TOYOTA TACOMA 2000 Owners Manual (in English)

’00 Tacoma(U)
144
If following another vehicle on a dusty
road, or driving in windy and dusty
conditions, it is recommended that the
air intake selector be temporarily set to
RECIRCULATE, which will close off the
outside passage and prevent outside
air and dust from entering the vehicle
interior.
Heating
For best results, set controls to:
Fan speed Any setting except OFF"
Temperature To w a r d s WA R M
(red zone)
Air intakeFRESH (outside air)
Air flowFLOOR
Air conditioningOFF
For quick heating, select recirculated
air for a few minutes. To keep the
windows from fogging, select fresh af-
ter the vehicle interior has been
warmed.
Press the A/C" button on for dehumidi-
fied heating.
Choose floor/windshield air flow to heat
the vehicle interior while defrosting or
defogging the windshield. Air conditioning
For best results, set controls to:
Fan speed Any setting except OFF"
Temperature To w a r d s COLD
(blue zone)
Air intakeFRESH (outside air)
Air flowPANEL
Air conditioningON
For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speed Any setting except OFF"
Temperature To w a r d s COLD
(blue zone)
Air intakeFRESH (outside air)
Air flowPANEL
Air conditioningOFF

’00 Tacoma(U)
145
Defogging
The inside of the windshield
For best results, set controls to:Fan speed Any setting except OFF"
Temperature To w a r d s WA R M
(red zone) to heat;
COLD (blue zone) to
cool
Air intakeFRESH (outside air)
Air flowWINDSHIELD
Turning the Air Flow Selector to wind-
shield position turns on the defroster to
clear the front view more quickly.
Vehicles with A/C" button
Press the A/C" button for dehumidified
heating or cooling. This setting clears the
front view more quickly.
On humid days, do not blow cold air
on the windshieldthe difference be-
tween the outside and inside tempera-
tures could make the fogging worse. Defrosting
The outside of the windshield
For best results, set controls to:
Fan speed Any setting except OFF"
Temperature To w a r d s WA R M
(red zone)
Air intakeFRESH (outside air)
Air flowWINDSHIELD
Turning the Air Flow Selector to wind-
shield position turns on the defroster to
clear the front view more quickly.
Vehicles with A/C" button
Press the A/C" button for dehumidified
heating or cooling. This setting clears the
front view more quickly.
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
Side vents
If air flow control is not satisfactory, check
the side vents. The side vents may be
opened or closed as shown.

’00 Tacoma(U)
146

’0 0 Ta c om a (U)
147
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Clock148
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 148
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlets 149
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Glove box 150
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Cup holder 150
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Floor mat 151
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
SECTION 1− 9

’00 Tacoma(U)
148
Clock
The digital clock indicates the time.
The key must be in the ACC" or ON"
position.
To reset the hour: Push the H" button.
To reset the minutes: Push the M" button.
If quick adjustment to a full hour is de-
sired, push the :00" button.
For example, if the :00" button is de-
pressed when the time is between
1:011:29, the time will change to 1:00.
If the time is between 1:301:59, the
time will change to 2:00.If the electrical power source has been
disconnected from the clock, the time dis-
play will automatically be set to 1:00 (one
o’clock).
When the instrument panel lights are
turned on, the brightness of the time in-
dication will be reduced.
Cigarette lighter and ashtray
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automatical-
ly pops out ready for use.
If the engine is not running, the key must
be in the ACC" position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.

’00 Tacoma(U)
149
ASHTRAY
To use the ashtray, pull it out.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, push it back
in completely.
To remove the ashtray, press down on the
lock spring plate and pull out.
CAUTION
To reduce the chance of injury in
case of an accident or sudden stop
while driving, always push the ash-
tray back in completely after using.
Power outlets
The power outlets are designed for
power supply for car accessories.
The key must be in the ACC" or ON"
position for the power outlets to be used.
NOTICE
To prevent the fuse from being
blown, do not use the electricity
over the total vehicle capacity of
12V/120W.
 To prevent the battery from being
discharged, do not use the power
outlets longer than necessary when
the engine is not running.
Close the power outlet lids when
the power outlets are not in use.
Inserting a foreign object other than
the appropriate plug that fits the
outlet, or allowing any liquid into
the outlet may cause electrical fail-
ure or short circuits.

’00 Tacoma(U)
150
Glove box
To open the glove box door, pull the
lever.
On some models, the glove box light will
come on when the glove box is open with
the instrument panel lights on.
CAUTION
To reduce the chance of injury in
case of an accident or a sudden stop,
always keep the glove box door
closed while driving.
Cup holder
The cup holder is designed for holding
cups or drink−cans securely in its
holes.
To use the second cup holder, pull it out.
CAUTION
Xtra−cab models only: Do not use
the second cup holder when you
move passenger ’s seat for rear seat
entry. The seat may interfere with
second cup holder and the drink
may spill over the occupants. If the
spilled drink is hot, it may cause
burns.
Do not place anything else other
than cups or drink−cans on the cup
holder, as such items may be
thrown about in the compartment
and possibly injure people in the
vehicle during sudden braking or in
an accident.
To reduce the chance of injury in
case of an accident or sudden stop
while driving, keep the second cup
holder closed when it is not in use.
NOTICE
Xtra−cab models only: Do not use the
second cup holder when you move
passenger ’s seat for rear seat entry.
The seat may interfere with the sec-
ond cup holder and the spilled drink
may cause a malfunction on the elec-
trical components.

’00 Tacoma(U)
151
Cup holder (Xtra−cab models)
The cup holder is designed for holding
cups fit securely in its holes.
To use the cup holder, raise the folding
table under the right−rear seat. Stand the
table by compressing and turning down
the table legs.
CAUTION
Do not place anything else other
than cups on the cup holder, as
such item may be thrown about in
the compartment and possibly in-
jure people in the vehicle during
sudden braking or an accident.
To reduce the chance of injury in
case of an accident or sudden stop
while driving, keep the cup holder
closed when it is not in use.
Floor mat
Use a floor mat of the correct size.
If the floor carpet and floor mat have a
hole, then it is designed for use with a
locking clip. Fix the floor mat with locking
clip into the hole in the floor carpet.

’00 Tacoma(U)
152
CAUTION
Make sure the floor mat is properly
placed on the floor carpet. If the floor
mat slips and interferes with the
movement of the pedals during driv-
ing, it may cause an accident.

’00 Tacoma(U)
153
INFORMATION BEFORE DRIVING YOUR
TOYOTA
Off−road vehicle precautions154
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Break−in period 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Fuel 155
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Operation in foreign countries 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Three−way catalytic converter 157
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine exhaust cautions 159
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Facts about engine oil consumption 160
. . . . . . . . . . . . . . . . . . . . . . . . . .
Twin ground electrode spark plugs 161
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake system 161
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Brake pad wear limit indicators 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage stowage precautions 164
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear step bumper 165
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Your Toyota’s identification 165
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension and chassis 166
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Types of tires 167
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
SECTION 2
