− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−307
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
1 Read PNP, REVERSE, 2ND and LOW signals.
When using TOYOTA hand−held tester:
PREPARATION:
(a) Connect a TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and TOYOTA hand−held tes-
ter main switch ON.
CHECK:
Shift lever into the P, R, N, 2 and L positions, and read the PNP,
REVERSE, 2ND and LOW signals on the TOYOTA hand−held
tester.
OK:
Shift positionSignal
22ND OFF → ON
LLOW OFF → ON
RREVERSE OFF → ON
P, NPNP OFF → ON
When not using TOYOTA hand−held tester:
PREPARATION:
Turn the ignition switch ON.
CHECK:
Measure voltage between terminals NSW, 2, L and R of ECM
and body ground when the shift lever is shifted to the following
positions.
OK:
*: The voltage will drop slightly due to lighting up of the back up
light.
OK Check and replace ECM.
NG

Downloaded from www.Manualslib.com manuals search engine Q07657
DI−308
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
2 Check park/neutral position switch.
PREPARATION:
(a) Jack up the vehicle.
(b) Disconnect the park/neutral position switch connector.
CHECK:
Check continuity between each terminal shown below when the
shift lever is moved to each position.
OK:
Shift PositionTerminal No. to continuityTerminal No. to continuity
P4 − 75 − 6
R4 − 8−
N4 − 105 − 6
D4 − 9−
22 − 4−
L3 − 4−
NG Replace park/neutral position switch.
OK
Repair or replace harness and connector between battery and park/neutral position switch,
park/neutral position switch and ECM (See page IN−26).

Downloaded from www.Manualslib.com manuals search engine Q00758
Cruise Control Actuator with ECU ECM
B+
OD1
E47
Y−R
C17
9
OD
D00053
ON
OD1 (−)
(+)
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−309
1996 TOYOTA T100 (RM449U)
O/D Cancel Signal Circuit (5VZ−FE only)
CIRCUIT DESCRIPTION
While driving uphill with cruise control activated, in order to minimize gear shifting and provide smooth cruis-
ing overdrive may be prohibited temporarily under some condition.
The cruise control ECU sends O/D cut signals to the ECM as necessary and the ECM cancels O/D shifting
until these signals are discontinued.
WIRING DIAGRAM
INSPECTION PROCEDURE
1 Check voltage between terminal OD1 of ECM and body ground.
PREPARATION:
Turn the ignition switch ON.
CHECK:
Measure voltage between terminal OD1 of ECM and body
ground.
OK:
Voltage: 4 − 6 V
OK Proceed to next circuit inspection shown on
problem symptoms table (See page DI−282).
NG
DI0W9−02

Downloaded from www.Manualslib.com manuals search engine D10999
DI−310
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
2 Check voltage between terminal OD of cruise control ECU harness side
connector and body ground.
PREPARATION:
(a) Disconnect the cruise control ECU connector.
(b) Turn the ignition switch ON.
CHECK:
Measure voltage between terminal OD of cruise control ECU
harness side connector and body ground.
OK:
Voltage: 4 − 6 V
OK Check and replace cruise control ECU.
NG
3 Check harness and connector between cruise control ECU and ECM
(See page IN−26).
NG Repair or replace harness or connector.
OK
Check and replace ECM.

Downloaded from www.Manualslib.com manuals search engine Q10013
*O/D Main Switch
Contacts go open with switch pushed in.
Contacts go closed with switch pushed once again.
*1: 3RZ−FE
*2: 5VZ−FEO/D OFF Indicator Light
(Combination Meter)
Integration
Relay Ignition Switch
R/B No.2 R/B No.2J/B No.1ECM
GAUGE
Battery AM1
IG1
ALT AM1B+
OD2 B−YB−OY−G
W W
WW 65
2222
2 1 199 2
3
1A
141
2O3
O3E4
C13 C12
IA3
875
6
Y−G
W−B
IC
*1
*2
*
O/D
Main
Switch
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−311
1996 TOYOTA T100 (RM449U)
O/D Main Switch & O/D OFF Indicator Light Circuit
CIRCUIT DESCRIPTION
The O/D main switch contacts go open when the switch is pushed in and go closed when it is pushed out.
In O/D main switch at OFF position, the O/D OFF indicator light lights up, and the ECM prohibits shifting O/D.
WIRING DIAGRAM
DI0WD−02

Downloaded from www.Manualslib.com manuals search engine BE3840Q06780AT5623D00221
ON
O/D Main Switch
ON
OFFOFF
ON
DI−312
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
INSPECTION PROCEDURE
O/D OFF indicator light does not light up:
1 Check operation of O/D main switch.
PREPARATION:
Turn the ignition switch ON.
CHECK:
(a) Check the O/D OFF indicator light when O/D main switch
is pushed in to ON.
(b) Check the O/D OFF indicator light when O/D main switch
is pushed again to OFF.
OK:
(a) O/D OFF indicator light goes off
(b) O/D OFF indicator light lights up
NG Go to step 4.
OK

Downloaded from www.Manualslib.com manuals search engine BE3840
Q07661
Q07662D00016
3RZ−FE
5VZ−FEOD2
(+)
(−) ON
OD2 (+) (−)
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−313
1996 TOYOTA T100 (RM449U)
2 Check OVRDRIVE CUT SW2 signal.
When using TOYOTA hand−held tester:
PREPARATION:
(a) Connect a TOYOTA hand−held tester to the DLC3.
(b) Turn the ignition switch ON and TOYOTA hand−held tes-
ter main switch ON.
CHECK:
Read the ”OVRDRIVE CUT SW2” signal on the TOYOTA
hand−held tester.
OK:
O/D main switch conditionOVRDRIVE CUT SW2 signal
ON (Pushed in)ON
OFF (Pushed once again)OFF
When not using TOYOTA hand−held tester:
PREPARATION:
Turn the ignition switch ON.
CHECK:
Check voltage between terminal OD2 of ECM and body ground.
OK:
O/D main switch conditionVoltage
ON (Pushed in)9 − 14 V
OFF (Pushed once again)Below 3 V
OK Proceed to next circuit inspection shown on
problem symptoms table (See page DI−282).
NG

Downloaded from www.Manualslib.com manuals search engine Q07663
1
2
DI−314
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
3 Check harness and connector between O/D OFF indicator light and ECM (See
page IN−26).
NG Repair or replace harness or connector.
OK
Check O/D main switch.
4 Check O/D main switch.
PREPARATION:
Disconnect the O/D main switch connector.
CHECK:
Check continuity resistance between terminal 1 and 2 of O/D
main switch connector.
OK:
O/D main switch conditionSpecified condition
ON (Pushed in)No continuity
OFF (Pushed once agin)Continuity
NG Replace O/D main switch.
OK
Check and replace the combination meter
(See page BE−38).

Downloaded from www.Manualslib.com manuals search engine Q07663
1
2
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−315
1996 TOYOTA T100 (RM449U)
O/D OFF indicator light remains ON:
1 Check O/D main switch.
PREPARATION:
Disconnect the O/D main switch connector.
CHECK:
Check continuity between terminals 1 and 2 of O/D main switch
connector.
OK:
O/D main switchSpecified condition
ONNo continuity
OFFContinuity
NG Replace O/D main switch.
OK
2 Check harness and connector between O/D OFF indicator light and O/D main
switch, O/D OFF indicator light and ECM (See page IN−26).
NG Repair or replace harness or connector.
OK
Check and replace ECM.

Downloaded from www.Manualslib.com manuals search engine D09979
DI−316
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
Stop Light Switch Circuit
CIRCUIT DESCRIPTION
The purpose of this circuit is to prevent the engine from stalling, while driving in lock−up condition, when
brakes are suddenly applied.
When the brake pedal is operated, this switch sends a signals to the ECM. Then the ECM cancels operation
of the lock−up clutch while braking is in progress.
WIRING DIAGRAM
DI98I−01
