Recalling settings for driver seat and outside mirrors
x Briefly press the appropriate memory button when the vehicle is not moving, the ignition is
switched off, and the driver door is open.
x OR: If the ignition is switched on and the driver door is closed, press and hold the appropriate
memory button until the stored position is reached.
x The passenger-side outside mirror automatically adjusts back from the position stored for backing
up when the vehicle moves forward at about 10 mph (15 km/h) or more or when the rotary knob is
rotated from R into a different position.
Assigning driver seat and outside mirror settings to a vehicle key
The memory function of all vehicle keys is disabled when the vehicle is first delivered from the factory.
To enable vehicle key memory function:
x Unlock the driver door.
x Press and hold a memory button until memory position is reached.
x Press and hold the unlock button 1 on the vehicle key and then press the desired memory button at
the same time within about 3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
x Press and hold the 3%4 button.
x Press and hold the unlock button 0 on the vehicle key and the desired memory button at the same
time within about 10 seconds. A chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
x Follow the instructions 85 to assign the driver seat and outside mirror settings to the vehicle key.
x Unlock the vehicle with the same vehicle key.
x Adjust driver seat and outside mirrors.
x Lock the vehicle with locking button 0in the vehicle key to store the settings.
Once the settings are stored, the driver seat and the outside mirrors move to the stored positions
whenever the vehicle is unlocked with the vehicle key open button 1 and the driver door is opened. If
2 people use the vehicle, each of them should always use the key in which his or her personal settings
have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop in certain situations, for instance, if a new
driver seat is installed.
Initializing clears all memories and assignments of the memory seat. After that, memory buttons can
be reprogrammed and assigned to a vehicle key.
x Open the driver door but do not enter the vehicle.
x Adjust the seats from the outside.
x Move the angle of the backrest forward as far as it will go.
x Release the backrest adjustment switch and press it again until you hear a chime sound.
Cancellation conditions when storing settings for the memory buttons
When one of the following conditions is met, the storing process will be cancelled:
x The vehicle battery is weak or dead.
x The 3%4 button is pressed again within about 10 seconds.
x The seat position is readjusted within about 10 seconds after pressing the 3%4 button.

Applicable only in the United States
Back massage feature

Safety belts

WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of
severe personal injury or death. Safety belts offer optimum protection only when they are
used properly.
x Properly worn safety belts are the single most effective means of reducing the risk of
serious injury and death in a collision or other accident. For this reason, always wear your
safety belt properly and make sure all passengers wear their safety belts properly as well
whenever the vehicle is moving.
x The driver must always make sure that every person in the vehicle is properly seated on a
seat of his or her own, properly fastens the safety belts belonging to that seat before the
vehicle starts to move, and keeps the belts properly fastened while riding in the vehicle. This
applies even when just driving around town. Therefore, always wear your safety belts and
make sure that everybody in your vehicle is properly restrained.
x Always secure children in the vehicle with a restraint system appropriate for their age,
weight and height 102.
x Always fasten safety belts correctly before driving off and make sure that all passengers
are properly restrained.
x Never attach the safety belt to the buckle of another seat. Attaching the safety belt to the
wrong buckle will reduce safety belt effectiveness and can cause serious personal injury.
x Never let any objects or liquids get into the safety belt latch and prevent it from working
properly.
x Never remove a safety belt while the vehicle is moving. Doing so will increase your risk of
being injured or killed.
x Never strap more than one person, including small children, into any single safety belt.
x Never let children or babies ride sitting on your lap, and never place a safety belt over a
child sitting on your lap.
x Never wear belts over rigid or breakable objects in or on your clothing, such as
eyeglasses, pens, keys, etc., as these may cause injury.
x Several layers of heavy clothing (such as a coat worn over top of a sports jacket) may
interfere with proper positioning of the safety belt and reduce the overall effectiveness of the
system.
x Never use comfort clips or devices that create slack in the shoulder belt. However, special
clips may be required for the correct use of some child restraint systems.
x Safety belts offer optimum protection only when the seat backrest is upright and belts are
correctly positioned on the body.

WARNING
Damage to safety belts reduces their overall effectiveness and increases the risk of serious
personal injury and death whenever the vehicle is being used.
x Never let safety belts become damaged by being caught in the door or seat hardware.
x Torn or frayed safety belts can tear, and damaged safety belt hardware can break in an
accident.
x Inspect belts regularly for damage. If webbing, bindings, buckles, or retractors are
damaged, have the belts replaced immediately with the correct replacement belts approved
by Volkswagen for your vehicle, model, and model year.
x Safety belts that were subject to stress in an accident and stretched must be replaced with
a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized
Volkswagen Service Facility.
x Replacement after a crash may be necessary even if a safety belt shows no visible
damage. Anchorages that have been loaded must also be inspected.
x Damaged safety belts must be replaced; they cannot be repaired.
x Never try to repair a damaged safety belt yourself. Never remove or modify the safety belts
in any way.
x Have safety belts, bindings, retractors and buckles replaced by an authorized Volkswagen
dealer or authorized Volkswagen Service Facility.
x Always keep the belts clean. Dirty belts may not work correctly and can impair the
function of the inertia reel.
Warning light

Fig. 46 Warning light in the instrument cluster.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
A warning chime also sounds.
The safety belt warning light ª comes on for 6 seconds when the ignition is switched on. A warning
chime also sounds for up to 6 seconds if the driver's safety belt is not buckled. The chime stops
sooner if the driver buckles his or her safety belt. The warning light and the chime go out when both
driver and front passenger have bucked their safety belts.
If the driver and front seat passenger do not both fasten their safety belts within about 24 seconds
after the chime stops and the vehicle is moving at a speed of more than about 15 mph (25 km/h), the
chime will again sound for about 6 seconds, then go off for about 24 seconds, then sound again for
about another 6 seconds. The same thing happens if one of the safety belts is fastened and then
unfastened while the vehicle is moving. The safety belt warning light ª also flashes. The warning
chime continues to sound at 24 second intervals for up to 2 minutes. No chime sounds at speeds of
less than about 5 mph (8 km/h).
If the ignition is switched on, the safety belt warning light ª stays on until the driver and front
passenger have both buckled their safety belts.
WARNING
Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of
severe personal injury or death. Safety belts offer optimum protection only when used
correctly.
Frontal collisions and laws of physics

Fig. 47 A vehicle with passengers not wearing safety belts approaches a wall.

Fig. 48 A vehicle with passengers not wearing safety belts hits a wall.

Fig. 50 Unbelted passengers in the rear seats are thrown forward on top of the belted driver.

If you cannot untwist the safety belt, wear it anyway. Make sure that the safety belt is twisted in a spot
where it does not come in direct contact with your body. Have the safety belt untwisted immediately by
an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Lockable safety belt
The retractors for the rear seat safety belts and the front passenger safety belt have a switchable
locking feature for child restraints in addition to the emergency locking feature. Whenever a child
restraint is installed with a safety belt, the safety belt must be locked so that the safety belt webbing
cannot unreel. The switchable locking feature lets you lock the belt so that a child restraint can be
properly installed and, for example, so that it can't tip to the side when the vehicle goes around a
corner
To see whether a safety belt is lockable, pull the safety belt all the way out of the safety belt retractor.
You should then hear a “clicking” sound as the belt winds back into the retractor reel. Test the
switchable locking feature by pulling on the belt. When the switchable locking feature is active, you
should no longer be able to pull the belt out of the retractor.
The locking feature must be deactivated when a vehicle occupant uses the safety belt.
WARNING
Improper use and care of safety belts increases the risk of severe personal injury or death.
x Regularly check safety belts and related parts for damage.
x Damaged safety belts must be replaced; they cannot be repaired.
x Always keep safety belts clean.
x Never catch, damage or chafe safety belt webbing on sharp edges.
x Always keep objects and liquids away from the belt buckle and buckle opening.
Fastening and unfastening safety belts

Fig. 52 Inserting the safety belt buckle tongue into the belt buckle.
