VOLVO C70 CONVERTIBLE 2007 Owner´s Manual

2007 Volvo C70
2 0 0 7
VOLVO C70

VOLVO OWNER'S MANUAL C70
1

Welcome to the worldwide family of Volvo owners. We hope that you will e\
njoy many years of safe
driving in your Volvo, an automobile designed with your safety and comfo\
rt in mind. To help ensure
your satisfaction with this vehicle, we encourage you to familiarize you\
rself with the equipment
descriptions, operating instructions and maintenance requirements/recomm\
endations in this manual. We
also urge you and your passengers to wear seat belts at all times in thi\
s (or any other) automobile. And,
of course, please do not operate a vehicle if you may be affected by alc\
ohol, medication or any
impairment that could hinder your ability to drive.
Your Volvo is designed to meet all applicable safety and emission standa\
rds, as indicated by the
certification labels attached to the driver's door opening, and on the u\
nderside of the hood.
For further information please contact your retailer, or:
In the USA: Volvo Cars of North America, LLC
Customer Care Center
P.O. Box 914 Rockleigh, New Jersey 07647-0914
1-800-458-1552
www.volvocars.us
In Canada: Volvo Cars of Canada Corp.
National Customer Service
175 Gordon Baker Road
North York, Ontario M2H 2N7
file:///K|/delme/2007_C70/07c70_00.htm (1 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
1-800-663-8255
www.volvocanada.com
2006 © Volvo Car Corporation. All rights reserved.
2 Contents

00 Introduction
General information
6
Volvo and the environment
7
Important warnings
9

01 Safety
Occupant safety
12
Seat belts
14
Supplemental Restraint System
17
Front airbags
18
Occupant Weight Sensor
21
Side impact protection airbags
24
Door mounted inflatable curtains
25
Whiplash Protection System
26
Roll-over Protection System
28
Crash mode
29
Child safety
30
Child restraint systems
33
Infant seats
35
Convertible seats
37
Booster cushions
39
ISOFIX lower anchors
40

02 Instrument and controls
Instrument overview
44
Instrument panel
57
Symbols - instrument panel
50
Information display
53
Lighting panel
55
Left-side steering wheel lever
57
Trip computer
58
Right-side steering wheel lever
60
Cruise control
62
Right-side steering wheel keypad
64
Steering wheel adjustment,
Hazard warning flashers
65
Parking brake
66
12-volt sockets
67
Power windows
68
Mirrors
69
Personal settings
72
HomeLink® Universal
Transceiver (option)
74
file:///K|/delme/2007_C70/07c70_00.htm (2 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
3 Contents

03 Climate
General information
80
Air vents
81
Electronic Climate Control (ECC)
82
Air distribution
85

04 Interior
Front seats
88
Power retractable hard top
92
Interior lighting
98
Storage compartments
100

05 Locks and alarm
Remote control and key blade
108
Locking and unlocking
114
Glove compartment and trunk
115
Opening the trunk from the inside
116
Alarm
117
4 Contents

06 Starting and driving
General information
122
Fuel requirements
125
Ignition switch, Steering wheel
lock
128
Starting the vehicle
129
Manual transmission
131
Automatic transmission
132
Shiftlock override
135
Brake system
136
Stability system
138
Front/rear park assist
140
Towing
142
Jump starting
145
Towing a trailer
146
Detachable trailer hitch
148
Transporting loads
149

07 Wheel and tires
General information
152
Tire inflation
154
Tire designations
158
Glossary of tire terminology
160
Vehicle loading
161
Uniform tire quality gradings
163
Snow chains, snow tires, studded tires
164
Wheel nuts
165
Tire rotation
166
Temporary spare
167
Changing a wheel
168
Tire sealing system
170

08 Car care
Washing and cleaning the vehicle
178
Paint touch up
182
5 Contents
file:///K|/delme/2007_C70/07c70_00.htm (3 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70

09 Maintenance and servicing
Volvo maintenance
186
Maintaining your vehicle
187
Hood
189
Engine compartment
190
Engine oil
191
Fluids
193
Wiper blades
195
Battery
196
Bulbs
198
Replacing bulbs
199
Fuses
208

10 Audio
Audio functions
218
Radio functions
221
CD player/CD changer (option)
227
Audio menu
231

11 Specifications
Label information
234
Dimensions and weights
236
Fluids
238
Engine oil
239
Engine specifications
241
Electrical system
242
Volvo programs
244
6 Introduction
General information
Shiftlock (automatic transmission)
When your car is parked, the gear selector is locked in the Park (P) position. To release the selector from this position, turn the igniti\
on
key to position II (or start the engine), depress the brake pedal, pre\
ss the button on the front side of the gear selector and move the selector
from Park (P).
Keylock (automatic transmission)
When the ignition is switched off, the gear selector must be in the Park\
(P) position before the key can be removed from the ignition
switch.
Anti-lock Brake System (ABS)
The ABS system in your car performs a self-diagnostic test when the vehi\
cle first reaches the speed of approximately 12 mph (20 km/ h).
The brake pedal will pulsate several times and a sound may be audible fr\
om the ABS control module. This is normal.
Fuel filler door
Press the button on the light switch panel when the car is at a standsti\
ll to open the fuel filler door.
Fuel filler cap
After refueling, close the fuel filler cap by turning it clockwise until\
it clicks into place. If this cap is not closed tightly or if the engine is
running when the car is refueled, the Malfunction Indicator Lamp ("Chec\
k Engine" light) may indicate a fault.
Points to keep in mind
l Before you operate your vehicle for the first time, please familiarize y\
ourself with the new-engine oil consumption information on page
191. You should also be familiar with the information found in the chapters\
"Instruments and controls," and "Starting and driving."
l Information contained in the balance of the manual is extremely useful a\
nd should be read after operating the vehicle for the first time.
l The manual is structured so that it can be used for reference. For this \
reason, it should be kept in the vehicle for ready access.
l Do not export your Volvo to another country before investigating that co\
untry's applicable safety and emission control requirements. In
some cases it may be difficult or impossible to comply with these requir\
ements. Modifications to the emission control system(s) may
render your Volvo not certifiable for legal operation in the U.S., Canad\
a and other countries.
l All information, illustrations and specifications contained in this manu\
al are based on the latest product information available at the
file:///K|/delme/2007_C70/07c70_00.htm (4 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
time of publication. Please note that some vehicles may be equipped diff\
erently, depending on special legal requirements. Optional
equipment described in this manual may not be available in all markets. \
l Volvo reserves the right to make model changes at any time, or to change\
specifications or design without notice and without incurring
obligation.
WARNING
If your vehicle is involved in an accident, unseen damage may affect its\
drivability and
safety.
WARNING
CALIFORNIA proposition 65
Engine exhaust, some of its constituents, and certain vehicle components\
contain or emit chemicals known to the state of California to
cause cancer, and birth defects or other reproductive harm. In addition,\
certain fluids contained in vehicles and certain products of
component wear contain or emit chemicals known to the State of Californi\
a to cause cancer, and birth defects or other reproductive
harm.
7 Introduction
Volvo and the environment
Volvo is committed to the well being of its customers. As a natural part\
of this commitment, we care about the environment in which we
all live. Caring for the environment means an everyday involvement in re\
ducing our environmental impact. Volvo's environmental
activities are based on a holistic view, which means we consider the ove\
rall environmental impact of a product throughout its complete
life cycle. In this context, design, production, product use, and recycl\
ing are all important considerations. In production, Volvo has partly
or completely phased out several chemicals including CFCs, lead chromate\
s, asbestos, and cadmium; and reduced the number of
chemicals used in our plants 50% since 1991.
Volvo was the first in the world to introduce into production a three-wa\
y catalytic converter with a Lambda sond, now called the heated
oxygen sensor, in 1976. The current version of this highly efficient sys\
tem reduces emissions of harmful substances (CO, HC, NOx) from
the exhaust pipe by approximately 95-99% and the search to eliminate the\
remaining emissions continues. Volvo is the only automobile
manufacturer to offer CFC-free retrofit kits for the air conditioning sy\
stem of all models as far back as the 1975 model 240. Advanced
electronic engine controls and cleaner fuels are bringing us closer to o\
ur goal. After Volvo vehicles and parts have fulfilled their use,
recycling is the next critical step in completing the life cycle. The me\
tal content is about 75% of the total weight of a vehicle, which makes
the vehicle among the most recycled industrial products. In order to hav\
e efficient and well controlled recycling, all Volvo variants have
printed dismantling manuals, indicating the weight and material of indiv\
idual components. For Volvo, all homogeneous plastic parts
weighing more than 3.4 oz. (100 grams) are marked with international s\
ymbols that indicate how the component is to be sorted for
recycling. In addition to continuous environmental refinement of convent\
ional gasoline-powered internal combustion engines, Volvo is
actively looking at advanced technology alternative-fuel vehicles.
When you drive a Volvo, you become our partner in the work to lessen the\
car's impact on the environment. To reduce your vehicle's
environmental impact, you can:
l Maintain proper air pressure in your tires. Tests have shown decreased f\
uel economy with improperly inflated tires.
l Follow the recommended maintenance schedule in your Warranty and Service\
Records Information booklet.
l Drive at a constant speed whenever possible.
l See a trained and qualified Volvo service technician as soon as possible\
for inspection if the check engine (malfunction indicator) light
illuminates, or stays on after the vehicle has started.
l Properly dispose of any vehicle-related waste such as used motor oil, us\
ed batteries, brake pads, etc.
l When cleaning your vehicle, please use genuine Volvo car care products. \
All Volvo car care products are formulated to be
environmentally friendly.
For additional information regarding the environmental activities in whi\
ch Volvo Cars of North America, LLC and Volvo Car Corporation
file:///K|/delme/2007_C70/07c70_00.htm (5 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
are involved, visit our Internet home page at: http://www.volvocars.us.
WARNING
Certain components of this vehicle such as air bag modules, seat belt pr\
etensioners, adaptive steering columns, rollover protection
system, and button cell batteries may contain Perchlorate material. Spec\
ial handling may apply for service or vehicle end of life disposal.
See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
8 Introduction
Important warnings
Accessory Installation
l We strongly recommend that Volvo owners install only genuine, Volvo-appr\
oved accessories, and that accessory installations be
performed only by the factory-trained technicians at your authorized Vol\
vo retailer.
l Genuine Volvo accessories are tested to ensure compatibility with the pe\
rformance, safety, and emission systems in your car.
Additionally, your authorized Volvo retailer knows where accessories may\
and may not be safely installed in your Volvo. In all cases,
please consult your authorized Volvo retailer before installing any acce\
ssory in or on your car.
l Accessories that have not been approved by Volvo may or may not be speci\
fically tested for compatibility with your car. Additionally,
an inexperienced installer may not be familiar with some of your car's s\
ystems.
l Any of your car's performance and safety systems could be adversely affe\
cted if you install accessories that Volvo has not tested, or if
you allow accessories to be installed by someone unfamiliar with your ca\
r.
l Damage caused by unapproved or improperly installed accessories may not \
be covered by your new car warranty. See your Warranty
and Service Records Information booklet for more warranty information. V\
olvo assumes no responsibility for death, injury, or expenses
that may result from the installation of non-genuine accessories.
Driver distraction
Driver distraction results from driver activities that are not directly \
related to controlling the car in the driving environment. Your new
Volvo is, or can be, equipped with many feature-rich entertainment and c\
ommunication systems. These include hands-free cellular
telephones, navigation systems, and multipurpose audio systems. You may \
also own other portable electronic devices for your own
convenience. When used properly and safely, they enrich the driving expe\
rience. Improperly used, any of these could cause a distraction.
For all of these systems, we want to provide the following warning that \
reflects the strong Volvo concern for your safety:
l Never use these devices or any feature of your vehicle in a way that dis\
tracts you from the task of driving safely. Distraction can lead to
a serious accident.In addition to this general warning, we offer the fol\
lowing guidance regarding specific newer features that may be found
in your vehicle:
l Never use a hand-held cellular telephone while driving. Some jurisdictio\
ns prohibit cellular telephone use by a driver while the vehicle
is moving.
l If your car is equipped with a navigation system, set and make changes t\
o your travel itinerary only with the vehicle parked.
l Never program your audio system while the vehicle is moving. Program rad\
io presets with the vehicle parked, and use your
programmed presets to make radio use quicker and simpler.
l Never use portable computers or personal digital assistants while the ve\
hicle is moving.
A driver has a responsibility to do everything possible to ensure his or\
her own safety and the safety of passengers in the vehicle and
others sharing the roadway. Avoiding distractions is part of that respon\
sibility.
9 Introduction
This page left intentionally blank.
file:///K|/delme/2007_C70/07c70_00.htm (6 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70

Contents | Top of Page
file:///K|/delme/2007_C70/07c70_00.htm (7 of 7)12/22/2006 9:15:34 PM

2007 Volvo C70
2 0 0 7
VOLVO C70
10 01 Safety
Occupant safety
12
Seat belts
14
Supplemental Restraint System
17
Front airbags
18
Occupant Weight Sensor
21
Side impact protection airbags
24
Door mounted inflatable curtains
25
Whiplash Protection System
26
Roll-over Protection System
28
Crash mode
29
Child safety
30
Child restraint systems
33
Infant seats
35
Convertible seats
37
Booster cushions
39
ISOFIX lower anchors
40
11 01 Safety
file:///K|/delme/2007_C70/07c70_01.htm (1 of 41)12/22/2006 9:15:37 PM

2007 Volvo C70
12 01 Safety
Occupant safety
Volvo's concern for safety
Safety is Volvo's cornerstone. Our concern dates back to 1927 when the f\
irst Volvo rolled off the
production line. Three-point seat belts (a Volvo invention), safety ca\
ges, and energy-absorbing impact
zones were designed into Volvo cars long before it was fashionable or re\
quired by government regulation.
We will not compromise our commitment to safety. We continue to seek out\
new safety features and to
refine those already in our cars. You can help. We would appreciate hear\
ing your suggestions about
improving automobile safety. We also want to know if you ever have a saf\
ety concern with your car. Call
us in the U.S. at: 1-800-458-1552 or in Canada at: 1-800-663-8255.
Occupant safety reminders
How safely you drive doesn't depend on how old you are but rather on:
l How well you see.
l Your ability to concentrate.
l How quickly you make decisions under stress to avoid an accident.
The following suggestions are intended to help you cope with the ever ch\
anging traffic environment.
l Never drink and drive.
l If you are taking any medication, consult your physician about its poten\
tial effects on your driving
abilities.
l Take a driver-retraining course.
l Have your eyes checked regularly.
l Keep your windshield and headlights clean.
l Replace wiper blades when they start to leave streaks.
file:///K|/delme/2007_C70/07c70_01.htm (2 of 41)12/22/2006 9:15:37 PM

2007 Volvo C70
l Take into account the traffic, road, and weather conditions, particularl\
y with regard to stopping distance.
Reporting safety defects in the U.S.
If you believe that your vehicle has a defect which could cause a crash \
or could cause injury or death, you
should immediately inform the National Highway Traffic Safety Administra\
tion (NHTSA) in addition to
notifying Volvo Cars of North America, LLC. If NHTSA receives similar co\
mplaints, it may open an
investigation, and if it finds that a safety defect exists in a group of\
vehicles, it may order a recall and
remedy campaign. However, NHTSA cannot become involved in individual pro\
blems between you, your
retailer, or Volvo Cars of North America, LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free \
at
1-888-327-4236 (TTY: 1-800-424-9153) or write to: NHTSA, U.S. Departme\
nt of Transportation,
Washington D.C. 20590.
You can also obtain other information about motor vehicle safety from:
http://www.safecar.gov
Volvo strongly recommends that if your vehicle is covered under a servic\
e campaign, safety or emission
recall or similar action, it should be completed as soon as possible. Pl\
ease check with your local retailer or
Volvo Cars of North America, LLC if your vehicle is covered under these \
conditions.
NHTSA can be reached at:
Internet:
http://www.nhtsa.gov
Telephone:
1-888-DASH-2-DOT (1-888-327-4236).
13 01 Safety
Occupant safety
Reporting safety defects in Canada
If you believe your vehicle has a defect that could cause a crash or cou\
ld cause injury or death, you should
immediately inform Transport Canada in addition to notifying Volvo Cars \
of Canada Corp.
file:///K|/delme/2007_C70/07c70_01.htm (3 of 41)12/22/2006 9:15:37 PM
