TOYOTA YARIS 2019 Accessories, Audio & Navigation (in English)

31
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
8. Navigation starts if is select
ed, or after 10 seconds of no user
interaction.
By touching the location displa yed on the screen, you can verify the route.
Additionally, the rout e can be revised by selecting other optio ns.

32
Yaris Sedan_Navi_OM99S53z_(U)
3.1.1.2 Entering the midpoint of a street as the destination
You can navigate to the midpoin
t of a street if the house number is not available:
1. Select after selectin g on the MAP screen.
2. Select .
3. If necessary, modify the country and city as described earlier (page 27).
4. Enter the street name: a. Select .
b. Start entering the str eet name on the keyboard.
c. Find the street you need: • The most likely street name is always shown in the input field . To accept
it, select .
• If the desired name does not s how up, the names that match the string
appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, select ). Select the s treet from
the list.

33
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
5. Instead of entering the house
number, select . The midpoint
of the street is select ed as the destination.
6. The selected location is shown on the map.
The system transitions to the next screen by selecting , or it
returns to the previous screen by selecting the button. By tou ching the
location displayed on the scree n, you can change the destinatio n to anywhere
on the map.
• : You can search for POI (point of interest)
around the selected location.
• : The selected location can be registered to Favorites.

34
Yaris Sedan_Navi_OM99S53z_(U)
7. Navigation starts if is select
ed, or after 10 seconds of no user
interaction.
By touching the location displa yed on the screen, you can verify the route.
Additionally, the rout e can be revised by selecting other optio ns.

35
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
3.1.1.3 Selecting an intersec
tion as the destination
To enter an address as the d estination, do as follows:
1. Select after selectin g on the MAP screen.
2. Select .
3. If necessary, modify the country and city as described earlier (page 27).
4. Enter the street name: a. Select .
b. Start entering the str eet name on the keyboard.
c. Find the street you need: • The most likely street name is always shown in the input field . To accept
it, select .
• If the desired name does not s how up, the names that match the string
appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, select ). Select the s treet from
the list.

36
Yaris Sedan_Navi_OM99S53z_(U)
5. Enter the inters
ecting street name:
a. Select . • If only a few intersecting street s exist, their list appears immediately.
• In case of a longer street, the keyboard screen appears. Start entering the
name of the intersecting street on the keyboard. As soon as the street
names that match the entered string can be shown on one screen, their
list appears automatically. Sel ect the street from the list.

37
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
6. The selected location is shown on the map.
The system transitions to the next screen by selecting , or it
returns to the previous screen by selecting the button. By tou ching the
location displayed on the scree n, you can change the destinatio n to anywhere
on the map.
7. Navigation starts if is select ed, or after 10 seconds of no user
interaction.
By touching the location displa yed on the screen, you can verify the route.
Additionally, the rout e can be revised by selecting other optio ns.
•: You can search for POI (point of interest)
around the selected location.
• : The selected location can be registered to Favorites.

38
Yaris Sedan_Navi_OM99S53z_(U)
3.1.1.4 Selecting a city
center as the destination
The city center is not the geome tric center of the city but an arbitrary point on the
map the creators have chosen. In cities and villages, it is usually the most important
intersection; in larger cities, it is one of the important inte rsections.
1. Select after selectin g on the MAP screen.
2. Select .
3. If necessary, modify the country and city as described earlier (page 27).
4. Instead of entering the street name, select . This way the
center of the display ed city becomes the destination of the route.

39
1
2
3
4
5
6
Yaris Sedan_Navi_OM99S53z_(U)
5. The selected location is shown on the map.
The system transitions to the next screen by selecting , or it
returns to the previous screen by selecting the button. By tou ching the
location displayed on the scree n, you can change the destinatio n to anywhere
on the map.
6. Navigation starts if is select ed, or after 10 seconds of no user
interaction.
By touching the location displa yed on the screen, you can verify the route.
Additionally, the rout e can be revised by selecting other optio ns.
•: You can search for POI (point of interest)
around the selected location.
• : The selected location can be registered to Favorites.

40
Yaris Sedan_Navi_OM99S53z_(U)
3.1.2 Selecting the destination from the POI (point of interest)
You can select your destination from the POI (point of interest
) included with the
navigation system.
Using the same screen, you can fi nd a POI (point of interest) in different ways:
• You can quickly find a nearby POI (point of interest) by its name using the Quick
search feature.
• You can find frequently searched types of POI (point of interest) with only a few
screen selects using th e Preset search feature.
• You can search for a POI (point of interest) by its category.
• You can search for a POI (point of interest) by its name.
3.1.2.1 Quick search for a POI (point of interest)
If the name for a POI (point of interest) is input, a search candidate list is displayed.
One destination among the candidates can be selected.
• Along the recommended route if it exists or
• Around your current location if there is no destination given.
Start the Quick search function:
1. Select after selectin g on the MAP screen.
2. Select .
3. Select .
