Page 101 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
94
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of  P" position when the
brake pedal i

Page 102 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
95
(b) Overdrive switch
You can select either a third gear (with
overdrive off) or fourth gear  (with over-
drive on) by pushing this switch.
To turn the overdrive off, push the switch

Page 103 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
96
Shift into the 2" position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than the following
speed, and stronger engine br

Page 104 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
97
Front drive control lever  in L4"3RZ−FE engine2" 43 km/h (27 mph) . . . . . . . . .
L" 22 km/h (14 mph) . . . . . . . . .
5VZ−FE engine 2" 46 km/h (29 mph

Page 105 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
98
(i) Driving in POWER" mode
In the POWER" mode, the transmission
is shifted up and down at a higher vehicle
speed than in the NORMAL" mode and a
more powerful accelera

Page 106 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
99
Manual transmission
The shift pattern is as shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest  your  foot on  the pedal  while d

Page 107 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
100
Upshifting too soon or downshifting too
late will cause lugging, and possibly ping-
ing. Regularly revving the engine to maxi-
mum speed  in each gear will  cause ex-
cessive engin

Page 108 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
101
Use the front drive control lever to se-
lect the following transfer modes.
H2" (high speed position, two−wheel
drive): Lever at H2"
Use this for normal driving on dry

Page 109 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
102
N" (neutral position): Lever at N"
No power is delivered to the wheels. The
vehicle must be stopped.
L4" (low speed position, four−wheel
drive):  Lever at L4"

Page 110 of 270

TOYOTA TACOMA 2000  Owners Manual (in English) ’00 Tacoma(U)
103
The A.D.D. can be engaged or disen-
gaged by the shifting operations de-
scribed in (d) Shifting procedure".
You should drive in four−wheel drive for
at  least 16 km (10 mil
