key TOYOTA YARIS HATCHBACK 2020 (in English) Owner's Manual

102
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
WARNING
■Always take all children and p ets with you or leave a responsib le per-
son with them
Leaving a child or a pet unattended in a parked vehicle is dang erous. In hot
weather, temperatures inside a vehicle can become high enough t o cause
brain damage or even death.
■ Do not leave the key in your vehi cle with children and keep them in a
place where your children will not find or play with them
Leaving children in a vehicle with the key is dangerous. This c ould result in
someone being badly injured or even killed.
■ Keep all doors locked when driving
Unlocked doors in a moving vehicle are dangerous. Passengers ca n fall out
if a door is accidentally opened and can more easily be thrown out in an
accident.
■ Always close all the windows, lo ck the doors and the liftgate and take
the key with you when leaving your vehicle unattended
Leaving your vehicle unlocked is dangerous as children could lock them-
selves in a hot vehicle, which could result in death. Also, a v ehicle left
unlocked becomes an easy target for thieves and intruders.
■ After closing the door s and the liftgate/trunk lid, always veri fy that they
are securely closed
Doors and the liftgate/trunk lid not securely closed are danger ous, if the
vehicle is driven with a door and the liftgate/trunk lid not se curely closed, the
door and the liftgate/trunk lid could open unexpectedly resulti ng in an acci-
dent.
■ Always confirm the safety around the vehicle before opening a d oor
and the liftgate/trunk lid
Suddenly opening a door and the liftgate/trunk lid is dangerous .
A passing vehicle or a pedestrian could be hit and cause an accident.
■ When opening or closing a door and the trunk lid
Always confirm the conditions around the vehicle before opening /closing
the doors and the liftgate/trunk lid and use caution during str ong winds or
when parked on an incline. Not being aware of the conditions around the
vehicle is dangerous because fingers could get caught in the do or and the
liftgate/trunk lid or a passing pedestrian could be hit, result ing in an unex-
pected accident or injury.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1032-3. Door and Locks
2
Before Driving
Turn the auxiliary key toward the
front to lock, toward the back to
unlock.Lock
Unlock
■To l o c k
All doors and the liftgate lock automatically when the driver’s door
is locked using th e auxiliary key.
■To unlock
The driver’s door unlocks when the auxiliary key is turned brie fly to
the unlock position and then imm ediately returned to the center
position.
All doors and the liftgate unlock when the driver’s door is unl ocked
and the auxiliary key is held in the unlock position for one second or
longer.
All doors and the liftgate can be
locked/unlocked by pressing the
request switch while the key is
being carried.
Locking, Unlocking with Auxiliary Key
1
2
Locking, Unlocking with Reques t Switch (With the advanced
keyless function)
Request switch

104
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
■To l o c k
To lock the doors and the liftgate, press the request switch and the
hazard warning lights will flash once.
A beep sound will be heard once.
■To unlock
● Driver’s door request switch
To unlock the driver’s door, p ress the request switch. A beep
sound will be heard twice and t he hazard warning lights will flash
twice.
To unlock all doors and the liftgate, press the request switch
again within three seconds a nd two more beep sounds will be
heard.
● Front passenger door request switch
To unlock all doors and the liftgate, press the request switch. A
beep sound will be heard twice and the hazard warning lights wi ll
flash twice.
● The system can be set to unlock all doors by performing a singl e operation.
Refer to Customizable Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door.
Within 30 seconds of opening the driver’s door, press and hold the
UNLOCK button on the key for 5 seconds or longer (the sound of the
doors locking/unlocking can be heard).
After this, the system switches the setting of pressing the dri ver’s request
switch once or twice to unlock all doors and the liftgate each time the
UNLOCK button is pressed (the sound of the doors locking/unlocking can
be heard).
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the UNLOCK button on the key.
• Pressing a request switch.
1
2
3
4

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1052-3. Door and Locks
2
Before Driving
●Confirm that all doors and the liftgate are securely locked.
For the liftgate/trunk lid, move it without pressing the electr ic liftgate/trunk lid
opener to verify that the liftgate/trunk lid has not been left ajar.
● All doors and the liftgate cannot be locked when any door or the liftgate is
open.
● It may require a few seconds for the doors to unlock after the request switch
is pressed.
● A beep sound is heard for confirmation when the doors and the l iftgate are
locked/unlocked using the request switch. If you prefer, the beep sound can
be turned off.
The volume of the beep sound can also be changed. Refer to Cust omizable
Features on P. 555.
Use the following procedure to change the setting.
Switch the ignition off and close all of the doors and the lift gate/trunk lid.
Open the driver’s door.
Within 30 seconds of opening the driver’s door, press and hold the LOCK
button on the key for 5 seconds or longer (All of the doors and the liftgate
are locked and unlocked when the LOCK button on the key is pressed
and held for 5 seconds.).
The beep sound activates at the currently set volume. The setting
changes each time the LOCK button on the key is pressed and the beep
sound activates at the set volume. (If the beep sound has been set to not
activate, it will not activate.)
The setting change is completed by doing any one of the followi ng:
• Switching the ignition to ACC or ON.
• Closing the driver’s door.
• Opening the liftgate/trunk lid.
• Not operating the key for 10 seconds.
• Pressing any button except the LOCK button on the key.
• Pressing a request switch.
1
2
3
4

106
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
●With theft deterrent system:
The hazard warning lights flash when the theft deterrent system is armed or
turned off.
Refer to Theft Deterrent System on P. 138.
● The setting can be changed so that the doors and the liftgate a re locked
automatically without pressing the request switch.
Refer to Customizable Features on P. 555.
Walk-away auto lock function:
A beep sound is heard when all doors and the liftgate are close d while the
advanced key is being carried. All doors and the liftgate are l ocked auto-
matically after about three seconds when the advanced key is ou t of the
operational range. Also, the hazard warning lights flash once. (Even if the
driver is in the operational range, all doors and the liftgate are locked auto-
matically after about 30 seconds.) If you are out of the operat ional range
before the doors and the liftgate/trunk lid are completely clos ed or another
key is left in the vehicle, the function will not work. Always make sure that
all doors and the liftgate/trunk lid are closed and locked befo re leaving the
vehicle. The function does not close the power windows.
● Auto re-lock function:
After unlocking with the request switch, all doors and the liftgate will auto-
matically lock if any of the following operations are not performed within
about 60 seconds. If your vehicle has a theft deterrent system, the hazard
warning lights will flash for confirmation.
The time required for the doors to lock automatically can be ch anged. Refer
to Customizable Features on P. 555.
• Opening a door or the liftgate/trunk lid.
• Switching the ignition to any position other than off.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1072-3. Door and Locks
2
Before Driving
All doors and the liftgate can be locked/unlocked by operating the key-
less entry system smart key, r efer to Keyless Entry System ( P. 92).
All doors and the liftgate lock automatically when the lock sid e is
pressed. They all unlock when the unlock side is pressed.
Driver’s door Lock
Unlock
Front passenger’s door Lock
Unlock
To lock all the doors and the liftgate from an open front door, press the
lock side of the door lock swi tch and then close the door.
When locking the doors this way, be careful not to leave the ke y inside the
vehicle.
Locking, Unlocking with Smart Key
Locking, Unlocking with Door-Lock Switch
1
2
1
2

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1112-3. Door and Locks
2
Before Driving
■Operation from insideLock
To lock any door from the inside,
press the door-lock knob.
Unlock
To unlock, pull it outward.
This does not operate the other
door locks.
■Operation from outside
To lock any door using its door-
lock knob from the outside,
press the door-lock knob to the
lock position and close the door
(holding the door handle in the
open position is not required).
This does not operate the other
door locks.
When locking the door this way:• Be careful not to leave the key inside the vehicle.
• The doors cannot be locked using the driver’s door lock knob i f any
door is open when the ignition is switched to ACC or ON.
Locking, Unlocking with Door-Lock Knob
1
2
Door-lock knob
The red indication can be seen when the
door-lock knob is unlocked.Red indication

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1152-3. Door and Locks
2
Before Driving
■Opening the liftgate (5-Door)
Using the electric liftgate opener
Unlock the doors and liftgate,
then press the electric liftgate
opener on the liftgate and raise
the liftgate when the latch
releases.
■ Opening the liftgate (With the advanced keyless function)
● A locked liftgate can also be opened while the key is being car ried.
● When opening the liftgate with the doors and the liftgate locke d, it may
require a few seconds for the liftgate latch to release after t he electric liftgate
opener is pressed.
● The liftgate can be closed when the doors are locked with the key left in the
vehicle. However, to prevent locking the key in the vehicle, the liftgate can
be opened by pressing the electric liftgate opener. If the liftgate cannot be
opened despite doing this procedure, first push the liftgate co mpletely
closed, then press the electric liftgate opener to fully open t he liftgate.
● When the liftgate latch is released by pressing the electric li ftgate opener,
the liftgate raises slightly. If the liftgate is not operated f or a certain period of
time, the liftgate cannot be raised.
To o p e n
Press the electric liftgate opener again.
To close
To close the liftgate from its slightly raised position, open i t first by pressing
the electric liftgate opener, then close it after waiting at least 1 second.
● If the liftgate is not fully closed, the driver is notified by a warning indicated in
the instrument cluster.
● If the vehicle battery is dead or there is a malfunction in the electrical system
and the liftgate cannot be unlocked, the liftgate can be opened by perform-
ing the emergency procedure.
Refer to When Liftgate/Trunk Lid Cannot be Opened on P. 506
Opening and Closing th e Liftgate/Trunk Lid

116
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-3. Door and Locks
■Opening the trunk lid (4-Door)
●Using the remote release button
Push the remote release but-
ton.
● Using the electric trunk lid opener (With the advanced keyless
function)
A locked trunk lid can also be
opened while the key is
being carried.
Press the electric trunk lid
opener on the trunk lid, then
raise the trunk lid when the
latch releases.
■Closing the liftgate/trunk lid
5-Door
Lower the liftgate slowly using
the liftgate grip recess, then
push the liftgate closed using
both hands. Do not slam it. Pull
up on the liftgate to make sure it
is secure.
4-Door
Use both hands to push the trunk lid down until the lock snaps shut.
Do not slam it. Pull up on the trunk lid to make sure it is sec ure.
Liftgate grip
recess

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1172-3. Door and Locks
2
Before Driving
■Opening the trunk lid
●When opening the trunk lid with the doors locked, it may requir e a few sec-
onds for the trunk lid latch to release after the electric trun k lid opener is
pressed.
● The trunk lid can be closed when the doors are locked with the key left in the
vehicle. However, to prevent locking the key in the vehicle, the trunk lid can
be opened by pressing the electric trunk lid opener. If the tru nk lid cannot be
opened despite doing this procedure, press the electric trunk l id opener to
fully open the trunk lid after pushing the trunk lid completely closed.
● If the vehicle battery is dead or there is a malfunction in the electrical system
and the trunk lid cannot be unlocked, the trunk lid can be open ed by per-
forming the emergency procedure.
Refer to When Liftgate/Trunk Lid Cannot be Opened on P. 506.
■
Luggage compartment cover (5-Door)
The luggage compartment can
be accessed by opening the lift-
gate when the straps are
attached to the sides of the lift-
gate.
Luggage Compartment
Strap
WARNING
■ Do not place anything on top of the cover
Placing luggage or other cargo on top of the luggage compartment cover is
dangerous. During sudden braking or a collision, the cargo coul d become a
projectile that could hit and injure someone. The vehicle has a light weight
luggage compartment cover to keep the contents of your luggage area out
of sight; it will not retain heavy objects that are not tied down in an accident
such as a rollover. Tie down all heavy objects, whether luggage or cargo,
using the tie down hooks.
■ Make sure luggage and cargo are secured before driving
● Not securing cargo while driving is dangerous as it could move or be
crushed during sudden braking or a collision and cause injury.
● Make sure the luggage compartment cover is firmly secured. If it is not
firmly secured, it could unexpectedly disengage resulting in in jury.
