TOYOTA YARIS iA 2018 Accessories, Audio & Navigation (in English)

22Yaris iA_Navi_OM99Q50z_(U)
2D or 3D view
, , When this button is selected, the map view mode
can be changed.
• : The map is displayed so that north is up
regardless of the direction of travel.
• : The map is rotated so that the directi on of
t ravel is displayed in the upward direction.
• : Displays things such as actual constructio n
si tes three dimensionally on the map.
Zoom-in/
zoom-out mode You can zoom-in/zoom-out of maps.
Rotate mode Rotates maps.
Perspective
angle mode You can change the angle of perspective on a map.
ActionButton(s)Description

23
1
2
3
4
5
6
Yaris iA_Navi_OM99Q50z_(U)
2.4.5 Checking the details of th
e current position (Where Am I?)
This screen contains information about the current position (or about the last known
position if GPS receptio n is not available).
You can access this screen from the map in one of the following ways:
1. Select after selectin g on the MAP screen.
2. Select the Where Am I? screen.

24Yaris iA_Navi_OM99Q50z_(U)
2.5 Voice Recognition
Some items can be operated by voice using the vehicle’s microphone.1. Press the talk button on the steering switch.
2. After “Say a command” is output from the speaker and the beep sound is
h eard, say your commands.
Set a new destination, “Gas station” (on navigation
screen). 1) Press the talk button on the steering switch.
2) After “Say a command” is output from the speaker and the beep sound is
heard, say, “New Destination”.
3) After “Which type of destination would you like?” is output from th e speaker
and the beep sound is heard, say, “Gas station”.
4) After “Gas station, say the desired line number. You can also say: Try again”
is output from the speaker and the b eep sound is heard, say, “Number one”
(Desti nation is gas station on the first row).
5) After “To begin navigation, say start” is output from the speaker and the b eep
so und is heard, say, “Start” to start route guidance.
2.5.1 Voice command list
If you have seven or more candidates, say the command, “Page down” to move the
list.
Function operationVoice command
Switches to the screen where
new destinations can be selected. New Destination
Displays the route to your home. Take me home
Specifies the de stination using
the address. Navigate to an address
Displays the history of the
recently specified destinations. Navigate to a recent destination
Displays the current location. Where am I?
Reads out the previous guidance
again. Repeat instruction
Adds a route using keywords. Add way Point ~
Zooms in/out of the map screen. Zoom in/Zoom out
Adds the route using the address. Add way point address/Travel via address

25
1
2
3
4
5
6
Yaris iA_Navi_OM99Q50z_(U)
Memo

26Yaris iA_Navi_OM99Q50z_(U)
3 On-road navigation
You can set up your route in different ways:
If you need a route for immediate navigation, you can select the destination and start
navigating to it right away (normal navigation).
You can plan routes with multiple destinations. Select the first destination. Then
select a second destination and add it to your route to create a mu lti-point route. You
can add as many destinations to your route as you like.
3.1 Selecting the destination of a route
The navigation system offers you seve ral ways of choosing your destination:
• Enter a full address or a part of an address (page 27).
• Select a POI (point of interest) from a database as your destination (page 40).
• Searches the destination from the map (page 56).
• Use a previously saved Favorite destination (page 58).
• Select a location from the History of previously used destinations (page 60).
• Enter the coordinate of the destination (page 62).
There are other convenient functions.

27
1
2
3
4
5
6
Yaris iA_Navi_OM99Q50z_(U)
3.1.1 Entering an address or a part of the address
If you know at least a part of the addres
s, it is the quickest way to select the
destination of the route.
Using the same screen, you can find an address by entering:
• Destination address
• The center of a city
• An intersection
• The midpoint of a street
3.1.1.1 Entering an address
To enter an address as the destination, do as follows:
1. Select
after selectin g on the MAP screen.
2. Select .
3. By default, the navigation system pr oposes the country and city where you
are. If needed, select , enter the first few letters of the country name
on the keyboard, and select one country from the list of results.
If an address or part of a facility name is input, a search candidate list including the
input characters is displayed. The greater the number of characters input the more
the list is refined.

28Yaris iA_Navi_OM99Q50z_(U)
4. If needed, select a new city:
a.Select .
b . Start entering the name of the city on the keyboard.
c. Find the city you need: • The most likely city na me is always shown in the input field. To accept
it, select .
• If the desired name does not show up, the names that match the stri ng
appear in a list after entering a couple of characters (to open the li st of
resu lts before it appears automatically , select ). Select the city from
th e list.

29
1
2
3
4
5
6
Yaris iA_Navi_OM99Q50z_(U)
5. Enter the street name:
a. Select .
b. Start entering the street name on the keyboard.
c. Find the street you need: • The most likely street name is always shown in the input field. To accep t
it, select .
• If the desired name does not show up, the names that match the stri ng
appear in a list after entering a coup le of characters (to open the list of
resu lts before it appears automatically , select ). Select the street from
th e list.

30Yaris iA_Navi_OM99Q50z_(U)
6. Enter the house number:
a.Select .
b . Enter the house number on the keyboard. (To enter le tters, select.)
c. Select to finish entering the ad dress. (If the entered house number
can not be found, the midpoint of the street is selected as the destination.)
7. The selected location is shown on the map. The system transitions to the next screen by selectin g
, or it
returns to the previous screen by selectin g the button. By touching the
location displayed on the screen, you can change the destination to anyw here
on the map.
• : You can search for POI (point of interest)
around the selected location.
• : The selected location can be registered to Favorites.

31
1
2
3
4
5
6
Yaris iA_Navi_OM99Q50z_(U)
8. Navigation starts if is selected
, or after 10 seconds of no user
i nteraction.
By touching the location displayed on the screen, you can verify the rout e.
A dditionally, the route can be revised by selecting other options.
