VOLVO XC70 2007 Owners Manual

2007 Volvo XC70
CAUTION!
- Under no circumstances should gasoline, naphtha or similar cleaning ag\
ents be used on the plastic
or the leather since these can cause damage.
- Take extra care when removing stains such as ink or lipstick since the\
coloring can spread.
- Use solvents sparingly. Too much solvent can damage the seat padding. \
- Start from the outside of the stain and work toward the center.
- Sharp objects (e.g. pencils or pens in a pocket) or velcro fasteners\
on clothing may damage the
textile upholstery.
- Clothing that is not colorfast, such as new jeans or suede garments, m\
ay stain the upholstery.
Cleaning the seat belts
Clean only with lukewarm water and a mild soap solution.
Cleaning floor mats
The floor mats should be vacuumed or brushed clean regularly, especially\
during winter when they
should be taken out for drying. Spots on textile mats can be removed wit\
h a mild detergent.
Bear in mind
l Take extra care when removing stains such as ink or lipstick since the c\
oloring can spread.
l Use solvents sparingly. Too much solvent can damage the seat padding.
l Start from the outside of the stain and work toward the center.
pg. 182 Vehicle care
Paint touch up
Paint damage requires immediate attention to avoid rusting. Make it a ha\
bit to check the finish regularly
- when washing the vehicle for instance. Touch-up if necessary.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_08.htm (5 of 7)12/30/2006 \
5:51:41 PM

2007 Volvo XC70
Paint repairs require special equipment and skill. Contact your Volvo re\
tailer for any extensive damage.
Color code
Make sure you have the right color. When ordering touch-up paint from yo\
ur Volvo retailer, use the
paint code indicated on the model plate (1 in the illustration above).\
Minor stone chips and scratches
Material:
l Primer - can
l Paint - touch-up pen
l Brush
l Masking tape
l If the stone chip has not gone down to the bare metal and an undamaged c\
olor coat remains, you can
add paint immediately after removing dirt.
NOTE: When touching up the vehicle, it should be clean and dry. The surface t\
emperature should be
above 60° F (15° C).
Minor scratches on the surface
If the stone chip has not penetrated down to the metal and an undamaged \
layer of paint remains, the
touch-up paint can be applied as soon as the spot has been cleaned.
Deep scratches
- Place a strip of masking tape over the damaged surface. Pull the tape \
off so that any loose flakes of
paint adhere to it.
- Thoroughly mix the primer and apply it with a small brush. When the pr\
imer surface is dry, the paint
can be applied using a brush. Mix the paint thoroughly; apply several th\
in paint coats and let dry after
each application.
- If there is a longer scratch, you may want to protect surrounding pain\
t by masking it off.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_08.htm (6 of 7)12/30/2006 \
5:51:41 PM

2007 Volvo XC70
1. The model plate is located on the passenger's side center door pillar\
.



Contents | Top of Page
file:///K|/ownersdocs/2007/2007_XC70/07xc70_08.htm (7 of 7)12/30/2006 \
5:51:41 PM

2007 Volvo XC70
2 0 0 7
VOLVO XC70
Maintenance and servicing

pg. 183 Maintenance and servicing
Volvo service
184
Maintaining your car
185
Emission inspection readiness
186
Working on your car
187
Hood and engine
compartment
189
Engine oil
190
Fluids
192
Wiper blades
194
Battery
195
Replacing bulbs
198
Fuses
205
pg. 184 Maintenance and servicing
Volvo service
Maintenance service
Periodic maintenance will help keep your vehicle running well. Your Warr\
anty and Service Records
Information booklet provides a comprehensive maintenance schedule up to \
150,000 miles (240,000 km)
of vehicle service. This maintenance program contains inspections and se\
rvices necessary for the proper
function of your vehicle, and includes components that affect vehicle em\
issions. The maintenance
services contain several checks that require special instruments and too\
ls and therefore must be
performed by a qualified technician. Volvo advises you to follow the ser\
vice program outlined in this
booklet. To keep your Volvo in top condition, specify time-tested and pr\
oven Genuine Volvo Parts and
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (1 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
Accessories.
The Federal Clean Air Act - U.S.
The Federal Clean Air Act requires vehicle manufacturers to furnish writ\
ten instructions to the ultimate
purchaser to assure the proper servicing and function of the components \
that control emissions. These
services, which are listed in the "Warranty and Service Records Informat\
ion booklet," are not covered
by the warranty. You will be required to pay for labor and material used\
.
Maintenance services
Your Volvo passed several major inspections before it was delivered to y\
ou, in accordance with Volvo
specifications. The maintenance services outlined in the Warranty and Se\
rvice Records Information
booklet, many of which will positively affect your vehicle's emissions, \
should be performed as
indicated. It is recommended that receipts for vehicle emission services\
be retained in case questions
arise concerning maintenance.
Inspection and service should also be performed anytime a malfunction is\
observed or suspected.
Vehicle Event Data (Black Box)
Your vehicle's driving and safety systems employ computers that monitor,\
and share with each other,
information about your vehicle's operation. One or more of these compute\
rs may store what they
monitor, either during normal vehicle operation or in a crash or near-cr\
ash event. Stored information
may be read and used by:
l Volvo Car Corporation
l service and repair facilities
l law enforcement or government agencies
l others who may assert a legal right to know, or who obtain your consent \
to know such information.
Applicable warranties
In accordance with applicable U.S. and Canadian regulations, the followi\
ng list of warranties is
provided.
l New Car Limited Warranty
l Parts and Accessories Limited Warranty
l Corrosion Protection Limited Warranty
l Seat Belt and Supplemental Restraint Systems Limited Warranty
l Emission Design and Defect Warranty
l Emission Performance Warranty
These are the Federal warranties; other warranties are provided as requi\
red by state/ provincial law.
Refer to your separate Warranty and Service Records Information booklet \
for detailed information
concerning each of the warranties.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (2 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
pg. 185 Maintenance and servicing
Maintaining your car
Owner maintenance
Periodic maintenance requirements and intervals are described in your ve\
hicle's Warranty and Service
Records Information booklet.
The following points can be carried out between the normally scheduled m\
aintenance services.
Each time the vehicle is refueled:
l Check the engine oil level
l Clean the windshield, windshield wipers, headlights, and tail lights
Monthly:
l Check cold tire pressure in all tires. Inspect the tires for wear.
l Check that engine coolant and other fluid levels are between the indicat\
ed "min" and "max" markings.
l Clean interior glass surfaces with a glass cleaner and soft paper towels\
.
l Wipe driver information displays with a soft cloth.
l Visually inspect battery terminals for corrosion. Corrosion may indicate\
a loose terminal connector, or
a battery near the end of its useful service life. Consult your Volvo re\
tailer for additional information.
As needed:
l Wash the vehicle, including the undercarriage, to reduce wear that can b\
e caused by a buildup of dirt,
and corrosion that can be caused by salt residues.
l Clean leaves and twigs from air intake vents at the base of the windshie\
ld, and from other places
where they may collect.
NOTE: Complete service information for qualified technicians is available onl\
ine for purchase or
subscription at
www.volvotechinfo.com.
pg. 186 Maintenance and servicing
Emission inspection readiness
What is an Onboard Diagnostic System (OBD II)?
OBD II is part of your vehicle's computerized engine management system. \
It stores diagnostic
information about your vehicle's emission controls. It can light the Che\
ck Engine light (MIL) if it detects
an emission control "fault." A "fault" is a component or system that is \
not performing within an expected
range. A fault may be permanent or temporary. OBD II will store a messag\
e about any fault.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (3 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
How do states use OBD II for emission inspections?
Many states connect a computer directly to a vehicle's OBD II system. Th\
e inspector can then read
"faults." In some states, this type of inspection has replaced the tailp\
ipe emission test.
How can my vehicle fail OBD II emission inspection?
Your vehicle can fail OBD II emission inspection for any of the followin\
g reasons.
l If your Check Engine (MIL) light is lit, your vehicle may fail inspect\
ion.
l If your vehicle's Check Engine light was lit, but went out without any a\
ction on your part, OBD II will
still have a recorded fault. Your vehicle may pass or fail, depending on\
the inspection practices in your
area.
l If you had recent service that required disconnecting the battery, OBD I\
I diagnostic information may
be incomplete and "not ready" for inspection. A vehicle that is not read\
y may fail inspection.
How can I prepare for my next OBD II emission inspection?
l If your Check Engine (MIL) light is lit - or was lit but went out with\
out service, have your vehicle
diagnosed and, if necessary, serviced by a qualified Volvo technician.
l If you recently had service for a lit Check Engine light, or if you had \
service that required
disconnecting the battery, a period of driving is necessary to bring the\
OBD II system to "ready" for
inspection. A half-hour trip of mixed stop-and-go/ highway driving is ty\
pically needed to allow OBD II
to reach readiness. Your Volvo retailer can provide you with more inform\
ation on planning a trip.
l Maintain your vehicle in accordance with your vehicle's maintenance sche\
dule.
pg. 187 Maintenance and servicing
Working on your car
Note the following before you begin working on your vehicle
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (4 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
Battery
l Ensure that the battery cables are correctly connected and tightened.
l Never disconnect the battery when the engine is running (e.g. when repl\
acing the battery).
l Never use a fast charger to charge the battery. The battery cables shoul\
d be disconnected when
recharging.
l The battery contains acid that is both corrosive and poisonous. It is im\
portant that the battery is
handled in an environmentally friendly way. Let your Volvo dealer assist\
you.
Hoisting the vehicle
If a garage jack is used to lift the vehicle, the two jack attachments p\
oints should be used. They are
specially reinforced to bear the weight of the vehicle. A garage jack ca\
n also be placed under the front of
the engine support frame. Take care not to damage the splash guard under\
the engine. Ensure that the
jack is positioned so that the vehicle cannot slide off it. Always use a\
xle stands or similar structures.
If a two-post hoist is used to lift the vehicle, the front and rear lift\
arm pads should be centered under the
reinforced lift plates on the inboard edge of the sill rail (see illust\
ration).
pg. 188 Maintenance and servicing
Working on your car
WARNING!
The vehicle ignition system has very high voltage!
The voltage in the ignition system is dangerous!
Do not touch spark plugs, ignition cables or the ignition coil when the \
engine is running or the
ignition is switched on!
The ignition should be switched off when:
l Conducting engine tests.
l Replacing parts in the ignition system, such as spark plugs, ignition co\
il, distributor, ignition
cables, etc.
WARNING!
Never try to repair any part of the SRS or SIPS bag systems yourself. Any int\
erference in the system
could cause malfunction and serious injury. Any work should only be perf\
ormed by an authorized
Volvo retailer.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (5 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
Belt check
Check the belt regularly to make sure it is in good condition and is cle\
an. A worn or dirty belt can cause
poor cooling and low alternator output as well as impair the operation o\
f the power steering and the air
conditioning unit.
NOTE: The drive belt is equipped with a self-tensioning mechanism and require\
s no adjustment
between changes.
WARNING!
The engine must not be running when this check is
performed.
Check coolant level
The cooling system must be filled with coolant and not leak to operate a\
t maximum efficiency. Check
the coolant level regularly. The level should be between the "MAX" and "\
MIN" marks on the expansion
tank. The check should be made with particular thoroughness when the eng\
ine is new or when the
cooling system has been drained.
Do not remove the filler cap other than for topping up with coolant. Fre\
quent removal may prevent
coolant circulation between the engine and the expansion tank during eng\
ine warm up and cooling.
Changing coolant
Normally, the coolant does not need to be changed. If the system must be\
drained, consult your Volvo
retailer.
NOTE: Do not top off with water only. This reduces the rust-protective and an\
tifreeze qualities of the
coolant and has a lower boiling point. It can also cause damage to the c\
ooling system if it should freeze.
Top off with Volvo Genuine Coolant/Antifreeze only (a 50/ 50 mix of wat\
er and antifreeze). CAUTION!
The cooling system must always be kept filled to the correct level. If i\
t is not kept filled, there can be
high local temperatures in the engine which could result in damage. Diff\
erent types of antifreeze/
coolant may not be mixed.
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (6 of 38)12/30/2006\
5:51:43 PM

2007 Volvo XC70
WARNING!
Never remove the radiator cap while the engine is warm. Wait until the v\
ehicle
cools.
pg. 189 Maintenance and servicing
Hood and engine compartment
Opening the hood
- Pull the lever located under the left side of the dash to release the \
hood lock.
- Lift the hood slightly.
- Press up the release control located under the front edge of the hood \
(at the center) and lift.
WARNING!
Check that the hood locks properly when
closed!
file:///K|/ownersdocs/2007/2007_XC70/07xc70_09.htm (7 of 38)12/30/2006\
5:51:43 PM
