TOYOTA YARIS 2019 Owners Manual (in English)

YARIS SEDAN_OM_OM99S50z_(U)
4915-4. Appearance Care
5
Maintenance and Care
■Vinyl
Remove dust and loose dirt from vinyl with a whisk broom or vac-
uum cleaner. Clean vinyl with a leather-and-vinyl cleaner.
■Leather (if equipped)
Remove dust and sand first using a vacuum cleaner or other
means, then wipe dirt off using a soft cloth with a leather cle aner or
a soft cloth soaked in mild soap. Wipe off the remaining cleane r or
soap using a cloth s oaked in clean water and wrung out well.
Remove moisture with a dry, soft cloth and allow the leather to fur-
ther dry in a well-ventilated, shaded area. If the leather gets wet
such as from rain, also remove moisture and dry it as soon as p os-
sible.
■Fabric
Remove dust and loose dirt from fabric with a whisk broom or va c-
uum cleaner. Clean it with a mild soap solution good for uphols tery
and carpets. Remove fresh spots immediately with a fabric spot
cleaner.
To keep the fabric looking clean and fresh, take care of it. Ot her-
wise its color will be affected , it can be stained easily, and its fire-
resistance may be reduced.
■Panel
When the interior panels need to be cleaned, use soft material such
as a soft cloth soaked in clean water and wrung out well and li ghtly
wipe off dirt from the surface. If a panel requires further cle aning,
use the following procedure.
Wipe dirt off using a soft cloth soaked in mild detergent (abou t
5% solution).
Wipe off any remaining detergent using a cloth soaked in clean
water and wrung out well.
Cleaning the Upholster y and Interior Trim
1
2

4925-4. Appearance Care
YARIS SEDAN_OM_OM99S50z_(U)
■Leather
●Because genuine leather is a natural material, its surface is n ot uniform and
it may have natural scars, scratches, and wrinkles.
● To maintain the quality for as long as possible, periodical maintenance,
about twice a year, is recommended.
NOTICE
■Leather
● Sand and dust on the seat surface may damage the overcoat of the genu-
ine leather surfaces and accelerate wear.
● Greasy soiling on genuine leather may cause molding and stains.
● Rubbing hard with a stiff brush or cloth may cause damage.
● Do not wipe the leather using alcohol, chlorine bleach, or orga nic solvents
such as thinner, benzene, or gasoline. Otherwise, it may cause discolor-
ation or stains.
● If the seats get wet, promptly remove moisture with a dry cloth. Remaining
moisture on the surface may cause deterioration such as hardeni ng and
shrinkage.
● Exposure to direct sunlight for long periods may cause deterior ation and
shrinkage. When parking the car under direct sunlight for long periods,
shade the interior using sunshades.
● Do not leave vinyl products on the seats for long periods as they may
affect the leather quality and coloring. If the cabin temperatu re becomes
hot, the vinyl may deteriorate and adhere to the genuine leathe r.
■ Fabric
Use only recommended cleaners and procedures. Others may affect
appearance and fire-resistance.
■ Panel
● Do not wipe leather parts using alcohol, chlorine bleach, or or ganic sol-
vents such as thinner, benzene, or gasoline. Otherwise, it may cause dis-
coloration or stains.
● Scratches or nicks on the panels and metallic trim resulting from the use of
a hard brush or cloth may not be repairable.
● Be particularly careful when cleaning high lustre panels and me tallic trim
as they can be easily scratched.

YARIS SEDAN_OM_OM99S50z_(U)
4935-4. Appearance Care
5
Maintenance and Care
Clean the webbing with a mild soap solution recommended for uphol-
stery or carpets. Follow instructions. Do not bleach or dye the web-
bing; this may weaken it.
After cleaning the belts, thoroughly dry the belt webbing and m ake
sure there is no rema ining moisture before retracting them.
If the windows become covered with an oily, greasy, or waxy fil m,
clean them with glass cleaner. Fo llow the directions on the container.
Rubber floor mats shou ld be cleaned with mild soap and water only.
After removing the floor mats for cleaning, always reinstall th em
securely. ( P. 135)
Cleaning the Lap/Shoulder Belt Webbing
WARNING
■Have your Toyota dealer replace damaged seat belts immediately
Using damaged seat belts is dangerous. In a collision, damaged belts can-
not provide adequate protection.
Cleaning the Window Interiors
NOTICE
● Do not scrape or scratch the inside of the window glass. It cou ld damage
the thermal filaments and the antenna lines.
● When washing the inside of the window glass, use a soft cloth d ampened
in lukewarm water, gently wiping the thermal filaments and the antenna
lines.
Use of glass cleaning products could damage the thermal filamen ts and
the antenna lines.
Cleaning the Floor Mats
WARNING
■ Do not use rubber clean ers, such as tire cleaner or tire shine, when
cleaning rubber floor mats
Cleaning the rubber floor mats with rubber cleaning products ma kes the
floor mats slippery.
This may cause an accident when depressing the accelerator, brake, or
clutch (Manual transaxle) pedal or when getting in or out of the vehicle.

4945-4. Appearance Care
YARIS SEDAN_OM_OM99S50z_(U)

495
YARIS SEDAN_OM_OM99S50z_(U)
6If Trouble Arises
6-1. Parking in an EmergencyParking in an Emergency ...................... 496
6-2. Flat Tire Spare Tire and Tool Storage ........................... 497
Changing a Flat Tire ......... 501
6-3. Battery Runs Out Jump-Starting.................... 511
6-4. Emergency Starting Starting a Flooded Engine............................. 515
Push-Starting .................... 516
6-5. Overheating Overheating ...................... 517
6-6. Emergency Towing Towing Description ........... 519
Tiedown Hooks ................. 520
6-7. Warning/Indicator Lights and Warning Sounds
If a Warning Light Turns On or Flashes ................. 522
Message Indicated on Display ............................ 533
Warning Sound is Activated ......................... 535
6-8. When Trunk Lid Cannot be Opened
When Trunk Lid Cannot be Opened ...................... 539

496
YARIS SEDAN_OM_OM99S50z_(U)
6-1. Parking in an Emergency
Parking in an Emergency
The hazard warning lights should
always be used when you stop on
or near a roadway in an emer-
gency.
The hazard warning lights warn
other drivers that your vehicle is a
traffic hazard and that they must
take extreme caution when near
it.
Depress the hazard warning flasher and all the turn signals will flash.
The hazard warning indicator lights in the combination meter fl ash
simultaneously.
● The turn signals do not work when the hazard warning lights are on.
● Check local regulations about the use of hazard warning lights while the
vehicle is being towed to verify that it is not in violation of the law.

497
YARIS SEDAN_OM_OM99S50z_(U)
6-2. Flat Tire
6
If Trouble Arises
Spare Tire and Tool Storage
Spare tire and tools are stored in the locations illustrated in the dia-
gram.
*1: The jack point attachment can be used by vehicle repair shops and
road assistance services. Consult your Toyota dealer for detail s.
■To remove the jack
Lift the trunk mat.
Remove trunk board.
Spare tire
Spare tire hold-down bolt
Tool bag
Jack
Jack point attachment
*1
Jack lever
Tiedown eyelet (if equipped)
Lug wrench
Flat tire belt
Jack
1
2
3
4
5
6
7
8
9
1
2

4986-2. Flat Tire
YARIS SEDAN_OM_OM99S50z_(U)
Turn the wing bolt and jack
screw counterclockwise.
■To secure the jackInsert the wing bolt into the
jack with the jack screw
pointing to the right side and
turn the wing bolt clockwise
to temporarily tighten it.
Turn the jack screw in the
direction shown in the figure.
Turn the wing bolt completely
to secure the jack.
If the jack is not completely secured, it could rattle while dr iving. Make
sure the jack screw is sufficiently tightened.
Return the trunk board to its original position.
Verify that the trunk board is securely installed.
■
Maintenance • Always keep the jack clean.
• Make sure the moving parts are k ept free from dirt or rust.
• Make sure the screw thread is adequately lubricated.
Wing boltJack screw
3
Wing boltJack screw
N
O
P
Q

YARIS SEDAN_OM_OM99S50z_(U)
4996-2. Flat Tire
6
If Trouble Arises
Your Toyota has a temporary spare tire. The temporary spare tire is
lighter and smaller than a convent ional tire, and is designed only for
emergency use and should be used only for VERY short periods.
Temporary spare tire s should NEVER be used for long drives or
extended periods.
■To remove the spare tire
Lift the trunk mat.
Turn the spare tire hold-down
bolt counterclockwise.
■To secure the spare tire
Store the spare tire in the reverse order of removal. After sto ring,
verify that the spare tire is stored securely.
Spare Tire
1
Spare tire hold-down boltO
WARNING
■Do not install the temporary spare tire on the front wheels (dr iving
wheels)
Driving with the temporary spare tire on one of the front driving wheels
is dangerous. Handling will be affe cted. You could lose control of the
vehicle, especially on ice or snow bound roads, and have an acc ident.
Move a regular tire to the front wheel and install the temporar y spare tire
to the rear.

5006-2. Flat Tire
YARIS SEDAN_OM_OM99S50z_(U)
NOTICE
●When using the temporary spare tire, driving stability may decrease
compared to when using only the co nventional tire. Drive carefully.
●To avoid damage to the temporary spare tire or to the vehicle, observe
the following precautions:
• Do not exceed 50 mph (80 km/h).
• Avoid driving over obstacles. Also, do not drive through an au to-
matic car wash. This tire’s diameter is smaller than a conventi onal
tire, so the ground cl earance is reduced.
• Do not use a tire chain on this tire bec ause it will not fit properly.
• Do not use your temporary spare tire on any other vehicle, it has
been designed only for your Toyota.
• Use only one temporary spare tire on your vehicle at the same time.
