TOYOTA VENZA 2014 Owners Manual (in English)

521
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73019U_(U)
ItemFunctionDefault
settingCustomized setting
Smart key
system
(P. 30)
and wireless
remote control
( P. 45) Operation signal
(Emergency
flashers)
ON OFF O O
Operation signal
(Buzzer) Level 7Level 1 to 6
—O
OFF
Time elapsed before
automatic door lock
function is activated
if door is not opened
after being unlocked 60 secondsOFF
OO
30 seconds
120
seconds
Power easy
access system
( P. 75) Driver’s seat
movement when
exiting the vehicle
ON OFF — O

522 6-2. Customization
VENZA_OM_OM73019U_(U)
ItemFunctionDefault settingCustomized setting
Door lock
(P. 50) Unlocking using
a key
Driver’s
door
unlocked in
one step, all doors
unlocked in two step All doors
unlocked in one step —O
Speed-detecting
automatic door lock
function OFF ON O O
Shifting the shift
lever to position
other than “P” locks
all doors ON OFF O O
Shifting the shift
lever to “P” unlocks
all doors ON OFF O O
Opening driver’s
door unlocks all
doors OFF ON O O

523
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73019U_(U)
ItemFunctionDefault
settingCustomized setting
Automatic light
control system
(P. 208) Light sensor
sensitivity
Level 3 Level 1 to 5 — O
Daytime running light
system (U.S.A. only) ON OFF — O
Automatic
High Beam
(if equipped) ON OFF O O
Time elapsed before
headlights
automatically turn off
after doors are
closed 30 seconds0 seconds
OO
60 seconds
90 seconds
Alarm system
( P. 1 1 1 ) Time elapsed before
the alarm is set
14 seconds 30 seconds — O
Multi-
information
display
(TFT type only:
 P. 192) Language selection English
French
OO
Spanish

524 6-2. Customization
VENZA_OM_OM73019U_(U)
ItemFunctionDefault settingCustomized setting
Illumination
(P. 305) Time period before
lights turn off
15 seconds7.5 seconds
OO
30 seconds
Vehicles with smart
key system:
Operation after the
“ENGINE START
STOP” switch is
turned off
Vehicles without
smart key system:
Operation after the
engine switch is
turned to the “LOCK”
position ON OFF — O
Operation when the
doors are unlocked ON OFF — O
Operation when you
approach the
vehicle with the
electronic key on
your person (When
the personal/interior
light main switch is
door position.)
(vehicles with smart
key system) ON OFF — O

525
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73019U_(U)
ItemFunctionDefault
settingCustomized setting
Seat belt
reminder
(P. 441) Vehicle speed linked
seat belt reminder
buzzer
ON OFF — O
Power
window
( P. 96) Rear window Auto
Up/Down
ON OFF — O
Auto Up function ON OFF — O

526 6-2. Customization
VENZA_OM_OM73019U_(U)
Customizing the features by using the multi-information display
(vehicles with TFT type mu lti-information display)
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 10
seconds, the display will revert to
the previous screen.
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
STEP1
STEP2

527
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73019U_(U)
Select the setting you wish to
change by pressing the “INFO”
or “SETUP” button, and press
the “SELECT RESET” button.
The illustration assumes that
“Door” was chosen in .
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will revert to the “Custom
Settings” screen.
Choose a desired setting by
pressing the “INFO” or “SETUP”
button, and press the “SELECT
RESET” button.
If any settings are changed, the
display will revert to the previous
screen.
The illustration assumes that
“Auto Locking” was chosen in
.
The current setting is indicated by
yellow text.
If you select “Return” and press
the “SELECT RESET” button, the
display will revert to the previous
screen.
STEP3
STEP2
STEP4
STEP3

528 6-2. Customization
VENZA_OM_OM73019U_(U)■
Restoring default settings
Press the “SETUP” button while
the vehicle is stopped.
The “Custom Settings” screen is
displayed on the multi-information
display.
If left idle for approximately 10
seconds, the display will revert to
the previous screen.
Select “Default Settings” by
pressing the “INFO” or “SETUP”
button, and press the “SELECT
RESET” button.
If you select “Exit” and press the
“SELECT RESET” button, the
display will revert to the previous
screen.
Select “Yes” by pressing the
“INFO” or “SETUP” button, and
press the “SELECT RESET” but-
ton.
“Default Settings Restored” is dis-
played, and the default settings
are restored.
If you select “No” and press the
“SELECT RESET” button, the
display will revert to the “Custom
Settings” screen without restor-
ing the default settings.
STEP1
STEP2
STEP3
■If the vehicle is moved while setti ngs are being changed on the multi-
information display
P. 202

529
6
Vehicle specifications
VENZA_OM_OM73019U_(U)
6-3. Initialization
Items to initialize
ItemWhen to initializeReference
Power back door • After reconnecting or changing the
battery
• After changing a fuse P. 6 0
Maintenance data
(U.S.A. only) After the maintenance is performed P. 353
The following items must be init
ialized for normal system operation
in cases such as after the battery is reconnected, or maintenance is
performed on the vehicle.

530 6-3. Initialization
