813-1. Basic operation
3
Navigation system
*: This function is not made avail-
able in some countries or areas.
1Press the “MENU” button.
2Select “Info”.
3Select “Traffic Incidents”.
When the route has not been
set
Select to display traffic infor-
mation for the current road.
(P. 8 2 )Select to display nearby traf-
fic information. (P.82)
Select to display a map with
predictive traffic data.
(P.82)
Select to display traffic along
the saved routes. (P.82)
When the route has been set
Select to display traffic infor-
mation for the set route.
(P.82)
Select to display nearby traf-
fic information. (P.82)
Select to display a map with
predictive traffic data.
(P.82)
Select to display traffic along
the saved routes. (P.82)
●If a large amount of information is
being received, it may take longer
than normal for the information to
be displayed on the screen.
●If traffic information cannot be
received because the vehicle is
outside of HD Radio coverage
area, it may still be able to be
received using DCM. (P.168)
Tr af fic infor mation*
Traffic data can be received
via HD Radio™ broadcast
or via DCM (Data Communi-
cation Module) to display
traffic information on the
map screen.
Displaying the traffic inci-
dents screen
A
B
C
D
A
B
C
D

823-1. Basic operation
A list of current traffic informa-
tion can be displayed along with
information on the location of
each incident.
1Display the traffic incidents
screen. (P.81)
2Select “Traffic Events on Cur-
rent Road”, “Traffic Events on
Current Route” or “Traffic
Events Nearby”.
3Select the desired traffic
information.
When “Traffic Events Nearby”
is selected, depending on
whether the traffic flow infor-
mation is enabled/disabled,
the following will be displayed:
When enabled: Traffic event and
congestion information
When disabled: Traffic event infor-
mation only
4Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
A map with predictive traffic data
can be displayed.
1Display the traffic incidents
screen. (P.81)
2Select “Predictive Traffic
Map”.3Scroll the map to the desired
point (P.75) and set the
time of predictive traffic infor-
mation.
The time of the predictive traf-
fic information can be
changed in 15-minute inter-
vals up to +45 minutes.
“<”: Moves the time forward 15 min-
utes.
“>”: Moves the time back 15 min-
utes.
Traffic information along the
saved routes can be displayed.
To use this function, it is neces-
sary to register a route.
(P.110)
1Display the traffic incidents
screen. (P. 8 1 )
2Select “My Traffic Routes”.
If map data has been
updated, a confirmation
screen will be displayed.
Select “OK” or “Do Not Tell
Me Again”.
3Select the desired route.
“Options”: Select to add, edit or
delete personal traffic routes.
(P. 1 1 0 )
If routes have not been regis-
tered yet, a confirmation
screen will be displayed.
Select “Yes” to register the
route.
4Select the desired traffic
information. Displaying traffic informa-
tion
Displaying predictive traf-
fic information
My traffic routes

833-1. Basic operation
3
Navigation system
5Check that the traffic informa-
tion is displayed.
“Detail”: Select to display detailed
traffic information.
1Select on the map
screen.
2Select “Traffic Information”.
3Check that the traffic informa-
tion is displayed.
●The icons indicate traffic incidents
such as construction, accidents,
etc. Select an icon to hear more
detail by voice.
●The arrows indicate the flow of
traffic. The color changes depend-
ing on the speed.
Displaying traffic informa-
tion on the map

843-2. Destination search
3-2.Destination search
The destination screen enables
to search for a destination. The
destination screen can be
reached by the following meth-
ods:
■From the map screen
1Press the “MAP” button.
2Select .
3Follow the steps in “From the
menu screen” from step 3.
(P. 8 4 )
■From the menu screen
1Press the “MENU” button.
2Select “Destination”.
3Select the desired search
method.Select to set a destination by
home. (P.85)
Select to search for a desti-
nation by entering keywords.
(P.85)
Select to search for a desti-
nation via the Toyota
response center.
* (P.288)
Select to search for a desti-
nation from a registered entry
in “Favorites”. (P. 8 6 )
Select to search for a desti-
nation from recent set desti-
nations. (P. 8 6 )
Select to search for a desti-
nation from emergency ser-
vice points. (P.86)
Select to search for a desti-
nation by address. (P. 8 7 )
Select to search for a desti-
nation by point of interest.
(P.88)
Select to search for a desti-
nation from contact data
which had been transferred
to the navigation system from
a registered Bluetooth
®
phone. (P.87)
*: This function is not made avail-
able in some countries or areas.
●To hide the destination screen,
touch any part of the map screen.
Destination search
operation
Destination screen
A
B
C
D
E
F
G
H
I

853-2. Destination search
3
Navigation system
The selected state (province)
can be changed to set a desti-
nation from a different state
(province) by using “Address” or
“Point of Interest”.
1Display the destination
screen. (P.84)
2Select “Address” or “Point of
Interest”.
3Select “Change State/Prov-
ince”.
If a state (province) has not
been selected yet,
“State/Province” screen is dis-
played directly.
4Select the desired state
(province).
To change countries, select
“Change Country”.
To use this function, it is neces-
sary to register a home address.
(P.102)
1Display the destination
screen. (P.84)2Select “Home”.
The navigation system per-
forms a search for the route
and the route overview is dis-
played. (P.92)
The destination can be
searched by entering various
keywords.
1Display the destination
screen. (P. 8 4 )
2Select “Search”.
3Enter characters on the key-
board.
4Select “Search”.
5When there is more than 1
result, select the desired item
from the list.
: Select to display updated infor-
mation about the selected entry.
This function is displayed only
when there is information from the
Cloud.
●To search for a facility name using
multiple search words, put a
space between each word.
●Search results may differ depend-
ing on the connected services
subscription status and communi-
Selecting search area
Setting home as destina-
tion
Searching by keyword

863-2. Destination search
cation status.
To use this function, it is neces-
sary to register a favorites list
entry. (P.103)
1Display the destination
screen. (P.84)
2Select “Favorites”.
3Select the desired favorites
list entry.
*: This function is not made avail-
able in some countries or areas.
A Destination Assist operator
can search for a destination.
You can request a specific busi-
ness, address, or ask for help
locating your desired destina-
tion. (P.288)
1Display the destination
screen. (P.84)
2Select “Dest Assist”.1Display the destination
screen. (P. 8 4 )
2Select “Recent”.
3Select the desired destina-
tion.
“Sort/Delete”: Select to sort (date,
name) or delete destination(s).
●Up to 100 previously set destina-
tions are displayed on the screen.
1Select “Sort/Delete”.
2Select “Delete Recent Desti-
nations”.
3Select the desired recent
destination(s) to be deleted.
4Select “Yes” when the confir-
mation screen appears.
“Sort/Delete All”: Select to sort
(date, name) destinations or delete
all.
1Display the destination
screen. (P. 8 4 )
Searching by favorites list
Searching by Destination
Assist*
Searching by recent desti-
nations
Deleting recent destina-
tions
Searching by emergency

873-2. Destination search
3
Navigation system
2Select “Emergency”.
3Select the desired emer-
gency category.
4Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. (P. 1 1 4 )
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. (P.250)
1Display the destination
screen. (P.84)
2Select “Contacts”.
3Select the desired contact.
4Select “Addresses”.
5Select the desired address.6Follow the steps in “Search-
ing by keyword” from step 4.
(P.85)
●This function may not be available
depending on the type of Blue-
tooth
® phone.
1Display the destination
screen. (P. 8 4 )
2Select “Address”.
3Enter a house number and
select “Search”.
4Enter a street name and
select “Search”.
5Select the desired street
name.
6Enter a city name and select
“Search”.
7Select the desired city name.
If multiple locations with the
same address exist, the
address list screen will be dis-
played. Select the desired
address.
●A street name can be searched
using only the body part of its
name.
For example: S WESTERN AVE
Searching by contact
Searching by address

883-2. Destination search
• A search can be performed by
entering “S WESTERN AVE”,
“WESTERN AVE” or “WEST-
ERN”.
There are 3 methods to search
for a destination by Points of
Interest.
1Display the destination
screen. (P.84)
2Select “Point of Interest”.
3Select the desired search
method.
Select to change the search
area. (P.85)
Select to search by name.
(P. 8 8 )
Select to search by category.
(P. 8 9 )
Select to search by phone
number. (P.89)
1Select “Name”.
2Enter a POI name and select
“Search”.3Select the desired POI.
“Sort/Category/City”: Select to sort
(name, distance) the displayed
entries, change the POI category,
or enter a city name.
When entering the name of a
specific POI, and there are 2
or more sites with the same
name, the list screen will be
displayed. Select the desired
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1Select “Sort/Category/City”.
2Select “Enter a city name”.
3Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5Select the desired POI.
1Select “Sort/Category/City”.
2Select “Change POI cate-
gory”.
3Select the desired category.
If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4Select the desired POI.
Searching by point of
interest
Searching by name
A
B
C
D
6HOHFWLQJDFLW\WRVHDUFK
6HOHFWLQJIURPWKHFDWHJR
ULHV

893-2. Destination search
3
Navigation system
1Select “Category”.
2Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
(P. 8 9 )
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3Select the desired POI cate-
gory.
If there is more than 1 result
for the selected category, a
detailed list will be displayed.
Select “Other POIs” to select
other than default POI catego-
ries. The following button can
be displayed.
“List All Categories”: Select to dis-play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs that have been pre-
viously set. (P.107)
4Select the desired POI.
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed
up to 200 names.
1Select “Near a City Center in
XX
*”.
2Enter a city name and select
“Search”.
“Last 5 Cities”: Select the desired
city name from the list of the last 5
cities.
3Select the desired city name.
4Select “OK” when the city
center map screen is dis-
played.
5Follow the steps in “Search-
ing by category” from step 3.
(P.89)
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1Select “Phone #”. Searching by category
A
B
C
D
:KHQ

903-2. Destination search
2Enter a phone number and
select “OK”.
If multiple locations with the
same phone number exist,
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
will be displayed.
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. (P.102, 103)
To set the home or a preset des-
tination as the destination,
select the corresponding button.
1Turn the engine switch to
ACC or ON.
2Press the “MAP” button.
3Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.)
The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis-
played.
If the home or a preset desti-
nation has not been regis-
tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current position, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. (P.106)
One-touch setting
home/favorite as a desti-
nation
A
B
