Yaris Sedan_Navi_OM99S53z_(U)
2.3.2 Press and Hold
You usually need to select the s
creen only once, however, some useful features can
be accessed with combined touch screen selecting. Those are as follows:
ActionButton(s)Details
Continue
pressing the
button. ,
Touching the button on
the map screen once
changes the scale in one step. Continuously
touching the button changes the scale sequentially.
, Touching the button on
the map screen once
changes the point of view in one step.
Continuously touching the button changes the
point of view sequentially.
, Touching the button on
the map screen once
rotates the map. Continuously touching the button
rotates the map sequentially.
Touching the button on th e keyboard screen once
erases one character. Continuously touching the
button erases several characters rapidly.

12
Yaris Sedan_Navi_OM99S53z_(U)
2.4 Map screen
2.4.1 Navigatin g on the map
The data fields are different when you are navigating an active route and when you
have no specified destination ( the burgundy line is not display ed).
FieldDescription
* On some vehicles, the
speed display is
not indicated in
the center
display, only the
active driving
display. Shows the speed limit of the current road if the map contains
it.
Shows the distance yo
u need to travel on the route before
reaching your final destination.
Shows the estimated arrival time at the final destination of
the route.
If the navigation sy stem is capable of r eceiving live traffic
information, the calculation takes into account traffic delays
affecting your route.
This estimation can be inaccurate at times.

13
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
2.4.2 Position markers
2.4.2.1 Selected map location (C
ursor) and selected map object
You can mark a map location in the following ways:
• Select the map during route guidance.
• Select the map when asked so tha t the destination can be confirmed after the search
is completed.
• Select the destination from the map. (page 56)
When a map location is selected, the Cursor appears at the selected point on the map.
A symbol with a combined crosshair and red circle is displayed for easy
visibility of any map scale size.
The location of the Cursor can be used as the destination of th e route.
You can search for a POI (point of interest), or you can save it as one of your
Favorites destinations.
You can also select some of the objects on the map. If you select the map at the icon
of a POI (point of interest) or a traffic event, the object wil l be selected. You can then
get information about this objec t or use it as a route point.
2.4.3 Objects on the map
2.4.3.1 Streets and roads
The navigation system shows the roads in different widths and c olors so that they can
be easily identified. A highway/freeway will be thicker and a d ifferent color than a
small street.
Some functions are not available depending on some countries an d regions.
Some functions are not available depending on some countries an d regions.

14
Yaris Sedan_Navi_OM99S53z_(U)
2.4.3.2 Turn previe
w and Next street
When navigating a route, the top section of the Map screen shows information about
the next maneuver, street or city.
There is an area at the top left part of screen which indicates the next operation.
Displays both the event type (such as turning, detouring, exiting expressways) and
the distance from the current position.
When the next event ap proaches, the second event is displayed u sing a small icon. If
there is no second event, only the next event is displayed.
Most of these icons are very in tuitive. The same symbols are us ed in both fields:
IconDescription
Turn left.
Turn right.
Turn back.
Bear right.
Turn sharp left.
Keep left.
Continue straight in the intersection.

15
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
Go right on the roundabout, 3rd exit
(next maneuver).
Enter highway/freeway.
Exit highway/freeway.
Board ferry.
Leave ferry.
Approaching a waypoint.
Approaching the destination.
IconDescription

16
Yaris Sedan_Navi_OM99S53z_(U)
2.4.3.3 Lane informat
ion and Signposts
When navigating on multilane roads, it is important to take the appropriate lane in
order to follow the recommended route. If lane information is available in the map
data, the navigation system displ ays the lanes and their directions using small arrows
at the bottom of the map. Highlighted arrows represent the lane s and direction you
need to take.
Lane guidance is provided consta ntly if there is map informatio n. Signposts are
displayed at the top of the map. The color and style of the sig nposts are similar to the
real ones you see above road or by the roadside. They show the available
destinations and the number of the road the lane leads to.
When navigating a route, only the signpost that points to the l ane(s) to be taken is
displayed in bright colors; all others are darker. All signpost s and lane guidance
arrows are displayed in vivid colors while driving (when there is no recommended
route).
If you want to hide the currently displayed signposts, touch an ywhere and the normal
Map screen returns until new signpost information is received.

17
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
2.4.3.4 Junction view
If you are approaching a highway/freeway exit or a complex inte
rsection and the
needed information exists, the ma p is replaced with a 3D view of the junction. The
optimum driving lane is indicated by an arrow, and road signs a re displayed as
additional information at the top of the screen.
2.4.3.5 Highway/Freeway exit services
You may need a gasoline station or a restaurant during your jou rney. This feature
displays a new button on the map when you are driving on highways/freeways.

18
Yaris Sedan_Navi_OM99S53z_(U)
Select this Open button to open a panel with the details of the
next few exits or
service stations.
Applicable only when the setting is “Only when menu is open”.
Select any of them to display the exit area on the map. You can now easily add this
exit as a waypoint to your route if needed.
There are two types of settings for displaying the next expressway exit; one which
constantly displays the next expressway exit while traveling on an expressway, or the
other which displays the next expressway exit only when the men u panel is open.
You can change the settings in Vi sual Guidance settings (page 85).

19
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
2.4.3.6 Elements of the active route
The navigation system shows the route in the following way:
SymbolNameDescription
Current car position
marker If there is a road close by, a blue-colored arrow
symbol moves to the road which is the closest.
The red mark present around a blue-colored
arrow symbol indicat
es the correct GPS
information. It may be indicated away from the
road because there is no existing road
information.
Waypoint
(intermediate
destination) An intermediate destination of the route before
reaching the fina
l destination.
Destination (end
point) The final destination of the route.
Route color The route always s tands out with its color on
the map, both in daytime and in nighttime
mode.
Streets and roads that
are excluded from the
navigation You can choose whether you want to use or
avoid certain road types (page 82). However,
when the navigation system cannot avoid such
roads, the route will include them and it will
show them in a color that is different from the
route color.
Streets and roads that
are affected by traffic
events Road segments may be affected by traffic
events received. These s
treets and roads are
displayed in an alternate color, and small
symbols displayed along the route show the
type of traffic event.
Some functions are not available depending on some countries an d regions.

20
Yaris Sedan_Navi_OM99S53z_(U)
2.4.4 Manipulating the map
By touching and dragging any pa
rt of the map screen, it can be moved to a location
close to the currently displayed map.
In addition, the map operation button is displayed, and by touc hing each of the
buttons, you can zoom in and out of maps, change the map perspe ctive and select a
destination.
ActionButton(s)Description
Map movement
using touch and
drag No buttons You can move the map in any direction: select and
hold the map, and move your finger towards the
direction you want to move the map.
Zooming in
and out , Changes how much of the map is displayed on the
screen.
The navigation system uses high-quality vector
maps that let you examine the map at various
zoom levels, always wi
th optimized content.
Map scaling has a limit in 3D map view mode. If
you zoom out further, the map switches to 2D view
mode.
Select the button once to modify the view in large
steps, or select and hold the button to modify it
continuously and smoothly.
