TOYOTA TUNDRA 2008 2.G Navigation Manual

DESTINATION SEARCH
472008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5008aG
If inputting a street name first, the screen
changes. The house number can then be in-
put.
RS02006a
If the above screen appears, an address
range on the screen can be selected.
2U5010G
If the same address exists in more than one
city, the current screen changes to the city list
screen.(b) Selecting a city to search
2U5090aG
Touch “City”.

DESTINATION SEARCH
482008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5011aG
To search by city, the following three methods
are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch “Any
City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2U5013G
2. Input a city name.
2U5014aG
3. Touch the touchscreen button of the
desired city name from the displayed list.
“Map”: To display the selected destination
and the route preference. (See “Starting
route guidance” on page 61.)
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)

DESTINATION SEARCH
492008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2U5012aG
2. Touch the touchscreen button of the
desired city name from the displayed list.
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)SELECTING FROM THE LAST 5 CITIES
2U5091aG
Touch the touchscreen button of the de-
sired city name.
If the navigation has not be used, no cities will
be displayed on the screen.
The current screen changes to the screen for
inputting a house number or a street name.
(See “(a) Inputting a house number and a
street name” on page 45.)
— Destination search by “POI
Name”
1. Push the “DEST” button.
2. Touch “POI Name” on the
“Destination” screen.
2U5015G
3. Input the name of the Point of Interest.

DESTINATION SEARCH
502008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5016aG
4. Touch the touchscreen button of the
desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route
guidance” on page 61.)
When inputting the name of a specific Point of
Interest, and there are two or more sites with
the same name, the list screen is displayed.
2U5017G
Touch the touchscreen button of the de-
sired destination.
If the same name exists in more than one city,
a search can be performed more easily with
“City” and “Category”. (See “(a) Selecting
a city to search” on page 50 and “(b)
Selecting from the categories” on page 52.)
INFORMATION
The desired Point of Interest can be
displayed on the map screen. (See “ —
Display POI icons” on page 76.)
(a) Selecting a city to search
2U5092bG
Touch “City”.

DESTINATION SEARCH
512008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5093aG
To search by city, the following three methods
are possible.
1. Input the city name
2. Select from the nearest 5 cities
3. Select from the last 5 cities
INFORMATION
To change the search area, touch
“Search Area”.
To cancel the city setting, touch “Any
City”.
INPUTTING THE CITY NAME
1. Touch “Input City Name”.
2U5019G
2. Input the city name.
2U5020aG
3. Touch the touchscreen button of the
desired city name from the displayed list.SELECTING FROM THE NEAREST 5
CITIES
1. Touch “Nearest 5 Cities”.
2U5018aG
2. Touch the touchscreen button of the
desired city name.

DESTINATION SEARCH
522008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) SELECTING FROM THE LAST 5 CITIES
2U5094aG
Touch the touchscreen button of the de-
sired city name.
If the navigation has not be used, no cities will
be displayed on the screen.(b) Selecting from the categories
2U5097aG
Touch “Category”.
2U5021G
If the desired POI category is on the screen,
touch the name to display a detailed list of the
POI category.If the desired POI category is not on the
screen, touch “List All Categories” to list all
POI categories.
2U5022aG
When the desired category is touched, the
POI name list screen is displayed.

DESTINATION SEARCH
532008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
— Destination search by “POI
Category”
The destination can be set by selecting the
search point and the POI category.
1. Push the “DEST” button.
2. Touch “POI Category” on the “Destina-
tion” screen.
2U5023aG
Set the search point by the following
method:
1. Input the city center
2. Set the current position as the search
point
3. Set the search point via the map screen
4. Set the search point from any destination
It is possible to display the names of POIs lo-
cated within approximately 20 miles (32 km)
from the selected search point.INPUTTING THE CITY CENTER
1. Touch “Input City Center”.
2U5024G
2. Input the city center name.
2U5025aG
3. Touch the touchscreen button of the
desired city center name.
2U5026G
When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
4. Touch “Enter”.
The search point is set and the “POI
Category” screen will be displayed.

DESTINATION SEARCH
542008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) SETTING THE CURRENT POSITION AS
THE SEARCH POINT
Touch “Current Position”.
The search point is set at the current position,
and the “POI Category” screen will be dis-
played.SETTING THE SEARCH POINT VIA THE
MAP SCREEN
1. Touch “Map”.
2U5027G
When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
2. Touch “Enter”.
The search point is set and the “POI
Category” screen will be displayed.SETTING THE SEARCH POINT FROM
DESTINATIONS
1. Touch the destination buttons at the
bottom of the screen.
2U5028G
When an arrow facing the desired point is
touched, the map scrolls in that direction. Re-
leasing the finger from the arrow will stop the
scrolling
2. Touch “Enter”.
The search point is set and the “POI
Category” screen will be displayed.

DESTINATION SEARCH
552008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
To search POIs near the search point
When the search point is set, the “POI
Category” screen will be displayed.
2U5029aG
Select the desired POI categories.
“List”: If the desired POI categories have al-
ready been selected, a list of POI will be dis-
played from among the selected categories.
The selected category icon appears on the
top left of the screen.
If the desired POI category is not on the
screen, touch “List All Categories” to list all
POI categories.
2U5030aG
Select the desired POI categories from the
list and touch “OK”.
The selected category icon appears on the
top left of the screen.
2U5095G
“Select Category”: To return to the POI
category selection screen.
“Show List”: To display the list of POIs in the
selected categories.

DESTINATION SEARCH
562008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
2U5031G
By touching the touch−screen button of the
desired item, the screen changes and dis-
plays the map location of the selected des-
tination and the route preference. (See
“Starting route guidance” on page 61.)
“On Route”: When the indicator is illumi-
nated by touching this touch−screen button,
the list of the items searched along the route
is displayed.
— Destination search by
“Emergency”
1. Push the “DEST” button.
2. Touching “Emergency” on the
“Destination” screen.
The display changes to a screen to select po-
lice stations, dealers, hospitals or fire sta-
tions. While driving, only nearby police sta-
tions, dealers, hospitals, or fire stations are
shown. The current position is shown with an
address, and the latitude and the longitude at
the top of the screen.
2U5033aG
3. Touch the desired emergency catego-
ry.
The selected emergency category list is dis-
played.
2U5034aG
4. Touch the touchscreen button of the
desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See
“Starting route
guidance” on page 61.)
INFORMATION
The navigation system does not guide in
areas where route guidance is unavail-
able. (See page 235.)
