4615-3. Owner Maintenance
5
Maintenance and Care
Also, inspect them for uneven wear and damage. Abnormal wear is
usually caused by one or a combination of the following:
• Incorrect tire pressure
• Improper wheel alignment
• Out-of-balance wheel
• Severe braking
After rotation, inflate all tire pressures to specification (
P. 582) and
inspect the lug nu ts for tightness.
With tire pressure monitoring system:
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operate normally .
Refer to Tire Pressure Monitorin g System Initialization on P. 233.
WARNING
■Rotate tires periodically
Irregular tire wear is dangerous. To equalize tire wear and ext end tire
life, Toyota recommends that tire rotation is carried out at th e same
interval as tire inspection.
For scheduled maintenance information, please refer to the “Own er’s
Manual Supplement/Schedul ed Maintenance Guide”.
NOTICE
Rotate unidirectional tires and radial tires that have an asymm etrical
tread pattern or studs only from front to rear, not from side t o side. Tire
performance will be redu ced if rotated from side to side.

4625-3. Owner Maintenance
YARIS SEDAN_OM_OM99S50z_(U)
If a tire wears evenly, a wear indicator will appear as a solid band
across the tread.
Replace the tire when this happens.New tread
Worn tread
Tread wear indicator
You should replace the tire bef ore the band crosses the entire tread.
With tire pressure monitoring system:
After adjusting the tire pressur e, initialization of the tire p ressure mon-
itoring system is necessary to m ake the system operate normally .
Refer to Tire Pressure Monitorin g System Initialization on P. 233.
Tires degrade over time, even wh en they are not being used on the road.
It is recommended that tires gen erally be replaced when they are 6 years
or older. Heat caused by hot climates or frequent high loading conditions
can accelerate the aging process. You should replace the spare tire when
you replace the other road tires due to the aging of the spare tire. The
period in which the tire was manufactured (both week and year) is indi-
cated by a 4-digit number.
Refer to Tire Labeling on P. 554.
Replacing a Tire
1
2
3
WARNING
■Always use tires that are in good condition
Driving with worn tires is dangero us. Reduced braking, steering, and
traction could result in an accident.
■Replace all four tires at the same time
Replacing just one tire is dangerous. It could cause poor handl ing and
poor braking resulting in loss of vehicle control. Toyota strongly recom-
mends that you replace all four tires at the same time. If you replace
only two tires, the new tires should be installed on the rear o f the vehi-
cle.

YARIS SEDAN_OM_OM99S50z_(U)
4635-3. Owner Maintenance
5
Maintenance and Care
Inspect the temporary spare tire at least monthly to make sure it is
properly inflated and stored.
The temporary spare tire is easier to handle because of its con struc-
tion which is lighter and smaller than a conventional tire. Thi s tire
should be used only for an emergency and only for a short dista nce.
Use the temporary spare tire o nly until the conventional tire is
repaired, which should be as soon as possible.
Refer to Tires on P. 582.
●The temporary spare tire condition gradually deteriorates even if it has
not been used.
●Tires degrade over time, even when they are not being used on t he
road. It is recommended that tires generally be replaced when t hey are
6 years or older. Heat caused by hot climates or frequent high loading
conditions can accelerate the aging process. You should replace the
spare tire when you replace the other road tires due to the agi ng of the
spare tire. The period in which the tire was manufactured (both week
and year) is indicated by a 4-digit number.
Refer to Tire Labeling on P. 554.
Proper tire balancing provides t he best riding comfort and help s
reduce tread wear. Out-of-balance tires can cause vibration and
uneven wear, such as c upping and flat spots.
When replacing a wheel, make sure the new one is the same as th e orig-
inal factory wheel in diameter, rim width, and offset (inset/outset).
For details, contact your Toyota dealer.
Temporary Spare Tire
NOTICE
●Do not use your temporary spare tire rim with a snow tire or a conven-
tional tire. Neither will properly fit and could damage both tire and rim.
●The temporary spare tire has a tread life of less than 3,000 mi les
(5,000 km). The tread life may be shorter depending on driving condi-
tions.
●The temporary spare tire is for limited use, however, if the tr ead wear
solid-band indicator appears, replace the tire with the same ty pe of
temporary spare ( P. 463).
Replacing a Wheel

4645-3. Owner Maintenance
YARIS SEDAN_OM_OM99S50z_(U)
WARNING
■Always use wheels of the correct size on your vehicle
Using a wrong-sized wheel is dangerous. Braking and handling could
be affected, leading to loss of control and an accident.
NOTICE
A wrong-sized wheel may adversely affect:
●Tire fit
●Wheel and bearing life
●Ground clearance
●Snow-chain clearance
●Speedometer calibration
●Headlight aim
●Bumper height
●Tire Pressure Monitoring System (if equipped)

465
YARIS SEDAN_OM_OM99S50z_(U)
5-3. Owner Maintenance
5
Maintenance and Care
Light Bulbs
■Front
With Halogen Headlights
Headlights (Low/High beam)/
Daytime running lights
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Fog lights (if equipped)
With LED Headlights
Headlights (High beam)
Headlights (Low beam)
Front side-marker lights
Overhead lights/Map lights
Side turn signal lights (if
equipped)
Front turn signal lights/Park-
ing lights
Daytime running light/Park-
ing light
Fog lights
1
2
3
4
5
6
1
2
3
4
5
6
7
8

4665-3. Owner Maintenance
YARIS SEDAN_OM_OM99S50z_(U)■
Rear
Trunk light
High-mount brake lights
License plate lights
Reverse lights
Rear turn signal lights
Brake lights/Taillights/Rear
side-marker lights
●To replace the bulb, contact your Toyota dealer.
● If the halogen bulb is accidentally touched, it should be clean ed with rubbing
alcohol before being used.
● Use the protective cover and carton of the replacement bulb to dispose of
the old bulb promptly out of the reach of children.
1
2
3
4
5
6
WARNING
■ Never touch the glass portion of a halogen bulb with your bare hands
and always wear eye protection wh en handling or working around the
bulbs
When a halogen bulb breaks, it is dangerous. These bulbs contai n pressur-
ized gas. If one is broken, it will explode and serious injurie s could be
caused by the flying glass.
If the glass portion is touched with bare hands, body oil could cause the
bulb to overheat and explode when lit.
■ Always keep halogen bulbs out of the reach of children
Playing with a halogen bulb is dangerous. Serious injuries coul d be caused
by dropping a halogen bulb or breaking it some other way.
NOTICE
When removing the lens or lamp unit using a flathead screwdrive r, m a k e
sure that the flathead screwdriver does not contact the interio r terminal. If
the flathead screwdriver contacts the terminal, a short circuit may occur.

YARIS SEDAN_OM_OM99S50z_(U)
4675-3. Owner Maintenance
5
Maintenance and Care
■Headlights/Daytime running lights (With halogen headlights)
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Lift the hood.
Disconnect the connector
from the bulb.
Detach the sealing cover
from the bulb.
Retaining spring
Sealing cover
Unhook the bulb retaining spring.
Swing the retaining spring out and away to free the headlight
bulb.
Carefully remove the headlight bulb from the socket by pulling it
straight back.
Replace the bulb.
Install the new bulb in the reverse order of the removal proce-
dure.
Replacing Exterior Light Bulbs
1
2
3
4
1
2
5
6
7
8
9

4685-3. Owner Maintenance
YARIS SEDAN_OM_OM99S50z_(U)■
Front turn signal lights/Parking
lights, Front side-marker lights
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Lift the hood.
Front turn signal lights/Park-
ing lights: Remove the fuse
block cover.
Turn the socket and bulb assembly counterclockwise and
remove it.
Disconnect the bulb from the socket.
Install the new bulb in the reverse order of the removal proce-
dure.
1
2
3
4
5
Front turn signal lights/Parking
lightsFront side-marker lights
6

YARIS SEDAN_OM_OM99S50z_(U)
4695-3. Owner Maintenance
5
Maintenance and Care
■Fog lights (if equipped)Make sure the ignition is switched off, and the fog light switc h is
off.
Turn the screws counter-
clockwise and remove them.
Pull the center of each retain-
ers and remove them, and
then partially peel back the
front under cover.
Removal
Installation
Disconnect the connector
from the unit by pressing the
tab on the connector with
your finger and pulling the
connector downward.
1
2
3
1
2
4

4705-3. Owner Maintenance
YARIS SEDAN_OM_OM99S50z_(U)
Turn the socket and bulb
assembly to remove it. Care-
fully remove the bulb from its
socket in the reflector by
gently pulling it straight back-
ward out of the socket.
Install the new bulb in the reverse order of the removal proce-
dure.
■Rear turn signal lights, Brake lights/Taillights/Rear side-marker
lights
Make sure the ignition is swit ched off, and the headlight switc h is
off.
Remove the cover.
Turn the socket and bulb assembly counterclockwise and
remove it.
Disconnect the bulb from the socket.
5
6
1
2
3
4
Rear turn signal lightsBrake lights/Taillights/Rear
side-marker lights
