VOLKSWAGEN PASSAT CC 2013 1.G Owners Manual

Turn signal lever and high beam switch

Fig. 72 Turn signal lever and high beam switch.

High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 73 Headlight switch next to the steering wheel. A: Vehicles with fog lights. B: Vehicles without fog lights.

WARNING
Daytime running lights are not bright enough to let you see ahead or be seen by others when
it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
x Even if automatic headlight control (AUTO) is switched on, the low-beam headlights may
still not come on by themselves in fog or heavy rain. You have to switch on the low-beam
headlights manually.
In cool or humid weather, the insides of the headlights, the taillights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the AUT O position ⇒ fig. 73), they work only when the headlights have been
automatically switched on. The static cornering lights do not come on when the headlight switch is in
the O position or when the fog lights themselves have been switched on
Automatic headlight control (AUTO)
Automatic headlight control is a convenience feature only and cannot always recognize all lighting and
driving situations.
If the light switch is in the !54/, position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.
If the rain sensor recognizes rain and switches
the windshield wipers on.
If the windshield wipers have not moved for
several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistants menu in the instrument cluster display
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
x If automatic headlight control (AUTO) is switched on, the low-beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

Daytime running lights (DRL)
Separate lamps are installed in the headlights or in the front bumper for the daytime running lights
(DRL).
When the daytime running lights are switched on, only these separate lamps come on ⇒ .
The daytime running lights are switched on whenever the ignition is switched on and the light switch is
in position / or !54/.The indicator light  or $2, may come on in the instrument cluster to indicate
that the feature is active
If the light switch is in position AUT O, a low-light sensor switches the low beams as well as the
instrument and switch lighting on and off automatically.
Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static
cornering lights. On some models the static cornering lights may be integrated in the headlights. At
speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically
when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. If you are using automatic headlight
control (headlight switch in the AUT O position) ⇒ fig. 73, they work only when the headlights have been
automatically switched on. The static cornering lights do not come on when the headlight switch is in
the O position or when the fog lights themselves have been switched on.
Automatic headlight control !54/
Automatic headlight control is a convenience feature only and cannot always recognize all lighting and
driving situations.
If the light switch is in the !54/, position, both vehicle lighting and instrument and switch lighting are
automatically switched on and off in the following situations ⇒ :

Automatic activation: Automatic deactivation:
If the low-light sensor registers darkness, for
example when driving through a tunnel.
If sufficient brightness is registered.
If the rain sensor recognizes rain and switches
the windshield wipers on.
If the windshield wipers have not moved for
several minutes.

Adaptive Front Lighting System (AFS)
The Adaptive Front Lighting System works only with the low beams switched on and only at speeds
above about 6 mph (10 km/h). The swivel-mounted lamps automatically improve road illumination
during cornering.
On vehicles equipped with the Adaptive Front Lighting System, the feature is switched on and off via
the Assistants menu in the instrument cluster display

WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
x If automatic headlight control (AUTO) is switched on, the low-beam headlights still may not
be switched on in fog or heavy rain. You have to switch on the low-beam headlights yourself.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
“Coming home” and “Leaving home” feature (orientation lighting)

The delay period can be adjusted and the function can be switched on and off in the Lights &
Vision menu
If the “Coming home” feature is switched on and the driver door is opened, no warning chime will
sound to alert you that the lights are still on.
Instrument panel lighting and headlight range adjustment

Fig. 74 To the left of the steering wheel: Thumbwheel to adjust instrument panel lighting 1.

WARNING
If dynamic headlight range adjustment does not work properly or at all, the headlights could
blind and distract other drivers. This can lead to a crash and serious personal injuries.
x Have headlight range adjustment checked immediately by an authorized Volkswagen
dealer or an authorized Volkswagen Service Facility.
Interior and reading lights

Sun protection

x Lift it out of the retaining clip ⇒ fig. 75 (1) and swivel it over toward the door.
Additional sun visor positions:
x On some vehicles, you can slide the sun visor towards the rear of the vehicle after swiveling it over
to the door.
Vanity mirror and lighting
A vanity mirror is behind a cover in the sun visor. A light (3) may come on when you slide the cover (2)
open.
The light goes out when you shut the cover or if you flip the sun visor up again.
The vanity mirror light and the interior light above the sun visor go out after several minutes. This
helps to prevent unnecessary drain on the vehicle battery.
Rear window sunshade

Fig. 77 In the center console: Button for the electrical sunshade on the rear window.
