Opening the DVD film menu manually
The DVD film menu must be opened manually if the DVD film menu does not open automatically with
the unit's own menu control, or if the video DVD is already being played.
x In the video DVD menu, press the Menufunction key to open the unit's own menu control .
x If an introduction is playing, it can be skipped by pressing the Menufunction key in the unit's own
menu control ⇒ fig. 157 (B).
The DVD film menu is displayed (A).
DVD does not start!
Note that an inserted DVD cannot start automatically if the volume is set to “0” (display: +). A played
media source is always stopped (paused) in this case.
.The visual appearance of the DVD film menus and the menu options which it offers are the
responsibility of the DVD manufacturer.
.The language of a video DVD for voice output can be changed .
.The DVD manufacturer is responsible for the different ways in which individual films respond to
identical commands.
Video DVD menu: controlling playback and changing display settings

Fig. 158 Video DVD menu.
.

x Press the desired chapter to select it from the list.
Film playback continues from the beginning of the selected chapter.
Changing aspect ratio
The aspect ratio, in which a film is played, can be adapted to the aspect ratio of the screen.
x In the Video DVD menu, press the Extrasfunction key.
x In the pop-up window, press the function key with the set aspect ratio to switch through the
available aspect ratios one after the other.
For further information on possible aspect ratios .
DVD settings

Fig. 159 Menu: Video settings.
.

Introduction to navigation

Navigation data
All navigation data required for navigation is stored in the unit navigation data memory.
Street routing is subject to ongoing changes like, for example, new streets, street names or street
numbers. The route guidance may be inaccurate or incorrect if the navigation data is no longer up to
date. You should therefore have the unit navigation data memory updated by a Volkswagen
dealership on a regular basis. The updates are subject to a fee.
Possible errors in navigation
When the navigation system cannot receive any data from GPS satellites (dense canopy of trees,
tunnel, underground CAR park), navigation can still continue using the vehicle sensors.
In areas that are not or only incompletely digitized on the data medium (such as one-way streets and
street type not sufficiently captured), the navigation system also tries to enable route guidance.
Please remember that the navigation may sometimes not be so accurate as usual if the precise
vehicle position cannot be determined.
Navigation main menu

Fig. 160 Navigation main menu: Destination mode.

Fig. 161 Navigation main menu: Tour mode.
.

x Press the NAVInfotainment button twice in quick succession. After changing to the map display, the
main menu Navigation is displayed.
x Press the e function key to switch menu by menu from a navigation submenu to the Navigation
main menu.
x You can switch back and forth between the map view and the Navigation main menu by pressing
the NAVInfotainment button.
The Navigation main menu is displayed either in “normal” Destination mode or in Tour mode or as the
Waypoint navigation menu ⇒ fig. 201.
If Tour mode ⇒ fig. 161 is displayed .
If the Waypoint navigation menu is displayed .
Display of the last destination
In the upper third of the screen, the destination last used as route guidance is displayed.
x Briefly touch the display box to show the displayed destination in the detailed view.
x Press the New destinationfunction key followed by the + Addressfunction key to show the displayed
destination in the Address entry menu and edit it .
If no destination is displayed, this means no route guidance has been started or that the
destination memory has been deleted manually .
Function keys in the Navigation main menu

Function key: Effect
Options : Defines route options for calculating a route .
Position : opens the current position in the detailed view and displays the coordinates.
Store : stores the displayed position in the destination memory .
D: Stores the current position as a “Flagged destination” in the destination memory .
': Enter home address or show home address in the Navigation main menu .
New destination : opens the selection menu for entry of destination .
Memory: Opens a pop-up window for storing the current destination, loading stored destinations or
managing destinations .
Route: Opens options for route guidance .
Route list: Shows street names or street designations of the route section to be driven.
Remove area to avoid: Removes an entered route exclusion.
Avoid area: To enter a route exclusion.
Extras: opens a pop-up window.

Accept new stopover: for entering a stopover .
Tour mode: for switching to tour mode in order to drive to several destinations during route
guidance .
Offroad: for navigation in off-road areas (waypoint navigation) .
Start: Starts route guidance to the displayed destination .

Destination entry

Destination entry menu: defining destination selection

Fig. 162 Menu: Destination entry.
.

Address: selecting a destination address

Fig. 163 Selecting addresses.

Fig. 164 Country and town selected: Narrowing down the address.
.

area you have selected in a previous window, you will not be able to find the street at the street
selection stage.
Finishing destination input
x Press the Start route guidance function key to start route guidance to the entered destination .
x OR: Press the Store in directoryfunction key to store the destination in the destination memory .
Address entry menu

Fig. 165 Navigation main menu with destination.

Fig. 166 Address input menu with destination address.
.

In the Select a street menu, the towns where you can search for a street name are listed. The
town currently selected in the Address entry menu is displayed at the top of the list.
x Press a function key with a town name to search for a newly entered street in that town.
x OR: Press the In all citiesfunction key to search for a street name across the country.
Further function keys in the Address entry menu
Store 1):Store the displayed destination in the destination memory after assigning an entry name .
Points of interest: Select a point of interest .
Map 1):: Select the destination from the map view in the vicinity of the entered address .
Start 1):Starts route guidance to the displayed destination .
Search for points of interest using point of interest categories

Fig. 167 Selection for point of interest search.

Fig. 168 Special destination detailed view.
.
