605
7
For owners
Cargo weight rating and proper matchingWhen the truck is used to carry a slide-in camper, the total cargo load
of the truck consists of the manufacturer’s camper weight figure, the
weight of installed additional camper equipment not included in the
manufacturer’s camper weight figu re, the weight of camper cargo,
and the weight of passengers in the camper.
The total cargo load should not exceed the truck’s cargo weight rating
and the camper’s center of gravity should fall within the truck’s rec-
ommended center of gravity zone when installed.
Camper center of gravity
Recommended center of grav-
ity location zone
■ Cargo weight rating
Regular Cab models
3 people, 2TR-FE engine, 2WD: 700 lb. (317 kg)
2 people, 2TR-FE engine, 4WD: 1000 lb. (453 kg)
3 people, 2TR-FE engine, 4WD: 850 lb. (385 kg)
CAUTION
■Loading precaution
If a load is too far back, it can cause dangerous handling. If it is too far
forward, the front axle may be overloaded.
606
Access Cab models
2 people, 2TR-FE engine, 2WD except PreRunner:750 lb. (340 kg)
4 people, 2TR-FE engine, 2WD except PreRunner: 450 lb. (204 kg)
2 people, 2TR-FE engine, PreRunner: 1000 lb. (453 kg)
4 people, 2TR-FE engine, PreRunner: 700 lb. (317 kg)
2 people, 1GR-FE engine, PreRunner: 950 lb. (430 kg)
4 people, 1GR-FE engine, PreRunner: 650 lb. (294 kg)
2 people, 2TR-FE engine, 4WD: 900 lb. (408 kg)
4 people, 2TR-FE engine, 4WD: 600 lb. (272 kg)
2 people, 1GR-FE engine, 4WD: 850 lb. (385 kg)
4 people, 1GR-FE engine, 4WD: 550 lb. (249 kg)
Double Cab models with short deck
2 people, 2TR-FE engine, 2WD except PreRunner: 650 lb. (294 kg)
5 people, 2TR-FE engine, 2WD except PreRunner: 200 lb. (90 kg)
2 people, 1GR-FE engine, PreRunner: 850 lb. (385 kg)
5 people, 1GR-FE engine, PreRunner: 400 lb. (181 kg)
2 people, 1GR-FE engine, 4WD: 750 lb. (340 kg)
5 people, 1GR-FE engine, 4WD: 300 lb. (136 kg)
Double Cab models with long deck
2 people, 1GR-FE engine, PreRunner: 850 lb. (385 kg)
5 people, 1GR-FE engine, PreRunner: 400 lb. (181 kg)
2 people, 1GR-FE engine, 4WD: 750 lb. (340 kg)
5 people, 1GR-FE engine, 4WD: 300 lb. (136 kg)
CAUTION
■Overloading
Be careful — overloading can cause dangerous braking and handling
problems, and can damage your vehicle and its tires.
607
7
For owners
Gross axle and vehicle weight ratingsSecure loose items to prevent weight shifts that could affect the bal-
ance of your vehicle. When the truck camper is loaded, drive to a
scale and weigh on the front and on the rear wheels separately to
determine axle loads. Individual ax le loads should not exceed either
of the Gross Axle Weight Ratings (GAWR). The total of the axle loads
should not exceed the Gross Vehicl e Weight Rating (GVWR). These
ratings are given on the vehicle cert ification label which is located on
the door latch post on the left side of the vehicle. ( P. 553) If weight
ratings are exceeded, move or remove items to bring all weights
below the ratings.
Gross axle weight rating Front GAWR
Rear GAWR
Gross vehicle weight rating Not exceed GVWR
