VOLVO S60 2012 Owner´s Manual

05 Infotainment
Cell phone voice control
05

241
While using the voice control system, keep the
following points in mind:
•When giving commands, speak at your
usual speed and in a normal tone of voice
after the tone
•The vehicle's doors, windows and moon-
roof should be closed when using the voice
control system
•Avoid background noises in the cabin
when using the system
NOTE
If you are uncertain of the commands that
you can use, saying "help" will prompt the
system to provide a number of commands
that can be used in a specific situation.
Voice control commands can be cancelled
by:
•Saying "cancel"
•Not speaking
•Pressing and holding the voice control
button
•Pressing EXIT or one of the mode but-
tons (RADIO, MEDIA, etc.).
Voice control support features
•Tutorial: A feature that helps acquaint you
with the system and the procedure for giv-
ing commands.
•Training: A feature that enables the voice
control system to become familiar with
your voice and pronunciation, and allows
you to set up user profiles. Two user pro-
files can be voice trained.
These support features are accessed by press-
ing the MY CAR button in the center console
and turning TUNE to scroll to the desired menu
selection.
TutorialThe tutorial feature can be started in two ways:
NOTE
The tutorial feature can only be started when
the vehicle is parked and the parking brake
is applied.
•By pressing the voice control button and
saying "Voice tutorial."
•By pressing MY CAR and going to
Settings
Voice settingsVoice
tutorial. Press OK/MENU to begin the
tutorial lesson.The tutorial is divided into three lessons, which
take a total of approximately 5 minutes to com-
plete.
By default, the system will begin with the first
lesson. To skip to the next lesson, press the
voice control button and say "next." Go back
to a previous lesson by saying "previous."
Press and hold the voice control button to exit
the tutorial.
TrainingThe system will display up to fifteen phrases for
you to say. To start the voice training proce-
dure, press MY CAR and go to Settings
Voice settingsVoice training. Select User
1
or User 2 and press OK/MENU to begin.
After the training has been completed, remem-
ber to set your user profile in
Voice user
setting.
Other voice control settings found in MY
CAR
•Voice user setting: Two user profiles can
be set by pressing MY CAR and going to
Settings
Voice settingsVoice user
setting. Select
User 1 or User 2.
•Voice output volume: Press MY CAR and
go to Settings
Voice settingsVoice
output volume. Press OK/MENU and turn
TUNE to raise or lower the volume. Press
EXIT to save the change and exit the menu.

05 Infotainment
Cell phone voice control
05
242
Using voice commands
The driver initiates a voice command dialogue
by pressing the voice control button (see the
illustration on page 240).
When a dialogue has been initiated, commonly
used commands will be shown in the display.
Grayed-out texts or texts in parentheses are
not part of the spoken command.
Once you become familiar with the system, you
can speed up the command dialogue by briefly
pressing the voice control button to skip
prompts from the system.
Commands can be given in several ways.
For example, the command "Phone call con-
tact" can be spoken as:
•"Phone > Call contact"—say "Phone," wait
for a system response, and then continue
by saying "Call contact."
•"Phone call contact"—give the entire com-
mand at one time
The following is a list of features that can be
voice-controlled with a Bluetooth
Ÿ-connected
cell phone.
ShortcutsShortcut commands for using the phone can
be found in the
MY CAR menu system, under
Settings
Voice settingsVoice
command list
Phone commands and
General commands. See page 133 for more
information on the menu system.
Dialing a numberThe system understands the digits zero to nine.
These numbers can be spoken individually, in
groups of several digits at a time, or the entire
number can be given at once. Numbers above
nine will not be recognized.
The following is an example of a voice com-
mand dialogue. The system's response may
vary depending on the situation.
The user initiates the dialogue by saying:Phone > dial number
or
Phone dial number
System responseNumber please
User actionBegin saying the digits in the phone number. If
you say several digits and pause, the system
will repeat them and prompt you by saying
"Continue."
Continue saying the digits. When you have fin-
ished, complete the command by saying
"Dial."
•You can also change the number by using
the commands "Correction" (which dele-
tes the last group of digits spoken) or"Delete" (which will erase the entire phone
number).
Dialing from a call listThe dialogue below enables you make a call
from one of your cell phone's call lists.
The user initiates the dialogue by saying:Phone > dial from call list
or
Phone dial from call list
Continue by responding to the system's
prompts.
Calling a contactThe dialogue below enables you to call the pre-
defined contacts in your cell phone. See the
phone's user's guide if necessary.
The user initiates the dialogue by saying:Phone > call contact
or
Phone call contact
Continue by responding to the system's
prompts.
When calling contacts, keep the following in
mind:
•If there are several contacts with similar
names, they will be presented in the dis-

05 Infotainment
Cell phone voice control
05
243
play in numbered lines and the system will
prompt you to pick a line number
•If there are more lines in the list than can
be displayed at one time, saying "Down"
will enable you to scroll downward in the
list (and saying "up" will take you back up
through the list).
Dialing voicemailThe dialogue below enables you to call your
voicemail to check any messages that you may
have received. Your voicemail phone number
must be registered in the Bluetooth
Ÿ function,
see page 235.
The user initiates the dialogue by saying:Phone > dial voicemail
or
Phone dial voicemail
Continue by responding to the system's
prompts.

05 Infotainment
Infotainment system menus
05
244
Navigating in the menus
Infotainment settings are made via the sys-
tem's menus. Press one of the mode buttons
(RADIO, MEDIA, or TEL—see the illustration
on page 206) to select it and access its specific
menus. When a mode has been selected, press
OK/MENU to access its menus.
Menu selections can be made using the con-
trols in the center console and certain functions
can also be controlled from the steering wheel
keypad. Each mode is described in its respec-
tive section.
Controls in the center console
RADIO
MEDIA
TEL
TUNE
OK/MENU
Search pathsThroughout this manual, search paths to the
menu system functions are listed as shown in
the following example: Audio settings
Equalizer, if the following steps have been
taken first:
1.
Press the desired mode button, (RADIO,
MEDIA, etc). Continue pressing the button
to navigate through the various selections
displayed (e.g.,
FM1). Release the button
and wait several seconds to automatically
accept the selection or turn TUNE and
press OK/MENU.
2.
Turn TUNE or use the thumb wheel on the
steering wheel keypad to scroll to the
desired menu selection, such as
Audio
settings, and press OK/MENU to confirm
a selection.
3.
Turn TUNE again to scroll to the desired
submenu (e.g.,
Equalizer) where applica-
ble and press OK/MENU.
RADIO menus
Main AM menuAM menu
Show presets
Scan
Audio settings1
Sound stage
Equalizer
Volume compensation
Reset all audio settings
Main FM1/FM2 menuFM menu
Show radio text
Show presets
Scan
Advanced settings
Reset all FM settings
Audio settings1
1The audio settings are the same for all infotainment system modes

05 Infotainment
Infotainment system menus
05

* Option/accessory, for more information, see Introduction.245
Main Sirius1*/Sirius2* menuSirius1
SIRIUS radio off. Press RADIO button
to activate SIRIUS.
Sirius2
SIRIUS radio off. Press RADIO button
to activate SIRIUS.
Song memory
Add song
Song Seek
Delete song
View song memory
Channel list information
Station name
Artist
Title
Information
Show presets
Category list
Advanced SIRIUS settings
Skip options
Channel skip listLock options
Channel lock list
Unlock all channels
Temporarily unlock all chan-
nels
Change code
Audio settings1
MEDIA menus
Main CD Audio menuDisc menu
Random
Scan
Audio settings1
Main CD/DVD Data menuDisc menu
Play/Pause
Stop
Random
Repeat folder
Change subtitlesChange audio track
Scan
Audio settings1
Main DVD Video menuDisc menu
DVD disc menu
Play/Pause/Continue
Stop
Subtitles
Audio tracks
Advanced settings
Angle
DivX® VOD code
Audio settings1
Main iPod menuiPod menu
Random
Scan
Audio settings1
1The audio settings are the same for all infotainment system modes

05 Infotainment
Infotainment system menus
05
246
Main USB menuUSB menu
Play/Pause
Stop
Random
Repeat folder
Select USB device
Change subtitles
Change audio track
Scan
Audio settings1
Main Bluetooth media menuBluetooth menu
Random
Change device
Remove Bluetooth device
Scan
Bluetooth software version in car
Audio settings1
Main AUX menuAUX menu
AUX input volume
Audio settings1
TEL menus
Main BluetoothŸŸ hands-free menuPhone menu
Call lists
All calls
Missed calls
Answered calls
Dialed calls
Call duration
Phone book
Search
New contact
Speed dials
Receive vCard
Memory status
Clear phone bookChange phone
Remove Bluetooth device
Phone settings
Discoverable
Sounds and volume
Download phone book
Bluetooth software version in
car
Call options
Auto answer
Voicemail number
Disconnect phone
1The audio settings are the same for all infotainment system modes

05 Infotainment

05
247

248
Driving recommendations..................................................................... 250
Refueling............................................................................................... 254
Loading................................................................................................. 259
Towing a trailer...................................................................................... 262
Emergency towing................................................................................ 265

DURING YOUR TRIP

06 During your trip
Driving recommendations
06
250
General information
Economical driving conserves natural
resources
Better driving economy may be obtained by
thinking ahead, avoiding rapid starts and stops
and adjusting the speed of your vehicle to
immediate traffic conditions.
Observe the following rules:
•Bring the engine to normal operating tem-
perature as soon as possible by driving
with a light foot on the accelerator pedal for
the first few minutes of operation. A cold
engine uses more fuel and is subject to
increased wear.
•Whenever possible, avoid using the vehicle
for driving short distances. This does not
allow the engine to reach normal operating
temperature.
•Drive carefully and avoid rapid acceleration
and hard braking.
•Use the transmission's Drive (D) position
as often as possible and avoid using kick-
down.
•Using the transmission's Sport mode1 may
increase fuel consumption somewhat. Use
the transmission's Drive (D) position as
often as possible. See page 119 for addi-
tional information about Sport mode.
•Do not exceed posted speed limits.
•Avoid carrying unnecessary items (extra
load) in the vehicle.
•Maintain correct tire pressure. Check tire
pressure regularly (when tires are cold).
•Remove snow tires when threat of snow or
ice has ended.
•Note that roof racks, ski racks, etc,
increase air resistance and also fuel con-
sumption.
•At highway driving speeds, fuel consump-
tion will be lower with the air conditioning
on and the windows closed than with the
air conditioning off and the windows open.
•Using the onboard trip computer's fuel
consumption modes can help you learn
how to drive more economically.
Other factors that decrease gas mileage
are:
•Dirty air cleaner
•Dirty engine oil and clogged oil filter
•Dragging brakes
•Incorrect front end alignment
Some of the above mentioned items and others
are checked at the standard maintenance
intervals.
WARNING
Driving with the trunk open: Driving with
the trunk open could lead to poisonous
exhaust gases entering the passenger com-
partment. If the trunk must be kept open for
any reason, proceed as follows:
•Close the windows
•Set the ventilation system control to air
flow to floor, windshield and side win-
dows and the blower control to its high-
est setting.
Weight distribution affects handlingAt the specified curb weight your vehicle has a
tendency to understeer, which means that the
steering wheel has to be turned more than
might seem appropriate for the curvature of a
bend. This ensures good stability and reduces
the risk of rear wheel skid. Remember that
these properties can alter with the vehicle load.
The heavier the load in the trunk, the less the
tendency to understeer.
Handling, roadholdingVehicle load, tire design and inflation pressure
all affect vehicle handling. Therefore, check
that the tires are inflated to the recommended
pressure according to the vehicle load. See the
"Tire pressure" section. Loads should be dis-
1Certain models only.
