TOYOTA TUNDRA 2008 2.G Navigation Manual

ROUTE GUIDANCE
672008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
:To scroll for farther junctions or exits.
:To scroll for closer junctions or exits.
:To scroll for the closest three junctions
or exits.
When approaching a freeway exit or
junction
When the vehicle approaches an exit or junc-
tion, the guidance screen for the freeway will
be displayed.
3U5059aG
1Road/area name
2Distance from the current position to
the exit or junction
3Current position
“OFF”: The guidance screen on freeway dis-
appears and the map screen appears.
When touching
or pushing the “MAP/
VOICE” button, the guidance screen on free-
way reappears.
When approaching an intersection
When the vehicle approaches an intersec-
tion, the intersection guidance screen will be
displayed.
3U5060aG
1Next street name
2Distance to the intersection
3Current position
“OFF”: The intersection guidance screen
disappears and the map screen appears.
When touching
or pushing the “MAP/
VOICE” button, the intersection guidance
screen reappears.

ROUTE GUIDANCE
682008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
Other screens
TURN LIST SCREEN
On this screen, the list of turns on the guid-
ance route can be viewed.
Touching
during guidance displays the
turn list.
3U5061bG
1Next street name or destination name
2Turn direction
3Distance between turns
4Current street nameARROW SCREEN
On this screen, information about next turns
on the guidance route can be viewed.
Touching
during guidance displays the
arrow screen.
3U5062aG
1Exit number, street name containing
number or next street name
2Turn direction
3Distance to the next turn
4Current street name
Typical voice guidance
prompts
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver the
vehicle.
3U5114a
4.7 miles
0.25 miles
+α
1“Proceed about 5 miles.”
2“In a quarter of a mile, right turn.”
3“Right turn.”
4(Beep sound only)

ROUTE GUIDANCE
692008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
INFORMATION
On freeways, interstates or other high-
ways with higher speed limits, the voice
guidance will be made at earlier points
than on city streets in order to allow time
to maneuver.
3U5115a
4.2 miles
0.25 miles
1“Proceed about 4 miles to the traf-
fic circle.”
2“In a quarter of a mile, traffic circle
ahead, and then 3rd exit ahead.”
3“The 3rd exit ahead.”
4“The exit ahead.”
5(Beep sound only)
3U5116a
One−way road
One−way road
∗: The system indicates a U−turn if the dis-
tance between two one−way roads (of oppo-
site directions) is less than 50 feet (15 m) in
residential areas or 164 feet (50 m) in non−
residential areas.
1“In half of a mile, make a legal
U−turn.”
2“Make a legal U−turn ahead.”
3(Beep sound only)

ROUTE GUIDANCE
702008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
3U5117a
The system announces the approach to the fi-
nal destination.
1“Your destination is ahead.”
2“You have arrived at your
destination. The route guidance is
now finished.”
INFORMATION
If the system cannot determine the
current vehicle position correctly (in
cases of poor GPS signal reception),
the voice guidance may be made ear-
ly or delayed.
If you did not hear the voice guidance
command, push the “MAP/VOICE”
button to hear it again.
To adjust the voice guidance volume,
see “Volume” on page 88.
Distance and time to
destination
3U5057aG
When the vehicle is on the guidance route,
the distance and the estimated travel/arrival
time to the destination are displayed. When
the vehicle is not on the guidance route, the
distance and the direction of the destination
are displayed.
When driving on the guidance route and more
than one destination is set, the distance and
the estimated travel/arrival time from the cur-
rent position to each destination are dis-
played.
1. Touch this touchscreen button to dis-
play the following screen.

ROUTE GUIDANCE
712008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
3U5064G
2. Touch the number button to display
the desired destination.
The distance, the estimated travel time and
the estimated arrival time from the current
position to the selected destination are dis-
played.
Estimated travel time is displayed.
Estimated arrival time is dis-
played.
To switch to estimated arrival
time.
To switch to estimated travel time.
Displayed while driving off the
guidance route. The destination
direction is indicated by an arrow.
INFORMATION
When the vehicle is on the guidance
route, the distance measured along the
route is displayed. Travel time and arriv-
al time is calculated based on the set ve-
hicle speed information. (See page 104.)
However, when the vehicle is not on the
guidance route, the distance is the linear
distance between the current position
and the destination.
Setting and deleting
destination —
— Adding destinations
Adding destinations and searching again for
the routes can be done.
3U5094G
1. Touch “Route”.
3U5095G
2. Touch “Add”.

ROUTE GUIDANCE
722008 TUNDRA Navigation from Oct.07 Prod.(OM34469U) 3. Input an additional destination in the
same way as the destination search. (See
“Destination search” on page 41.)
3U5067aG
4. Touch the desired “Add” to determine
the arrival order of the additional destina-
tion.
— Reordering destinations
When more than one destination is set, you
can change the arrival order of the destina-
tions.
3U5094G
1. Touch “Route”.
3U5096G
2. Touch “Reorder”.
3U5068aG
3. Select the destination in the order of
arrival by touching the destination button.
Reordered number of arrival is displayed on
the right side of the screen.
Touching “Undo” will cancel each selected
order number from the previously input num-
ber.
4. After selecting the destinations, touch
“OK”.
The system searches for the guidance route
again, and displays the entire route. Even if
“OK” is not touched, the entire route is dis-
played automatically within a few seconds
when the order is fixed.

ROUTE GUIDANCE
732008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
— Deleting destinations
A set destination can be deleted.
3U5094G
1. Touch “Route”.
3U5097G
2. Touch “Delete”.
When more than one destination is set, a list
will be displayed on the screen.
3U5069aG
3. Touch the destination for deletion.
“Delete All”: To delete all destinations on the
list.
A message appears to confirm the request to
delete.
4. To delete the destination(s), touch
“Yes”.
If “Yes” is touching, the data cannot be recov-
ered.
If “No” is touching, the previous screen will
return.
5. If more than one destination is set,
touch “OK” after deleting the destination-
s.
The system searches for the guidance route
again, and displays the entire route.
Setting route —
— Search condition
You can designate the route conditions of the
route to the destination.
3U5094G
1. Touch “Route”.
3U5098G
2. Touch “Search Condition”.

ROUTE GUIDANCE
742008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
3U5070G
3. Touch “Quick”, “Quick1”, “Quick2” or
“Short” and touch “OK”.
3U5071G
The entire route from the starting point to the
destination is displayed.
“Guide”: To start guidance.
“Route”: To change a route. (See pages 71
and 73.)
— Detour setting
While the route guidance is operating, you
can change the route to detour around a sec-
tion of the route where a delay is caused by
road repairs, or an accident, etc.
3U5094G
1. Touch “Route”.
3U5099G
2. Touch “Detour”.
3U5072G
3. Select the touchscreen button below
to select the desired detour distance.
“1 mile (km)”, “3 miles (km)” or “5 miles
(km)”: Touch one of these touch−screen but-
tons to start the detour process. After detour-
ing, the system returns to the original guid-
ance route.
“Whole Route”: By touching this touch−
screen button, the system will calculate an
entire new route to the destination.

ROUTE GUIDANCE
752008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
3U5118a
This picture shows an example of how the
system would guide around a delay caused
by a traffic jam.
1This position indicates the location of a
traffic jam caused by road repairs or an
accident.
2This route indicates the detour sug-
gested by the system.
INFORMATION
When your vehicle is on a freeway, the
detour distance selections are 5, 15,
and 25 miles (km).
The system may not be able to calcu-
late a detour route depending on the
selected distance and surrounding
road conditions.
— Route preference
A number of choices are provided on the con-
ditions which the system uses to determine
the route to the destination.
3U5094G
1. Touch “Route”.
3U5100G
2. Touch “Route Preference” to change
the conditions which are to determine the
route to the destination.
3U5073G
3. The indicator can be turned on or off by
touching the button.
When searching for a route, the system func-
tions to avoid routes where the indicator is
dimmed.
4. After choosing the conditions, touch
“OK”.

ROUTE GUIDANCE
762008 TUNDRA Navigation from Oct.07 Prod.(OM34469U)
— Starting route from
adjacent road
You can start the route guidance from the ad-
jacent road.
(ex. When route guidance is set on the free-
way, but the vehicle is driven parallel along
the freeway.)
3U5094G
1. Touch “Route”.
3U5101aG
2. Touch “Start from Adjacent Road”.
When there is no adjacent road, this button
will not be displayed.
Map view —
— Display POI icons
Points of Interest such as gas stations and
restaurants can be displayed on the map
screen. You can also set their location as a
destination and use them for route guidance.
3U5102G
1. Touch “Map View”.
