Fuse (Relay Block)
2. Wire Harness
3. Headlight BulbBE−14
−
−
”Lo−Beam” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
”Hi−Beam” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
”Flash” does not light up
1. Headlight Control Relay
2. Headlight Dimmer Relay
3. Headlight Dimmer Switch
4. Wire Harness
5. Headlight BulbBE−17
BE−17
BE−17
−
−
Taillight does not light up
(Headlight does not light up)
1. TAIL Fuse (Junction Block No.1)
2. Light Control Switch
3. Wire Harness
4. Headlight BulbBE−17
BE−17
−
−
Taillight does not light up
(Headlight is normal)
1. TAIL Fuse (Junction Block No.1)
2. Light Control Switch
3. Taillight Control Relay
4. Wire Harness
5. Taillight BulbBE−14
BE−17
BE−17
−
−
Only one light goes out or does not light up1. Wire Harness
2. Taillight Bulb−
−
Rear Combination light does not light up
1. TAIL Fuse (Junction Block No.1)
2. Wire Harness
3. Taillight BulbBE−14
−
−
”Light−on warning system” does not operate.
1. Integration Relay
2. DOME Fuse (Relay Block)
3. GAUGE Fuse (Junction Block No.1)
4. Door Courtesy Switch
5. Wire HarnessBE−17
BE−14
BE−14
BE−25
−

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−3
1996 TOYOTA T100 (RM449U)
CANADA:
HEADLIGHT AND TAILLIGHT SYSTEM
SymptomSuspect AreaSee page
Only one side headlight does not light up.1. Headlight Bulb
2. Wire Harness−
−
”Lo−Beam” does not light up. (ALL)
1. D.R.L. Relay
2. Headlight Dimmer Relay
3. Headlight Control Relay
4. Headlight Dimmer Switch
5. Wire HarnessBE−14
BE−17
BE−17
BE−17
−
”Lo−Beam” does not light up. (ONE SIDE)
1. HEAD LH−Lo Fuse (Relay Block)
2. HEAD RH−Lo Fuse (Relay Block)
3. Headlight Bulb
4. Wire HarnessBE−14
BE−14
−
−
”Hi−Beam” does not light up. (ALL)
1. DRL Fuse (Junction Block No.1)
2. Headlight Dimmer Relay
3. Headlight Control Relay
4. Headlight Dimmer Switch
5. Wire HarnessBE−14
BE−17
BE−17
BE−17
−
”Hi−Beam” does not light up. (ONE SIDE)
1. HEAD LH−Hi Fuse (Relay Block)
2. HEAD RH−Hi Fuse (Relay Block)
3. Headlight Bulb
4. Wire HarnessBE−14
BE−14
−
−
”Flash” does not light up.1. Headlight Dimmer Switch
2. Wire HarnessBE−17
−
Headlight does not light up.
(Taillight is normal)
1. Headlight Control Relay
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. D.R.L. Resistor
5. Headlight Dimmer Switch
6. Light Control Switch
7. Headlight Bulb
8. Wire HarnessBE−17
BE−17
BE−17
BE−17
BE−17
BE−17
−
−
Headlight does not light up.
(Taillight does not light up)
1. Headlight Control Relay
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. D.R.L. Resistor
5. Headlight Dimmer Switch
6. Light Control Switch
7. Headlight Bulb
8. Wire HarnessBE−17
BE−17
BE−17
BE−17
BE−17
BE−17
−
−
Only one side taillight does not light up.1. Taillight Bulb
2. Wire Harness−
−
Taillight does not light up.
(Headlight is normal)
1. TAIL Fuse (Junction Block No.1)
2. Taillight Control Relay
3. Light Control Switch
4. Taillight Bulb
5. Wire HarnessBE−14
BE−17
BE−17
−
−
Taillight does not light up.
(Headlight does not light up)1. Light Control Switch
2. Taillight Bulb
3. Wire HarnessBE−17
−
−
Headlight does not light up with light control SW in HEAD.
1. Light Control Switch
2. D.R.L. Relay
3. D.R.L. No.4 Relay
4. Wire HarnessBE−17
BE−17
BE−17
−

Downloaded from www.Manualslib.com manuals search engine BE−4
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U) Headlight does not go out with light control SW in OFF.
1. Headlight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Taillight does not light up with light control SW in TAIL.
1. Taillight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Taillight does not go out with light control SW in OFF.
1. Taillight Control Relay
2. Light Control Switch
3. Wire HarnessBE−17
BE−17
−
Headlight do not light up with engine running, parking brake SW
and light control SW in OFF.
1. ECU−B Fuse (Junction Block No.1)
2. GAUGE Fuse (Junction Block No.1)
3. DRL Fuse (Junction Block No.1)
4. D.R.L. Relay
5. D.R.L. No.4 Relay
6. D.R.L. Resistor
7. Wire Harness
8. Generator L Terminal
9. Parking Brake SwitchBE−14
BE−14
BE−14
BE−17
BE−17
BE−17
−
−
BE−38
”Light−on warning system” does not operate.
1. Integration Relay
2. DOME Fuse (Relay Block)
3. GAUGE Fuse (Junction Block No.1)
4. Door Courtesy Switch
5. Wire HarnessBE−17
BE−14
BE−14
BE−25
−
TURN SIGNAL AND HAZARD WARNING SYSTEM
SymptomSuspect AreaSee page
”Hazard” and ”Turn” do not light up
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE−23
BE−23
−
The flashing frequency is abnormal
1. Bulb
2. Turn Signal Switch
3. Wire Harness−
BE−23
−
Hazard warning light does not light up
(Turn signal is normal)1. HAZ−HORN Fuse (Relay Block)
2. Wire HarnessBE−22
−
Hazard warning light does not light up in one direction1. Hazard Warning Switch
2. Wire HarnessBE−23
−
*1 Turn signal does not light up
1. Ignition Switch
2. TURN Fuse (Junction Block No.1)
3. Turn Signal Switch
4. Wire HarnessBE−12
BE−22
BE−23
−
*2 Turn signal does not light up
1. TURN Fuse (Junction Block No.1)
2. Turn Signal Switch
3. Wire HarnessBE−22
BE−23
−
Turn signal does not light up in one direction1. Turn Signal Switch
2. Wire HarnessBE−23
−
Only one bulb does not light up1. Bulb
2. Wire Harness−
−
*1: Combination Meter, Wiper and Washer do not operate.
*
2: Combination Meter, Wiper and Washer are normal.

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−5
1996 TOYOTA T100 (RM449U)
INTERIOR LIGHT SYSTEM
SymptomSuspect AreaSee page
Room light does not light up
1. DOME Fuse (Relay Block)
2. Room Light Switch
3. Door Courtesy Switch
4. Wire Harness
5. BulbBE−24
BE−25
BE−25
−
−
Room light remains always on
1. Room Light Switch
2. Door Courtesy Switch
3. Wire HarnessBE−25
BE−25
−
BACK−UP LIGHT SYSTEM
SymptomSuspect AreaSee page
Back−Up Light does not light up
1. GAUGE Fuse (Junction Block No.1)
2. Ignition Switch
3. Back−Up Light Relay (Column A/T)
4. Back−Up Light Switch (M/T)
5. PNP Switch (A/T)
6. Bulb
7. Wire HarnessBE−26
BE−12
BE−28
BE−28
DI−306
−
−
Back−Up Light remains always on1.Wire Harness−
Only one light does not light up1. Bulb
2. Wire Harness−
−
STOP LIGHT SYSTEM
SymptomSuspect AreaSee page
Stop light does not light up
1. STOP Fuse (Junction Block No.1)
2. Stop Light Switch
3. Wire Harness
4. BulbBE−29
BE−30
−
−
Stop light remains always on1. Stop Light Switch
2. Wire HarnessBE−30
−
Only one light does not light up1. Wire Harness
2. Bulb−
−
WIPER AND WASHER SYSTEM
SymptomSuspect AreaSee page
Wiper does not operate or turn to off position
1. WIPER Fuse (Junction Block No.1)
2. Ignition Switch
3. Wiper and Washer Switch
4. Wiper Motor
5. Wire HarnessBE−31
BE−12
BE−32
BE−32
−
Wiper does not operate in INT position
1. Wiper and Washer Switch
2. Wiper Motor
3. Wire HarnessBE−32
BE−32
−
Washer does not operate
1. Wiper and Washer Switch
2. Washer Hose and Nozzle
3. Washer Motor
4. Wire HarnessBE−32
−
BE−32
−

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−7
1996 TOYOTA T100 (RM449U) A/T Oil temperature warning indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. A/T Oil Temperature Sensor
4. Wire Harness−
BE−36
BE−38
−
SRS warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Center Airbag Sensor Assembly
4. Wire Harness−
BE−36
DI−372
−
Malfunction indicator does not light up
1. Bulb
2. ECM
3. Wire Harness−
−
−
−
Seat belt warning light does not light up
1. Bulb
2. Integration Relay
3. Wiring Harness−
−
−
Discharge warning light does not light up
1. IGN Fuse (Junction Block No.1)
2. Bulb
3. Wire Harness
4. Generator−
−
−
−
Brake warning light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Parking Brake Switch
4. Brake Fluid Level Warning Switch−
BE−36
BE−38
BE−38
COMBINATION METER
Indicator Lights:
SymptomSuspect AreaSee page
O/D OFF indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. O/D OFF Switch
4. Wire Harness−
BE−36
DI−311
−
High beam indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Wire Harness
4. Headlight System−
BE−36
−
BE−2
Turn indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. Wire Harness
4. Turn Signal and Hazard Warning System−
BE−36
−
BE−2
Shift indicator lights do not light up (ALL)
1. Bulb
2. Combination Meter Wiring Circuit
3. PNP Switch
4. Wire Harness−
BE−36
DI−306
−
Shift indicator lights do not light up (L, 2, D)
1. Bulb
2. Combination Meter Wiring Circuit
3. PNP Switch
4. Light Control Rheostat
5. Wire Harness−
BE−36
DI−306
BE−38
−
Only one shift indicator does not light up1. Bulb
2. Combination Meter Wiring Circuit−
BE−36

Downloaded from www.Manualslib.com manuals search engine BE−8
− BODY ELECTRICALBODY ELECTRICAL SYSTEM
1996 TOYOTA T100 (RM449U) ndicator lights do not light up (Except. Turn, Hi−beam)
1. GAUGE Fuse (Junction Block No1.)
2. Wire Harness−
−
ABS indicator light does not light up
1. Bulb
2. Combination Meter Wiring Circuit
3. ABS ECU
4. Wire Harness−
BE−36
DI−331
−
POWER WINDOW CONTROL SYSTEM
SymptomSuspect AreaSee page
*1Power window does not operate
1. POWER WINDOW Fuse (Junction Block No.1)
2. GAUGE Fuse (Junction Block No.1)
3. Door Lock Control Relay
4. Ignition Switch
5. Power Window Master Switch
6. Wire HarnessBE−46
BE−46
BE−47
BE−12
BE−47
−
*2Power window does not operate
1. POWER WINDOW Fuse (Junction Block No.1)
2. GAUGE Fuse (Junction Block No.1)
3. Ignition Switch
4. Door Lock Control Relay
5. Power Window Master Switch
6. Wire HarnessBE−46
BE−46
BE−12
BE−47
BE−47
−
”One Touch Power Window System” does not operate1. Power Window Master SwitchBE−47
Only one window glass does not move
1. Power Window Master Switch
2. Power Window Switch
3. Power Window Motor
4. Wire HarnessBE−47
BE−47
BE−47
−
”Window Lock System” does not operate1. Power Window Master SwitchBE−47
”Window Lock Illumination” does not operate1. Power Window Master SwitchBE−47
*1 Power door lock system does not operate
*
2 Power door lock system is normal

Downloaded from www.Manualslib.com manuals search engine − BODY ELECTRICALBODY ELECTRICAL SYSTEM
BE−9
1996 TOYOTA T100 (RM449U)
POWER DOOR LOCK CONTROL SYSTEM
SymptomSuspect AreaSee page
”Door lock control system” does not operate (All)
1. GAUGE Fuse (Junction Block No.1)
2. POWER WINDOW Fuse (Junction Block No.1)
3. Door Lock Control Relay
4. Wire Harness
5. Other PartsBE−50
BE−50
BE−51
−
−
Malfunction in Door Lock / Unlock
(Using door manual switch)
1. Door Lock Manual Switch
2. Wire Harness
3. Door Lock Control Relay
4. Other PartsBE−51
−
BE−51
−
Mulfunction in Door Lock / Unlock
(Using door manual switch and key)1. Wire Harness
2. Other Parts−
−
Mulfunction in Door Lock / Unlock
(Using Key)
1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Door Lock Control Relay
4. Other PartsBE−51
−
BE−51
−
Fault in 2 − Operation unlock function of Driver’s side door key
Lock and Unlock switch
1. Door Key Lock and Unlock Switch
2. Wire Harness
3. Door Lock Control Relay
4. Other PartsBE−51
−
BE−51
−
Fault in key confine prevention operation
1. Key Unlock Warning Switch
2. Door Courtesy Switch
3. Door Lock Switch
4. Wire Harness
5. Door Lock Control Relay
6. Other PartsBE−12
BE−25
BE−51
−
BE−51
−
Only one door lock does not operate1. Door Lock Motor
2. Wire HarnessBE−51
−
POWER MIRROR CONTROL SYSTEM
SymptomSuspect AreaSee page
Power mirror on each side does not operate at all
1. RADIO Fuse (Junction Block No.1)
2. Mirror Switch
3. Mirror Motor (Up/Down or Left/Right Control)
4. Wire HarnessBE−56
BE−57
BE−57
−
Left or Right power mirror does not operate at all
1. Mirror Switch
2. Mirror Motor (Up/Down or Left/Right Control)
3. Wire HarnessBE−57
BE−57
−
Up/Down Control of left or right power mirror does not operate1. Mirror Motor (Up/Down Control)
2. Wire HarnessBE−57
−
Left/Right control of left or right power mirror does not operate1. Mirror Motor (Left/Right Control)
2. Wire HarnessBE−57
−

Downloaded from www.Manualslib.com manuals search engine Z16012
Relay Block
Junction Block No.1
BE02V−02
BE−10
− BODY ELECTRICALPOWER SOURCE
1810 Author: Date:
1996 TOYOTA T100 (RM449U)
POWER SOURCE
LOCATION

Downloaded from www.Manualslib.com manuals search engine N15094
Junction Block No.1
 Integration RelayIgnition Switch
 Key Unlock Warning
Switch
BE02W−03
− BODY ELECTRICALIGNITION SWITCH AND KEY UNLOCK WARNING
SWITCHBE−11
1811 Author: Date:
1996 TOYOTA T100 (RM449U)
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH
LOCATION
