Page 3 of 572

3
1
8 7
6 4 3
2
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
5
2-5. Steering WheelSteering Wheel.................. 127
2-6. Mirrors Mirrors ............................... 129
2-7. Windows Power Windows ................ 132
2-8. Security System Modification and Add-On Equipment ......... 135
Immobilizer System ........... 136
Theft Deterrent System ..... 138
2-9. Driving Tips Break-In Period ................. 141
Saving Fuel and Protection of the
Environment .................... 142
Hazardous Driving............. 143
Floor Mat ........................... 144
Rocking the Vehicle .......... 145
Winter Driving.................... 146
Driving In Flooded Area ................................ 149
Overloading ....................... 150
Driving on Uneven Road ............................... 151
2-10. Towing Trailer Towing ................... 152
Recreational Towing ......... 153 3-1. Start/Stop Engine
Ignition Switch ................... 156
Starting the Engine ............ 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges ........... 164
Warning/Indicator Lights ............................... 173
3-3. Transaxle Manual Transaxle Operation......................... 177
Automatic Transaxle Controls ........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights .......................... 198
Turn and Lane-Change Signals............................. 199
Windshield Wipers and Washer ..................... 201
Rear Window Wiper and Washer ............................ 206
Rear Window Defogger.......................... 207
Hazard Warning Flasher ............................ 208
3-5. Brake Brake System .................... 209
Hill Launch Assist (HLA) .... 213
3When Driving
Page 92 of 572

92
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-1. Keys
Keyless Entr y System
It can also help you signal for attention.
Operating the theft deterrent s ystem is also possible on theft deterrent
system-equipped vehicles.
Press the buttons slo wly and carefully.
System malfunctions or warnings a re indicated by the following warn-
ing lights or beeps.
● KEY Warning Light (Red)
Refer to Warning/Indi cator Lights on P. 173.
● Ignition Not Switched O ff (STOP) Warning Beep
Refer to Ignition Not Switched Off (STOP) Warning Beep on P. 504.
● Key Removed from Vehicle Warning Beep
Refer to Key Removed from Ve hicle Warning Beep on P. 504.
If you have a problem with the key, consult your Toyota dealer.
If your key is lost or stolen, consult your Toyota dealer as soon as pos-
sible for a replacement and to make the lost or stolen key inop erative.
This system uses the key buttons to remotely lock and unlock
the doors and the liftgate, and opens the trunk lid.
The system can start the engine without having to take the key
out of your purse or pocket.
Page 123 of 572

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1232-4. Fuel and Emission
2
Before Driving
Engine Exhaust (Carbon monoxide)
WARNING
■Do not drive your vehicle if you smell exhaust gas inside the v ehicle
Engine exhaust gas is dangerous. This gas contains carbon monox ide
(CO), which is colorless, odorless, and poisonous. When inhaled , it can
cause loss of consciousness and death. If you smell exhaust gas inside the
vehicle, keep all windows fully open and contact your Toyota de aler immedi-
ately.
■ Do not run the engine when inside an enclosed area
Running the engine inside an enclosed area, such as a garage, i s danger-
ous. Exhaust gas, which contains poisonous carbon monoxide, cou ld easily
enter the cabin. Loss of consciousness or even death could occu r.
■ Open the windows or adjust the heating or cooling system to draw
fresh air when idling the engine:
Exhaust gas is dangerous. When the vehicle is stopped with the windows
closed and the engine running for a long time even in an open a rea,
exhaust gas, which contains poisonous carbon monoxide, could en ter the
cabin. Loss of consciousness or even death could occur.
■ Clear snow from underneath and around your vehicle, particularl y the
tail pipe, before starting the engine:
Running the engine when a vehicle is stopped in deep snow is da ngerous.
The exhaust pipe could be blocked by the snow, allowing exhaust gas to
enter the cabin. Because exhaust gas contains poisonous carbon monox-
ide, it could cause loss of consciousness or even death to occu pants in the
cabin.
Page 140 of 572

140
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-8. Security System
An armed system can be turned off using any one of the following
methods: • Pressing the unlock button on the smart key.
• Starting the engine with the push button start.
• With the advanced ke yless function:
Pressing a request switch on the doors.
The hazard warning li ghts will flash twice.
When the doors are unlocked by pressing the unlock button on the smart key
while the theft deterrent system is turned off, the hazard warn ing lights will
flash twice to indicate that the system is turned off.
A triggered alarm can be turned off using any one of the follow ing
methods: • Pressing the unlock button or the trunk button (4-door) on the smart
key.
• Starting the engine with the push button start.
• With the advanced ke yless function:
Pressing a request switch on the doors.
The hazard warning li ghts will flash twice.
To Turn Off an Armed System
To Stop the Alarm
Page 141 of 572

141
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-9. Driving Tips
2
Before Driving
Break-In Period
No special break-in is necessary, but a few precautions in the first 600
miles (1,000 km) may add to the performance, economy, and life of
the vehicle. • Do not race the engine.
• Do not maintain one constant speed, either slow or fast, for a long
period of time.
• Do not drive constant ly at full-throttle or high engine rpm fo r
extended periods of time.
• Avoid unnecessa ry hard stops.
• Avoid full-throttle starts.
Page 142 of 572

142
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
2-9. Driving Tips
Saving Fuel and Protection of the Environment
How you operate your Toyota determines how far it will travel o n a
tank of fuel. Use these suggesti ons to help save fuel and reduce CO2.
• Avoid long warm-ups. Once the engine runs smoothly, begin driv -
ing.
• Avoid fast starts.
• Drive at lower speeds.
• Anticipate when to apply the br akes (avoid sudden braking).
• Follow the maintenance schedule and have your Toyota dealer pe r-
form inspections and servicing.
• Use the air conditioner only when necessary.
• Slow down on rough roads.
• Keep the tires properly inflated.
• Do not carry unnecessary weight.
• Do not rest your foot on the brake pedal while driving.
• Keep the wheels in correct alignment.
• Keep windows clos ed at high speeds.
• Slow down when driving in crosswinds and headwinds.
WARNING
■ Never stop the engine when going down a hill
Stopping the engine when going down a hill is dangerous. This c auses the
loss of power steering and power brake control, and may cause d amage to
the drivetrain. Any loss of steering or braking control could c ause an acci-
dent.
Page 155 of 572

155
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3When Driving
3-1. Start/Stop EngineIgnition Switch ................... 156
Starting the Engine ........... 158
Turning the Engine Off ...... 163
3-2. Combination Meter and Display
Meters and Gauges .......... 164
Warning/Indicator Lights .............................. 173
3-3. Transaxle Manual Transaxle Operation ........................ 177
Automatic Transaxle Controls........................... 181
3-4. Switches and Controls Lighting Control ................. 192
Fog Lights ......................... 198
Turn and Lane-Change Signals ............................ 199
Windshield Wipers and Washer..................... 201
Rear Window Wiper and Washer............................ 206
Rear Window Defogger ......................... 207
Hazard Warning Flasher ............................ 208 3-5. Brake
Brake System.................... 209
Hill Launch Assist (HLA) ... 213
3-6. ABS/TCS/DSC Antilock Brake System (ABS) .............................. 215
Traction Control System (TCS) .............................. 216
Dynamic Stability Control (DSC) .............................. 218
3-7. Fuel Economy Monitor Fuel Economy Monitor ...... 221
3-8. Drive Selection Drive Selection (Automatic Transaxle) ..... 224
3-9. Power Steering Power Steering ................. 226
3-10. Active Safety System Active Safety System ........ 227
Low Speed Pre-Collision System ............................ 228
Laser Sensor..................... 234
3-11. Cruise Control Cruise Control ................... 236
3-12. Tire Pressure Monitoring System
Tire Pressure Monitoring System ............................ 241
3-13. Rear View Monitor Rear View Monitor ............ 245
Page 156 of 572

156
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-1. Start/Stop Engine
Ignition Switch
The system operates only when the driver is in the vehicle or within
operational range while the key is being carried.
Each time the push button start is
pressed, the ignition switches in
the order of off, ACC, and ON.
Pressing the push button start
again from ON switches the igni-
tion off.
■Off
The power supply to electrical devices turns off and the push b utton
start indicator light (amber) also turns off.
In this position the st eering wheel is locked.
■ACC (Accessory)
Some electrical access ories will operate and the indicator light
(amber) illuminates.
■ON
This is the normal running posit ion after the engine is started. The
indicator light (amber) turns off. (The indicator light (amber) illumi-
nates when the ignition is switched ON and the engine is not ru n-
ning.)
Some indicator lights/warning lights should be inspected before the
engine is started ( P. 1 7 3 ) .
Push Button Start Positions
Push button start Indicator light
Page 157 of 572

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1573-1. Start/Stop Engine
3
When Driving
■Push Button Start Positions
●The engine starts by pressing the push button start while depre ssing the
clutch pedal (manual transaxle) or the brake pedal (automatic t ransaxle). To
switch the ignition position, press the push button start without depressing
the pedal.
● Do not leave the ignition switched ON while the engine is not r unning. Doing
so could result in the battery going dead. If the ignition is l eft in ACC (For
automatic transaxle, the selector lever is in the P position, a nd the ignition is
in ACC), the ignition switches off automatically after about 25 minutes.
■ ACC (Accessory)
The keyless entry system does not function while the push butto n start has
been pressed to ACC, and the doors will not lock/unlock even if they have
been locked manually.
■ ON
When the push button start is pressed to ON, the sound of the f uel pump
motor operating near the fuel tank can be heard. This does not indicate an
abnormality.
WARNING
■ Before leaving the driver’s seat, set the parking brake, make s ure the
selector lever is in 1st gear or R (manual transaxle) or in P ( automatic
transaxle), and always switch the ignition off
Leaving the driver’s seat without setting the parking brake, sh ifting the
selector lever to 1st gear or R (manual transaxle) or to P (automatic tran-
saxle), and switching the ignition off is dangerous. Unexpected vehicle
movement could occur which could result in an accident.
In addition, if your intention is to leave the vehicle for even a short period, it
is important to switch the ignition off, as leaving it in anoth er position will dis-
able some of the vehicle’s security systems and run the battery down.
Page 158 of 572

158
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
3-1. Start/Stop Engine
Starting the Engine
Make sure you are carrying the key.
Occupants should fasten their seat belts.
Make sure the parking brake is on.
Continue to press the brake pedal firmly until the engine has c om-
pletely started.
Manual transaxle:
Continue to press the clutch pedal firmly until the engine has com-
pletely started.
The starter will not operate if the clutch pedal is not depress ed sufficiently.
Automatic transaxle:
Put the vehicle in park (P). If you must restart the engine while the
vehicle is moving, shift into neutral (N).
The starter will not operate if the selector lever is not in P or N and the
brake pedal is not depressed sufficiently.
Press the push button start after both the KEY indicator light
(green) in the combination meter and the push button start indi cator
light (green) illuminate.
After starting the engine, the push button start indicator ligh t (amber) turns
off and the ignition switches to the ON position.
1
2
3
4
5
Verify that the KEY indicator
light (green) in the combination
meter and the push button start
indicator light (green) illumi-
nate.
If the push button start indicator
light (green) flashes, make sure
that the key is being carried.
If the push button start indicator
light (green) flashes with the key
being carried, touch the key to the
push button start and start the
engine. Refer to Engine Start Func-
tion When Key Battery is Dead on
P. 161.
6
Push button start Indicator light
T
