VOLKSWAGEN T-ROC 2021 Owner´s Manual

Always keep the vehicle key, key ring with batteries, spare batteries, button cells and other batteries
that are larger than 20 mm out of the reach of children.
Call for medical help immediately you suspect that someone has swallowed a battery.

NOTICE
The vehicle key can be damaged if the button cell is not changed properly.
Unsuitable batteries can damage the vehicle key. Replace discharged batteries only with new
batteries of the same voltage rating, size and specification.
Make sure the polarity is correct when inserting the battery.

Dispose of discharged batteries in accordance with environmental regulations.
Synchronising the vehicle key
If you cannot lock or unlock the vehicle with the vehicle key, synchronise the vehicle key or replace
the button cell ⇒ Replacing the button cell .
Fold out the key bit.
Remove the cap on the driver door handle ⇒ Opening and closing the driver door manually .
Stand beside the vehicle.
Press the button on the vehicle key.
Unlock the vehicle using the key bit.
Fit the cap ⇒ Opening and closing the driver door manually .
The synchronisation process is complete.
Troubleshooting
Vehicle cannot be locked or unlocked
The remote control is subject to interference caused by obstacles, adverse weather conditions or
other transmitters operating in the same frequency range in the vicinity of the vehicle, e.g. mobile
devices.
OR: the central locking switches off briefly to protect it from overloading.
Close the driver door.
OR: synchronise the vehicle key ⇒ Synchronising the vehicle key .
Indicator lamp does not flash
If the indicator lamp in the vehicle key does not flash when a button is pressed, the button cell in the
vehicle key must be changed ⇒ Replacing the button cell .

Keyless locking and starting system Keyless Access
Introduction
This chapter contains information on the followingsubjects:
⇒ Unlocking or locking the vehicle with  
⇒ Troubleshooting 
The Keyless Access locking and starting system enables the vehicle to be locked and unlocked
without active use of the key. For this purpose, a valid vehicle key must be within the vehicle's
range.
Unlocking or locking the vehicle with Keyless Access

Fig. 52 Keyless Access: operating ranges.

Fig. 53 In the door handle: sensors.
First read and observe the introductoryinformation and safety warnings⇒Introduction 
Unlocking and locking the vehicle
Touch the sensor ⇒ Fig. 53Ⓐ  on the inside of the driver or front passenger door handle.
Switch off the ignition.
Close driver or front passenger door.
Touch the sensor ⇒ Fig. 53Ⓑ  on the outside of the driver or front passenger door handle.

Vehicle unlocking is confirmed by all the turn signals flashing twice and locking by the turn signals
flashing once.
Locking and unlocking the boot lid
When the vehicle is locked, the boot lid will be unlocked automatically if you open it when a vehicle
key is located within the operating range of the boot lid ⇒ Fig. 52 .
The boot lid is locked automatically after it is closed.
If the vehicle is completely unlocked, the boot lid will not lock automatically when closed.
Temporarily deactivating Keyless Access
Keyless Access can be deactivated temporarily as described below so that the vehicle cannot be
unlocked and started due to misuse by unauthorised third parties.
Lock the vehicle with the button in the vehicle key.
In addition, touch the sensor on the outside of the door handle ⇒ Fig. 53Ⓑ  once within five
seconds. Do not reach into the door handle.
Keyless Access is temporarily deactivated.
Check deactivation by waiting for at least ten seconds and then pull the door handle again. It should
not be possible to open the door.
When the vehicle is next unlocked, it can be unlocked only using the vehicle key. The Keyless Access
locking and starting system is reactivated the next time the vehicle is unlocked.
Operating the convenience functions
All electric windows and the glass roof can be closed automatically.
Keep a finger on the sensor ⇒ Fig. 53Ⓑ  of the driver or front passenger door handle for a few
seconds until the windows and glass roof are closed.
The sensor functions can be set in the Vehicle settings menu in the Infotainment system
⇒ Infotainment system controls and displays .

The unlocking function is deactivated for a few seconds so that you can check that the vehicle has
been locked successfully.

If the message Keyless Access system faulty appears on the instrument cluster display, there may be
a malfunction in the Keyless Access system. Go to a qualified workshop.

If there is no vehicle key in the vehicle or if it is not detected, a message will be shown on the
instrument cluster display. This may occur if the vehicle key is subject to interference by another

radio signal or is covered by another item, e.g. an aluminium case ⇒ Starting and stopping the
engine .

If the vehicle has a DSG® dual clutch gearbox, it can be locked only if the selector lever is in
position P.

The entire vehicle will be unlocked if the sensor is touched twice, even if a single door has already
been unlocked.
Troubleshooting
First read and observe the introductoryinformation and safety warnings⇒Introduction 
Keyless Access does not work
The function of the sensors may be restricted if they become very dirty.
Clean the sensors.
All turn signals flash four times
The vehicle key used last is still in the vehicle.
Doors and central locking button
Introduction
This chapter contains information on the followingsubjects:
⇒ Indicator lamp in the driver door 
⇒ Automatic locking and unlocking 
⇒ Central locking button 
⇒ Opening and closing the driver door manually 
⇒ Manually closing the front passenger door and rear doors 
⇒ Childproof lock 
⇒ SAFELOCK 
⇒ Troubleshooting 
If the vehicle key or central locking fails, the doors can be locked manually and, in some cases, also
unlocked manually.
The central locking system enables you to centrally lock and unlock all the doors, the boot lid and
the tank flap of the vehicle.

The vehicle can be locked only if the ignition has been switched off or the driver has switched off the
engine before leaving the vehicle.
A symbol in the instrument cluster display ⇒ Displays  indicates if one or more doors are not closed
properly. Do not drive on! Open the appropriate door and then close it again.
This symbol is also visible when the ignition is switched off and will go out a few seconds after the
vehicle has been locked when all doors are closed.

WARNING
A door which is not closed properly could open suddenly while the vehicle is in motion. This could
lead to serious injuries.
Stop as soon as possible and close the door.
Make sure that the door is closed properly and that the lock has engaged. The closed door must be
flush with the surrounding body panels.
Doors should be opened or closed only when you are sure that nobody is in their path.

WARNING
Any door being held open by the door arrester could close unexpectedly in strong winds or if the
vehicle is on a slope. This could lead to injuries.
Always hold doors by the handle when opening and closing doors.

WARNING
The opening and closing paths of the doors and boot lid are potential danger areas where injury can
occur.
The doors and boot lid should therefore be opened or closed only when you are sure that nobody is
in their path.

WARNING
Careless locking of the doors can cause serious injuries.
If the vehicle is locked from the outside, the doors and electric windows cannot be opened from the
inside.
The central locking system locks all doors. Locking the vehicle from the inside can prevent the doors
from being opened unintentionally and unauthorised persons from entering the vehicle. However,
locked doors can delay assistance to passengers inside the vehicle in the event of an accident or
emergency.

Never leave children or people requiring assistance alone in the vehicle. All doors can be locked from
the inside using the central locking button. This may mean that people lock themselves in the
vehicle. People locked in the vehicle may be subjected to very high or very low temperatures.
Temperatures inside a locked vehicle may become extremely hot or cold, depending on the season.
This can cause serious injuries and illness or fatalities, especially in the case of small children.
Never leave anyone inside a locked vehicle. People in the vehicle could become trapped in an
emergency and will not be able to get themselves to safety.

NOTICE
When carrying out manual opening or closing, remove parts carefully and install them again
correctly in order to avoid damage to the vehicle.
Indicator lamp in the driver door
First read and observe the introductoryinformation and safety warnings⇒Introduction 
The central locking indicator lamp is located in the driver door ⇒ Vehicle overviews .
Vehicle is locked: a red LED flashes for approximately two seconds, firstly at short intervals and then
more slowly. The indicator lamp does not flash if the vehicle was locked with the central locking
button in the driver door ⇒ Central locking button .
Automatic locking and unlocking
First read and observe the introductoryinformation and safety warnings⇒Introduction 
Settings for central locking can be made in the Vehicle settings menu in the Infotainment system
⇒ Infotainment system controls and displays .
Automatic locking (Auto Lock)
The vehicle can lock itself automatically at speeds above approximately 15 km/h (9 mph). The
indicator lamp in the central locking button will light up yellow when the vehicle is locked.
Automatic unlocking (Auto Unlock)
If one of the following conditions applies, all doors and the boot lid will be automatically unlocked:
The vehicle is at a standstill and the vehicle key has been removed.
In vehicles with DSG® dual clutch gearbox: the selector lever is in position P and the ignition has
been switched off.
OR: the vehicle is stationary and the button has been pressed.
OR: the door release lever has been operated.
OR: in an accident where the airbags have been triggered ⇒ Troubleshooting .
Automatic unlocking provides access to the vehicle if assistance is required.

Depending on the settings made for central locking in the Infotainment system, it may be the case
that all of the doors and the boot lid are unlocked only when the button has been pressed twice.
Central locking button

Fig. 54 In the driver door: central locking button.

Fig. 55 In the driver door: release for the boot lid.
First read and observe the introductoryinformation and safety warnings⇒Introduction 
Key to ⇒ Fig. 54  and ⇒ Fig. 55 :
Unlock the vehicle.
Lock the vehicle.
Unlock the boot lid.
If the button in the driver door is pressed, only the boot lid opens. All doors remain locked.
The central locking button functions with the ignition switched on or off only when all doors are
closed.
If the vehicle has been locked from outside with the vehicle key, the central locking buttons do not
work.
Please note the following when using the central locking button to lock the vehicle from the inside:
The indicator lamp in the button lights up yellow when all doors are closed and locked.
The anti-theft alarm will not be activated ⇒ Anti-theft alarm .

The doors can be opened from the inside by pulling the door release handle. The indicator lamp in
the button goes out. The unopened doors and boot lid remain locked and cannot be opened from
the outside.
If the driver door is open, it will not be locked.
Opening and closing the driver door manually

Fig. 56 Driver door handle: concealed lock cylinder.

Fig. 57 Driver door handle: lever off cap.
First read and observe the introductoryinformation and safety warnings⇒Introduction 
All doors are normally locked in the case of manual locking. With manual unlocking, only the driver
door is unlocked. Observe information on the anti-theft alarm ⇒ Anti-theft alarm .
Pull on the door release lever until the cap is removed.
Position the key bit at the notch in the driver door handle from below.
Hold your index finger under the key bit.
Lever off the cap with the vehicle key in the direction of the arrow ⇒ Fig. 57 .
Insert the key bit into the lock cylinder and lock or unlock the vehicle.
Pull the door release lever and fit the cap again.

Keyless Access ⇒ Unlocking or locking the vehicle with Keyless Access  is not activated if the vehicle
was locked manually.
Things to note when unlocking manually
The alarm is triggered when the driver door is opened ⇒ Anti-theft alarm .
After unlocking, an emergency start must be carried out ⇒ Starting and stopping the engine .
Switch on the ignition to switch off the alarm.
The electronic immobiliser recognises a valid vehicle key.

The anti-theft alarm is not activated when the vehicle is locked manually using the key bit ⇒ Anti-
theft alarm .
Manually closing the front passenger door and rear doors

Fig. 58 In the front edge of the rear right-hand door: manually locking the vehicle with the vehicle
key.
First read and observe the introductoryinformation and safety warnings⇒Introduction 
The front passenger door and the rear doors can be locked manually. The anti-theft alarm is not
activated in this case ⇒ Anti-theft alarm .
Open the door.
Remove the rubber seal in the front edge of the door.
Insert the key bit into the slot and turn ⇒ Fig. 58 .
Reattach the rubber seal.
Check that the door is locked.
The vehicle should be checked by a qualified workshop as soon as possible.
A door that has been locked manually will be unlocked again if the vehicle is unlocked or the door in
question is opened from the inside.

The doors can be unlocked and opened from inside by pulling the door release handle.
Childproof lock

Fig. 59 Childproof lock: rear left door, rear right door.
First read and observe the introductoryinformation and safety warnings⇒Introduction 
Key to ⇒ Fig. 59 :
Childproof lock is switched off.
Childproof lock is switched on.
The childproof lock prevents the rear doors being opened from the inside.
When the childproof lock is activated, the door can only be opened from the outside.
Switching the childproof lock on and off
Unlock the vehicle and open the appropriate rear door.
Move the slot to the corresponding position.

WARNING
The door cannot be opened from the inside when the childproof lock is activated.
Never leave children or people requiring assistance alone in the vehicle when the doors are locked.
This may mean that these people lock themselves in the vehicle. They could become trapped in the
vehicle in an emergency and may not be able to get themselves to safety. People locked in the
vehicle may be subjected to very high or very low temperatures.
Temperatures inside a locked vehicle may become extremely hot or cold, depending on the season.
This can cause serious injuries and illness or fatalities, especially in the case of small children.
SAFELOCK
First read and observe the introductoryinformation and safety warnings⇒Introduction
