key VAUXHALL VIVARO 2018 Service Manual

Driving and operating143Filling station9Danger
Follow the operating and safety
instructions of the filling station
when refilling AdBlue.
1. Switch off engine and remove key
from ignition switch.
2. Open left-hand door and pull fuel filler flap to open.
3. Unscrew protective capanticlockwise from the filler neck.
Caution
The AdBlue protective cap is the
blue lower cap (arrowed in
illustration), and the fuel filler cap
is the black upper cap 3 158.
In case of incorrect refilling, do not switch on ignition. Seek the
assistance of a workshop
immediately.
4. Fully insert the pump nozzle into the filler neck and switch it on.
5. When refilling is complete, mount the protective cap and turn
clockwise until it engages.
6. Close fuel filler flap and left-hand door.
AdBlue canister Notice
Only use the designated AdBlue
canisters for refilling, to prevent a
topping-up of too much AdBlue.
Additionally, the fumes in the tank
are captured in the canister and do
not emerge.
Notice
Since AdBlue has a limited
durability, check the date of expiry
before refilling.
1. Switch off engine and remove key
from ignition switch.
2. Open left-hand door and pull fuel filler flap to open.
3. Unscrew protective capanticlockwise from the filler neck.

158Driving and operatingFuel
Fuel for diesel engines Only use diesel fuel that complies
with EN 590. The fuel must have low
sulphur content (max. 10 ppm).
Equivalent standardised fuels with a
biodiesel (= FAME according to
EN14214) content of max. 7% by
volume (like DIN 51628 or equivalent
standards) may be used.
In countries outside the European
Union, use Euro-Diesel fuel with a
sulphur concentration below 50 ppm.Caution
Use of fuel that does not comply to EN 590 or similar can lead to
engine powerloss, increased wear
or engine damage and loss of
warranty.
Do not use marine diesel oils, heating
oils, Aquazole and similar diesel-
water emulsions. Diesel fuels must
not be diluted with fuels for petrol
engines.
The flow and filterability of diesel fuels are temperature-dependent. When
temperatures are low, refuel with
diesel fuel with guaranteed winter
properties.
Diesel fuel filter 3 171.
Diesel fuel system bleeding 3 171.
Low temperature operation
At temperatures below 0 °C, some
diesel products with biodiesel blends may clog, freeze or gel, which may
affect the fuel supply system. Starting
and engine operation may not work
properly. Make sure to fill winter
grade diesel fuel at ambient
temperatures below 0 °C.
Arctic grade diesel fuel can be used
in extreme cold temperatures below
-20 °C. Using this fuel grade in warm
or hot climates is not recommended
and may cause engine stalling, poor starting or damage on the fuel
injection system.Refuelling9 Danger
Before refuelling, switch off engine
and any external heaters with
combustion chambers.
Vehicles with stop-start system:
The engine must be switched off
and the ignition key removed, to avoid risk of engine being
restarted automatically by the
system.
Switch off any mobile phones.
Follow the operating and safety
instructions of the filling station
when refuelling.
9 Danger
Fuel is flammable and explosive.
No smoking. No naked flames or
sparks.
If you can smell fuel in your
vehicle, have the cause of this
remedied immediately by a
workshop.

Vehicle care171disconnecting the main vehicle
battery or before jump starting the vehicle.
The terminals are designed for
additional electrical consumers up to
a maximum of 50 A.
Jump starting 3 195.
Diesel fuel filter The diesel fuel filter is accessible from the underside of the vehicle.
Drain filter of residual water at every
engine oil change.
Place a container underneath the
filter housing. Loosen the knurled
screw on the lower part of the filter by approx. one turn, to drain off the
water.
The filter is drained as soon as water-
free diesel fuel emerges. Retighten
the screw.
Check diesel fuel filter at shorter
intervals if the vehicle is subjected to
extreme operating conditions.
Diesel fuel system bleeding
If the fuel tank has been run dry, it will be necessary to air vent or bleed the
diesel fuel system.
Refuel then proceed as follows:With ignition key
● Switch on the ignition (key to position 2) for five seconds at a
time.
● Switch off ignition (key to position
1 ) for three seconds.
● Repeat this process multiple times.
● Start the engine (key to position 3) then switch off (key to position
0 ).
Ignition switch positions 3 130.

172Vehicle careWith power button
● Insert the electronic key in thecard reader.
● Press START/STOP without
pressing any of the pedals.
● Wait a few minutes before starting engine.
Power button 3 130.
If the engine fails to start, seek the
assistance of a workshop.
Starting the engine 3 132.
Wiper blade replacement
Wiper blades on the windscreen
Before replacing the wiper blades,
move the wiper lever to the
maintenance position (if equipped).
Windscreen wiper/washer 3 84.
Lift the wiper arm, press button to
disengage the wiper blade and
remove.
Attach new wiper blade slightly
angled to the wiper arm and push until
it engages.
Lower wiper arm carefully.
Wiper blade on the rear window
Lift wiper arm, press retaining lugs
together to disengage the wiper blade
and raise to remove.
Lower wiper arm carefully.
When attaching new wiper blade,
ensure it is engaged securely.

182Vehicle careNo.Circuit1Battery backup (with electronic
key system)2Adaptations3Adaptations4Vehicle battery (with electronic
key system)5Additional heating and ventila‐
tion / Air conditioning system6Supplementary heating and
ventilation system7Electric exterior mirrors / Addi‐
tional adaptations8Heated exterior mirrors9Radio / Multimedia / Electric
exterior mirrors / Diagnostic
socket10Multimedia / Trailer hitch11Courtesy lights / Battery
discharge protectionNo.Circuit12Right-hand high beam / Left-
hand low beam / Sidelights /
Right-hand daytime running
light13Hazard warning flashers / Turn
and lane-change signals14Central locking15Left-hand high beam / Right-
hand low beam / Tail lights /
Left-hand daytime running light16Front fog lights / Rear fog lights /
Number plate lighting17Alarm / Horn / Lighting / Wiper18Instrument cluster19Heating and ventilation system20Rear window wiper / Wind‐
screen washer pump / Horn21General battery22Reversing lights23Brake switchNo.Circuit24Fuel injection / Starter25Airbag / Steering column lock26Passenger power window27Power steering28Brake lights29Battery backup (with electronic
key system)30Service display31Cigarette lighter / Power outlet32Heating and ventilation system33Brake lights / ABS / Immobiliser34Interior lighting / Air conditioning35Starting with electronic key
system36Rear window wiper37Warning chimes38Load compartment power outlet39Driver power window

Vehicle care183No.Circuit40Rear power outlet41Starting / Body control module42Heated seats43Tachograph44Windscreen wiper45Heating / Air conditioning
After having changed defective fuses,
replace the trim panel.
Vehicle tools
Tools
The jack, wheel wrench, wheel bolt
sleeve, torx key, adapters, wheel
cover hook, towing eye are contained
in a unit, stowed under the driver's
seat.
Slide seat forwards and fold the
backrest forwards 3 46 to access the
tool box. The tool box may be secured
in position with a wing nut. Rotate
wing nut anticlockwise to release.
Wheel changing 3 192.
Spare wheel 3 193.
Vehicles with tyre repair kit: The wheel cover hook and torx key are
stored within the tyre repair kit case,
stowed under the driver's seat.
Tyre repair kit 3 189.

218Customer informationCustomer
informationCustomer information ................218
Declaration of conformity .........218
REACH .................................... 222
Collision damage repair ...........222
Registered trademarks ............222
Vehicle data recording and pri‐
vacy ........................................... 222
Event data recorders ...............222
Radio Frequency Identification (RFID) ..................................... 223Customer information
Declaration of conformity
Radio transmission systems
This vehicle has systems that
transmit and / or receive radio waves
subject to Directive 1999/5/EC or 2014/53/EU. The manufacturers ofthe systems listed below declare
conformity with Directive 1999/5/EC
or 2014/53/EU . The full text of the EU
declaration of conformity for each
system is available at the following
internet address: www.opel.com/
conformity
Importer is
Opel / Vauxhall, Bahnhofsplatz,
65423 Ruesselsheim am Main,
Germany.
Electronic key transmitter
Continental Automotive
1 Rue de Clairefontaine, 78120
Rambouillet, France
Operation frequency: 433 MHz
Maximum output: 10 mW ERPImmobiliser
Visteon Electronics
04 Rue Nelson Mandela, Zone
Industrielle Borj Cedria, 2055 Bir El
Bey, Tunisia
Operation frequency: 125 kHz
Maximum output:
42 dBµA/m @ 10 m
Immobiliser
Continental Automotive
1 Rue de Clairefontaine, 78120
Rambouillet, France
Operation frequency: 125 kHz
Maximum output:
42 dBµA/m @ 10 m
IntelliLink Touch
Continental Automotive
1 Rue de Clairefontaine, 78120
Rambouillet, France
Operation frequency: N/A
Maximum output: N/A
NAVI 50 IntelliLink / NAVI 80
IntelliLink
LGE

225Charging system .......................... 96
Child locks ................................... 30
Child restraint installation locations ................................... 66
Child restraints.............................. 63
Child restraint systems ................63
Cigarette lighter ........................... 88
Cleaning the vehicle ...................198
Climate control ............................. 15
Climate control systems .............114
Clock ............................................ 86
Coat hooks ................................... 73
Coin holder ................................... 71
Collision damage repair ..............222
Control indicators.......................... 92
Control of the vehicle .................129
Controls ........................................ 83
Controls in steering wheel ............83
Convex shape .............................. 39
Coolant ....................................... 167
Coolant and antifreeze ...............202
Coolant heater ............................ 120
Cooling (A/C) .............................. 115
Cornering light ............................ 108
Cruise control ....................100, 150
Cupholders .................................. 73
Curtain airbag system .................. 62D
Danger, Warnings and Cautions ...4
Dashboard .................................... 10
Daytime running lights ........107, 108
Declaration of conformity ............218
DEF ............................................ 139
Demisting and defrosting ..............15
Diesel exhaust fluid ....................139
Diesel fuel ................................... 158
Diesel fuel filter .......................... 171
Diesel fuel system bleeding .......171
Diesel particle filter ....................138
Directional tyres ..................184, 193
Distance to service .......................91
Document tray .............................. 73
Door locks..................................... 24
Door open .................................. 100
Door panel storage .......................74
Doors ............................................ 31
Double cab ................................... 74
DPF (diesel particle filter) ...........138
Driver assistance systems ..........150
Driver Information Centre ...........100
Driving characteristics and towing tips .............................. 160
Driving economically................... 128
Driving hints ........................ 128, 129
Driving style indicator ...................91E
ECO mode .................................. 128
ecoScoring.................................. 103
Electric adjustment ......................39
Electrical accessories ...................86
Electrical system......................... 179
Electronic climate control system 116
Electronic data recording ..............41
Electronic key system ...................22
Electronic Stability Program 97,
148, 161
Electronic Stability Program off ...97
End-of-life vehicle recovery .......164
Engine air filter............................ 166
Engine air flow indicator .............166
Engine coolant ........................... 167
Engine coolant temperature ........97
Engine data ............................... 207
Engine Drag Torque Control ......148
Engine exhaust .......................... 138
Engine identification ...................205
Engine oil ...........165, 202, 206, 216
Engine oil additives ....................202
Engine oil level .......................... 102
Engine oil pressure ......................98
Engine oil viscosity grades .........202
Enhanced Traction function 147, 148
Entry lighting .............................. 112
Event data recorders ..................222
Exhaust gases ....................138, 196

227JJack ............................................ 183
Journey record............................ 103
Jump starting ............................. 195
K
Keys ............................................. 19
Keys, locks ................................... 19
L
Lashing eyes ............................... 77
Lashing straps .............................. 77
Laying up the vehicle ..........163, 169
LED spotlights ............................ 110
Light covers, misted.................... 110
Lighting ....................................... 106
Lighting features .........................112
Light switch ................................ 106
Load compartment ................33, 76
Load compartment cover .............77
Load compartment grille ...............79
Load compartment lighting .........112
Loading information .....................80
Load-through feature ....................74
Low fuel ....................................... 99
Luggage floor net .........................77
M
Malfunction indicator light ............96
Manual adjustment ......................39
Manual anti-dazzle ......................40Manual transmission .................. 145
Maximum speed limiter............... 153
Messages ................................... 101
Mirror adjustment ........................... 8
Mirrors .................................... 39, 40
Misted light covers .....................110
N New vehicle running-in ..............130
Number plate light .....................177
O
Object detection systems ...........153
Odometer ..................................... 89
Oil ............................................... 165
Oil, engine .................. 165, 202, 206
Oil pressure .................................. 98
Outside temperature ....................85
Overcab storage ..........................76
Overrun cut-off ........................... 134
P Parking ................................ 18, 137
Parking assist ............................ 153
Parking brake ............................ 146
Particulate filter ........................... 138
Pedals......................................... 129
Performing work ........................164
Phone controls.............................. 83
Phone holder ................................ 71
Pollen filter ................................. 126Power button........................ 17, 130
Power outlets ............................... 86
Power steering fluid ....................167
Power windows ............................ 42
Preheating ........................... 98, 132
Puncture ..................................... 192
R
Radio Frequency Identification (RFID) ..................................... 223
Radio remote control ...................20
REACH ....................................... 222
Reading lights ............................ 112
Rear air conditioning system .....119
Rear courtesy lights ....................110
Rear door manual lock .................24
Rear doors .............................. 24, 31
Rear fog light ............................... 99
Rear fog lights ....................106, 110
Rear heating system .................. 118
Rear parcel shelf .......................... 77
Rear seats ................................... 49
2nd row seats ............................ 49
3rd row seats............................. 49
Folding ...................................... 49
Installing .................................... 49
Rear seat access ......................49
Removing .................................. 49
Seat cushion adjustment ...........49
Rear seats lights .........................110

228Rear view camera ...................... 155
Rear windows .............................. 42
Rear window wiper/washer .......... 85
Recommended fluids and lubricants ........................ 202, 206
Refuelling ................................... 158 Registered trademarks ...............222
Remote control ............................. 20
Restraining lattice .........................79
Reversing light ........................... 176
Reversing lights .........................110
Ride control systems ..................147
Roof load ...................................... 80
Roof rack ..................................... 80
S Safety belts ................................... 53
Safety net .................................... 78
Seat adjustment ....................... 7, 46
Seat belt ........................................ 8
Seat belt reminder .......................95
Seat belts ..................................... 53
Seat folding .................................. 48
Seat heating ................................. 48
Seat position ................................ 45
Seats ............................................ 74
Selective catalytic reduction .......139
Service ............................... 127, 201
Service display ............................ 91
Service information ....................201Service vehicle soon .................... 96
Side airbag system ......................61
Sidelights .................................... 106
Side turn signal lights ................175
Sliding door .................................. 31
Sliding side door ........................... 31
Spare wheel ............................... 193
Spare wheel security tool ...........183
Speed limiter......................... 89, 153
Speedometer ............................... 89
Starting and operating ................130
Starting off ................................... 17
Starting the engine ...............17, 132
Steering ...................................... 129
Steering column controls ..............83
Steering wheel adjustment ......9, 83
Steering wheel controls ...............83
Stop engine .................................. 96
Stop-start system............ 17, 99, 134
Storage ......................................... 71
Storage box .................................. 74
Storage compartment ...................73
Storage compartments .................71
Sun visors .................................... 43
Symbols ......................................... 4
T
Tablet holder................................. 71
Tachograph ........................ 100, 105
Tachometer ................................. 90Tailgate......................................... 33
Tailgate emergency release .........33
Tail lights ................................... 174
Technical data ............................ 207
Temporary spare wheel ..............193
Three-point seat belt .................... 54
Toll road stickers .......................... 41
Tools .......................................... 183
Top-Tether .................................... 63
Torx key ...................................... 183
Touchscreen ............................... 100
Tow bar....................................... 160
Towing ................................ 160, 196
Towing another vehicle .............197
Towing a trailer ........................... 161
Towing eye ......................... 183, 196
Towing the vehicle .....................196
Traction Control system ............. 147
Trailer coupling ........................... 160
Trailer stability assist .................161
Trailer towing ............................. 161
Transmission ............................... 16
Tread depth ............................... 188
Trip computer ............................ 103
Trip odometer .............................. 89
Turbo engine warm-up ...............132
Turn and lane-change signals ...109
Turn signal ................................... 94
Tyre chains ................................ 189
Tyre changing ............................. 192
