Function key: Effect
£ Station list: All available stations and channels can be browsed in sequence with the arrow
buttons.
£ Presets: Only stations and channels that are stored to station buttons can be browsed with the
arrow buttons.
Presets: Select the station buttons to be displayed
Press one of the functions buttons Presets x...xto display the desired group of station buttons in
the main menu RADIO.
= HD radio: HD radio is activated
Delete Presets: When Delete is pressed, all stations and channels stored to station buttons are deleted.
SIRIUS ID: Displays the Sirius ID
Sort stations: the station list shows all satellite stations as selected:
Station number : in the all categories view arranged according to channel number.
Category/Station name : in the category view arranged according to station name.
Category/Station no. : in the category view arranged according to channel number.
Station name : in the all categories view arranged according to station name.
Category filter: restrict selection of stations to certain categories.
If the check box in the = Category filter on function key is deactivated, all categories are
displayed and all stations can be selected.
.NOTICE
x When inserting and removing CDs and DVDs, always hold them at right angles to the front
of the unit. Inserting or removing them at an angle to the DVD drive may lead to scratching.
x Inserting a second CD or DVD while a CD or DVD is inserted or is being ejected can destroy
the DVD drive. Always wait until the data media is completely ejected.
.NOTICE
Any foreign objects attached to a data medium and non-round data media can damage the DVD
drive.
x Only clean 12-cm standard CDs or DVDs should be used!
– Do not attach stickers or other items to the data medium. Stickers may peel off and damage the
drive.
– Do not insert 8-cm single CDs or non-round CDs (shaped CDs) or DVDs.
– Do not insert DVD-Plus, Dual Discs and Flip Discs, as these are thicker than standard CDs.
.CDs can also be played in a DVD drive if they meet the requirements .
.Uneven road surfaces and strong vibrations may cause CDs and DVDs being played in the
DVD drive to jump.
.If the temperature inside a DVD drive is too high, loading and playback of CDs and DVDs is
disabled.
Data media and file requirements
Data media Conditions for playback
Audio files Video files
i Audio CDs (up to 80 min).
i Standard video DVD and DVD-
compatible DVD audio.
i CD-ROM-, CD-R-, CD-RW audio
data CD up to max. 700 MB
(Megabyte) in the data system ISO
9660 Level 1 and 2, Joliet or UDF
1.02, 1.5, 2.01, 2.5
i DVD+/-R/RW up to 4.7 GB and
dual layer DVDs up to 8.5 GB in the
Joliet file system (single-session
only); UDF.
Þ SDHC memory CARds up
to 32 GB. Þ SD- and MMC memory
CARds in the data system FAT12,
FAT16, FAT32 or VFAT up to
max. 2 GB (Gigabyte) and SDHC
memory CARds up to max. 32 GB.
– Digital audio specification
!.
– Bit rates from 160 kbit/s
(recommended) up to
320 kbit/s and 48 kHz
sampling frequency.
– Format: MPEG layers 1, 2,
and 3 (.MP3).
– Format: .Windows Media
Audio 8 and 9 (.wma, .asf).
– Format: MPEG layers 2
and 4 (.m4a, .m4b, .mp4,
.aac).
– Bit rates up to 2000 kbit/s.
– Maximum resolution
720 x 576 pixel.
– Format: MPEG layers 1 and -
2 (.mpg, .mpeg).
– Format: ISO-MPEG4; DivX 3,
4 and 5 Xvid (.avi).
– Format: ISO-MPEG4 H.264
(.mp4, .m4v, .mov).
– Format: Windows Media
Video 9 (.wmv, .asf).
– Playlists supported in formats M3U, PLS and WPL (not
supported by the media center (HDD)).
– Limit of 4 partitions.
– On DVD limit of 1000 files per medium and directory.
– On memory CARds limit of 4000 files and limit of 1000 files
per directory.
– Limit of 3000 files in the media center (HDD).
Requirements for using external data media via the MEDIA-IN multimedia jack .
Restrictions and notes
Windows Media Audio 9 Voice, Lossless and Professional as well as DRM-protected files are not
supported. Other data media with copy protection and multi-session CDs and DVDs can sometimes
not be played back or only with limitations.
Dirt, high temperatures and mechanical damage can render a data medium unusable. Please observe
data medium manufacturer information.
Quality differences between data media of different manufacturers can cause problems during
playback.
The data medium configuration or the devices or programs used for recording can cause individual
tracks or data medium to be unreadable. Information can be found on the Internet on the best ways to
create audio files, video files and data media (compression rate, ID3 tag etc.).
Due to the larger quantity of data, it takes longer to read a data medium containing compressed audio
files (such as MP3, WMA) than a “normal” audio CD. Complex directory structures can also the delay
the reading process. If possible, only use data media with readable audio and video files.
Play lists only define a certain playback sequence. Play lists do not save any files. Play lists cannot
be played if the files on the data medium are not saved in the location to which the play list is referring
(relative data path). Play lists cannot be copied to the media center (HDD).
.NOTICE
Do not use memory CARd adapters.
.No liability can be accepted for damaged or lost files on the data media.
