TOYOTA T100 1996 Factory Service Manual

Downloaded from www.Manualslib.com manuals search engine DI98H−01
D10997
D10998
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−277
1996 TOYOTA T100 (RM449U)
PARTS LOCATION

Downloaded from www.Manualslib.com manuals search engine Q07506
No.1 Vehicle Speed Sensor
(In Combination Meter)
O/D Main Switch
Cruise Control ECU
DLC3
Stop Light SwitchECM
DI−278
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)

Downloaded from www.Manualslib.com manuals search engine DI0VI−02
FI6526
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25 261 2 3 4 5 6 7 8
9 10 11 12 13 14 15 161 2 3 4 5 6
7 8 9 10 11 121 2 3 4 5 6 7 8 9 10 11
14 15 16 17 18 19 20 21 22 1213
EE6
E
ECM Terminals
E
− DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−279
1996 TOYOTA T100 (RM449U)
TERMINALS OF ECM
3RZ−FE:
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
SP1 − E1 (E4, 8 − E7, 24)G ↔ BR
IG switch ON (Disconnect cruise control connector)Below 1.5 or 4 − 6
Turn one rear wheel slowly (Disconnect cruise control connec-
tor)Pulse signal is output
Below 1.5 ↔ 4 − 6

S1 − E1 (E7, 10 − E7, 24)

W ↔ BR
IG switch ON9 − 14
1st or 2nd gear9 − 14
3rd or O/D gearBelow 1.5
S2 − E1 (E7, 9 − E7, 24)B−W ↔ BR
IG switch ONBelow 1.5
2nd or 3rd gear9 − 14
1st or O/D gearBelow 1.5
SL − E1 (E7, 8 − E7, 24)Y−B ↔ BRIG switch ONBelow 1.5
Vehicle driving under lock−up position9 − 14
SP2+ − SP2− (E5, 10 − E5, 4)BR−R ↔ B−RVehicle is runningPulse signal is output
Below 1.5 ↔ 4 − 10
OD2 − E1 (E4, 5 − E7, 24)Y−G ↔ BRO/D main switch ON (Pushed in)9 − 14
O/D main switch OFF (Pushed once again)Below 3
OIL − E2 (E7, 21 − E6, 9)G−B ↔ BR−BATF temperature: 110°C (230°F) or moreBelow 1.5
L − E1 (E4, 15 − E7, 24)V−W ↔ BRIG switch ON, Shift lever L position7.5 − 14
IG switch ON, Shift lever other than L positionBelow 1.5
2 − E1 (E4, 16 − E7, 24)P−G ↔ BRIG switch ON, Shift lever 2 position7.5 − 14
IG switch ON, Shift lever other than 2 positionBelow 1.5
R − E1 (E4, 17 − E7, 24)R−B ↔ BRIG switch ON, Shift lever R position7.5 − 14
IG switch ON, Shift lever other than R positionBelow 1.5
NSW − E1 (E4, 22 − E7, 24)B−Y ↔ BRIG switch ON, Shift lever P or N positionBelow 3
IG switch ON, Shift lever other than P or N position9 − 14
B/K − E1 (E4, 21 − E7, 24)G−W ↔ BRIG switch ON, Brake pedal is depressed7.5 − 14
IG switch ON, Brake pedal is releasedBelow 1.5
THW − E2 (E6, 4 − E6, 9)G−Y ↔ BR−BEngine coolant temperature: 80°C (176°F)Below 1.5
IDL − E2 (E6, 11 − E6, 9)Y−L ↔ BR−BIG switch ON, Accel. pedal is releasedBelow 1.5
IG switch ON, Accel. pedal is depressed9 − 14
VTA − E2 (E6, 10 − E6, 9)Y−B ↔ BR−BIG switch ON, Accel. pedal is releasedBelow 0.3 − 0.8
IG switch ON, Accel. pedal is depressed3.2 − 4.9

Downloaded from www.Manualslib.com manuals search engine FI6810
E7
E6 E5 E4
34 33 32 31 30 29 28 2717 18 19 20 21 22 23 24 25 2611 12 13 14 15 161 2 3 4 5 6 7 8 9 101 2 3 4 5 6 7 8
9 10 11 12 13
14 15 16 17 18 19 20 21
22 23 24 25 26 27 28 1 2 3 4
5 6 7
8 9 10 11
12 13 14 15 16 1 2 3 4 5 6
7 8 9 10 11
12 13 14 15 16 17
18 19 20 21 22
ECM Terminals DI−280
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
5VZ−FE:
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
SPD − E1 (E4, 12− E5, 16)G ↔ BR
IG switch ON (Disconnect cruise control connector)Below 1.5 or 4 − 6
Turn one rear wheel slowly (Disconnect cruise control connec-
tor)Pulse signal is output
Below 1.5 ↔ 4 − 6

S1 − E1 (E7, 11 − E5, 16)

W ↔ BR
IG switch ON9 − 14
1st or 2nd gear9 − 14
3rd or O/D gearBelow 1.5
S2 − E1 (E7, 17 − E5, 16)B−W ↔ BR
IG switch ONBelow 1.5
2nd or 3rd gear9 − 14
1st or O/D gearBelow 1.5
SL − E1 (E7, 27 − E5, 16)Y−B ↔ BRIG switch ONBelow 1.5
Vehicle driving under lock−up position9 − 14
SP2 − E1 (E6, 9 − E5, 16)BR−R ↔ BRTurn one rear wheel slowlyPulse signal is output
Below 1.5 ↔ 4 ∼ 6
OD1 − E1 (E4, 7 − E5, 16)Y−R ↔ BRIG switch ON9 − 14
OD2 − E1 (E4, 6 − E5, 16)Y−G ↔ BRO/D main switch ON (Pushed in)9 − 14
O/D main switch OFF (Pushed once again)Below 3
OIL − E2 (E6, 12 − E6, 22)G−B ↔ BR−BATF temperature: 110°C (230°F) or moreBelow 1.5
L − E1 (E4, 3 − E5, 16)V−W ↔ BRIG switch ON, Shift lever L position7.5 − 14
IG switch ON, Shift lever other than L positionBelow 1.5
2 − E1 (E4, 2 − E5, 16)P−G ↔ BRIG switch ON, Shift lever 2 position7.5 − 14
IG switch ON, Shift lever other than 2 positionBelow 1.5
R − E1 (E4, 1 − E5, 16)R−B ↔ BRIG switch ON, Shift lever R position7.5 − 14
IG switch ON, Shift lever other than R positionBelow 1.5
NSW − E1 (E7, 14 − E6, 22)B−O ↔ BRIG switch ON, Shift lever P or N positionBelow 3
IG switch ON, Shift lever other than P or N position9 − 14
B/K − E1 (E4, 25 − E5, 16)G−W ↔ BRIG switch ON, Brake pedal is depressed7.5 − 14
IG switch ON, Brake pedal is releasedBelow 1.5
THW − E2 (E6, 20 − E6, 22)G−Y ↔ BR−BEngine coolant temperature: 80°C (176°F)Below 1.5
IDL − E2 (E7, 32 − E6, 22)Y−L ↔ BR−BIG switch ON, Accel. pedal is releasedBelow 1.5
IG switch ON, Accel. pedal is depressed9 − 14
VTA − E2 (E6, 7 − E6, 22)Y−B ↔ BR−BIG switch ON, Accel. pedal is releasedBelow 0.3 − 0.8
IG switch ON, Accel. pedal is depressed3.2 − 4.9
TFN − E1 (E4, 17 − E5, 16)Y ↔ BRIG switch ON, Transfer N positionBelow 3
IG switch ON, Transfer other than N position9 − 14

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−281
1996 TOYOTA T100 (RM449U) L4 − E1 (E7, 29 − E5, 16)
R ↔ BRIG switch ON, Transfer L4 position7.5 − 14
IG switch ON, Transfer other than L4 positionBelow 1.5
4WD − E1 (E4, 26 − E5, 16)R−G ↔ BRIG switch ON, Transfer H2 position9 − 14
IG switch ON, Transfer other than H2 positionBelow 3

Downloaded from www.Manualslib.com manuals search engine DI0VJ−02
DI−282
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the diagnostic trouble code check but the trouble still occurs, check the
circuits for each symptom in the order given in the charts on the following pages and proceed to the page
given for troubleshooting.
The Matrix Chart is divided into 3 chapters.
Chapter 1: Electronic Circuit Matrix Chart
Chapter 2: On−vehicle Repair Matrix Chart
Chapter 3: Off−vehicle Repair Matrix Chart
If the instruction ”Proceed to next circuit inspection shown on matrix chart” is given in the flow
chart for each circuit, proceed to the circuit with the next highest number in the table to continue
the check.
If the trouble still occurs even though there are no abnormalities in any of the other circuits, then
check and replace the ECM.
Chapter 1: Electronic Circuit Matrix Chart
SymptomSuspect AreaSee page
No up−shift
(A particular gear, from 1st to 3rd gear, is not up−shifted)1. ECMDI−279
No up−shift (3rd → O/D)
1. O/D main switch & O/D OFF indicator light circuit
2. O/D cancel signal circuit
3. ECMDI−311
DI−309
DI−279
No down−shift (O/D → 3rd)1. ECMDI−279
No down−shift
(A particular gear, from 1st to 3rd gear, is not up−shifted)1. ECMDI−279
No lock−up1. Stop light swich circuit
2. ECMDI−316
DI−279
No lock−up off1. Stop light swich circuit
2. ECMDI−316
DI−279
Shift point too high or too low1. ECMDI−279
Up−shift to O/D from 3rd while O/D main switch is OFF1. O/D main switch & O/D OFF indicator light circuit
2. ECMDI−311
DI−279
Up−shift to O/D from 3rd while engine is cold1. ECMDI−279
No kick−down1. ECMDI−279
Engine stalls when starting off or stopping1. Stop light swich circuit
2. ECMDI−316
DI−279

Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−283
1996 TOYOTA T100 (RM449U)
Chapter 2: On−Vehicle Repair Matrix Chart
(: A340E, A340F, A340H AUTOMATIC TRANSMISSION Repair Manual Pub. No. RM391U)
(: A340F, A343F AUTOMATIC TRANSMISSION Repair Manual Pub. No. RM479U)
SymptomSuspect AreaSee page
Vehicle does not move in any forward position and reverse
position
1. Throttle cable
2. No.1 gear shifting rod
3. Manual valve
4. Parking lock pawl
5. Off−vehicle repair matrix chartDI−265
DI−265

AT−17
DI−282
Vehicle does not move in R position1. Off−vehicle repair matrix chartDI−282
Vehicle does not move in particular position or positions
(except R position)1. Off−vehicle repair matrix chartDI−282
No up−shift (1st → 2nd)1. 1−2 shift valve
2. Off−vehicle repair matrix chart
DI−282
No up−shift (2nd → 3rd)1. 2−3 shift valve
2. Off−vehicle repair matrix chart
DI−282
No up−shift (3rd → O/D)1. 3−4 shift valve
2. Off−vehicle repair matrix chart
DI−282
No down−shift (O/D → 3rd)1. 3−4 shift valve
2. Off−vehicle repair matrix chart
DI−282
No down−shift (3rd → 2nd)1. 2−3 shift valve
2. Off−vehicle repair matrix chart
DI−282
No down−shift (2nd → 1st)1. 1−2 shift valve
2. Off−vehicle repair matrix chart
DI−282
No lock−up or No lock−up off1. Lock−up relay valve
2. Off−vehicle repair matrix chart
DI−282
Harsh engagement (N → D)1. Accumulator control valve
2. Off−vehicle repair matrix chart
DI−282
Harsh engagement (Lock−up)1. Lock−up relay valve
2. Off−vehicle repair matrix chart
DI−282
Harsh engagement (N → R)
1. Accumulator control valve
2. C
2 accumulator
3. Off−vehicle repair matrix chart


DI−282
Harsh engagement (N → L)1. Low coast modulator valve
Harsh engagement (2nd → 3rd → O/D)1. Cut−back valve
Harsh engagement (1st → 2nd → 3rd → O/D)1. Throttle valve
2. Actuator control valve

Harsh engagement (2nd → 3rd)
1. Accumulator control valve
2. C
2 accumulator
3. Off−vehicle repair matrix chart


DI−282
Harsh engagement (3rd → O/D)
1. Accumulator control valve
2. B
0 accumulator
3. Off−vehicle repair matrix chart


DI−282
Harsh engagement (O/D → 3rd)
1. Accumulator control valve
2. C
0 accumulator
3. Off−vehicle repair matrix chart


DI−282
Slip or shudder (Forward and reverse)
1. Throttle cable
2. No.1 gear shifitng rod
3. Oil strainer
4. Pressure relief valve
5. Off−vehicle repair matrix chartDI−265
DI−265
AT−12

DI−282

Downloaded from www.Manualslib.com manuals search engine DI−284
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U) Slip or shudder (Particular position)
1. Throttle cable
2. No.1 gear shifting rod
3. Off−vehicle repair matrix chartDI−265
DI−265
DI−282
No engine braking (1st: L position)1. Low coast modulator valve
2. Off−vehicle repair matrix chart
DI−282
No engine braking (2nd: 2 position)1. 2nd coast modulator valve
2. Off−vehicle repair matrix chart
DI−282
No kick−down1. 1−2 shift valve
2. 2−3 shift valve


Downloaded from www.Manualslib.com manuals search engine − DIAGNOSTICSAUTOMATIC TRANSMISSION
DI−285
1996 TOYOTA T100 (RM449U)
Chapter 3: Off−Vehicle Repair Matrix Chart
(: A340E, A340F, A340H AUTOMATIC TRANSMISSION Repair Manual Pub. No. RM391U)
(: A340F, A343F AUTOMATIC TRANSMISSION Repair Manual Pub. No. RM479U)
SymptomSuspect AreaSee page
Vehicle does not move in any forward position and reverse posi-
tion
1. O/D one−way clutch (F0)
2. O/D direct clutch (C
0)
3. O/D planetary gear unit
4. Torque converter clutch



AT−38
Vehicle does not move in R position
1. Front and rear planetary gear unit
2. Direct clutch (C
2)
3. 1st and reverse brake (B
3)
4. O/D direct clutch (C
0)




No up−shift (1st → 2nd)1. 2nd brake (B2)
2. No. 1 one−way clutch (F
1)


No up−shift (2nd → 3rd)1. Direct clutch (C2)
No up−shift (3rd → O/D)1. O/D brake (B0)
No lock−up or No lock−up off1. Torque converter clutchAT−38
Harsh engagement (N → D)
1. Forward clutch (C1)
2. O/D one−way clutch (F
0)
3. No. 2 one−way clutch (F
2)



Harsh engagement (N → R)
1. Direct clutch (C2)
2. 1st and reverse brake (B
3)
3. O/D one−way clutch (F
0)



Harsh engagement (N → 2)
1. Forward clutch (C1)
2. O/D one−way clutch (F
0)
3. No. 2 one−way clutch (F
2)



Harsh engagement (N → L)
1. Forward clutch (C1)
2. 1st and reverse brake (B
3)
3. O/D one−way clutch (F
0)
4. No. 2 one−way clutch (F
2)




Harsh engagement (Lock−up)1. Torque converter clutchAT−38
Slip or shudder (Forward and reverse: After warm−up)
1. Torque converter clutch
2. O/D one−way clutch (F
0)
3. O/D direct clutch (C
0)
AT−38


Slip or shudder (Particular position: Just after engine starts)1. Torque converter clutchAT−38
Slip or shudder (R position)1. Direct clutch (C2)
2. 1st and reverse brake (B
3)


Slip or shudder (1st)1. Forward clutch (C1)
2. No. 2 one−way clutch (F
2)


Slip or shudder (2nd)
1. 2nd brake (B2)
2. 2nd coast brake (B
1)
3. No. 1 one−way clutch (F
1)



Slip or shudder (3rd)1. Direct clutch (C2)
Slip or shudder (O/D)1. O/D brake (B0)
No engine braking (1st ∼ 3rd: D position)1. 2nd brake (B2)
No engine braking (1st: L position)1. 1st and reverse brake (B3)
No engine braking (2nd: 2 position)1. 2nd coast brake (B1)
Poor acceleration (All position)1. Torque converter clutchAT−38
Poor acceleration (O/D)1. O/D direct clutch (C0)
2. O/D planetary gear unit

Engine stalls when starting off or stopping1. Torque converter clutchAT−38

Downloaded from www.Manualslib.com manuals search engine DI0VK−01
DI−286
− DIAGNOSTICSAUTOMATIC TRANSMISSION
1996 TOYOTA T100 (RM449U)
CIRCUIT INSPECTION
DTC P0500 Vehicle Speed Sensor Malfunction
(No.1 Vehicle Speed Sensor)
See page 3RZ−FE DI−92, 5VZ−FE DI−226.
