TOYOTA TACOMA 2021 Accessories, Audio & Navigation (in English)

913-2. Destination search
3
Navigation system
1Select “Go” on the confirm
destination screen.
For details about this screen:
P. 9 1
2Select “OK” on the route
overview screen.
For details about this screen:
P. 9 2
●The route for returning may not be
the same as that for going.
●The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges-tion.
●Route guidance may not be avail-
able if there is no road data for the
specified location.
●When setting the destination on a
map with a scale more than 0.5
miles (800 m), the map scale
changes to 0.5 miles (800 m)
automatically. If this occurs, set
the destination again.
●If a destination that is not located
on a road is set, the vehicle will be
guided to the point on a road near-
est to the destination. The road
nearest to the selected point is set
as the destination.
Select to search for the route.
(P.91)
• If a destination has already been
set, “Go Directly” and “Add to
Route” will be displayed.
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
Starting route guid-
ance
When the destination is set,
the entire route map from
the current position to the
destination is displayed.
Starting route guidance
WA R N I N G
●Be sure to obey traffic regula-
tions and keep road conditions
in mind while driving. If a traffic
sign on the road has been
changed, the route guidance
may not indicate such changed
information.
Confirm destination
screen
A

923-2. Destination search
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.
*
*: This function is displayed only
when there is information from
the Cloud. (P. 8 5 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. (P.93)
Select to change the route.
(P. 9 3 )
Select the desired route from
3 possible routes. (P. 9 2 )
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo mode. (P.92)
Displayed when the route
displayed is from the Cloud.
(P.94)
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1Select and hold “OK” on the
route overview screen until a
beep sounds.
Press the “HOME” or “MAP”
button to end demo mode.
1Select “3 Routes”.
2Select the desired route.
Displayed when the route
displayed is available from
the Cloud. ( )
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Select to display the alterna-
Route overview screen
B
C
D
A
B
C
D
E
F
G
H
6WDUWLQJGHPRPRGH
URXWHVVHOHFWLRQ
I
A
B
C
D

933-2. Destination search
3
Navigation system
tive route.
Select to display the informa-
tion about the 3 routes.
(P. 9 3 )
1Select “Info”.
2Check that the 3 routes infor-
mation screen is displayed.
Time necessary for the entire
trip
Distance of the entire trip
Distance of the toll road
Distance of the freeway
Distance of the ferry trip
A list of turn information from the
current position to the destina-
tion can be displayed.
1Select “Turn List”.2Check that the turn list is dis-
played.
Current position
Distance to the next turn
Turn direction at the intersec-
tion
Select to display the map of
the selected point.
●Not all road names on the route
may appear on the list. If a road
changes its name without requir-
ing a turn (such as on a street that
runs through 2 or more cities), the
name change will not appear on
the list. The street names will be
displayed in order from the start-
ing point, along with the distance
to the next turn or the destination.
Destinations can be added,
reordered or deleted, and condi-
tions for the route to the destina-
tion can be changed.
1Select “Edit Route”. Displaying 3 routes informa-
tion
Displaying turn list
E
A
B
C
D
E(GLWLQJURXWH
A
B
C
D

943-2. Destination search
2Select the desired item.
Select to add destinations.
(P. 9 4 )
Select to delete destinations.
(P. 9 4 )
Select to reorder destina-
tions. (P.100)
Select to set route prefer-
ences. (P.100)
When the vehicle is stopped
1Select “Add”.
2Search for an additional des-
tination in the same way as a
destination search. (P. 8 4 )
Up to 5 destinations can be
set.
3Select “Add” at the position in
the route which you want to
add the destination.
While driving
1Select “Add”.
2Search for an additional des-
tination in the same way as a
destination search. (P. 8 4 )
Up to 5 destinations can be set.
3Select “Beginning” or “End”.
1Select “Delete”.
2Select “Yes” when the confir-
mation screen appears.
If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)
*: This function is not made avail-
able in some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the
Cloud. This function is available
when dynamic route setting is
enabled. (P.106) Adding destinations
A
B
C
D
'HOHWLQJGHVWLQDWLRQV
$URXWHIURPWKH&ORXG

953-3. Route guidance
3
Navigation system
3-3.Route guidance
Distance to the next turn and
an arrow indicating the turn-
ing direction
Guidance route
Current position
Select to mute the voice
guidance.
Route information (P.95)
Select to delete destinations.
(P. 2 2 )
Displays the lane recommen-
dation (P. 9 6 )
●If the vehicle goes off the guid-
ance route, the route will be recal-
culated.
●For some areas, the roads have
not been completely digitized in
our database. For this reason, the
route guidance may select a road that should not be traveled on.
●When arriving at the set destina-
tion, the destination name will be
displayed on the upper part of the
screen.
●When the automatic zoom func-
tion is enabled, the map will auto-
matically change to a detailed
map as the vehicle approaches a
guidance point. (P.107)
When the vehicle is on the guid-
ance route, the route informa-
tion bar displays the distance
with the estimated travel/arrival
time to the destination.
When the set destination is 1
1Check that the distance and
time to destination is dis-
played.
When the set destinations are
more than 1
1Select the route information
bar.
Route guidance
screen
During the route guidance,
various types of guidance
screens can be displayed
depending on conditions.
Screen for route guidance
A
B
C
D
E
F
G
'LVWDQFHDQGWLPHWRGHVWL
QDWLRQ

963-3. Route guidance
2Check that the list of the dis-
tance and time is displayed.
By selecting one of the num-
ber buttons, the desired route
information is displayed.
●When the vehicle is on the guid-
ance route, the distance mea-
sured along the route is displayed.
Travel time and arrival time are
calculated based on the average
speed of the specified speed limits
and current traffic information.
●When the vehicle gets off the
guidance route, the arrow facing
the destination is displayed
instead of the estimated
travel/arrival time.
●The route information bar fills from
left to right as the vehicle pro-
gresses along the route.
When approaching a turning
point, the lane recommendation
will automatically be displayed
on the map.During freeway driving, the free-
way information screen can be
displayed.
Distance from the current
position to the freeway
exit/rest area
Name of the freeway exit/rest
area
POIs that are close to a free-
way exit
Select to display farther free-
way exits/rest areas.
When the vehicle approaches
an exit or junction, the freeway
guidance screen will be dis-
played. Lane recommendation
During freeway driving
When approaching free-
way exit or junction
A
B
C
D

973-3. Route guidance
3
Navigation system
Next exit or junction name
Select to hide the freeway
guidance screen.
• To return to the freeway guidance
screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. (P.106)
When the vehicle approaches a
tollgate, the tollgate view will be
displayed.
Select to hide the tollgate
guidance screen.
• To return to the tollgate guidance
screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. (P.106)
When the vehicle approaches a
junction, the junction view with
signage will be displayed.
Select to hide the real free-
way junction view.
• To return to the real freeway junc-
tion view, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. (P.106)
When the vehicle approaches
an intersection, the intersection
guidance screen will be dis-
played. When approaching toll-
gate
A
B
C
A
B
:KHQDSSURDFKLQJMXQF
WLRQ
:KHQDSSURDFKLQJLQWHU
VHFWLRQ
A
B

983-3. Route guidance
Next street name
Select to hide the intersection
guidance screen.
• To return to the intersection guid-
ance screen, press the “MAP”
button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. (P.106)
1Select “Turn List” on the map
mode screen. (P.77)
2Check that the turn list
screen is displayed.
Turn direction
Next street or destination
name
Distance between turns
On this screen, information
about the next turn on the guid-
ance route can be displayed.1Select “Turn-by-Turn Arrow”
on the map mode screen.
(P.77)
2Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
Turn-by-turn arrow screen
A
B
C
A
B
C
A
B
C

993-3. Route guidance
3
Navigation system
●If a voice guidance command can-
not be heard, press the “MAP”
button to hear it again.
●To adjust the voice guidance vol-
ume: P. 6 4
●To mute the voice guidance:
P. 9 5
●Voice guidance may be made
early or late.
●If the navigation system cannot
determine the current position cor-
rectly, you may not hear voice
guidance or may not see the mag-
nified intersection on the screen.
1Select on the map
screen. (P. 7 2 )
2Select the desired item to be
set.
Select to display the over-
view of the entire route.
(P.92)
Select to reorder destina-
tions. (P.100)
Select to change route type.
(P.100)
Select to set route prefer-
ences. (P.100)
Select to set detours.
(P.100)
Select to start from adjacent
road. (P.101)
To hide the route options
screen, touch any part of the
map screen.
3Check that the route over-
view is displayed. (P.92)
Typical voice guid-
ance prompts
As the vehicle approaches
an intersection, or point,
where maneuvering the
vehicle is necessary, the
navigation system’s voice
guidance will provide vari-
ous messages.
WA R N I N G
●Be sure to obey the traffic regu-
lations and keep the road condi-
t i o n i n m i n d e s p e c i a l l y w h e n y o u
are driving on IPD roads (roads
that are not completely digitized
in our database). The route
guidance may not have the
updated information such as the
direction of a one way street.
Editing route
Displaying the edit route
screen
A
B
C
D
E
F

1003-3. Route guidance
When more than 1 destination
has been set, the arrival order of
the destinations can be
changed.
1Select on the map
screen. (P.72)
2Select “Reorder”.
3Select the desired destina-
tion and select “Move Up” or
“Move Down” to change the
arrival order. Then select
“OK”.
1Select on the map
screen. (P.72)
2Select “Route Type”.
3Select the desired route type.
The entire route from the
starting point to the destina-
tion is displayed. (P.92)
During driving, the route guid-
ance starts after selecting the
desired route type.The conditions to determine the
route can be selected from vari-
ous choices such as freeways,
toll roads, ferries, etc.
1Select on the map
screen. (P. 7 2 )
2Select “Preference”.
3Select the desired route pref-
erences and select “OK”.
●Even if the “Avoid Freeways”
route preference is turned off, the
route may not be able to avoid
freeways in some cases.
●If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After traveling
by ferry, the current position may
be incorrect. Upon reception of
GPS signals, it is automatically
corrected.
During the route guidance, the
route can be changed to detour
around a section of the route
where a delay is caused by road
repairs, an accident, etc.
1Select on the map
screen. (P. 7 2 )
2Select “Detour”. Reordering destinations
Selecting route type
Setting route preferences
Detour setting
