TOYOTA VENZA 2015 Owners Manual (in English)

640 6-1. Specifications
VENZA_OM_OM73023U_(U)
Tire related termMeaning
Cord The strands forming the plies in the tire
Cord separation The parting of cords from adjacent rubber com-
pounds
Cracking Any parting within the tread, sidewall, or inner-
liner of the tire ext
ending to cord material
CT A pneumatic tire with an inverted flange tire
and rim system in which the rim is designed
with rim flanges pointed radially inward and the
tire is designed to fit on the underside of the
rim in a manner that encloses the rim flanges
inside the air cavity of the tire
Extra load tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Groove The space between two adjacent tread ribs
Innerliner The layer(s) forming the inside surface of a
tubeless tire that contains the inflating medium
within the tire
Innerliner separation The parting of the innerliner from cord material
in the carcass

641
6-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73023U_(U)
Tire related termMeaning
Intended outboard
sidewall (a)The sidewall that cont
ains a whitewall, bears
white lettering, or bears manufacturer, brand,
and/or model name molding that is higher or
deeper than the same molding on the other
sidewall of the tire, or
(b)The outward facing sidewall of asymmetrical
tire that has a particular side that must always
face outward when mounted on a vehicle
Light truck (LT) tire A tire designated by its manufacturer as prima-
rily intended for use on lightweight trucks or
multipurpose passenger vehicles
Load rating The maximum load that a tire is rated to carry
for a given inflation pressure
Maximum load rating The load rating for a tire at the maximum per-
missible inflation pressure for that tire
Maximum permissible
inflation pressure The maximum cold inflation pressure to which
a tire may be inflated
Measuring rim The rim on which a tire is fitted for physical
dimension requirements
Open splice Any parting at any junction of tread, sidewall, or
innerliner that extends to cord material
Outer diameter The overall diameter of an inflated new tire
Overall width The linear distance between the exteriors of
the sidewalls of an inflated tire, including eleva-
tions due to labeling, decorations, or protective
bands or ribs

642 6-1. Specifications
VENZA_OM_OM73023U_(U)
Tire related termMeaning
Passenger car tire A tire intended for use on passenger cars, mul-
tipurpose passenger vehicles, and trucks, that
have a gross vehicle weight rating (GVWR) of
10,000 lb. or less.
Ply A layer of rubber-coated parallel cords
Ply separation A parting of rubber compound between adja-
cent plies
Pneumatic tire A mechanical device made of rubber, chemi-
cals, fabric and steel or
other materials, that,
when mounted on an automotive wheel, pro-
vides the traction and contains the gas or fluid
that sustains the load
Radial ply tire A pneumatic tire in which the ply cords that
extend to the beads are laid at substantially 90
degrees to the centerline of the tread
Reinforced tire A tire designed to operate at higher loads and
at higher inflation pressures than the corre-
sponding standard tire
Section width The linear distance between the exteriors of
the sidewalls of an inflated tire, excluding ele-
vations due to labeling, decoration, or protec-
tive bands
Sidewall That portion of a tire between the tread and
bead
Sidewall separation The parting of the rubber compound from the
cord material in the sidewall

643
6-1. Specifications
6
Vehicle specifications
VENZA_OM_OM73023U_(U)
Tire related termMeaning
Snow tire A tire that attains a traction index equal to or
greater than 110, compared to the ASTM E-
1136 Standard Reference Test Tire, when
using the snow traction test as described in
ASTM F-1805-00, Standard Test Method for
Single Wheel Driving Traction in a Straight Line
on Snow-and Ice-Covered Surfaces, and which
is marked with an Alpine Symbol ( ) on at
least one sidewall
Te s t r i m The rim on which a tire is fitted for testing, and
may be any rim listed as appropriate for use
with that tire
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing

644 6-1. Specifications
VENZA_OM_OM73023U_(U)
*:Table 1  Occupant loading and distribution for vehicle normal load
for various designated seating capacities
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehicle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

645
6
Vehicle specifications
VENZA_OM_OM73023U_(U)
6-2. Customization
Customizable features
Customizable featuresVehicles with TFT type multi-info rmation display: Some function
settings can be changed by opera ting the multi-information display.
(  P. 652)
Settings that can be chan ged by your Toyota dealer
Definition of symbols: O = Available,  = Not available
Your vehicle includes a variety of electronic features that can be
personalized to your preferen ces. Programming these preferences
requires specialized equipment and may be performed by your
Toyota dealer.
Some function settings are changed simultaneously with other functions
being customized. Contact your Toyota dealer for further details.

646 6-2. Customization
VENZA_OM_OM73023U_(U)
ItemFunctionDefault settingCustomized setting
Smart key
system
(P. 30) Smart key system ON OFF — O
Select doors to
unlock
Driver’s
door All doors — O
Wireless
remote control
( P. 45) Wireless remote
control
ON OFF — O
Unlocking operation Driver’s
door
unlocked in one step, all doors
unlocked in two step All doors
unlocked in one step OO
Open door warning
function (when
locking the vehicle) ON OFF — O
Panic function ON OFF — O

647
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73023U_(U)
ItemFunctionDefault
settingCustomized setting
Smart key
system
(P. 30)
and wireless
remote control
( P. 45) Operation signal
(Emergency
flashers)
ON OFF O O
Operation signal
(Buzzer) Level 7Level 1 to 6
—O
OFF
Time elapsed before
automatic door lock
function is activated
if door is not opened
after being unlocked 60 secondsOFF
OO
30 seconds
120
seconds
Power easy
access system
( P. 75) Driver’s seat
movement when
exiting the vehicle
ON OFF — O

648 6-2. Customization
VENZA_OM_OM73023U_(U)
ItemFunctionDefault settingCustomized setting
Door lock
(P. 50) Unlocking using
a key
Driver’s
door
unlocked in
one step, all doors
unlocked in two step All doors
unlocked in one step —O
Speed-detecting
automatic door lock
function OFF ON O O
Shifting the shift
lever to position
other than “P” locks
all doors ON OFF O O
Shifting the shift
lever to “P” unlocks
all doors ON OFF O O
Opening driver’s
door unlocks all
doors OFF ON O O

649
6-2. Customization
6
Vehicle specifications
VENZA_OM_OM73023U_(U)
ItemFunctionDefault
settingCustomized setting
Automatic light
control system
(P. 212) Light sensor
sensitivity
Level 3 Level 1 to 5 — O
Daytime running light
system (U.S.A. only) ON OFF — O
Automatic
High Beam
(if equipped) ON OFF O O
Time elapsed before
headlights
automatically turn off
after doors are
closed 30 seconds0 seconds
OO
60 seconds
90 seconds
Alarm system
( P. 1 1 2 ) Time elapsed before
the alarm is set
14 seconds 30 seconds — O
Multi-
information
display
(TFT type only:
 P. 194) Language selection English
French
OO
Spanish
