09 Specifications
Type approval 09
380
Country
Jamaica:Approved for use in Jamaica SMA EI: IAM2.1
Thailand:This telecommunication equipment conforms to NTC technical requirement.
Nigeria:
Mexico:Warning
"Este equipo opera a titulo secundario, consecuentemente, debe aceptar interferencias perjudiciales incluyendo equipos de la misma
clase y puede no causar interferencias a sistemas operando a titulo primario."
Bluetooth
Ÿ module installation information
This module board is to be installed only by the professional line operator and used only for car audio produced by ALPINE ELEC-
TRONICS, INC. When this Bluetooth
Ÿ Module Board is installed in the Car Audio, we shall consider the following points: 1. Since
"IAM2.1 BT PWB US" owns its FCC ID/IC Number, we shall affix an exterior label on the outside of the product if the FCC ID is not
visible. The exterior label shall use wording such as either "Contains Transmitter Module Board FCC ID: A269ZUA130 / IC: 700B-
IAM2101" or "Contains FCC ID: A269ZUA130 / IC: 700B-IAM2101". 2. "IAM2.1 BT PWB US" complies with requirements of subsections
15.19(a)(3) in FCC Rules Part 15 Subpart C. The manual statement 15.19 (a)(3) is included in User Guide of the product.
COFETEL No. RCPALIA10-0353
ProCarManuals.com

09 Specifications
Type approval09
381
Country
Bot-
swana:
Croatia:
ProCarManuals.com

09 Specifications
Symbols in the display 09
382* Option/accessory, for more information, see Introduction.
General
There are a variety of different symbols in the
display in the car. The symbols are divided into
warning, indicator and information symbols.
Shown below are the most common symbols
with their meanings and a reference to where
in the manual further information can be found.
For more information on symbols and text
messages, see pages 74, 76 and 142.
- Red warning symbol, illuminates when
a fault has been indicated which could affect
the safety and/or driveability of the car. At the
same time an explanatory text is displayed in
the information display.
- Yellow information symbol, illuminates
in combination with text in the information dis-
play, when a deviation in any of the car's sys-
tems has occurred. The yellow symbol infor-
mation can also illuminate in combination with
other symbols.
Symbols in the display
Indicator and warning symbols in the
combined instrument panel
SymbolMeaningPage
Low oil pres-
sure76
Parking
brake76, 133, 135
Airbags -
SRS19, 76
Seatbelt
reminder16, 76
Alternator
not charging76
Fault in the
brake system76, 132
Warning,
safety mode19, 30, 76, 77,
121
Indicator and information symbols in the
combined instrument panel
SymbolMeaningPage
Fault in the ABL
system*74, 89
Emissions sys-
tem74
Fault in the ABS
system74, 132
Rear fog lamp on74, 90
Stability system,
DSTC, Trailer
stability assist74, 169, 288
Stability system,
sport mode74, 169
Engine pre-
heater (diesel)74
Low level in fuel
tank74, 163
Information,
read display text74
Main beam on74, 89
ProCarManuals.com

09 Specifications
Symbols in the display09

* Option/accessory, for more information, see Introduction.383
SymbolMeaningPage
Left-hand direc-
tion indicators74
Right-hand
direction indica-
tors74
DRIVe - Start/
Stop*74, 123, 127
Other information symbols in the
combined instrument panel
SymbolMeaningPage
Adaptive cruise
control*171,
177, 183
Adaptive cruise
control*183
Adaptive cruise
control*, Distance
Warning* (Distance
Alert)183, 186
Adaptive cruise
control*, Distance
Warning* (Distance
Alert)183, 186
SymbolMeaningPage
Adaptive cruise
control*183
Adaptive cruise
control*, Distance
Warning* (Distance
Alert)178, 185
Adaptive cruise
control*, Distance
Warning* (Distance
Alert)178, 185
Adaptive cruise
control*177
Radar sensor*183,
186, 197
Start/Stop*, Adap-
tive cruise control*127, 183
Speed limiter173
SymbolMeaningPage
Camera sensor*,
Laser sensor*191,
197,
201, 203
Auto Brake*, Dis-
tance Warning*
(Distance Alert), City
Safety
TM, Collision
warning system*
186,
191, 197
G025102
Fuel-driven engine
block heater and
passenger com-
partment heater*163
ABL system*89
Fuel filler flap, right-
hand side273
Low battery163
Parking brake135
Rain sensor*97
ProCarManuals.com

09 Specifications
Symbols in the display 09
384* Option/accessory, for more information, see Introduction.
SymbolMeaningPage
Driver Alert System*200
Driver Alert Sys-
tem*, Lane Depar-
ture Warning*201, 203
Driver Alert Sys-
tem*, Lane Depar-
ture Warning*203
Driver Alert Sys-
tem*, Time for a
break201
Information symbols in the roof console
display
SymbolMeaningPage
Seatbelt reminder18
Airbag, passenger
seat, activated22, 23
Airbag, passenger
seat, deactivated23
ProCarManuals.com

09 Specifications
09
385ProCarManuals.com
