TOYOTA TACOMA 2021 Accessories, Audio & Navigation (in English)

612-4. Other settings
2
Basic function
Select to change the keyboard lay-
out.
“Delete Keyboard History”
Select to delete the keyboard his-
tory.
“Memorize Keyboard History”
Select to set the memorize key-
board history on/off.
“Animation”
Select to turn the animations on/off.
“Driver Setting”
Select to change the driver set-
tings. (P. 6 3 )
“Delete Personal Data”
Select to delete personal data.
(P.63)
“Software Update”
Select to update software versions.
For details, contact your Toyota
dealer.
“Software Update Setting”*2, 3
Select to set software update set-
ting. (P. 6 3 )
“Gracenote Database
Update”
Select to update Gracenote® data-
base versions. For details, contact
your Toyota dealer.
“Software Information”
Select to display the software infor-
mation. Notices related to third
party software used in this product
are enlisted. (This includes instruc-
tions for obtaining such software,
where applicable.)
“SW Sensitivity Level”
Select to change the capacitive touch screen button sensitivity to 1
(low), 2 (medium), or 3 (high).
*1: Premium Audio only
*2: This function is not made avail-
able in some countries or areas.
*3: Vehicles equipped with DCM
1Display the general settings
screen. (P. 6 0 )
2Select “Clock”.
3Select the desired items to
be set.
Select to change the time
zone. (P.62)
Select to set daylight saving
time on/off/auto
*.
Select to set automatic
adjustment of the clock by
GPS on/off.
When set to off, the clock can
be manually adjusted.
(P.62)
Select to set the 24 hour time
format on/off.
When set to off, the clock is
displayed in 12 hour time for-
mat.Clock settings
A
B
C
D

622-4. Other settings
*: Premium Audio only
1Select “Time Zone”.
2Select the desired time zone.
Premium Audio only:
If “Auto” is selected, the time
zone is selected automatically
by current vehicle position.
When “Auto Adjust by GPS” is
turned off, the clock can be
manually adjusted.
1Select “Auto Adjust by GPS”
to set to off.
2Adjust the clock manually.
Select “+” to set the time for-
ward one hour and “-” to set
the time back one hour.
Select “+” to set the time for-
ward one minute and “-” to
set the time back one minute.
Select to round to the nearest
hour.
e.g.
1:00 to 1:29  1:00
1:30 to 1:59  2:00
*: This function is not made avail-
able in some countries or areas.
1Display the general settings
screen. (P. 6 0 )
2Select “Projection Settings”.
3Select the desired items to
be set.
Select to turn Apple CarPlay
connection establishment
on/off.
Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device
before attempting to change
the setting.
Select to turn Android Auto
connection establishment
on/off.
Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device
before attempting to change
the setting. Setting the time zone
Manual clock setting
A
B
C
3URMHFWLRQVHWWLQJV
A
B

632-4. Other settings
2
Basic function
The driver settings feature will
allow the system to link some
preferences (such as audio pre-
sets, screen theme, language,
etc.) to a paired Bluetooth
®
phone.
1Display the general settings
screen. (P.60)
2Select “Driver Setting”.
3Select “Enable This Feature”.
1Select “Manually Select
Linked Settings”.
2Select the desired phone.
After a few seconds, loaded
screen automatically switches
to the home screen.Registered or changed per-
sonal settings will be deleted or
returned to their default condi-
tions.
1Display the general settings
screen. (P. 6 0 )
2Select “Delete Personal
Data”.
3Select “Delete”.
4Select “Yes” when the confir-
mation screen appears.
Examples of settings that can be
returned to their default conditions:
Navigation settings*
Audio settings
Phone settings
etc.*: Premium Audio only
*: Vehicles equipped with DCM
only. This function is not made
available in some countries or
areas.
When the automatic update
check function is enabled, if a
software update is available
from the Cloud, a message will
be displayed.
1Display the general settings
screen. (P. 6 0 )
2Select “Software Update Set-
ting”. Driver settings
Manually select linked set-
tings
Deleting personal data
Software update settings
*

642-4. Other settings
3Select “Automatic Update
Check” to enable/disable the
automatic update check func-
tion.
●When software update information
is displayed, contact your Toyota
dealer.
1Press the “MENU” button.
2Select “Setup”.
3Select “Voice”.
4Select the desired items to
be set.
Vo ic e s e t ti n g s
Voice volume, etc. can be
set.
Displaying the voice set-
tings screen
Voice settings screen

652-4. Other settings
2
Basic function
Select to adjust the volume of
voice guidance.
*1
Select to set the voice guid-
ance during route guidance
on/off.
*2
Select to set the voice guid-
ance during audio/visual sys-
tem use on/off.
*2
Select to set the voice recog-
nition prompts.
Select to train voice recogni-
tion.
The voice command system
adapts the user accent.
Select to start the voice rec-
ognition tutorial.
Select to set the beep sound
of navigation guidance.
*2
Select to set the voice
prompt interrupt on/off.
Select to reset all setup
items.
*1: When an Apple CarPlay/Android
Auto connection is established,
voice command system
(Siri/Google Assistant) and map
application voice guidance vol-
ume can be changed.
*2: Premium Audio only
A
B
C
D
E
F
G
H
I

662-4. Other settings
1Press the “MENU” button.
2Select “Setup”.
3Select “Vehicle”.
4Select the desired items to
be set.
Select to set maintenance.
*1
(P. 6 6 )
Select to set vehicle customi-
zation.
*2
Select to set valet mode.
(P.68)
Select to set dealer informa-
tion.
*3, 4
*1: Premium Audio only
*2: Refer to the “OWNER’S MAN-
UAL”
*3: If equipped
*4: This function is not made avail-
able in some countries or areas.
*: Premium Audio only
When the system is turned on,
the maintenance reminder
screen displays when it is time
to replace a part or certain com-
ponents. (P. 2 6 )
1Display the vehicle settings
screen. (P. 6 6 )
2Select “Maintenance”.
3Select the desired item.
The system is set to give
maintenance information with
the maintenance reminder
screen. (P. 2 6 )
Select to set a reminder for a
part or component. (P.67)
Vehicle settings
Settings are available for
maintenance, vehicle cus-
tomization, etc.
Displaying the vehicle
settings screen
Vehicle settings screen
A
B
0DLQWHQDQFH
C
D
A
B

672-4. Other settings
2
Basic function
Select to add a reminder
other than the provided ones.
Select to cancel all reminders
which have been entered.
Select to reset all reminders
which have expired.
Select to call the registered
dealer.
Select to register/edit dealer
information. (P.67)
●When the vehicle needs to be ser-
viced, the screen button color will
change to orange.
1Select the desired part or
component screen button.
2Set the conditions.
Select to enter the next main-
tenance date.
Select to enter the driving
distance until the next main-
tenance check.
Select to cancel the condi-
tions which have been
entered.Select to reset the conditions
which have expired.
3Select “OK” after entering the
conditions.
●For scheduled maintenance infor-
mation, refer to “Scheduled Main-
tenance Guide” or “Owner’s
Manual Supplement”.
●Depending on driving or road con-
ditions, the actual date and dis-
tance that maintenance should be
performed may differ from the
stored date and distance in the
system.
Dealer information can be regis-
tered in the system. With dealer
information registered, route
guidance to the dealer is avail-
able.
1Select “Set Dealer”.
2Select the desired item to
search for the location.
(P.84)
The editing dealer screen
appears after setting the loca-
tion.
3Select the desired items to
be edited.
Select to enter the name of a Maintenance information
setting
C
D
E
F
G
A
B
C
'HDOHUVHWWLQJ
D
A

682-4. Other settings
dealer. (P.68)
Select to enter the name of a
dealer member. (P. 6 8 )
Select to set the location.
(P. 6 8 )
Select to enter the phone
number. (P.68)
Select to delete the dealer
information displayed on the
screen.
Select to set the displayed
dealer as a destination.
(P. 9 1 )
1Select “Dealer” or “Contact”.
2Enter the name and select
“OK”.
1Select “Location”.
2Scroll the map to the desired
point (P.75) and select
“Enter”.
1Select “Phone #”.
2Enter the phone number and
select “OK”.
The security system can be set to on by entering a security code
(4-digit number).
When set to on, the system will
become inoperative once the
electrical power source is dis-
connected until the security
code is entered.
1Display the vehicle settings
screen. (P. 6 6 )
2Select “Valet Mode”.
3Enter the 4-digit personal
code and select “OK”.
4Enter the same 4-digit per-
sonal code again and select
“OK”.
The system will request that
you input the security code
again to confirm that you
remember it correctly.
When valet mode activates,
the system stops and a secu-
rity code (4-digit number)
standby screen is displayed.
●If the 4-digit personal code is for-
gotten, please contact your Toyota
dealer.
1Enter the 4-digit personal
code and select “OK”.
●If an incorrect security code (4-
digit number) is entered 6 times,
the system will not accept another
security code (4-digit number) for
10 minutes.
Editing dealer or contact
name
Editing the location
Editing phone number
Setting the valet mode
B
C
D
E
F
,IWKHYDOHWPRGHKDVEHHQ
DFWLYDWHG

692-4. Other settings
2
Basic function
*: If equipped
Dealer information can be regis-
tered in the system. If the vehi-
cle alert screen is displayed,
selecting the call dealer button
on the screen will call the phone
number registered in the dealer
information.
1Display the vehicle settings
screen. (P.66)
2Select “Dealer Info”.
3Select the desired items to
be edited.
Select to enter the name of a
dealer. (P.69)
Select to enter the name of a
dealer member. (P. 6 9 )
Select to enter the phone
number. (P.69)
Select to delete the dealer
information displayed on the
screen.1Select “Edit” next to “Dealer”
or “Contact”.
2Enter the name and select
“OK”.
1Select “Edit” next to “Phone
#”.
2Enter the phone number and
select “OK”.
Setting dealer informa-
tion*
A
B
C
D
(GLWLQJGHDOHURUFRQWDFW
QDPH
(GLWLQJSKRQHQXPEHU

702-4. Other settings
