’00 Tacoma(U)
104
SHIFTING BETWEEN H4" AND L4"
To shift from H4" to L4", stop the
vehicle or reduce your speed to less than
8 km/h (5 mph). With your foot off the
accelerator pedal, depress the clutch ped-
al and move the front drive control lever.
To shift from L4" to H4", depress the
clutch pedal and move the front drive con-
trol lever.
This can be done at any vehicle speed. SHIFTING BETWEEN H2" AND H4"
With free−wheeling hubs
To shift from H2" to H4",
move the
front drive control lever. Also, engage both
the free−wheeling hubs.
This can be done when the vehicle is
stopped, or moving straight ahead at
speeds of 40 km/h (25 mph) or less. If
you have trouble shifting, depress or re-
lease the accelerator pedal momentarily
while pushing the front drive control lever.
CAUTION
Never move the front drive control
lever if wheels are slipping. Stop
the slipping or spinning before
shifting.
Never drive with only one hub en-
gaged.
To shift from H4" to H2", simply move
the front drive control lever. Also, disen-
gage both the free−wheeling hubs for con-
tinued H2" use.
This can be done at any vehicle speed. If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse.
With A.D.D.
To shift from H2" to H4",
reduce your
speed to less than 80 km/h (50 mph) and
move the front drive control lever.
If you have trouble shifting in cold weath-
er, reduce your speed or stop the vehicle
and reshift.
CAUTION
Never move the front drive control
lever if wheels are slipping. Stop the
slipping or spinning before shifting.
To shift from H4" to H2", simply move
the front drive control lever.
This can be done at any vehicle speed.
If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse.
(d) Shifting procedure
(lever type with automatic
transmission)

’00 Tacoma(U)
105
SHIFTING BETWEEN H4" AND L4"
To shift between H4" and L4", stop
the vehicle and put the transmission in
N". With your foot holding down the
brake pedal, move the front drive control
lever. SHIFTING BETWEEN H2" AND H4"
To shift from H2" to H4",
reduce your
speed to less than 100 km/h (62 mph)
and push in the 4WD" button. You need
not depress the clutch pedal.
If the indicator light does not come on
when you push in the 4WD" button, drive
straight ahead while accelerating or decel-
erating.
If the indicator light flashes and the buzz-
er sounds when you push in the 4WD"
button, reduce your speed or stop the
vehicle and reset.
CAUTION
Never push the 4WD" button if
wheels are slipping. Stop the slipping
or spinning before shifting.
To shift from H4" to H2", push the
4WD" button again to turn it off.
This can be done at any vehicle speed.
You need not depress the clutch pedal.
If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse. SHIFTING BETWEEN H2" OR H4" AND
L4"
To shift from H2" or H4" to L4",
stop the vehicle or reduce your speed to
less than 8 km/h (5 mph). With your foot
off the accelerator pedal, depress the
clutch pedal and move the front drive con-
trol lever.
To shift from L4" to H2" or H4",
depress the clutch pedal and move the
front drive control lever. When the 4WD"
button is pushed in, the transfer shifts into
H4"; when the button is left out, the
transfer shifts into H2".
This can be done at any vehicle speed.
If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse.
(d) Shifting procedure
(lever/button type with manual
transmission)

’00 Tacoma(U)
106
SHIFTING BETWEEN H2" AND H4"
To shift from H2" to H4", reduce your
speed to less than 100 km/h (62 mph)
and push in the 4WD" button.
If the indicator light does not come on
when you push in the 4WD" button, drive
straight ahead while accelerating or decel-
erating.
If the indicator light flashes and the buzz-
er sounds when you push in the 4WD"
button, reduce your speed or stop the
vehicle and reset.
CAUTION
Never push the 4WD" button if
wheels are slipping. Stop the slipping
or spinning before shifting.
To shift from H4" to H2", push the
4WD" button again to turn it off.
This can be done at any vehicle speed.
If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse. SHIFTING BETWEEN H2" OR H4" AND
L4"
To shift from H2" or H4" to L4",
stop the vehicle and put the transmission
in N". With your foot holding down the
brake pedal, move the front drive control
lever.
To shift from L4" to H2" or H4",
stop the vehicle and put the transmission
in N". With your foot holding down the
brake pedal, move the front drive control
lever. When the 4WD" button is pushed
in, the transfer shifts into H4"; when the
button is left out, the transfer shifts into
H2".
If the indicator light does not go off when
you shift the transfer into H2", drive
straight ahead while accelerating or decel-
erating, or drive in reverse.
Rear differential lock system
The rear differential lock system is pro-
vided for use only when wheel spinning
occurs in a ditch or on a slippery or
ragged surface.
This differential lock system is effective in
case one of the rear wheels is spinning.
Except for Pre Runner models
⎯
Before using the rear differential lock sys-
tem, first shift the front drive control into
L4" with the free−wheeling hubs engaged
to see if it works. If this has no effect,
additionally use the rear differential lock
system.
(d) Shifting procedure
(lever/button type with
automatic transmission)

’00 Tacoma(U)
107
CAUTION
Do not use the rear differential lock
in the conditions other than above.
Large steering effort and careful cor-
nering control will be required.
To lock the rear differential, push the
switch.
Be sure to stop the wheels before locking
the differential.
For easy locking, depress the clutch ped-
al, push the lock switch and slowly re-
lease the clutch pedal.
The indicator light will blink when the
switch is turned on. Wait a few seconds
for the system to complete operation. Af-
ter the differential is locked, the light will
stop blinking and remain on.
The anti−lock brake system does not oper-
ate when the rear differential is locked. It
is normal operation for the ABS" warning
light to be on at this time.
CAUTION
Do not lock the differential until the
wheels have stopped spinning.
Otherwise, the vehicle may move in
an unexpected direction when the
differential lock is engaged, result-
ing in an accident. This may also
lead to possible damage to differen-
tial lock component parts.
Do not drive over 8 km/h (5 mph)
when the differential is locked.
To unlock the differential, push the
switch once again.
Unlock the differential as soon as the ve-
hicle moves out.
For easy unlocking, slightly turn the steer-
ing wheel in either direction while the ve-
hicle is in motion.
When the differential lock is disengaged,
the indicator light will go out.
Except for Pre Runner models⎯
The differential will also unlock if you shift
the front drive control lever out of L4".
Never forget to turn off the switch after
using this feature.

’00 Tacoma(U)
108
To check the indicator bulb, turn the igni-
tion key to the ON" position, but do not
start the engine.
CAUTION
Do not keep driving with the differen-
tial lock switch on.
Parking brake
When parking, firmly apply the parking
brake to avoid inadvertent creeping.
To set: Pull out on the lever. For better
holding power, first depress the brake
pedal and hold it while setting the parking
brake.
To release: Press the lock release button,
turn the lever, and push it in.
To remind you that the parking brake is
set, the parking brake reminder light in
the instrument panel remains on until you
release the parking brake.
CAUTION
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.

’00 Tacoma(U)
109
Cruise control
The cruise control allows you to cruise
the vehicle at a desired speed over 40
km/h (25 mph) even with your foot off
the accelerator pedal.
Your cruising speed can be maintained up
or down grades within the limits of engine
performance, although a slight speed
change may occur when driving up or
down the grades. On steeper hills, a
greater speed change will occur so it is
better to drive without the cruise control.
CAUTION
To help maintain maximum control
of your vehicle, do not use the
cruise control when driving in
heavy or varying traffic, or on slip-
pery (rainy, icy or snow−covered) or
winding roads.
Avoid vehicle speed increases when
driving downhill. If the vehicle
speed is too fast in relation to the
cruise control set speed, cancel the
cruise control then downshift the
transmission to use engine braking
to slow down.
TURNING ON THE SYSTEM
To operate the cruise control, press the
CRUISE ON·OFF" button. This turns the
system on. The indicator light in the
instrument panel shows that you can now
set the vehicle at a desired cruising
speed. Another press will turn the system
completely off.
CAUTION
To avoid accidental cruise control en-
gagement, keep the CRUISE ON·OFF"
switch off when not using the cruise
control.
SETTING AT A DESIRED SPEED
On vehicles with automatic transmission,
the transmission must be in D" before
you set the cruise control speed.
Bring your vehicle to the desired speed,
push the lever down in the SET/COAST"
direction and release it. This sets the ve-
hicle at that speed. If the speed is not
satisfactory, tap the lever up for a faster
speed, or tap it down for a slower speed.
Each tap changes the set speed by 1.6
km/h (1.0 mph). You can now take your
foot off the accelerator pedal.

’00 Tacoma(U)
11 0
If you need accelerationfor example,
when passingdepress the accelerator
pedal enough for the vehicle to exceed
the set speed. When you release it, the
vehicle will return to the speed set prior
to the acceleration.
CAUTION
For manual transmission:
While driving with the cruise control
on, do not shift to neutral without
depressing the clutch pedal, as this
may cause engine racing or overrev-
ving.
CANCELLING THE PRESET SPEED
You can cancel the preset speed by:
a. Pulling the lever in the CANCEL"direction and releasing it
b. Depressing the brake pedal
c. Depressing the clutch pedal (manual
transmission)
If the vehicle speed falls below about 40
km/h (25 mph), the preset speed will auto-
matically cancel out.
If the vehicle speed drops 16 km/h (10
mph) below the preset speed, the preset
speed will also automatically cancel out. If the preset speed automatically cancels
out other than for the above cases, have
your vehicle checked by your Toyota deal-
er at the earliest opportunity.
RESETTING TO A FASTER SPEED
Push the lever up in the RES/ACC" direc-
tion and hold it. Release the lever when
the desired speed is attained. While the
lever is held up, the vehicle will gradually
gain speed.
However, a faster way to reset is to ac-
celerate the vehicle and then push the
lever down in the SET/COAST" direction.
RESETTING TO A SLOWER SPEED
Push the lever down in the SET/COAST"
direction and hold it. Release the lever
when the desired speed is attained. While
the lever is held down, the vehicle speed
will gradually decrease.
However, a faster way to reset is to de-
press the brake pedal and then push the
lever down in the SET/COAST" direction.
On vehicles with automatic transmission,
even if you turn off the overdrive switch
with the cruise control on, engine braking
will not be applied because the cruise
control is not cancelled. To decrease the
vehicle speed, reset to a slower speed
with the cruise control lever or depress
the brake pedal. If you use the brake
pedal, cruise control is cancelled.
RESUMING THE PRESET SPEED
If the preset speed is cancelled by pulling
the control lever or by depressing the
brake pedal or clutch pedal, pushing the
lever up in the RES/ACC" direction will
restore the speed set prior to cancellation.
However, once the vehicle speed falls be-
low about 40 km/h (25 mph), the preset
speed will not be resumed.

’00 Tacoma(U)
111
CRUISE CONTROL FAILURE WARNING
If the CRUISE" indicator light in the
instrument cluster flashes when using the
cruise control, press the CRUISE
ON·OFF" button to turn the system off and
then press it again to turn it on.
If any of the following conditions then oc-
curs, there is some trouble in the cruise
control system.
The indicator light does not come on.
The indicator light flashes again.
The indicator light goes out after it
comes on.
If this is the case, contact your Toyota
dealer and have your vehicle inspected.
To crank the engine without depressing
the clutch pedal, push the switch with
the ignition on.
The switch stays on as long as the igni-
tion is on. And it will automatically turn off
when the ignition is off. An indicator light
will illuminate to indicate the system is
operating.
This switch cancels the clutch start sys-
tem, which is designed to keep the starter
motor from operating if the clutch pedal is
not depressed all the way down.
The switch allows the vehicle to be driven
out of difficult situations by cranking the
engine with the clutch engaged. Never use the switch for normal engine
starting. Be sure to follow the starting
procedure instructed in How to start the
engine" in Section 3.
Clutch start cancel switch
(four−wheel drive models
with manual transmission)

’00 Tacoma(U)
11 2

’0 0 Ta c om a (U)
11 3
OPERATION OF INSTRUMENTS AND
CONTROLS
Car audio system
Reference11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Using your audio system 11 4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Car audio system operating hints 134
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 1− 7
