VOLVO XC70 2007 Owners Manual

2007 Volvo XC70
2 0 0 7
VOLVO XC70
Interior

pg. 83 Interior
Front seats
84
Interior lighting
88
Storage compartments
90
Rear seat folding table
(option)
94
Extending the cargo area
95
Cargo area
100
pg. 84 Interior
Front seats
Manually adjusted front seats
1. Front-rear adjustment: lift the bar and move the seat to the position\
of your choice.
2. Raise/lower the front edge of the seat cushion (option): use the co\
ntrol to pump the front edge of the
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (1 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
cushion up or down.
3. Raise/lower seat height: pump the seat up or down.
4. Lumbar support: turn the control for firmer or softer lumbar support.\

5. Backrest tilt: turn the control to adjust the angle of the backrest. \
6. Control panel for optional power seat (see
page 86 for more information).
WARNING!
l Do not adjust the seat while driving. The seat should be adjusted so tha\
t the brake pedal can be
depressed fully. In addition, position the seat as far rearward as comfo\
rt and control allow.
l Check that the seat is securely locked into position after adjusting.
pg. 85 Interior
Front seats
Folding the backrests in the front seat
The front passenger seat backrest can be folded to a horizontal position\
to make room for a long load.
Fold the backrest as follows:
- Move the seat as far back as possible.
- Adjust the backrest to the upright position.
- Lift the catches on the rear of the backrest.
- Without releasing the catches, push the backrest forward.
- Move the seat as far forward as possible so that the head restraint sl\
ides under the glove compartment.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (2 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
WARNING!
Cover sharp edges on the load to help prevent injury to occupants. Secur\
e the load to help prevent
shifting during sudden stops.
pg. 86 Interior
Front seats
Power seat - (option on certain models)
Operation
Driver's seat: The seat can be adjusted if the ignition key is in position I, II or if\
the engine is running.
It can also be adjusted as follows with the ignition off:
l Within several minutes after the driver's door has been unlocked from th\
e outside, has been opened,
and remains open.
l Within a short period if the driver's door has just been closed.
l Within a short period if the driver's door has not been opened after the\
ignition has been switched off.
Passenger seat: The seat can only be adjusted if the ignition key is in position I, II \
or if the engine is
running.

Power seat control panel
Seat adjustment
If your Volvo is equipped with power seats, the following may be adjuste\
d with the two switches at the
side of the seat:
A. Front edge of seat (raise/lower)
B. Front - rear
C. Rear edge of seat (raise/lower)
D. Backrest tilt
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (3 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
NOTE: The power seats have an overload protector that activates if a seat is \
blocked by any object. If
this occurs, switch off the ignition (key in position 0) and wait for \
a short period before operating the
seat again.
Emergency stop
If the seat accidentally begins to move, press any of the buttons to sto\
p the seat.
NOTE: Please refer to the following page for information on programming the m\
emory function in the
driver's seat.
Remote keyless entry system and the driver's seat
The remote control transmitter also controls the position of the electri\
cally operated driver's seat in the
following way:
- Adjust the seat to your preferences.
- When you leave your vehicle, lock it using the remote control.
The position of the seat is now stored in the remote control.
Automatic seat adjustment
To move the seat to the position in which you left it:
- Unlock the driver's door with the same remote control (the one used t\
o lock the doors).
- Open the driver's door within 2 minutes.
The driver's seat will automatically move to the position in which you l\
eft it.
NOTE:
l The seat will move to this position even if someone else has moved it to\
a different seating position
and locked the vehicle with a different remote control.
pg. 87 Interior
Front seats
l This feature will work in the same way with all of the remote control tr\
ansmitters (up to 3) that you
use with your vehicle.
l This feature will not function if your lock your vehicle with the key.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (4 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
WARNING!
l Because the driver's seat can be adjusted with the ignition off, childre\
n should never be left
unattended in the vehicle.
l Movement of the seat can be STOPPED at any time by pressing any button o\
n the power seat
control panel.
l Do not adjust the seat while driving. The seat should be adjusted so tha\
t the brake pedal can be
depressed fully. In addition, position the seat as far rearward as comfo\
rt and control allow.
l The seat rails on the floor must not be obstructed in any way when the s\
eat is in motion.
Programming the memory (option)
Three different seating and door mirror positions can be stored in the d\
river seat's memory.
The following example explains how button 1 can be programmed. Buttons 2\
and 3 can be programmed
in the same way.
To program (store) a seat position in button 1:
- Move the seat to the desired position using the seat adjustment contro\
ls (see the previous page).
- Press and hold down the MEM (memory) button.
- With the MEM button depressed, press button 1 briefly to store the sea\
t's current position.
To move the seat to the position that it was in when button 1 was progra\
mmed:
Press and hold down button 1 until the seat stops moving.
As a safety precaution, the seat will stop automatically if the button i\
s released before the seat has
reached the preset position.
pg. 88 Interior
Interior lighting
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (5 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
Reading lights and courtesy light
1. Driver's side front reading lamp
2. Courtesy lights
3. Passenger's side front reading lamp
The reading lights can be switched on or off by pressing buttons 1 or 3.\

The courtesy light can be turned on or off by pressing button 2.
4. Driver's side rear reading light
5. Passenger's side rear reading light
The rear reading lights can be switched on and off by pressing buttons 4\
or 5.
Automatic function
The reading lights and courtesy lights will switch off automatically app\
roximately 10 minutes after the
engine has been turned off. The lights can be turned off sooner by press\
ing the respective buttons.
The courtesy lights come on automatically
1 and remain on for approximately 30 seconds when:
l The vehicle has been unlocked from the outside with the remote control o\
r key
l If the engine has been switched off and the ignition key has been turned\
to position 0
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (6 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
The courtesy lights will come on and remain on for approximately 10 minu\
tes when:
l One of the doors is opened (assuming the courtesy lighting has not prev\
iously been switched off)
The courtesy lighting will go off when:
l The engine is started
l The vehicle is locked from the outside with the remote control or key
The automatic function can be disconnected by pressing button 2 for more\
than 3 seconds.
Briefly pressing the button again automatically reconnects the function.\

The courtesy light timer periods can be changed. Contact your Volvo reta\
iler.
1. This function is light dependent and is only activated in dark condit\
ions.
pg. 89 Interior
Interior lighting
Vanity mirror
The light comes on when you open the cover.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (7 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
Extra handgrip
The Volvo XC70 is equipped with an extra handgrip on the front passenger\
's side. This handgrip can be
used for added support when travelling on unpaved roads, etc.
WARNING!
The handgrip may become very warm when the vehicle has been parked in st\
rong
sunlight.
pg. 90 Interior
Storage compartments
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (8 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
1. Storage compartment in door
2. Storage pocket in edge of front seat
3. Ticket clip
4. Glove compartment
5. Storage compartment and cup holders in center console (see the follo\
wing page for more information)
6. Storage space and cup holders in rear seat armrest
7. Storage pocket in rear side of front seats
pg. 91 Interior
Storage compartments
WARNING!
Make sure that no hard, sharp, or heavy objects lie on or in any of the \
storage spaces where they
might cause injury during sudden braking.
Storage compartments in the center console
1. Storage compartment cover
2. Front storage compartment
This storage space is fitted with a sliding cover (not on XC70 models)\

3. 12-volt socket
4. Space for accessory ashtray
pg. 92 Interior
file:///K|/ownersdocs/2007/2007_XC70/07xc70_04.htm (9 of 29)12/30/2006\
5:51:33 PM

2007 Volvo XC70
Storage compartments
Cup holder for rear seat passengers
- To access the storage compartment, press the button on the left side o\
f the armrest and fold the entire
cover rearward.
- To open the rear seat cup holder, press the button on the right side o\
f the armrest. Fold the upper
section of the cover rearward.
The two sections of the cover can be closed separately.
Storage in the glove compartment
The glove compartment has storage spaces designed specifically to hold c\
redit cards, pens, and pencils.
pg. 93 Interior
Storage compartments
