air condition TOYOTA YARIS HATCHBACK 2020 Owners Manual (in English)

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Pictorial IndexInterior, exterior views and part identification of
your Toyota.
1Essential Safety
EquipmentImportant information about safety equipment,
including seats, seat belt system, child-restraint
systems and SRS air bags.
2Before DrivingUse of various features, including keys, doors,
mirrors and windows.
3When DrivingInformation concerning safe driving and stopping.
4Interior FeaturesUse of various features for ride comfort, including
air-conditioning and audio system.
5Maintenance and
CareHow to keep your Toyota in top condition.
6If Trouble ArisesHelpful information on what to do if a problem
arises with the vehicle.
7
Customer Information
and Reporting Safety
DefectsImportant consumer information including
warranties and add-on equipment.
8SpecificationsTechnical information about your Toyota.
IndexSearch alphabetically

8
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
Please be aware that this manual applies to all models, equipment
and options. As a result, you may find some explanations for equip-
ment not installed on your vehicle.
■Important Notes A bout This Manual
Keep this manual in the glove box as a handy reference for the safe
and enjoyable use of your Toyota. Should you resell the vehicle,
leave this manual with it for the next owner.
All specifications and descripti ons are accurate at the time of print-
ing. Because improvement is a co nstant goal at Toyota, we reserve
the right to make changes in specifications at any time without
notice and without obligation.
■Air Conditioning and the Environment
Your Toyota’s genuine air conditioner is filled with a refriger ant that
has been found not to damage the earth’s ozone layer. If the ai r
conditioner does not operate properly, consult your Toyota deal er.
■Perchlorate
Certain components of this vehicle such as [air bag modules, seat
belt pretensioners, lithium batteries,...] may contain Perchlor ate
Material-- Special handling may apply for service or vehicle en d of
life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate.

39
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-2. Seat Belt Systems
1
Essential Safety Equipment
Seat Belt Pretensioner and Load Limiting
Systems
◆Pretensioners
When a collision is detected, the pretensioners deploy simultan e-
ously with the air bags.
The pretensioners deploy simult aneously with the air bags when a
roll-over is also detected.
For deployment details, refer to the SRS Air Bag Deployment Cri te-
ria ( P. 78).
The front seat belt retractors remove slack quickly as the air bags
are expanding. Any time the air bags and seat belt pretensioners
have fired they must be replaced.
A system malfunction or operation conditions are indicated by a
warning.
Refer to Warning/Indi cator Lights on P. 173.
Refer to Air Bag/Front Seat Belt Pretensioner System Warning
Beep on P. 503.
In addition, the pretensioner system for the front passenger, l ike the
front and side passenger air bag, is designed to only deploy wh en
the front passenger occupant class ification sensor detects a pas-
senger sitting on the front passenger’s seat.
For details, refer to the front passenger occupant classificati on sen-
sor ( P. 8 2 ) .
For optimum protection, the d river and front passenger seat
belts are equipped with pretensi oner and load limiting systems.
For both these systems to work properly you must wear the seat
belt properly.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
431-2. Seat Belt Systems
1
Essential Safety Equipment
WARNING
■Do not use an extende r that is too long
Using an extender that is too long is dangerous. The seat belt will not fit
properly. In an accident, the seat belt will not provide adequa te protection
and you could be seriously injured. Do not use the extender or choose one
shorter in length if the distance between the extender’s buckle and the cen-
ter of the user’s body is less than 6 in. (150 mm).
■ Do not leave a seat belt extende r connected to the buckle
Leaving a seat belt extender connected to the buckle without using the seat
belt is dangerous. When the seat belt extender is connected to the driver’s
seat belt buckle (or front passenger’s seat belt buckle), the S RS driver’s (or
front passenger’s) air bag system will determine that the drive r (or front pas-
senger) is wearing the seat belt even if the driver (or front p assenger) is not
wearing it. This condition could cause the driver’s (or front passenger’s) air
bag to not activate correctly and result in death or serious injury in the event
of collision. Always wear the seat belt with the seat belt exte nder.
■ Do not use the seat belt extender when installing a child-restr aint sys-
tem on the front or rear passenger seat
Using a seat belt extender to fasten a child-restraint system on any seat is
dangerous. Always follow the child-restraint system manufacture r’s installa-
tion instructions and never use a seat belt extender.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
471-3. Child Restraint
1
Essential Safety Equipment
WARNING
■Seating a child in a child-restraint system on the front passen ger seat
is dangerous under certain conditions
Your vehicle is equipped with front passenger occupant classifi cation sen-
sor. Even with the front passenger occupant classification sensor, if you
must use the front passenger seat to seat a child, using a chil d-restraint
system on the front passenger seat under the following conditio ns
increases the danger of the front passenger air bag deploying a nd could
result in serious injury or death to the child.
● The front passenger air bag deactivation indicator light does not illuminate
when seating a child in the child-restraint system.
● Luggage or other items are placed on the seat with the child in the child-
restraint system.
● A rear passenger or luggage pushing or pulling down on the front passen-
ger seatback.
● Luggage or other items are placed on the seatback or hung on the head
restraint.
● The seat is washed.
● Liquids are spilled on the seat.
● The front passenger seat is moved backward, pushing into luggag e or
other items placed behind it.
● The front passenger seatback contacts the rear seat.
● Luggage or other items are placed between the front passenger s eat and
driver seat.
● An electric device is put on the front passenger’s seat.
● An additional electrical device, such as a seat warmer is installed to the
surface of the front passenger seat.
The designated positions with seat belts on the rear seats are the safest
places for children. Always use seat belts and child restraints .

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
671-4. SRS Air Bags
1
Essential Safety Equipment
If your vehicle is also equipped with a front passenger occupant clas-
sification system, refer to the Front Passenger Occupant Classi fica-
tion System ( P. 82) for details.
If your vehicle is equipped with a
front passenger occupant classifi-
cation system, the front passen-
ger air bag deactivation indicator
light illuminates for a specified
time after the ignition is switched
ON.
Small children must be protected by a child-restraint system as stipu-
lated by law in every state and province. In certain states and prov-
inces, larger children must use a child-restraint system (P. 4 4 ) .
Carefully consider which child-re straint system is necessary for your
child and follow the installation directions in this Owner’s Manual as
well as the child-restraint syste m manufacturer’s instructions.
●If it becomes necessary to have the components or wiring system for the
supplementary restraint system modified to accommodate a person with
certain medical conditions in accordance with a certified physi cian, contact
your Toyota dealer.
● When an air bag deploys, a loud inflation noise can be heard an d some
smoke will be released. Neither is likely to cause injury, however, the texture
of the air bags may cause light skin injuries on body parts not covered with
clothing through friction.
● Should you sell your Toyota, we urge you to tell the new owner of its air bag
systems and that familiarization with all instructions about th em, from the
Owner’s Manual, is important.
● This highly-visible label is displayed
which warns against the use of a rear-
facing child-restraint system on the front
passenger seat.

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
771-4. SRS Air Bags
1
Essential Safety Equipment
◆Warning Light/Beep
A system malfunction or operation conditions are indicated by a
warning.
Refer to Warning/Indi cator Lights on P. 173.
Refer to Warning Sound i s Activated on P. 502.

82
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-4. SRS Air Bags
Front Passenger Occupant Classification
System
Your vehicle is equipped with a f ront passenger occupant classifica-
tion sensor as a part of the supplemental restraint system. Thi s sen-
sor is equipped in the front pas senger’s seat cushion. This sensor
measures the electrostatic capacity of the front passenger’s se at. The
SAS unit is designed to prevent the front passenger front and side air
bags and seat belt pretensioner system from deploying if the front
passenger air bag deactivation indicator light turns on.
To reduce the chance of injuries caused by deployment of the front
passenger air bag, the system deactivates the front passenger f ront
and side air bags and also the seat belt pretensioner system wh en the
front passenger air bag deactivat ion indicator light turns on. Refer to
the following table for the front passenger air bag deactivatio n indica-
tor light illumination conditions.
This system shuts off the front p assenger front and side air bags and
seat belt pretensioner system, s o make sure the front passenger air
bag deactivation indicator light turns on according to the foll owing
table.
The air bag/front seat belt pretensioner system warning light f lashes
and the front passenger air bag deactivation indicator light il luminates
if the sensors have a possible ma lfunction. If this happens, the front
passenger front and side air bags and seat belt pretensioner sy stem
will not deploy.
First, please read “Supplemental Restraint System (SRS) Pre-
cautions” ( P. 66) carefully.
Front Passenger Occupant Classification Sensor

YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
831-4. SRS Air Bags
1
Essential Safety Equipment
■Front passenger air bag deactivation indicator light
This indicator light turns on to
remind you that the front pas-
senger front and side air bags
and seat belt pretensioner will
not deploy duri ng a collision.
If the front passenger occupant cl assification sensor is normal, the
indicator light turns on when the ignition is switched ON. The light
turns off after a few seconds. Then, the indicator light turns on or is
off under the following conditions:
■Front passenger air bag deactivat ion indicator light on/off con-
dition chart
*1: The occupant classification sensor may not detect a child seat ed on the
seat, in a child-restraint system, or a junior seat depending o n the child’s
physical size and seated posture.
*2: If a smaller adult sits on the front passenger seat, the senso rs might detect
the person as being a child depending on the person’s physique.
The curtain air bag is ready for inflating regardless of what t he front
passenger air bag deactivation in dicator light on/off condition chart
indicates.
Condition detected
by the front passen-
ger occupant classi-
fication systemFront passen-ger air bag
deactivation
indicator lightFront passen- ger front and
side air bagsFront passen- ger seat belt
pretensioner
system
Empty (Not occu-
pied)OnDeactivatedDeactivated
A child less than 1
year old is seated in
a child-restraint sys-
tem
OnDeactivatedDeactivated
Child*1On or offDeactivated or readyDeactivated or ready
Adult*2OffReadyReady

84
YARIS_YARIS HATCHBACK_OM_OM99V59z_(U)
1-4. SRS Air Bags
If the front passenger air bag deactivation indicator light does not
turn on when the ignition is swi tched ON and does not turn on a s
indicated in the front passenger air bag deactivation indicator light
on/off condition chart, do not allow an occupant to sit in the front
passenger seat and consult your Toyota dealer as soon as possi-
ble. The system may not wor k properly in an accident.
●The system requires about 10 seconds to alternate between turning the
front passenger front and side air bags and seat belt pretensio ner system on
or off.
● The front passenger air bag deactivation indicator light may tu rn on repeat-
edly if luggage or other items are put on the front passenger s eat, or if the
temperature of the vehicle’s interior changes suddenly.
● The front passenger air bag deactivation indicator light may tu rn on for 10
seconds if the electrostatic capacity on the front passenger se at changes.
● The air bag/front seat belt pretensioner system warning light might turn on if
the front passenger seat receives a severe impact.
● If the front passenger air bag deactivation indicator light doe s not turn on
after installing a child-restraint system on the front passenge r seat, first, re-
install your child-restraint system according to the procedure in this owner’s
manual. Then, if the front passenger air bag deactivation indic ator light still
does not turn on, install the child-restraint system on the rea r seat and con-
sult your Toyota dealer as soon as possible.
● If the front passenger air bag deactivation indicator light tur ns on when an
occupant is seated directly in the front passenger seat, have the passenger
re-adjust their posture by sitting with their feet on the floor , and then re-fas-
tening the seat belt. If the front passenger air bag deactivati on indicator light
remains turned on, move the passenger to the rear seat. If sitt ing in the rear
seat is not possible, slide the front passenger seat as far bac k as possible.
Consult your Toyota dealer as soon as possible.
