TOYOTA YARIS iA 2018 Owners Manual (in English)

YARIS iA_OM_OM99Q46z_(U)
2614-2. Audio System
4
Interior Features
●ALC (Automatic volume adjustment)
The automatic level control (ALC) changes the audio volume auto-
matically according to the vehicle speed. The faster the vehicle
speed, the higher the volume increases. ALC has ALC OFF and
ALC LEVEL 1 to 7 modes. At ALC LEVEL 7, the amount that the
volume can increase is at the ma ximum. Select the mode according
to the driving conditions.
● BEEP (Audio operation sound)
The setting for the operation sound when pressing and holding a
button can be changed. The initial setting is ON. Set to OFF to
mute the operation sound.
● BT SETUP mode (if equipped)
Music and other audio such as voice data recorded on portable
audio devices and mobile phones available on the market which
are equipped with the Bluetooth
® transmission function can be lis-
tened to via wireless transmissi on over the vehicle’s speakers.
Using the BT SETUP mode, these devices can be programmed to
the Bluetooth
® unit or changed ( →P. 322).
● 12Hr< >24Hr (12 Hr/24 Hr time adjustment)
Rotating the audio control dial switches the display between 12 and
24-hour clock time ( →P. 262).
If not operated for several seconds, the display returns to the previous dis-
play. To reset bass, treble, fade, and balance, press the menu button ( )
for 2 seconds. The unit will beep and “CLEAR” will be displayed.

262
YARIS iA_OM_OM99Q46z_(U)
4-2. Audio System
■Setting the time
The clock can be set at any time when the ignition is switched to
ACC or ON.
To adjust the time, press the clock button ( ) for about 2
seconds until a beep is heard.
The clock’s current time will flash.
Time adjustment• To adjust the time, press the hour/minute set button ( , ) while the clock’s curr ent time is flashing.
• The hours advance while the hour set button ( ) is pressed. The minutes advance while the minute set button
( ) is pressed.
Press the clock button ( ) again to start the clock.
Clock
:00 button
Audio display
Menu button Audio control dial
Clock button
Hour/Minute set switch1
2
3
4
5
6
1
2
3

YARIS iA_OM_OM99Q46z_(U)
2634-2. Audio System
4
Interior Features
■Time resettingPress the clock button ( ) fo r about 2 seconds until a beep
is heard.
Press the :00 button (1).
When the button is pressed, the ti me will be reset as follows:
(Example) 12:01 - 12:29 →12:00
12:30 - 12:59 →1:00
●When the :00 button (1) is pressed, the seconds will start at “00”\
.
● Switching between 12 and 24-hour clock time:
Press the menu button ( ) several times until 12 and 24-hour clock time
are displayed. Turn the audio control dial in either direction, select the
desired clock setting while the preferred clock time is flashing.
■
Radio ON
Press a band selector button ( ) to turn the radio on.
■Band selection
Successively pressing the band selector button ( ) switches
the bands as follows: FM1 →FM2 →AM.
The selected mode will be indicated.
Operating the Radio
1
2
3
Audio display
Channel preset buttons
Auto memory button Scan button
Band selector button
Tuning button1
2
3
4
5
6

264
YARIS iA_OM_OM99Q46z_(U)
4-2. Audio System
■Tuning
The radio has the following tuning methods: Manual, Seek, Scan,
Preset channel, and Auto memory tuning. The easiest way to tune
stations is to set them on preset channels.
● Manual tuning
Select the station by pressing the tuning button ( , )
lightly.
● Seek tuning
Automatic search for radio stations starts when the tuning button
( , ) is pressed until a beep sound is heard. The
search stops when a station is found.
If you continue to press and hold the button, the frequency will con-
tinue changing without stopping.
●Scan tuning
Press and hold the scan button ( ) to automatically sample
strong stations. Scanning stops at each station for about 5 sec-
onds. To hold a station, press and hold the scan button ( )
again during this interval.
● Preset channel tuning
The 6 preset channels can be used to store 6 AM and 12 FM sta-
tions.
To set a channel first select AM, FM1, or FM2. Tune to the
desired station.
Press a channel preset button for about 2 seconds until a beep
is heard. The preset channel number or station frequency will
be displayed. The station is now held in the memory.
Repeat this operation for the other stations and bands you
want to store. To tune one in the memory, select AM, FM1, or
FM2 and then press its channel pr eset button. The station fre-
quency or the channel number will be displayed.
1
2
3

YARIS iA_OM_OM99Q46z_(U)
2654-2. Audio System
4
Interior Features
●Auto memory tuning
This is especially useful when driving in an area where the local
stations are not known.
Press and hold the auto memory button ( ) for about 2 sec-
onds until a beep is heard; t he system will automatically scan
and temporarily store up to 6 stations with the strongest frequen-
cies in each selected band in that area.
After scanning is completed, the station with the strongest fre-
quency will be tuned and its fr equency displayed. Press and
release the auto memory button ( ) to recall stations from
the auto-stored stations. One stor ed station will be selected each
time and its frequency and ch annel number will be displayed.
If no stations can be tuned after scanning operations, “A” will be dis-
played.
If the FM broadcast signal becomes weak, reception automatically changes
from STEREO to MONO for reduced noise.

266
YARIS iA_OM_OM99Q46z_(U)
4-2. Audio System
Operating the Compact Disc (CD) Player (if equipped)
Repeat button
Random button
Text button
Audio display
Play/Pause button
Folder up buttonFolder down button
CD eject button
CD slot
Media/Scan button
Track up/Fast-forward button
Track down/Reverse button1
2
3
4
5
6
7
8
9
10
11
12
Ty pePlayable data
Music/MP3/WMA/AAC CD player• Music data (CD-DA)
• MP3/WMA/AAC file

YARIS iA_OM_OM99Q46z_(U)
2674-2. Audio System
4
Interior Features
■Inserting the CD
Insert the CD into the slot, label-side up. The auto-loading mecha-
nism will set the CD and begin play.
There will be a short lapse before play begins while the player reads the
digital signals on the CD.
■
Ejecting the CD
Press the CD eject button ( ) to eject the CD.
■Playback
Press the media button ( ) to switch to CD mode and start
playback.
The CD mode cannot be selected if a CD has not been inserted.
■
Pause
To stop playback, press the Play/Pause button (4).
Press the button again to resume playback.
■Fast-forward/Reverse
Press and hold the fast-forward button ( ) to advance through
a track at high speed. Press and hold the reverse button ( ) to
reverse through a track at high speed.
■Track search
Press the track up button ( ) once to skip forward to the
beginning of the next track. Press the track down button ( )
within a few seconds after playback begins to track down to the
beginning of the previous track.
Press the track down button ( ) after a few seconds have
elapsed to start playback from the beginning of the current track.
■Folder search (during MP3/WMA/AAC CD playback)
To change to the previous folder, press the folder down button
( ), or press the folder up button ( ) to advance to the
next folder.

268
YARIS iA_OM_OM99Q46z_(U)
4-2. Audio System
■Music scan
●During music CD playback
This function scans the titles on a CD and plays 10 seconds of
each song to aid you in finding a song you want to listen to.
Press and hold the scan button ( ) during playback to start
the scan play operation (the trac k number will flash). Press and
hold the scan button ( ) again to cancel scan playback.
● During MP3/WMA/AAC CD playback
This function scans the titles in a folder currently being played
and plays 10 seconds of each s ong to aid you in finding a song
you want to listen to. Press and hold the scan button ( )
during playback to star t the scan play operation (the track num-
ber will flash).
Press and hold the scan button ( ) again to cancel scan
playback.

YARIS iA_OM_OM99Q46z_(U)
2694-2. Audio System
4
Interior Features
■Repeat playback
●During music CD playback
Press the repeat button (1) during playback to play the current
track repeatedly. “TRACK RPT” is displayed ( is dis-
played next to RPT at the bottom of the display area).
Press the button again to cancel the repeat playback.
● During MP3/WMA/AAC CD playback
Track repeat
Press the repeat button (1) during playback to play the current
track repeatedly. “TRACK RPT” is displayed ( is dis-
played next to RPT at the bottom of the display area).
To cancel the repeat playback, press the button again after 3
seconds.
Folder repeat
Press the repeat button (1) du ring playback, and then press
the button again within 3 seconds to play the tracks in the cur-
rent folder repeatedly. “FOLDER RPT” is displayed ( is
displayed next to RPT at the bottom of the display area).
Press the button again to cancel the repeat playback.
■Random playback
Tracks are randomly selected and played.
●During music CD playback
Press the random button (2) during playback to play the tracks
on the CD randomly. “DISC RDM” is displayed ( is dis-
played next to RDM at the bottom of the display area).
Press the button again to c ancel the random playback.
1
2
1
2
1
2
1
2

270
YARIS iA_OM_OM99Q46z_(U)
4-2. Audio System
●During MP3/WMA/AAC CD playback
Folder random
Press the random button (2) during playback to play the tracks
in the folder randomly. “FOLDER RDM” is displayed ( is
displayed next to RDM at the bottom of the display area).
To cancel the random playback, press the button again after 3
seconds.
CD random
Press the random button (2) du ring playback, and then press
the button again within 3 seconds to play the tracks on the CD
randomly. “DISC RDM” is displayed ( is displayed next
to RDM at the bottom of the display area).
Press the button again to c ancel the random playback.
1
2
1
2
